A5MMB601WLenovo Go Essential Travel Mouse

Reduce | Reuse | Recycle First Edition (May 2021) © Copyright Lenovo 2021. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925. Lenovo Go USB-C Wireless Mouse https://support.lenovo.com (1P) PN: SP41C21213 Printed in China https://www.lenovo.com/safety Safety information English The operating temperature range for the product is between 0°C (32°F) and 40°C (104°F). General battery notice DANGER Batteries supplied by Lenovo for use with your product have been tested for compatibility and should only be replaced with approved parts. Except the battery specified by Lenovo, a disassembled or modified battery is not covered by the warranty. Battery abuse or mishandling can cause overheat, liquid leakage, or an explosion. To avoid possible injury, do the following: • Do not open, disassemble, or service any battery. • Do not crush or puncture the battery. • Do not short-circuit the battery, or expose it to water or other liquids. • Keep the battery away from children. • Keep the battery away from fire. • Do not leave the battery in an extremely high-temperature environment or an extremely low air pressure environment. • Stop using the battery if it is damaged, or if you notice any discharge or the buildup of foreign materials on the battery leads. We recommend that the batteries be charged about once every three months to prevent overcharge. • Do not put the battery in trash that is disposed of in landfills. When disposing of the battery, comply with local laws or regulations. Built-in rechargeable battery notice DANGER • Do not attempt to replace the internal rechargeable lithium batteries. • Replacement of the battery must be done by a Lenovo-authorized repair facility or technician. • Only recharge the battery strictly according to instructions included in the product documentation. • Lenovo-authorized repair facilities or technicians recycle Lenovo batteries according to local laws and regulations. Arabic معلومات الأمان یتراوح نطاق درجھ حرارة التشغیل للمنتج بین 0° مئویة )32° فھرنھایت( و 40° مئویة )104 ° فھرنھایت(. إشعار البطاریة العام خطر دة من قبل شركة ّ تم اختبار البطاریات المزوLenovo للاستخدام مع منتجك للتأكد من توافقھا وینبغي استبدالھا بالقطع المعتمدة فقط. باستثناء البطاریة المحددة من قبل شركة Lenovo لا ، یغطي الضمان أي بطاریة تم تفكیكھا أو تعدیلھا. قد یتسبب سوء استعمال البطاریة أو التعامل معھا بصورة خاطئة في ارتفاع درجة حرارتھا أو تسرب السوائل منھا أو حدوث انفجار. لتفادى الإصابة المحتملة، قم بما یلي: • لا تعمل على فتح أي بطاریة أو تفكیكھا أو صیانتھا. • لا تعمل على تحطیم البطاریة أو ثقبھا. • ضھا للماء أو سوائل أخرى. ّ لا تقصر الدائرة الكھربائیة للبطاریة أو تعر • ا عن متناول ً احتفظ بالبطاریة بعید الأطفال. • اعمل على إبعاد البطاریة عن النار. • ا أو بیئة یكون فیھا ضغط الھواء ً لا تترك البطاریة في بیئة حیث درجات الحرارة عالیة جد شدید الانخفاض. • توقف عن استخدام البطاریة إذا تعرضت للتلف، أو إذا لاحظت تسرب أي سوائل منھا أو تراكم مواد غریبة على موصلاتھا. نحن نوصي بشحن البطاریات بواقع مرة كل ثلاثة أشھر لمنع الشحن الزائد. • البطاریة في القمامة التي یتم التخلص منھا في المكبات. عند التخلص من البطاریة، ِ لا تلق التزم بالقوانین أو اللوائح المحلیة. إشعار البطاریات المضمنة القابلة لإعادة الشحن خطر • لا تحاول استبدال بطاریات اللیثیوم الداخلیة القابلة لإعادة الشحن. • یجب أن یتم استبدال البطاریة في منشأة صیانة معتمدة أو فني معتمد من Lenovo . • نة في وثائق ّ لا تقم بإعادة شحن البطاریة إلا في ضوء الالتزام التام بالإرشادات المضم المنتج. • تقوم منشآت الصیانة المعتمدة أو الفنیون المعتمدون من شركة Lenovo بإعادة تدویر بطاریات Lenovo ا للقوانین واللوائح التنظیمیة المحلیة. ً وفق Bahasa Indonesia Informasi keamanan Kisaran temperatur pengoperasian untuk produk adalah antara 0°C (32°F) dan 40°C (104°F). Pemberitahuan umum tentang baterai BAHAYA Baterai yang disediakan oleh Lenovo untuk digunakan pada produk Anda telah melewati uji kompatibilitas dan hanya boleh diganti dengan komponen yang telah disetujui. Kecuali baterai telah ditentukan oleh Lenovo, baterai yang telah dibongkar atau dimodifikasi tidak dicakup oleh garansi. Penyalahgunaan atau kesalahan penanganan baterai dapat menyebabkan panas berlebih, kebocoran cairan, atau ledakan. Untuk menghindari kemungkinan cedera, lakukan hal berikut: • Jangan pernah membuka, membongkar, atau memperbaiki baterai. • Jangan memukul atau melubangi baterai. • Jangan sampai baterai korsleting, atau terkena air atau cairan lain. • Jauhkan baterai dari jangkauan anak-anak. • Jauhkan baterai dari api. • Jangan meninggalkan baterai di lingkungan bersuhu sangat tinggi atau lingkungan bertekanan udara sangat rendah. • Hentikan penggunaan jika baterai