A7AG6NAGNSS Receiver

1 G6NA User Manual 2 Content Chapter1 Brief introduction ....................................................................................................... 3 1.1 Key Features ..................................................................................................................... 3 1.2 G6 Receiver ....................................................................................................................... 5 1.2.1. Front side of the Receiver ........................................................................................ 5 1.2.2. Back side of the Receiver ......................................................................................... 7 1.2.3. The bottom of Receiver ............................................................................................ 8 Chapter2 Basic operations of G6 ................................................................................................ 9 2.1 The installation of base and rover .................................................................................... 9 2.2 The operation of keys ..................................................................................................... 10 2.3 Self-checking ................................................................................................................... 10 2.4 Measure the antenna height .......................................................................................... 11 Chapter3 Web UI function ....................................................................................................... 12 3.1 Status .............................................................................................................................. 13 3.2 Information ..................................................................................................................... 13 3.3 Download ....................................................................................................................... 13 3.4 Management .................................................................................................................. 14 3.4.1 Device register ......................................................................................................... 14 3.5 Settings ........................................................................................................................... 15 3.5.1. Working mode ........................................................................................................ 15 3.5.2. Device configuration .............................................................................................. 20 3.5.3. NMEA Message ...................................................................................................... 21 Chapter4 G6 standard accessories ........................................................................................... 22 4.1 The case of G6 ................................................................................................................ 22 4.2 Power supply .................................................................................................................. 22 4.3 The antenna .................................................................................................................... 23 4.4 Other accessories ........................................................................................................... 23 Chapter5 Appendixes ............................................................................................................... 25 Appendix 1 Default radio configuration .............................................................................. 25 Appendix 2 Specification ...................................................................................................... 26 3 Chapter1 Brief introduction This chapter is mainly used to introduce the key features and the appearance of G6. As the latest generation of GNSS receiver, G6 brings you a better user experience. The dimension and weight also has a great breakthrough, now the dimension is diameter 131mm × height 102mm, the weight is just 850g (without battery). Adopt many new technologies, there are some functions add to G6 and this make survey work more convenient. 1.1 Key Features Designed and developed by a group of excellent developers, G6 has many technical innovation. All of the innovation can help you finish the survey work quickly and high efficiently. They can be summarized in 5 points, as follow: (1) Electric bubble G6 has electronic bubble technology, bubble is appeared on the controller display screen. Thanks to the new electronic bubble, all measurement information will be displayed in one place. And when you check whether the support pole is leveling, you don’t need to use the physical bubble in the support hole to level. (2) WIFI wireless connection When the WIFI function is opened, G6 can be used as a hotspot. You can connect your phone to it via WIFI. Log on the WEB UI, then you can do many configurations with your phone, such as change work mode, change datalink, download static data. (3) Dual mode Bluetooth G6 supports 4.0 long-distance Bluetooth and can connect to mainstream mobile phone, pad and digital consume products. Meanwhile can be compatible with Bluetooth 2.1 and connected with industrial-grade controll e r. (4) Double backup of the survey data 4 G6 RTK survey data will have double back-up, by controller and receiver so as to make sure the survey data is safe and reliable. (5) Compatible with all satellite constellations Not only can track all of the current satellite systems, but also can support the satellites in planned. The excellent performance in tracking satellites make it easily cope with and face to future. Besides the latest technical innovation, there are also development in the hardware and accessories, such as the battery and some useful tools. All of these make sure our users grasp the mos…

Text truncated - open the document above for the full version.

Rev 11/20/07 (TI Asahi Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: A7AG6NA Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (Mikio Horie)

TI Asahi Co., Ltd. Model Difference 2021-03-08 EUT NAME: GNSS Receiver FCC ID: A7AG6NA MODEL : G6NA, G7H, G7N, G7 All the model are the same circuit and RF module, except model names. Regards Sincerely Client’s signature Client’s name / title : Mikio Horie / Manager Contact information / address: 4-3-4, Uneo, Iwatsuki-ku, Saitama-shi, Saitama 339-0073 Japan

(TI Asahi Co., Ltd.) Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2020/10/19 SUBJECT: FCC Application for FCC ID: A7AG6NA To Whom It May Concern: We, the undersigned, hereby authorize Alan Mei at Shenzhen BCTC Testing Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Alan Mei of Shenzhen BCTC Testing Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, (Mikio Horie)

External Photos RF-ID ANT

Size:40*20mm GNSS Receiver FCC ID: A7AG6NA Contains Wireless Data Transceiver Module (Single Module) FCC ID: 2ABNA-TRM101 Contains LTE Module (Single Module) FCC ID: XMR201903EG25G This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Label location

