TEST REPORT Report No. : AS0021025(0) Date : 17 Apr 2014 For and on behalf of CMA Industrial Development Foundation Limited Authorized Signature : Page 1 of 24 Mr. WONG Lap-pong, Andrew Assistant Manager Electrical Division FCC ID: A6O60001058TX Application No. : LS010836(7) Applicant : Hubsan (HK) Industrial Co., Ltd. 4/F Hong Fa Hi-Tech Industrial Park, Tangtou Village, Baoan District, Shiyan Town, Shenzhen, China Client : Shenzhen Hubsan Technology Co., Ltd Rm409 Municipal Building, Hongli West Road, FuTian District, Shenzhen, China. Sample Description : Two(2) item of submitted sample stated to be X4 Mini Quadcopter of Model No. H107, H107C Sample registration No. : RS011794-003, RS015168-001 Radio Frequency : 2410MHz – 2465 MHz Transceiver Rating : 4 x 1.5V AAA size batteries No. of submitted sample : Two (2) set (s) Date Received : 27 Mar 2014, 17 Apr 2014 Test Period : 27 Mar 2014 to 17 Apr 2014. Test Requested : FCC Part 15 Certificate Test Method : 47 CFR Part 15 (10-1-12 Edition) ANSI C63.4 – 2009 Test Engineer : Mr. LEUNG Shu-kan, Ken Test Result : See attached sheet(s) from page 2 to 24. Conclusion : The submitted sample was found to comply with requirement of FCC Part 15 Subpart C. TEST REPORT Report No. : AS0021025(0) Date : 17 Apr 2014 Page 2 of 24 FCC ID: A6O60001058TX Table of Contents 1 General Information ................................................................................................................................... 3 1.1 General Description ............................................................................................................................ 3 1.2 Location of the test site ....................................................................................................................... 4 1.3 List of measuring equipment............................................................................................................... 5 1.4 Measurement Uncertainty ................................................................................................................... 6 2 Description of the radiated emission test ................................................................................................... 7 2.1 Test Procedure .................................................................................................................................... 7 2.2 Test Result .......................................................................................................................................... 8 2.3 Radiated Emission Measurement Data ............................................................................................... 9 3 Description of the Line-conducted Test ................................................................................................... 12 3.1 Test Procedure .................................................................................................................................. 12 3.2 Test Result ........................................................................................................................................ 12 3.3 Graph and Table of Conducted Emission Measurement Data .......................................................... 12 4 Photograph ...............................................................................................................................................13 4.1 Photographs of the Test Setup for Radiated Emission and Conducted Emission ............................. 13 4.2 Photographs of the External and Internal Configurations of the EUT.............................................. 13 5 Supplementary document ......................................................................................................................... 14 5.1 Bandwidth ......................................................................................................................................... 14 5.2 Duty cycle ......................................................................................................................................... 14 5.3 Transmission time ............................................................................................................................. 14 5.4 Power Spectral Density..................................................................................................................... 14 5.5 Average on time ................................................................................................................................ 14 6 Appendices...............................................................................................................................................15 TEST REPORT Report No. : AS0021025(0) Date : 17 Apr 2014 Page 3 of 24 FCC ID: A6O60001058TX 1 General Information 1.1 General Description The equipment under test (EUT) is a transmitter for quadrocopter. The EUT is power by 4 x 1.5V AAA size batteries. It operates at 2410MHz – 2465 MHz. There are buttons and joysticks on the EUT. When the buttons are pressed or the joysticks are moved, the EUT will transmit radio control signal to receiver. The brief circuit description is listed as follows: - U3 and its associated circuit act as MCU - U6 and its associated circuit act as power - U2 and its associated circuit act as RF module - U4, LCD1 and its associated circuit act as display - S1, S2, S3, S4, S5, S6, S7, S8, RS1, RS2 and its associated circuit act as copter control TEST REPORT Report No. : AS0021025(0) Date : 17 Apr 2014 Page 4 of 24 FCC ID: A6O60001058TX 1.2 Location of the test site FCC Registered Test Site Number: 552221 Radiated emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2009. A Semi-Anechoic Chamber Testing Site is set up for investigation and located at: Ground Floor, Yan Hing Centre, 9 – 13 Wong Chuk Yeung Street, Fo Tan, Shatin, New Territories, Hong Kong. Conducted emissions measurements are investigated and also tak…

Text truncated - open the document above for the full version.

TEST REPORT Report No. : AS0021025(0) Date : 17 Apr 2014 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 23 of 24 FCC ID: A6O60001058TX A5. Band Edge Lower edge (Peak measurement) Lower edge (Average measurement) TEST REPORT Report No. : AS0021025(0) Date : 17 Apr 2014 Tested by: Reviewed by: Mr. LEUNG Shu-kan, Ken Mr. WONG Lap-pong, Andrew Page 24 of 24 FCC ID: A6O60001058TX A5. Band Edge Higher edge (Peak measurement) Higher edge (Average measurement) ***** End of Report *****

Test Setup Photo Front view (30MHz – 1GHz) Rear view (30MHz – 1GHz) Front view (9kHz - 30MHz) Rear view (9kHz - 30MHz) Front view (1GHz – 25GHz) Rear view (1GHz – 25GHz)
