A5MRG202-FWireless Receiver

Reduce | Reuse | Recycle First Edition (March 2020) © Copyright Lenovo 2020. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925. Lenovo Legion M600 Wireless Gaming Mouse https://support.lenovo.com SP40X87800 PN: SP40X87800 Printed in China ht tps: //www.lenovo.com/safety English Model: mouse:M600 dongle:RG202-F Scroll wheel and Logo LED status • Blinking red: Low battery power • Blinking blue: Pairing • Solid green for one second: Paring successful Safety information English The operating temperature range for the product is between 0°C (32°F) and 40°C (104°F). General battery notice DANGER Batteries supplied by Lenovo for use with your product have been tested for compatibility and should only be replaced with approved parts. Except the battery specified by Lenovo, a disassembled or modified battery is not covered by the warranty. Battery abuse or mishandling can cause overheat, liquid leakage, or an explosion. To avoid possible injury, do the following: •Do not open, disassemble, or service any battery. •Do not crush or puncture the battery. •Do not short-circuit the battery, or expose it to water or other liquids. •Keep the battery away from children. •Keep the battery away from fire. •Do not leave the battery in an extremely high-temperature environment or an extremely low air pressure environment. •Stop using the battery if it is damaged, or if you notice any discharge or the buildup of foreign materials on the battery leads. We recommend that the batteries be charged about once every three months to prevent overcharge. •Do not put the battery in trash that is disposed of in landfills. When disposing of the battery, comply with local laws or regulations. Built-in rechargeable battery notice DANGER •Do not attempt to replace the internal rechargeable lithium batteries. •Replacement of the battery must be done by a Lenovo-authorized repair facility or technician. •Only recharge the battery strictly according to instructions included in the product documentation. •Lenovo-authorized repair facilities or technicians recycle Lenovo batteries according to local laws and regulations. Arabic معلومات الأمان یتراوح نطاق درجھ حرارة التشغیل للمنتج بین 0 °مئویة )32 °فھرنھایت( و40 °مئویة )104 °فھرنھایت(. إشعار البطاریة العام خطر تم اختبار البطاریات المزوّدة من قبل شركة Lenovo للاستخدام مع منتجك للتأكد من توافقھا وینبغي استبدالھا بالقطع المعتمدة فقط. باستثناء البطاریة المحددة من قبل شركة Lenovo، لا یغطي الضمان أي بطاریة تم تفكیكھا أو تعدیلھا. قد یتسبب سوء استعمال البطاریة أو التعامل معھا بصورة خاطئة في ارتفاع درجة حرارتھا أو تسرب السوائل منھا أو حدوث انفجار. لتفادى الإصابة المحتملة، قم بما یلي: • لا تعمل على فتح أي بطاریة أو تفكیكھا أو صیانتھا. • لا تعمل على تحطیم البطاریة أو ثقبھا. • لا تقصر الدائرة الكھربائیة للبطاریة أو تعرّضھا للماء أو سوائل أخرى. • احتفظ بالبطاریة بعیدًا عن متناول الأطفال. • اعمل على إبعاد البطاریة عن النار. • لا تترك البطاریة في بیئة حیث درجات الحرارة عالیة جدًا أو بیئة یكون فیھا ضغط الھواء شدید الانخفاض. • توقف عن استخدام البطاریة إذا تعرضت للتلف، أو إذا لاحظت تسرب أي سوائل منھا أو تراكم مواد غریبة على موصلاتھا. نحن نوصي بشحن البطاریات بواقع مرة كل ثلاثة أشھر لمنع الشحن الزائد. • لا تلقِ البطاریة في القمامة التي یتم التخلص منھا في المكبات. عند التخلص من البطاریة، التزم بالقوانین أو اللوائح المحلیة. إشعار البطاریات المضمنة القابلة لإعادة الشحن خطر • لا تحاول استبدال بطاریات اللیثیوم الداخلیة القابلة لإعادة الشحن. • یجب أن یتم استبدال البطاریة في منشأة صیانة معتمدة أو فني معتمد من Lenovo. • لا تقم بإعادة شحن البطاریة إلا في ضوء الالتزام التام بالإرشادات المضمّنة في وثائق المنتج. •تقوم منشآت الصیانة المعتمدة أو الفنیون المعتمدون من شركة Lenovo بإعادة تدویر بطاریات Lenovo وفقًا للقوانین واللوائح التنظیمیة المحلیة. Brazilian Portuguese Informações sobre segurança A faixa de temperatura de operação do produto está entre 0 °C (32 °F) e 40 °C (104 °F). Aviso geral sobre baterias PERIGO Foi testada a compatibilidade das baterias fornecidas pela Lenovo para utilização com o produto, e elas devem ser substituídas somente por peças aprovadas. Exceto pela bateria especificada pela Lenovo, uma bateria desmontada ou modificada não é coberta pela garantia. O abuso ou uso incorreto da bateria podem causar superaquecimento, vazamento de líquidos ou explosão. Para evitar possíveis ferimentos, faça o seguinte: •Não abra, desmonte ou conserte qualquer bateria. •Não comprima nem perfure a bateria. •Não provoque curto-circuito na bateria nem a exponha à água ou outros líquidos. •Mantenha a bateria longe do alcance de crianças. •Mantenha a bateria longe do fogo. •Não deixe a bateria em um ambiente com temperatura extremamente alta ou em um ambiente com pressão de ar extremamente baixa. •Pare de usar a bateria se ela estiver danificada ou se você observar alguma descarga ou acúmulo de substâncias estranhas em seus condutores. Recomendamos que as baterias sejam carregadas pelo menos uma vez a cada três meses para evitar excesso de carga. •Não jogue a bateria em lixo que seja despejado em aterros sanitários. Ao descartar a bateria, siga as leis ou regulamentações locais. Aviso sobre baterias recarregáveis internas PERIGO •Não tente substituir as baterias de lítio recarregáveis internas. •A substituição da bateria deve ser feita por uma assistência técnica ou profissional autorizado Lenovo. •Somente recarregue a bateria estritamente de acordo com as instruções fornecidas com a documentação do produto. •As assistências técnicas ou os profissionais autorizados Lenovo reciclam as baterias Lenovo de acordo com as leis e regulamentações locais. Bulgarian Информация за безопасност Работната температура за този продукт е между 0°C (32°F) и 40°C (104°F). Обща забележка за батерията ОПАСНОСТ Батериите, доставени от Lenovo, за използване с вашия продукт, са тествани за съвместимост и трябва да бъдат подменяни само с одобрени части. Га…