Internal Photos 4G ANT 2 GPS ANT BT/WIFI ANT 4G ANT 1

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: A7AG6NA Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna, R=0.2m TEST RESULTS Tune up Produce power Maximu m peak output power (dBm) Output power to antenn a (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result 802.11b (2.4G Hz WIFI) 15±1 16 39.81 0.933 (-0.3dBi) 0.00739 1 Pass BT 4±1 5 3.16 0.933 (-0.3dBi) 0.00251 1 Pass

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000743-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 1 of 67 FCC Part 15C Test Report FCC ID:A7AG6NA Product Name: GNSS Receiver Trademark: N/A Model Name : G6NA G7H, G7N, G7 Prepared For : TI Asahi Co., Ltd. Address : 4-3-4, Uneo, Iwatsuki-ku, Saitama-shi, Saitama 339-0073 Japan Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Aug. 18, 2020 – Aug. 31, 2020 Date of Report : Aug. 31, 2020 Report No.: BCTC2008000743-1E Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000743-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 2 of 67 TEST RESULT CERTIFICATION Applicant’s name ............. : TI Asahi Co., Ltd. Address .............................. : 4-3-4, Uneo, Iwatsuki-ku, Saitama-shi, Saitama 339-0073 Japan Manufacture's Name ........ : TI Asahi Co., Ltd. Address .............................. : 4-3-4, Uneo, Iwatsuki-ku, Saitama-shi, Saitama 339-0073 Japan Product description Product name..................... : GNSS Receiver Trademark ......................... : N/A Model and/or type reference : G6NA G7H, G7N, G7 Standards ......................... : FCC Part15.247 ANSI C63.10:2013 558074 D01 15.247 Meas Guidance v05r02 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Tested by: Approved by: Willem Wang/Project Handler Zero Zhou/Reviewer Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000743-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 3 of 67 Table of Contents Test Report Declaration Page 1. TEST SUMMARY ...................................................... 5 2. TEST FACILITY ....................................................... 6 3. MEASUREMENT UNCERTAINTY........................................ 6 4. GENERAL INFORMATION .............................................. 7 4.1 GENERAL DESCRIPTION OF EUT ....................................... 7 4.2 Test Setup Configuration ................................................ 8 4.3 Support Equipment ..................................................... 8 4.4 Channel List ........................................................... 9 4.5 Test Mode ............................................................ 10 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 11 5.1 Test Facility ........................................................... 11 5.2 Test Instrument Used .................................................. 11 6. CONDUCTED EMISSIONS ............................................. 13 6.1 Block Diagram Of Test Setup ........................................... 13 6.2 Limit ................................................................. 13 6.3 Test procedure ........................................................ 13 6.4 Test Result ........................................................... 14 7. RADIATED EMISSIONS ............................................... 15 7.1 Block Diagram Of Test Setup ........................................... 15 7.2 Limit ................................................................. 16 7.3 Test procedure ........................................................ 16 7.4 Test Result ........................................................... 18 7.5 RADIATED BAND EMISSION MEASUREMENT AND RESTRICTED BANDS OF OPERATION ........................................................... 22 8. CONDUCTED EMISSION .............................................. 25 8.1 Block Diagram Of Test Setup ........................................... 25 8.2 Limit ................................................................. 25 8.3 Test procedure ........................................................ 25 8.4 Test Result ........................................................... 26 9. 20 DB BANDWIDTH .................................................. 35 9.1 Block Diagram Of Test Setup ........................................... 35 9.2 Limit ................................................................. 35 9.3 Test procedure ........................................................ 35 9.4 Test Result ........................................................... 36 10. MAXIMUM PEAK OUTPUT POWER .................................... 42 10.1 Block Diagram Of Test Setup .......................................... 42 10.2 Limit ................................................................ 42 10.3 Test procedure ....................................................... 42 10.4 Test Result .......................................................... 43 11. HOPPING CHANNEL SEPARATION .................................... 48 11.1 Block Diagram Of Test Setup .......................................... 48 Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000743-1E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 4 of 67 11.2 Limit ................................................................ 48 11.3 Test procedure ....................................................... 48 11.4 Test Result .......................................................... 49 12. NUMBER OF HOPPING FREQUENCY .................................. 54 12.1 Block Diagram Of Test Setup .......................................... 54 12.2 Limit ................................................................ 54 12.3 Test procedure ....................................................... 54 …

Text truncated - open the document above for the full version.

Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2008000743-2E Test Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-007 Ver.：A.0 Page 53 of 55 10. EUT TEST PHOTO Radiated Measurement Photos
