Lenovo Modern Wireless Combo, Lenovo Euterpe Wireless Combo https://support.lenovo.com Lenovo Yoga Life 无线键鼠套装 https://newsupport.lenovo.com.cn SP41A29613 (1P) PN: SP41A29613 Printed in China Reduce | Reuse | Recycle First Edition (September 2020) © Copyright Lenovo 2020. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925. 1 2 3 4 5 6 + - AA 3s 10%~20% < 10% >3s https://www.lenovo.com/safety English Press Fn+FnLock to enable or disable the Fn Lock function. To use the shortcut functions: • Press Fn+F1-F11 when the Fn Lock function is disabled. • Press F1-F11 when the Fn Lock function is enabled. The shortcut functions are denoted by the icons printed on the keys. To use all the shortcut functions, download and install the keyboard software from https://www.lenovo.com/support/keyboards. Operating system requirement Microsoft® Windows® 10 Czech Stiskem kláves Fn+FnLock zapněte nebo vypněte funkci klávesy Fn Lock. Použití funkcí klávesových zkratek: • Stisknete klávesu Fn+F1-F11, když je funkce Fn Lock vypnutá. • Stiskněte klávesu F1-F11, když je funkce Fn Lock zapnutá. Funkce klávesových zkratek jsou označeny pomocí ikon natištěných na klávesách. Chcete-li použít všechny funkce klávesových zkratek, stáhněte si a nainstalujte software klávesnice z webu https://www.lenovo.com/support/keyboards. Požadavky na operační systém Microsoft Windows 10 French Appuyez sur Fn+Fn Verr. pour activer ou désactiver la fonction de verrouillage de la touche Fn. Pour utiliser les fonctions de raccourci : • Appuyez sur Fn+F1-F11 lorsque la fonction de verrouillage de la touche Fn est désactivée. • Appuyez sur F1-F11 lorsque la fonction de verrouillage de la touche Fn est activée. Les fonctions de raccourci sont indiquées par les icônes sur les touches. Pour utiliser les fonctions de raccourci, téléchargez et installez le logiciel de clavier depuis https://www.lenovo.com/support/keyboards. Système d'exploitation nécessaire Microsoft Windows 10 German Drücken Sie Fn+FnLock, um die Fn Lock-Funktion zu aktivieren oder zu deaktivieren. So verwenden Sie die Tastaturkurzbefehle: • Drücken Sie die Tastenkombination Fn+F1-F11, wenn die Fn Lock-Funktion deaktiviert ist. • Drücken Sie die Tasten F1-F11, wenn die Fn Lock-Funktion aktiviert ist. Die Tastaturkurzbefehle erkennen Sie an den Symbolen, die auf die Tasten aufgedruckt sind. Zur Verwendung aller Tastaturkurzbefehle müssen Sie die Tastatursoftware unter https://www.lenovo.com/support/keyboards herunterladen und installieren. Anforderungen an das Betriebssystem Microsoft Windows 10 Hungarian Az Fn Lock funkció engedélyezéséhez vagy letiltásához nyomja meg az Fn+FnLock billentyűkombinációt. A billentyűparancsok használatához: • Nyomja meg az Fn+F1-F11 billentyűkombinációt, ha az Fn Lock funkció le van tiltva. • Nyomja meg az F1-F11 billentyűket, ha az Fn Lock funkció engedélyezve van. A billentyűparancsokat a billentyűkre nyomtatott ikonok jelzik. Az összes billentyűparancs használatához töltse le, majd telepítse a billentyűzet szoftverét a következő oldalról: https://www.lenovo.com/support/keyboards. Operációs rendszerrel kapcsolatos követelmények Microsoft Windows 10 Italian Premere Fn+FnLock per abilitare o disabilitare la funzione Fn Lock. Per utilizzare le funzioni di scelta rapida: • Premere Fn+F1-F11 quando la funzione Fn Lock è disabilitata. • Premere F1-F11 quando la funzione Fn Lock è abilitata. Le funzioni di scelta rapida sono contrassegnate dalle icone stampate sui tasti. Per utilizzare tutte le funzioni di scelta rapida, scaricare e installare il software della tastiera da https://www.lenovo.com/support/keyboards. Requisito del sistema operativo Microsoft Windows 10 Polish Naciśnij kombinację klawiszy Fn + FnLock, aby włączyć lub wyłączyć funkcję Fn Lock. Aby móc korzystać z funkcji skrótów: • Po wyłączeniu funkcji Fn Lock naciśnij kombinację klawiszy Fn + F1-F11. • Po włączeniu funkcji Fn Lock naciśnij klawisz F1-F11. Funkcje skrótów są oznaczone ikonami nadrukowanymi na klawisze klawiatury. Aby móc korzystać ze wszystkich funkcji skrótów, pobierz i zainstaluj oprogramowanie klawiatury ze strony https://www.lenovo.com/support/keyboards. Wymaganie dotyczące systemu operacyjnego Microsoft Windows 10 Portuguese Prima Fn+FnLock para ativar ou desativar a função Fn Lock. Para utilizar as funções de atalho: • Prima Fn+F1-F11 quando a função Fn Lock estiver desativada. • Prima F1-F11 quando a função Fn Lock estiver ativada. As funções de atalho são indicadas pelos ícones impressos nas teclas. Para utilizar as funções de atalho, transfira e instale o software do teclado a partir de https://www.lenovo.com/support/keyboards. Requisito de sistema operativo Microsoft Windows 10 Russian Нажмите сочетание клавиш Fn+FnLock, чтобы включить или выключить функцию Fn Lock. Чтобы использовать функции быстрого доступа: • Нажмите клавиши Fn+F1-F11, если функция Fn Lock выключена. • Нажмите клавиши F1-F11, если функция Fn Lock включена. Функции быстрого доступа обозначаются значками, напечатанными на клавишах. Чтобы использовать все функции быстрого доступа, скачайте и установите программное обеспечение для клавиатуры с сайта https://www.lenovo.com/support/keyboards. Требование к операционной системе Microsoft Windows 10 Simplified Chinese 按 Fn+FnLock 可启用或禁用 Fn 锁定功能。 