A98-AZB9304Cellular WCDMA/ HSDPA Phone with Bluetooth and WLAN

NEC Corporation of America

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Apr 29, 2010
Application Purpose: Original Equipment
Date of Application: Apr 29, 2010
Equipment Note: Cellular WCDMA/ HSDPA Phone with Bluetooth and WLAN
Company: NEC Corporation of America
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 Phone Calls Making a call/videophone call Making a call by entering the phone number 1 Enter the phone number starting with the area code, then (voice call) / Fn with 2 (V.phone) z Videophone operation ← / → : Adjust zoom (1 second or longer): Mute your voice 2 After the call ends, Making a call from Phonebook Add the phone number of the other party to the phonebook in advance. 1 MENU＞ " TEL function " ＞ " Phonebook " ＞ " Search phonebook " ＞ Select a search condition and search an entry ＞ Use ↑ / ↓ / ← / → to select an entry, then (voice call)/ Fn with 2 (V.phone) Making a call from Redial/Received calls Add the phone number of the other party to the phonebook in advance. 1 Use → (Redial) or ← (Received calls) to select the other party, then (voice call)/ Fn with 2 (V.phone) 2 Notifying the other party of your phone number Set whether to show your phone number (caller ID) on the other party's phone (display) when making a call. 1 MENU ＞ " TEL function " ＞ " Dial/Receive setting " ＞ " Caller ID notification " ＞ " Activate/Deactivate " 2 " ON " or " OFF " Information • If you hear a message requesting your caller ID, make a call again with Caller ID notification enabled or with 186 prefix. Making an international call Use WORLD CALL to make international calls from Japan. • You can make calls from overseas. ( → p.10) 1 010 ＞ Country codes ＞ Area code (City code) ＞ Other party's phone number ＞ (voice call)/ Fn with 2 (V.phone) 2 After the call ends, Information • Dial the other party's phone number excluding "0" at the beginning of the area code (city code). However, to make a call to some countries/areas, such as in Italy, "0" is required. 3 Receiving a call/videophone call • When you receive an incoming call, the ring tone sounds. 1 When you receive an incoming call, 2 After the call ends, Adjusting earpiece volume 1 MENU ＞ " TEL function " ＞ " Dial/Receive setting " ＞ " In-call setting " ＞ " Vo lum e " ＞ Adjust with ↑ / ↓ Information • During a call, you can adjust the volume with / 4 When you cannot answer a call Setting to record a voice and videophone message When you cannot answer a voice or videophone call, the FOMA terminal can record a voice or videophone message. 1 MENU ＞ " TEL function " ＞ " Rec. msg./Voice memo " ＞ " Record message setting " ＞ " ON " ＞ " Phone " or " Videophone " ＞ Select an item 2 Set ring time (3-digit number meaning 000-120 seconds) ■If you receive a call with Record message setting ON Record message activates if the set time ends. Press to answer a voice call while recording. Press (Answer with camera image) or Enter (Subst.) (Answer with substitute image) to answer a videophone call while recording. ■To play a recorded message On the standby screen, Enter ＞ "" (Record message) or "" (Record VP message) ＞ Select an item 5 Setting Public mode (Driving mode) When Public mode (Driving mode) is set, a caller hears a message that you cannot answer the call because you are driving or in a place where you have to refrain from using a mobile phone (on a train or bus, in a theater, etc.), then the call ends. 1 On the standby screen, Fn with z appears on the standy screen. ■To deactivate On the standby screen, Fn with Setting Public mode (Power OFF) When Public mode (Power OFF) is set, a caller who made a call while the power is off hears a message that you cannot answer the call because you are in a place where you have to turn off the mobile phone (in a hospital, on an airplane, around a priority seat on a train, etc.), then the call ends. 1 ＊２５２５１＞ ■To deactivate ＊２５２５０＞ 6 Using various Network Services ■ Available network services Useful DOCOMO network services are available. ・ The network services are not available when you are outside the service area or in a place where the signal is weak. ・ For details, refer to "Mobile Phone User's Guide [Network Services]". Service name Application Monthly charge Voice Mail Service Required Charged Call Waiting Required Charged Call Forwarding Service Required Free Nuisance Call Blocking Not required Free Caller ID Notification Not required Free Caller ID Request Not required Free Dual Network ServiceRequired Charged English Guidance Not required Free Multi Number Required Charged 2in1 Required Charged Public mode (Driving mode) Not required Free Public mode (Power OFF) Not required Free OFFICEED Required Charged Melody call Required Charged 7 ・ "OFFICEED" requires a subscription and is a fee based service. For details, refer to the NTT DOCOMO corporate website (http://www.docomo.biz/html/service/officeed/ (Japanese)). Setting Voice Mail Service 1 MENU ＞ " TEL function " ＞ " Voice mail service " ＞ Select an item Setting Call Waiting 1 MENU ＞ " TEL function " ＞ " Other network serv. " ＞ " Call waiting " ＞ Select an item Setting Call Waiting 1 MENU ＞ " TEL function " ＞ " Other network serv. " ＞ " Call forwarding " ＞ Select an item 8 Services available for the FOMA terminal Availabile services Phone number Directory assistance (pay: service charge + call charge) * Unlisted phone numbers cannot be given. (No area code) 104 Telegram (pay: telegram charge) (No area code) 115 Time (pay) (No area code) 117 Weather (pay) Area code for weather forecast your want +177 Police emergency (No area code) 110 Fire brigade/Ambulance emergency (No area code) 119 Maritime distress call (No area code) 118 Emergency Message Recording System (pay) (No area code) 171 Collect call (pay: service charge + call charge) (No area code) 106 ・ If you are using a "Call Forwarding" service from a general phone and if a mobile phone is set as the forwarding number, depending on the settings of the general phone or mobile phone, the caller may simply hear the ring tone even when the mobile phone is busy with another call, out of range, in Self mode or turned off. 9 ・ When calling 110, 119 or 118 from the FOMA terminal, first say you are calling from a mobile phone, give your number, and state your location clearly, because the police or fire dep…