rusak, atau jika Anda mendeteksi baterai bocor atau ada penumpukan material asing di kabel baterai. Kami sarankan agar baterai diisi kira-kira satu kali dalam tiga bulan untuk mencegah pengisian berlebih. • Jangan membuang baterai ke tempat sampah yang akan dibuang ke pusat pembuangan sampah umum. Saat membuang baterai, patuhi undang-undang atau peraturan lokal yang berlaku. Pemberitahuan tentang baterai isi ulang terintegrasi BAHAYA • Jangan mencoba untuk mengganti baterai lithium isi ulang internal. • Penggantian baterai harus dilakukan di fasilitas reparasi resmi atau oleh teknisi resmi Lenovo. • Hanya lakukan pengisian baterai sesuai petunjuk yang disertakan dalam dokumentasi produk. • Fasilitas reparasi atau teknisi resmi Lenovo akan mendaur ulang baterai Lenovo sesuai dengan undang-undang dan peraturan lokal. Brazilian Portuguese Informações sobre segurança A faixa de temperatura de operação do produto está entre 0 °C (32 °F) e 40 °C (104 °F). Aviso geral sobre baterias PERIGO Foi testada a compatibilidade das baterias fornecidas pela Lenovo para utilização com o produto, e elas devem ser substituídas somente por peças aprovadas. Exceto pela bateria especificada pela Lenovo, uma bateria desmontada ou modificada não é coberta pela garantia. O abuso ou …

Text truncated - open the document above for the full version.

Lenovo (Beijing) Limited QF094234 Page 1 of 1 Revision 0 Authority to Act as Agent Date: _2021-04-13_______ TUV Rheinland Group 762 Park Avenue Youngsville, NC 27596 To Whom It May Concern: I appoint TUV Rheinland (Shenzhen) Co., Ltd. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FC C or Industr y Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with ___ Lenovo (Beijing) Limited / 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing, China 100085___. For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: ____2022-04-12____ By: __________________________ ______Yang Liu________________ (Signature) (Print name) Title: __Standardization Manager___________Telephone:___ +86-10-58861975__________ On behalf of: _______Lenovo (Beijing) Limited ______ (Company Name)

Lenovo (Beijing) Limited Confidentiality Letter Date: 2021-04-13 Subject: Confidentiality Request for FCC ID: A5MMB601W Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Part List/Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent anual Lenovo (Beijing) Limited has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04- 1705. Sincerely, By: Yang Liu (Signature/Title) (Print name)

Label location

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN21AMGT 001 Auftrags-Nr.: Order no.: 168306700 Seite 1 von 18 Page 1 of 18 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2021-02-05 Auftraggeber: Client: Lenovo (Beijing) Limited 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing 100085, P.R.China Prüfgegenstand: Test item: Lenovo Go Essential Travel Mouse Bezeichnung / Typ-Nr.: Identification / Type no.: MB601W (Trademark: Lenovo) Auftrags-Inhalt: Order content: Test Report Prüfgrundlage: Test specification: FCC CFR Title 47, Part 15, Subpart C, Section 15.249 Wareneingangsdatum: Date of sample receipt: 2021-03-19 Please refer to Photo Document Prüfmuster-Nr.: Test sample no: A003017847-011 Prüfzeitraum: Testing period: 2021-03-19 – 2021-04-08 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: genehmigt von: authorized by: Datum: Date: 2021-04-12 Ausstellungsdatum: Issue date: 2021-04-12 Stellung / Position: Senior Project Manager Stellung / Position: Technical Certifier Sonstiges / Other: FCC ID: A5MMB601W Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21AMGT 001 Seite 2 von 18 Page 2 of 18 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 FIELD STRENGTH OF FUNDAMENTAL AND HARMONICS RESULT: Pass 5.1.3 20DB AND 99% BANDWIDTH RESULT: Pass 5.1.4 BAND EDGE RESULT: Pass 5.1.5 CONDUCTED EMISSION ON AC MAINS RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21AMGT 001 Seite 3 von 18 Page 3 of 18 Table of Contents 1 GENERAL REMARKS ............................................................................................................................ 4 1.1 COMPLEMENTARY MATERIALS ............................................................................................................. 4 2 TEST SITES ........................................................................................................................................ 5 2.1 TEST FACILITIES ................................................................................................................................. 