要使用快捷键功能： • 当禁用 Fn 锁定功能时按 Fn+F1-F11。 • 当启用 Fn 锁定功能时按 F1-F11。 按键上所印的图标指示快捷键功能。要使用所有快捷键功能，请通过 https://newsupport.lenovo.com.cn/driveDownloads_detail.html?driveId=72873 下载并安装键盘软件。 对操作系统的要求 Microsoft Windows 10 Spanish Presione Fn+FnLock para habilitar o deshabilitar la función de bloqueo Fn. Para utilizar las funciones de acceso directo: • Presione FN+F1-F11 cuando la función FnLock está deshabilitada. • Presione F1-F11 cuando la función FnLock está habilitada. Las funciones de acceso directo se indican mediante los iconos impresos en l…

Text truncated - open the document above for the full version.

Lenovo (Beijing) Limited QF094234 Page 1 of 1 Revision 0 Authority to Act as Agent Date: _2020-09-10_______ TUV Rheinland Group 762 Park Avenue Youngsville, NC 27596 To Whom It May Concern: I appoint TUV Rheinland (Shenzhen) Co., Ltd. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with ___ Lenovo (Beijing) Limited / 201-H2-6, Floor 2, Building 2, No.6 Shangdi West Road, Haidian District, Beijing, China 100085___. For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: ____2021-0 9-10____ By: __________________________ ______Yang Liu________________ (Signature) (Print name) Title: __Standardization Manager___________Telephone:___ +86-10-58861975__________ On behalf of: _______Lenovo (Beijing) Limited ______ (Company Name)

Lenovo (Beijing) Limited Confidentiality Letter Date: 2020-09-10 Subject: Confidentiality Request for FCC ID: A5MRG51-6108 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Part List/Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent anual Lenovo (Beijing) Limited has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04- 1705. Sincerely, By: Yang Liu (Signature/Title) (Print name)

Produkte Products Appendix B 60414293 002 Page 1 of 21 Appendix B: Test Results of General 2.4GHz APPENDIX B: TEST RESULTS OF GENERAL 2.4GHZ .................................................................................................................... 1 APPENDIX B.1: FUNDAMENTAL & HARMONICS RADIATED EMISSION ................................................................................................. 2 30MHz - 1GHz ....................................................................................................................................................................... 2 1GHz - 18GHz ........................................................................................................................................................................ 6 APPENDIX B.2: TEST RESULTS OF 20DB BANDWIDTH ..................................................................................................................... 12 APPENDIX B.3: TEST RESULTS OF 99% BANDWIDTH....................................................................................................................... 14 APPENDIX B.4: TEST RESULTS OF RADIATED EMISSIONS IN RESTRICTED BANDS ................................................................................. 16 APPENDIX B.5: TEST PLOTS OF CONDUCTED EMISSION ON AC MAINS ............................................................................................. 20 Produkte Products Appendix B 60414293 002 Page 2 of 21 Note: Testing w as carried out w ithin f requency range 9kHz to the tenth harmonics. The measurement results below 30MHz and 18GHz -26.5GHz w ere greater than 20dB below the limit, so only the radiated spurious emissions f rom 30MHz to 18GHz w ere reported. Appendix B.1: Fundamental & Harmonics Radiated Emission 30MHz - 1GHz EUT Information EUT Name: Wireless Receiver Model: RG51-6108 Test Mode: Low channel Test Voltage:: DC 5V From USB Remark: Temp 24 Humi:45% Test Standard: FCC 15.249 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Av erage (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 49.739500 20.19 --- 40.00 19.81 100.0 H 254.0 -18.6 103.768500 18.51 --- 43.50 24.99 100.0 H 334.0 -19.1 281.230000 23.24 --- 46.00 22.76 100.0 H 180.0 -17.0 709.145500 35.97 --- 46.00 10.03 100.0 H 303.0 -8.3 844.848500 37.74 --- 46.00 8.26 100.0 H 5.0 -6.0 Produkte Products Appendix B 60414293 002 Page 3 of 21 EUT Information