Text truncated - open the document above for the full version.

Lenovo Regulatory Notice About this document This document provides regulatory information about the Lenovo Legion M600 Wireless Gaming Mouse and the Wireless Receiver: Federal Communications Commission Declaration of Conformity Lenovo Legion M600 Wireless Gaming Mouse – M600A (FCC ID: A5MM600A) Wireless Receiver – RG202-F (FCC ID: A5MRG202-F) Note: The Lenovo Legion M600 Wireless Gaming Mouse (Model: M600A) and the Wireless Receiver (Model: RG202-F) underwent certification process for the FCC Part 15 Subpart B compliance under its FCC ID number. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Re orient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult an authorized dealer or service representative for help. Lenovo is not responsible for any radio or television interference caused by using other than specified or recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Responsible Party: Lenovo (United States) Incorporated 1009 Think Place - Building One Morrisville, NC 27560 Phone Number: 919-294-5900 RF Exposure compliance Lenovo Regulatory Notice The radiated energy from the Lenovo Legion M600 Wireless Gaming Mouse conforms to the FCC limit of the SAR (Specific Absorption Rate) requirement set forth in 47 CFR Part 2 section 1093. Canada — Industry Canada (IC) IC Number Lenovo Legion M600 Wireless Gaming Mouse –M600A (IC ID: 5903G-M600A) Wireless Receiver – RG202-F (IC ID: 5903G-RG202F) This device complies with Industry Canada's license-exempt RSSs. Operation is subject to the following two conditions: 1.This device may not cause interference; and 2.This device must accept any interference, including interference that may cause undesired operation of the device. Exposure of humans to RF fields (RSS-102) The device employs low gain integral antennas that do not emit RF field in excess of Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada's Web site at http://www.hc-sc.gc.ca/ . The radiated energy from the antennas connected to the wireless adapters conforms to the IC limit of the RF exposure requirement regarding IC RSS-102, Issue 5. Numéro d'homologation IC Lenovo Legion M600 Wireless Gaming Mouse –M600A (IC ID: 5903G-M600A) Wireless Receiver – RG202-F (IC ID: 5903G-RG202F) Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : 1.l'appareil ne doit pas produire de brouillage; 2.l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. Exposition des êtres humains aux champs radioélectriques (RF) (CNR-102) Cet équipement utilise des antennes intégrales à faible gain qui n'émettent pas un champ électromagnétique supérieur aux normes imposées par le Ministére de la santé canadien pour la population. Consultez le Safety Code 6 sur le site Web du Ministére de la santé canadien à l'adresse http://www.hc-sc.gc.ca. Cet appareil émise par les antennes reliées aux adaptateurs sans fil respecte la limite d'exposition aux radiofréquences telle que définie par Industrie Canada dans la document CNR-102, version 5. Europe — EU Declaration of Conformity Lenovo Regulatory Notice Products intended for sale within the European Union are marked with the Conformité Européenne (CE) Marking, which indicates compliance with the applicable Directives and European Norms, and amendments, identified below. For Model: M600A and RG202-F Lenovo, Digital Park, Einsteinova 21, 851 01 Bratislava, Slovakia English Hereby, Lenovo (Singapore) Pte. Ltd., declares that the wireless equipment listed in this section is in compliance with the Radio Equipment Directive 2014/53/EU. The full text of the system EU declaration of conformity and the EU wireless module declarations are available at the following Internet addresses: http://www.lenovo.com/social_responsibility/us/en/eu_doc_wirelessoptions/ French Par la présente, Lenovo (Singapore) Pte. Ltd., déclare que les équipements sans fil listés dans cette section sont conformes à la directive 2014/53/EU sur les équipements radio. Le texte complet de la déclaration européenne de conformité et des déclarations européennes concernant les modules sans fil, s'il y a lieu, sont disponibles à l'adresse Internet suivante: http://www.lenovo.com/social_responsibility/us/en/eu_doc_wirelessoptions/