5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS ................................................................................. 5 2.3 TRACEABILITY ..................................................................................................................................... 6 2.4 CALIBRATION ...................................................................................................................................... 6 2.5 MEASUREMENT UNCERTAINTY ............................................................................................................. 6 2.6 LOCATION OF ORIGINAL DATA .............................................................................................................. 6 2.7 STATUS OF FACILITY USED FOR TESTING ............................................................................................. 7 3 GENERAL PRODUCT INFORMATION ....................................................................................................... 8 3.1 PRODUCT FUNCTION AND INTENDED USE ............................................................................................. 8 3.2 RATINGS AND SYSTEM DETAILS ........................................................................................................... 8 3.3 INDEPENDENT OPERATION MODES ...................................................................................................... 9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ......................................................................... 9 3.5 SUBMITTED DOCUMENTS ..................................................................................................................... 9 4 TEST SET-UP AND OPERATION MODES ..............................................................................................10 4.1 PRINCIPLE OF CONFIGURATION SELECTION ........................................................................................10 4.2 TEST OPERATION AND TEST SOFTWARE ............................................................................................10 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ...........................................................................10 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE .........................................................................10 4.5 TEST SETUP DIAGRAM ................................................................…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix B CN21AMGT 001 Page 1 of 27 Appendix B: Test Results APPENDIX B: TEST RESULTS .......................................................................................................................................... 1 APPENDIX B.1: FIELD STRENGTH OF FUNDAMENTAL & HARMONICS ............................................................................................... 2 30MHz - 1GHz ............................................................................................................................................................... 2 1GHz - 18GHz ................................................................................................................................................................ 6 APPENDIX B.2: TEST RESULTS OF 20DB BANDWIDTH ................................................................................................................ 18 APPENDIX B.3: TEST RESULTS OF 99% BANDWIDTH ................................................................................................................. 20 APPENDIX B.4: BAND EDGE .................................................................................................................................................. 22 APPENDIX B.5: TEST PLOTS OF CONDUCTED EMISSION ON AC MAINS ......................................................................................... 26 Prüfbericht - Produkte Test Report - Products Appendix B CN21AMGT 001 Page 2 of 27 Note: The testing was carried out within frequency range 9kHz to the tenth harmonics. The measurement results below 30MHz and 18GHz to 26.5GHz were greater than 20dB below the limit, so only the radiated spurious emissions from 30MHz to 18GHz were reported. Appendix B.1: Field strength of fundamental & harmonics 30MHz - 1GHz EUT Information EUT Name: Lenovo Go Essential Travel Mouse Model: MB601W Test Mode: 2.4G-SRD_2402MHz Test Voltage:: Baterry Remark: Temp 22 Humi:50% Test Standard: FCC 15.249 Tested By: Alano Qu Reviewed By: Terry Yin 0 10 20 30 40 50 60 72 30M 5060 80 100M200300400 500 8001G Level in dB 礦 /m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 