EUT Name: Wireless Receiver Model: RG51-6108 Test Mode: Low channel Test Voltage:: DC 5V From USB Remark: Temp 24 Humi:45% Test Standard: FCC 15.249 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Av erage (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 57.063000 27.14 --- 40.00 12.86 100.0 V 344.0 -19.0 108.036500 19.22 --- 43.50 24.28 100.0 V 166.0 -19.3 729.030500 36.04 --- 46.00 9.96 100.0 V 99.0 -7.9 845.188000 36.65 --- 46.00 9.35 100.0 V 145.0 -6.0 Produkte Products Appendix B 60414293 002 Page 4 of 21 EUT Information EUT Name: Wireless Receiver Model: RG51-6108 Test Mode: High channel Test Voltage:: DC 5V From USB Remark: Temp 24 Humi:45% Test Standard: FCC 15.249 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Av erage (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 37.469000 21.19 --- 40.00 18.81 100.0 H 12.0 -21.3 100.664500 19.18 --- 43.50 24.32 100.0 H 305.0 -19.3 265.370500 22.73 --- 46.00 23.27 100.0 H 252.0 -17.3 728.788000 35.35 --- 46.00 10.65 100.0 H 315.0 -7.9 Produkte Products Appendix B 60414293 002 Page 5 of 21 EUT Information EUT Name: Wireless Receiver Model: RG51-6108 Test Mode: High channel Test Voltage:: DC 5V From USB Remark: Temp 24 Humi:45% Test Standard: FCC 15.249 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Av erage (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 39.215000 26.65 --- 40.00 13.35 100.0 V 0.0 -20.7 50.855000 28.15 --- 40.00 11.85 100.0 V 287.0 -18.6 235.300500 20.59 --- 46.00 25.41 100.0 V 45.0 -18.2 845.673000 38.47 --- 46.00 7.53 100.0 V 179.0 -6.0 Produkte Products Appendix B 60414293 002 Page 6 of 21 1GHz - 18GHz EUT Information EUT Name: Wireless Receiver Model: RG51-6108 Test Mode: Low channel Test Voltage:: DC 5V From USB Remark: Temp 22 Humi:52% Test Standard: FCC 15.249 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Av erage (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 2405.687500 --- 86.70 94.00 7.30 100.0 H 19.0 7.0 2405.687500 88.42 --- 114.00 25.58 100.0 H 19.0 7.0 4808.500000 57.04 --- 74.00 16.96 100.0 H 195.0 13.6 4809.000000 --- 47.03 54.00 6.97 100.0 H 195.0 13.6 7212.341667 --- 34.15 54.00 19.85 100.0 H 269.0 8.7 7213.816667 42.32 --- 74.00 31.68 100.0 H 153.0 8.7 Produkte Products Appendix B 60414293 002 Page 7 of 21 EUT Information EUT Name: Wireless Receiver Model: RG51-6108 Test Mode: Low channel Test Voltage:: DC 5V From USB Remark: Temp 22 Humi:52% Test Standard: FCC 15.249 Tested By: Kei Zhang Reviewed By: Terry Yin Level in dB 礦 /m Critical_Freqs Frequency (MHz) MaxPeak (dBμV/m) Av erage (dBμV/m) Limit (dBμV/m) Margin (dB) Height (cm) Pol Azimuth (deg) Corr. (dB/m) 2405.687500 70.60 --- 114.00 43.40 100.0 V 289.0 7.0 2405.687500 --- 67.76 94.00 26.24 100.0 V 289.0 7.0 4809.500000 51.06 --- 74.00 22.94 100.0 V 87.0 13.6 4809.500000 --- 42.23 54.00 11.77 100.0 V 87.0 13.6 7220.208333 --- 33.70 54.00 20.30 100.0 V 58.0 8.7 7229.550000 43.85 --- 74.00 30.15 100.0 V 264.0 8.6 Produkte Products Appendix B 60414293 002 Page 8 of 21 EUT Information EUT Name: Wireless Receiver Model: RG51-6108 Test Mode: Mid channel Test Voltage:: DC 5V From USB Remark: Temp 22 Humi:52% Test Standard: FCC 15.249 Tested By…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: 60414293 002 Auftrags-Nr.: Order no.: 168274339 Seite 1 von 18 Page 1 of 18 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2020-07-21 Auftraggeber: Client: LENOVO (BEIJING) LIMITED 201-H2-6, Floor 2, Building2, No.6 Shangdi West Road, Haidian District, Beijing 100085, P.R.China Prüfgegenstand: Test item: Wireless Receiver Bezeichnung / Typ-Nr.: Identification / Type No.: RG51-6108 Auftrags-Inhalt: Order content: FCC approval Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart C Section 15.249 CFR47 FCC Part 15: Subpart C Section 15.209 CFR47 FCC Part 15: Subpart C Section 15.207 Wareneingangsdatum: Date of sample receipt: 2020-08-04 Please refer to photo documents Prüfmuster-Nr.: Test sample no.: A002878830-001~003 Prüfzeitraum: Testing period: 2020-08-05 - 2020-09-08 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: genehmigt von: authorized by: Datum: Date: 2020-09-09 Ausstellungsdatum: Issue date: 2020-09-09 Stellung / Position Lin Lin / Senior Project Manager Stellung / Position Winnie Hou / Technical Certif ier Sonstiges / Other: FCC ID: A5MRG51-6108 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged: * Legende: 1 = sehr gut 2 = gut 3 = bef riedigend 4 = ausreichend 5 = mangelhalt P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet Legend: 1 = v ery good 2 = good 3 = satisfactory 4 = suf ficient 5 = poor P(ass) = passed a.m. test specifications(s) F(ail) = f ailed a.m. test specifications(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfm uster und darf ohne Genehm igung der Prüfstelle nicht auszugsw eise vervielfältigt w erden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be V05 duplicated in extracts. This test report does not entitle to carry any test mark. T UV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] http://www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. 