RF_160, Issue 03 Declaration of Authorization We Name: Lenovo (Beijing) Limited Address: 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road, Haidian District, City: Beijing Country: China Declare that: Name Representative of agent: Lisa Wang (1) Agent Company name: EMTEK (SHENZHEN) CO., LTD. Address: Bldg 69, Majialong Industry Zone, Nanshan District, City: Shenzhen Country China is authorized to apply for Certification of the following product(s): Product description: Wireless Receiver Type designation: RG202-F Trademark: Lenovo FCC ID: A5MRG202-F on our behalf. Date: 2020-3-19 Name: Yang Liu Function: Compliance Engineer Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Lenovo (Beijing) Limited Address : 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road, Haidian District, City: Beijing Country: China To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: A5MRG202-F Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5) Date: 2020-3-19 Name and signature of applicant: Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

External Photos General Appearance of the EUT General Appearance of the EUT General Appearance of the EUT General Appearance of the EUT General Appearance of the EUT General Appearance of the EUT

General Appearance of the EUT Note: The dimensions of the product are extremely small. So we will place the FCC ID in the user manual.

Internal Photos Internal view of EUT Internal view of EUT

Report No. ES200102047W Page 1 of 33 Ver.1.0 $印章$ TEST REPORT Product Name: Wireless Receiver Model Number: RG202-F FCC ID: A5MRG202-F Prepared for : Lenovo (Beijing) limited Address : 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing, China 100085 Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES200102047W Date(s) of Tests : Jan. 6, 2020 to Mar. 3, 2020 Date of issue : Mar. 5, 2020 $二维码$ Report No. ES200102047W Page 2 of 33 Ver.1.0 Table of Contents 1 TEST RESULT CERTIFICATION ............................................................................................................. 3 2 EUT TECHNICAL DESCRIPTION ........................................................................................................... 5 3 SUMMARY OF TEST RESULT ................................................................................................................ 6 4 TEST METHODOLOGY ........................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................ 7 4.2 MEASUREMENT EQUIPMENT USED .......................................................................................... 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................. 8 5 FACILITIES AND ACCREDITATIONS ..................................................................................................... 9 5.1 FACILITIES..................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ...................................................................... 9 6 TEST SYSTEM UNCERTAINTY ............................................................................................................ 10 7 SETUP OF EQUIPMENT UNDER TEST ................................................................................................ 11 7.1 RADIO FREQUENCY TEST SETUP 1 ......................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2 ......................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP ..................................................................................... 13 7.4 SUPPORT EQUIPMENT .............................................................................................................. 13 8 TEST REQUIREMENTS ......................................................................................................................... 14 8.1 BANDWIDTH TEST ...................................................................................................................... 14 8.2 RADIATED SPURIOUS EMISSION ............................................................................................. 17 8.3 CONDUCTED EMISSIONS TEST ................................................................................................ 29 8.4 ANTENNA APPLICATION ............................................................................................................ 32 Report No. ES200102047W Page 3 of 33 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Lenovo (Beijing) limited Address： 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing, China 100085 Manufacturer : Lenovo (Beijing) limited Address： 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing, China 100085 EUT : Wireless Receiver Model Name : RG202-F Trademark : Lenovo Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.249 The test results of this report relate only to the tested sample identified in this report Date of Test : Jan. 6, 2020 to Mar. 3, 2020 Prepared by : Joe Xia /Editor Reviewer : Lisa Wang /Editor Approve & Authorized Signer : David Lee /Manager Report No. ES200102047W Page 4 of 33 Ver.1.0 Modified Information Version Report No. Revision Date Summary Ver.1.0 ES200102047W / Original Report Report No. ES200102047W Page 5 of 33 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Characteristics Description Modulation: GFSK Frequency Range: 2402 MHz to 2480 MHz Number of Channels: 79 Channels Max Transmit Power: 70.65 dBuV/m Antenna: Internal Antenna Antenna Gain: 3.68 dBi Power supply DC 5.0V from external power Temperature Range: -20°C ~ +55°C Note: for more details, please refer to the User’s manual of the EUT. Report No. ES200102047W Page 6 of 33 Ver.1.0 3 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 15.207 Conducted Emission PASS 15.209 Radiated Emission PASS 15.249 Radiated Spurious Emission PASS 15.249 Band edge test PASS 15.249 20dB Bandwidth PASS 15.203 Antenna Requirement PASS NOTE1: N/A (Not Applicable) NOTE2: The report use radiated measurements in the restricted frequency bands. In addition, the radiated test is also performed to ensure the emissions emanating from the device cabinet also comply with the applicable limits. RELATED SUBMITTAL(S) / GRANT(S): This submittal(s) (test report) is intended for FCC ID: A5MRG202-F filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. Report No. ES200102047W Page 7 of 33 Ver.1.0 4 TEST METHODOLOGY 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS Ac…