40.185000 14.81 40.00 25.19 100.0 H 354.0 -20.4 49.982000 18.51 40.00 21.49 100.0 H 0.0 -18.6 93.729000 12.16 43.50 31.34 100.0 H 163.0 -20.4 243.400000 14.25 46.00 31.75 100.0 H 23.0 -17.9 517.570500 21.26 46.00 24.74 100.0 H 59.0 -11.9 Prüfbericht - Produkte Test Report - Products Appendix B CN21AMGT 001 Page 3 of 27 EUT Information EUT Name: Lenovo Go Essential Travel Mouse Model: MB601W Test Mode: 2.4G-SRD_2402MHz Test Voltage:: Baterry Remark: Temp 22 Humi:50% Test Standard: FCC 15.249 Tested By: Alano Qu Reviewed By: Terry Yin 0 10 20 30 40 50 60 72 30M 5060 80 100M200300400 500 8001G Level in dB 礦 /m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 31.212500 28.69 40.00 11.31 100.0 V 0.0 -23.1 37.517500 20.93 40.00 19.07 100.0 V 5.0 -21.2 44.016500 25.96 40.00 14.04 100.0 V 244.0 -19.3 49.982000 29.21 40.00 10.79 100.0 V 208.0 -18.6 115.554000 11.77 43.50 31.73 100.0 V 0.0 -20.2 396.611500 18.66 46.00 27.34 100.0 V 318.0 -14.2 Prüfbericht - Produkte Test Report - Products Appendix B CN21AMGT 001 Page 4 of 27 EUT Information EUT Name: Lenovo Go Essential Travel Mouse Model: MB601W Test Mode: 2.4G-SRD_2480MHz Test Voltage:: Baterry Remark: Temp 22 Humi:50% Test Standard: FCC 15.249 Tested By: Alano Qu Reviewed By: Terry Yin 0 10 20 30 40 50 60 72 30M 5060 80 100M200300400 500 8001G Level in dB 礦 /m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 36.984000 15.07 40.00 24.93 100.0 H 72.0 -21.5 49.982000 19.09 40.00 20.91 100.0 H 355.0 -18.6 115.602500 11.96 43.50 31.54 100.0 H 318.0 -20.2 243.497000 13.88 46.00 32.12 100.0 H 125.0 -17.9 398.648500 17.30 46.00 28.70 100.0 H 72.0 -14.1 573.442500 21.10 46.00 24.90 100.0 H 289.0 -10.7 Prüfbericht - Produkte Test Report - Products Appendix B CN21AMGT 001 Page 5 of 27 EUT Information EUT Name: Lenovo Go Essential Travel Mouse Model: MB601W Test Mode: 2.4G-SRD_2480MHz Test Voltage:: Baterry Remark: Temp 22 Humi:50% Test Standard: FCC 15.249 Tested By: Alano Qu Reviewed By: Terry Yin 0 10 20 30 40 50 60 72 30M 5060 80 100M200300400 500 8001G Level in dB 礦 /m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 31.212500 29.58 40.00 10.42 100.0 V 95.0 -23.1 44.404500 25.78 40.00 14.22 100.0 V 0.0 -19.3 49.982000 28.49 40.00 11.51 100.0 V 133.0 -18.6 118.755000 11.53 43.50 31.97 100.0 V 49.0 -20.8 242.963500 13.64 46.00 32.36 100.0 V 125.0 -17.9 552.490500 20.71 46.00 25.29 100.0 V 29.0 -11.1 Prüfbericht - Produkte Test Report - Products Appendix B CN21AMGT 001 Page 6 of 27 1GHz - 18GHz Note: The highest waveform in the figure is 2.4GHz Fundamental. EUT Information EUT Name: Lenovo Go Essential Travel Mouse Model: MB601W Test Mode: 2.4G-SRD_2402MHz Test Voltage:: Battery Remark: Temp 23 Humi:48% Test Standard: FCC 15.249 Tested By: Alano Qu Reviewed By: Terry Yin 0 20 40 60 80 100 120 130 1G2G3G4G5G 6.2G Level in dB 礦 /m Frequency in Hz Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Average (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 2401.480000 88.81 --- 114.00 25.19 100.0 H 252.0 7.0 2402.330000 --- 86.41 94.00 7.59 100.0 H 285.0 7.0 4803.000000 56.42 --- 74.00 17.58 100.0 H 274.0 11.8 4803.500000 --- 47.28 54.00 6.72 100.0 H 106.0 11.8 Prüfbericht - Produkte Test Report - Products Appendix B CN21AMGT 001 Page 7 of 27 EUT Information EUT Name: Lenovo Go Essential Travel Mouse Model: MB601W Test Mode: 2.4G-SRD_2402MHz Test Voltage:: Battery Remark: Temp 23 Humi:48% Test Standard: FCC 15.249 Tested By: Alano Qu Reviewed By: Terry Yin 0 20 4…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix A CN21AMGT 001 Page 1 of 3 Appendix A: Photographs of the Test Set-Up APPENDIX A: PHOTOGRAPHS OF THE TEST SET-UP ....................................................................................................... 1 PHOTOGRAPH 1: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, BELOW 1GHZ ......................................................................... 2 PHOTOGRAPH 2: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, ABOVE 1GHZ ......................................................................... 2 PHOTOGRAPH 3: SET-UP FOR CONDUCTED EMISSION ON AC MAINS ............................................................................................... 3 Prüfbericht - Produkte Test Report - Products Appendix A CN21AMGT 001 Page 2 of 3 Photograph 1: Set-up photo for Radiated Spurious Emission, Below 1GHz Photograph 2: Set-up photo for Radiated Spurious Emission, Above 1GHz Prüfbericht - Produkte Test Report - Products Appendix A CN21AMGT 001 Page 3 of 3 Photograph 3: Set-up for Conducted Emission on AC Mains