60414293 002 Seite 2 von 18 Page 2 of 18 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 FUNDAMENTAL & HARMONICS RADIATED EMISSION RESULT: Pass 5.1.3 20DB BANDWIDTH RESULT: Pass 5.1.4 RADIATED SPURIOUS EMISSION & BAND EDGE RESULT: Pass 5.1.5 CONDUCTED EMISSION ON AC MAINS RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. 60414293 002 Seite 3 von 18 Page 3 of 18 Contents 1 GENERAL REMARKS .......................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS ............................................................................................. 4 2 TEST SITES ..................................................................................................................... 5 2.1 TEST FACILITIES ............................................................................................................... 5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS ..................................................................... 5 2.3 TRACEABILITY.................................................................................................................. 6 2.4 CALIBRATION................................................................................................................... 6 2.5 MEASUREMENT UNCERTAINTY ............................................................................................. 6 2.6 LOCATION OF ORIGINAL DATA ............................................................................................. 6 2.7 STATUS OF FACILITY USED FOR TESTING ............................................................................... 7 3 GENERAL PRODUCT INFORMATION........................................................................................ 8 3.1 PRODUCT FUNCTION AND INTENDED USE................................................................................ 8 3.2 RATINGS AND SYSTEM DETAILS ........................................................................................... 8 3.3 INDEPENDENT OPERATION MODES ........................................................................................ 9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS............................................................... 9 3.5 SUBMITTED DOCUMENTS .................................................................................................... 9 4 TEST SET-UP AND OPERATION MODES................................................................................. 10 4.1 PRINCIPLE OF CONFIGURATION SELECTION ........................................................................... 10 4.2 TEST OPERATION AND TEST SOFTWARE............................................................................... 10 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ............................................................... 10 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE ............................................................. 10 4.5 TEST SETUP DIAGRAM ..................................................................................................... 11 5 TEST RESULTS ............................................................................................................... 13 5.1 TRANSMITTER REQUIREMENT & TEST SUITES ...…

Text truncated - open the document above for the full version.

Produkte Products Appendix A 60414293 002 Page 1 of 3 Appendix A: Photographs of the Test Set-Up APPENDIX A: PHOTOGRAPHS OF THE TEST SET-UP.................................................................................................................. 1 PHOTOGRAPH 1: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, 30MHZ ~ 1GHZ ........................................................................ 2 PHOTOGRAPH 2: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, 1GHZ ~ 18GHZ ......................................................................... 2 PHOTOGRAPH 3: SET-UP FOR CONDUCTED EMISSION ON AC MAINS ................................................................................................... 3 Produkte Products Appendix A 60414293 002 Page 2 of 3 Photograph 1: Set-up photo for Radiated Spurious Emission, 30MHz ~ 1GHz Photograph 2: Set-up photo for Radiated Spurious Emission, 1GHz ~ 18GHz Produkte Products Appendix A 60414293 002 Page 3 of 3 Photograph 3: Set-up for Conducted Emission on AC Mains