Text truncated - open the document above for the full version.

Users Manual

Radio Frequency (RF) Signals THIS MODEL DEVICE MEETS THE U.S. GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless device contains a radio transmitter and receiver. Your device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The exposure standard for wireless mobile devices employs a unit of measurement known as the Specific Absorption Rate (SAR). The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the output. Before a device model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the U.S. government-adopted requirement for safe exposure. The highest SAR value for this model device as reported to the FCC is 0.34 W/kg. While there may be differences between the SAR levels of various devices and at various positions, they all meet the U.S. government requirement. The FCC has granted an Equipment Authorization for this model device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model device is on file with the FCC and can be found under the Display Grant section at https:// gullfoss2.fcc.gov/oetcf/eas/reports/GenericSearch.cfm after search on FCC ID A98-AZB9304. There are no body-worn accessories for this device. _____________________________________________________________________________ * In the United States, the SAR limit for wireless mobile devices used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. SAR values may vary depending upon national reporting requirements and the network band. FCC Regulations This mobile device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This mobile device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

External Photos

NEC Corporation of America FCC ID: A98-AZB9304 Model: KMP7N3B1-1A External Photos EUT Type: Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 1 of 6 © 2009 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS NEC Corporation of America FCC ID: A98-AZB9304 Model: KMP7N3B1-1A External Photos EUT Type: Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 2 of 6 © 2009 PCTEST Engineering Laboratory Inc. NEC Corporation of America FCC ID: A98-AZB9304 Model: KMP7N3B1-1A External Photos EUT Type: Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 3 of 6 © 2009 PCTEST Engineering Laboratory Inc. NEC Corporation of America FCC ID: A98-AZB9304 Model: KMP7N3B1-1A External Photos EUT Type: Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 4 of 6 © 2009 PCTEST Engineering Laboratory Inc. NEC Corporation of America FCC ID: A98-AZB9304 Model: KMP7N3B1-1A External Photos EUT Type: Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 5 of 6 © 2009 PCTEST Engineering Laboratory Inc. NEC Corporation of America FCC ID: A98-AZB9304 Model: KMP7N3B1-1A External Photos EUT Type: Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 6 of 6 © 2009 PCTEST Engineering Laboratory Inc.

ID Label/Location Info

FCC ID Label Placement Label placement Rear View of the phone Place for battery Year/month of manufacture color of UE ID for TELEC (Japanese Accreditation) ID for JATE (Japanese Accreditation) Serial Number Barcode Japanese Accreditation Mark Applicant / Manufacturer: Model code: Warning: Please switch off this device on the airplane.Please do not remove this sticker. Serial code Vendor Name: IMEI Label Layout MAC Address 4

Internal Photos

NEC Corporation of America FCC ID: A98-AZB9304 Model: KMP7N3B1-1A Internal Photos EUT Type: Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 1 of 1 © 2009 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS

Test Report

Reviewed by: FCC ID: A98-AZB9304 FCC Pt. 15B MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1003250498.A98 March 30, 2010 Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 1 of 20 © 2010 PCTEST Engineering Laboratory, Inc. REV 5.7CT 10/30/09 Applicant Name: Date of Testing: NEC Corporation of America March 30, 2010 Radio Communications Systems Division Test Site/Location: 6535 N. State Highway 161 PCTEST Lab, Columbia, MD, USA Irving, TX 75039-2402 USA Test Report Serial No.: 0Y1003250498.A98 FCC ID: A98-AZB9304 APPLICANT: NEC Corporation of America EUT Type: Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Model(s): KMP7N3B1-1A FCC Rule Part(s): FCC Part 15 Subpart B FCC Classification: FCC Class B Digital Device (JBP) Test Procedure: ANSI C63.4-2003 The device bearing the FCC Identifier specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and has been tested in accordance with the measurement procedures specified in ANSI C63.4-2003 (See Test Report). The results shown herein are also deemed satisfactory evidence of compliance with Industry Canada Interference-Causing Equipment Standard ICES-003. These measurements were performed with no deviation from the standards. Test results reported herein relate only to the item(s) tested. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 15B Certification Reviewed by: FCC ID: A98-AZB9304 FCC Pt. 15B MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1003250498.A98 March 30, 2010 Cellular WCDMA/HSDPA Phone with Bluetooth and WLAN Page 2 of 20 © 2010 PCTEST Engineering Laboratory, Inc. REV 5.7CT 10/30/09 TABLE OF CONTENTS FCC Class B MEASUREMENT REPORT.....................................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 SCOPE .................................................................................................................................................. 4 1.2 PCTEST TEST LOCATION ................................................................................................................... 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION ................................................................................................................ 5 2.2 OPERATION MODE.............................................................................................................................. 5 2.3 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ............................................................................. 5 2.4 LABELING REQUIREMENTS ............................................................................................................... 5 3.0 DESCRIPTION OF TEST.................................................................................................................6 3.1 EVALUATION PROCEDURE................................................................................................................ 6 3.2 CONDUCTED EMISSIONS ................................................................................................................... 6 3.3 RADIATED EMISSIONS........................................................................................................................ 7 4.0 SAMPLE CALCULATIONS ..............................................................................................................8 4.1 CONDUCTED EMISSION MEASUREMENT SAMPLE CALCULATION ............................................... 8 4.2 RADIATED EMISSION MEASUREMENT SAMPLE CALCULATION.................................................... 8 5.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 6.0 ENVIRONMENTAL CONDITIONS .................................................................................................10 7.0 TEST DATA ....................................................................................................................................11 7.1 SUMMARY .......................................................................................................................................... 11 7.2 TEST SUPPORT EQUIPMENT ........................................................................................................... 11 7.3 RADIATED MEASUREMENT DATA ................................................................................................... 12 7.4 LINE CONDUCTED MEASUREMENT DATA ..................................................................................... 13 8.0 CONCLUSION................................................................................................................................15 9.0 TEST SETUP PHOTOGRAPHS ..........................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos
