A98-KMP6J1CHSingle-Band PCS GSM/ EDGE Phone with Bluetooth

i Emergency Services Emergency Services Emergency Services To make an emergency call in any country ☛Press 1 1 2 Ask the operator for the service which you require: Police, Ambulance, Fire Brigade, Coastguard or Mountain Rescue Services. Give your position and, if possible, remain stationary to maintain phone contact. The 112 emergency number service is available on every digital network service. The number 999 is an alternative emergency number for the UK only, and can only be used with a valid SIM card. 2Due to the nature of the cellular system, the success of emergency calls cannot be guaranteed. General Care General Care A cellphone contains delicate electronic circuitry, magnets, and battery systems. You should treat it with care and give particular attention to the following points. •Do not allow the phone or its accessories to come into contact with liquid or moisture at any time. •Do not place anything in the folded phone. •Do not expose your phone to extreme high or low temperatures. •Do not expose your phone to naked flame, cigars or cigarettes. •Do not paint your phone. •Do not drop or subject your phone to rough treatment. •Do not place the phone alongside computer disks, credit cards, travel cards and other magnetic media. The information contained on disks or cards may be affected by the phone. •Take care not to allow metal objects, such as coins or key rings, to contact or short-circuit the terminals. •Do not dispose of your phone in a fire. Your phone's Li- ion batteries may be safely disposed of at Li-ion recycling points. For more specific battery and power supply information, see page 11. •Do not attempt to dismantle the phone or any of its accessories. •This equipment is fitted with an internal battery that can only be replaced by a qualified service engineer. •Using any Vehicle power adapter, Dual tap, AC adapter or accessory not specified by the manufacturer for use with this phone creates a potential safety hazard. •The earpiece may become warm during normal use and the unit itself may become warm during charging. •Your phone may become warm during charging and normal use. Do not expose your phone to your skin for a long time. •Use a damp or anti-static cloth to clean the phone. Do NOT use a dry cloth or electrostatically charged cloth. Do not use chemical or abrasive cleaners as these could damage the case. •Remember to recycle: the cardboard packaging supplied with this phone is ideal for recycling. •Do not leave the battery empty for a long time, otherwise some data may be initialized. •Your phone contains metal which may cause you an itch, a rash or eczema depending on your constitution or physical condition. •Take care not to put your phone in the back pocket of your trousers or skirt and then sit on it. Also, do not put your phone at the bottom of bag where it may subject to excessive weight or pressure. Doing so may damage the display and camera lens and cause them malfunction. •The foam covers the earpiece of the headset. Do not put any other part of the headset in your ears. Aircraft Safety •Switch off your phone when inside or near aircraft. The use of cellphones in aircraft is illegal. It may be dangerous to the operation of the aircraft and it may disrupt the cellular network. Failure to observe this instruction may lead to suspension or denial of the cellphone service to the offender, or legal action, or both. •Do not use your phone on the ground without the permission of the ground crew. Hospital Safety •Switch off your phone in areas where the use of cellphones is prohibited. Follow the instructions given by the respective medical facility regarding the use of cellphones on their premises. General Safety •Observe ‘Turn off 2-way radio’ signs, such as those near stores of fuel, chemicals or explosives. •Do not allow children to play with the phone or its accessories. •Small parts are included in your phone. Keep them out of reach of small children, for whom it could be a choking hazard. •The operation of some medical electronic devices, such as hearing aids and pacemakers, may be affected if a cellphone is used next to them. Observe any warning signs and manufacturer's recommendations. •Keep your phone away from precision instruments. It may cause noise or malfunction of the instruments. •If you have a weak heart, you should take extra precautions when setting functions such as the Vibrator and Ringer volume functions for incoming calls. •If you set the Vibrator setting to anything other than OFF, be careful that the phone is not near a source of heat (e.g. a heater) and that it does not fall from a desk due to the vibration. ii General Care •To avoid risk of burns do not allow the product temperature to exceed 55°C; e.g. do not leave the phone on a car dashboard or on a window sill, behind glass in direct sunlight, etc. •Do not put the phone and its adapters (including the charger) in a heating/cooking device such as a microwave oven, or a pressure cooker. Doing so will cause the phone and adapters to heat up, smoke, burst or ignite. Road Safety •You MUST exercise proper control of your vehicle at all times. Give full attention to driving. •Observe all the recommendations contained in your local traffic safety documentation. •Pull off the road and park before making or answering a call if driving conditions so require. •You MUST NOT stop on the hard shoulder of a motorway to answer or make a call, except in an emergency. •Switch off your phone at a refuelling point, such as a petrol station, even if you are not refuelling your own car. •Do not store or carry flammable or explosive materials in the same compartment where a radio transmitter, such as a cellphone, is placed. •Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection systems are not normally affected by radio transmissions. The manufacturer of such equipment can advise if it is adequately shielded from radio transmissions. If you suspect vehicle problems caus…

Text truncated - open the document above for the full version.

N500iS SAR/DoC Radio Frequency (RF) Signals(900/1800MHz) THIS NEC PHONE (MODEL N500iS) COMPLIES WITH THE EU REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your mobile phone is a radio transceiver, designed and manufactured not to exceed the SAR* limits** for exposure to radio-frequency (RF) energy, which SAR* value , when tested for compliance against the standard was (TBD)W/kg. While there may be differences between the SAR* levels of various phones and at various positions, they all meet*** the EU requirements for RF exposure. *The exposure standard for mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. **The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/kg) averaged over ten grams of tissue, recommended by The Council of the European Union. The limit incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements. *** Tests for SAR have been conducted using standard operating positions with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a base station antenna, the lower the power output. Radio Frequency (RF) Signals(1900MHz) THIS NEC PHONE (MODEL N500iS) COMPLIES WITH THE USA REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone contains a radio transmitter and receiver. Your NEC phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U. S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate (SAR). The SAR limit set by the FCC is 1.6W/kg.* Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government- adopted requirement for safe exposure. The tests are performed on position and locations (for example, at the ear and worn on the body) as required by FCC for each model. The highest SAR value for this model phone as reported to the FCC when tested for use at the ear is (TBD) W/ kg, and when worn on the body, is (TBD) W/ kg. (Body- worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement. * In the United States, the SAR limit for wireless mobile phones used by the public is 1.6 watts/ kg (W/ kg) averaged over one gram of tissue. SAR values may vary depending upon national reporting requirements and the network band. Body- worn Operation The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section at http:// www. fcc. gov/ oet/ fcid after search on FCC ID A98－KMP6J1CH. For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with a NEC accessory designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body.

ii Emergency Services and Safety Precautions •Electronic vehicle systems, such as anti-lock brakes, speed control and fuel injection systems are not normally affected by radio transmissions. The manufacturer of such equipment can advise if it is adequately shielded from radio transmissions. If you suspect vehicle problems caused by radio transmissions, consult your dealer and do not switch on your phone until it has been checked by qualified approved installers. Vehicles Equipped with an Air Bag An air bag inflates with great force. Do not place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in- vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result. Third Party Equipment The use of third party equipment, cables or accessories, not made or authorized by NEC, may invalidate the warranty of your cellphone and also adversely affect the phone’s operation. For example use only the NEC mains cable supplied with the AC charger. Service The cellphone, batteries and charger contain no user- serviceable parts. We recommend that your NEC cellphone is serviced or repaired by an NEC authorized service centre. Please contact your Service Provider or NEC for advice. Non-Ionizing Radiations The radio equipment shall be connected to the antenna via a non-radiating cable (e.g. coax). The antenna shall be mounted in a position such that no part of the human body will normally rest close to any part of the antenna unless there is an intervening metallic screen, for example, the metallic roof. Use only an antenna that has been specifically designed for your phone. Use of unauthorized antennas, modifications or attachments could damage your phone and may violate the appropriate regulations, causing loss of performance and radio frequency (RF) energy above the recommended limits. Efficient Use For optimum performance with minimum power consumption, note the following: •Your phone has the internal antenna. Do not cover part of the internal antenna of the phone with your hands. This affects call quality, may cause the phone to operate at a higher power level than needed and may shorten talk and standby times. Radio Frequency Energy Your phone is a low-power radio transmitter and receiver. When it is turned on, it intermittently receives and transmits radio frequency (RF) energy (radio waves). The system that handles the call controls the power level at which the phone transmits. Exposure to Radio Frequency Energy Your phone is designed not to exceed the limits for exposure to RF energy set by national authorities and international health agencies. * These limits are part of comprehensive guidelines and establish permitted levels of radio wave exposure for the general population. The guidelines were developed by independent scientific organizations such as ICNIRP (International Commission on Non-Ionizing Radiation Protection) through periodic and thorough evaluation of scientific studies. The limits include a substantial safety margin designed to assure the safety of all persons, regardless of age and health, and to account for any variations in measurements. * Examples of radio frequency exposure guidelines and standards that your phone is designed to conform to: •ICNIRP, “Guidelines for limiting exposure to time-varying electric, magnetic, and electromagnetic fields (up to 300 G Hz)-International Commission on Non-Ionizing Radiation Protection (ICNIRP)”. Health Physics, vol. 74. pp, 494-522, April 1998. •99/519/EC Council Recommendation on the limitation of exposure to the general public to electromagnetic fields 0 Hz- 300 GHz, Official Journal of the European Communities, July 12,1999. •ANSI/IEEE C95.1-1992. “Safety levels with respect to human exposure to radio frequency electromagnetic fields, 3kHz to 300 GHz”. The Institute of Electrical and Electronics Engineers Inc., New York, 1991. •FCC Report and Order, ET Docket 93-62, FCC 96-326, Federal Communications Commission (FCC), August 1996. •Radio communications (Electromagnetic Radiation Human Exposure) Standard 2003, Australian Communications Media Authority. FCC Notices and information to user This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or experienced radio/TV technician for help. This equipment complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2)This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Licenses •T9 ® Text Input and the T9 logo are registered trademarks of Tegic Communication. “T9 Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,187,480, 5,818,437, 5,945,928, 5,953,541, 6,011,554, 6,286,064, 6,307,548, 6,307,549, and 6,636,162, 6,646…

Text truncated - open the document above for the full version.

NEC FCC ID: A98-KMP6J1CH Single-Band EUT Photographs © 2006 PCTEST Lab. PCS GSM/EDGE Phone w/ Bluetooth & USB Data Cable NVLAP Lab Code: 100431-0 NEC FCC ID: A98-KMP6J1CH Single-Band EUT Photographs © 2006 PCTEST Lab. PCS GSM/EDGE Phone w/ Bluetooth & USB Data Cable NVLAP Lab Code: 100431-0 NEC FCC ID: A98-KMP6J1CH Single-Band EUT Photographs © 2006 PCTEST Lab. PCS GSM/EDGE Phone w/ Bluetooth & USB Data Cable NVLAP Lab Code: 100431-0 NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A

© 2006 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) KMP6J1CH1-4A IMEI Label Design (Draft)

NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A NEC FCC ID: A98-KMP6J1CH EUT Photographs © 2006 PCTEST Lab. Single-Band PCS GSM Phone w/ Bluetooth Model: KMP6J1CH1-4A

© 2006 PCTEST Engineering Laboratory, Inc. PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: NEC AMERICA INC. Date(s) of Tests: April 19, 2006 6535 N. State Hwy. 161 Test Report S/N: 0604100253 Irving, TX 75039-2402 Test Site: PCTEST Lab, Columbia, MD USA FCC ID: A98-KMP6J1CH APPLICANT: NEC AMERICA INC. SUMMARY: Equipment EUT Type: Single-Band PCS GSM/EDGE Phone w/ Bluetooth & USB Data Cable FCC Rule Part(s): FCC Part 15 Subpart B FCC Classification: FCC Class B Digital Device (JBP) Test Procedure(s): ANSI C63.4-2003 / EN55022: 1998 w/ A1 (2000) + A2 (2003) The device bearing the FCC Identifier specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and has been tested in accordance with the measurement procedures specified in ANSI C63.4-2003 (See Test Report). These measurements were performed with no deviation from the standards. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST™ PT. 15. REPORT MEASUREMENT REPORT FCC Part 15B Reviewed by: Quality Manager Filename: 0604100253 Test Dates: April 19, 2006 EUT: Single-Band PCS GSM/EDGE Phone w/ Bluetooth & USB Data Cable FCC ID: A98-KMP6J1CH Page i of i © 2006 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS ATTACHMENT A. COVER LETTER ATTACHMENT B. ATTESTATION STATEMENT(S) ATTACHMENT C. TEST REPORT FCC Class B MEASUREMENT REPORT COVER PAGE ......................................................................... 1 1.0 INTRODUCTION ................................................................................................................................. 2 1.1 EVALUATION PROCEDURE............................................................................................................................................. 2 1.2 SCOPE ................................................................................................................................................................................... 2 1.3 PCTEST TEST LOCATION ................................................................................................................................................. 2 2.0 PRODUCT INFORMATION................................................................................................................3 2.1 EQUIPMENT DESCRIPTION.............................................................................................................................................. 3 2.2 OPERATION MODE ............................................................................................................................................................ 3 2.3 EMI SUPPRESSION DEVICE(S)......................................................................................................................................... 3 3.0 DESCRIPTION OF TEST.....................................................................................................................4 3.1 CONDUCTED EMISSIONS ................................................................................................................................................. 4 3.2 RADIATED EMISSIONS ..................................................................................................................................................... 5 4.0 SAMPLE CALCULATIONS ................................................................................................................6 4.1 CONDUCTED EMISSION MEASUREMENT SAMPLE CALCULATION ..................................................................... 6 4.2 RADIATED EMISSION MEASUREMENT SAMPLE CALCULATION ......................................................................... 6 5.0 UNCERTAINTY OF MEASUREMENT .............................................................................................7 5.1 LINE CONDUCTED MEASUREMENT UNCERTAINTY CALCULATIONS................................................................ 7 5.2 RADIATED EMISSIONS MEASUREMENT UNCERTAINTY CALCULATIONS ........................................................ 8 6.0 TEST EQUIPMENT CALIBRATION DATA......................................................................................9 7.0 ENVIRONMENTAL CONDITIONS ...................................................................................................10 8.0 CONCLUSION ..................................................................................................................................... 11 ATTACHMENT D. SUMMARY OF TEST RESULTS RADIATED TEST DATA LINE-CONDUCTED TEST DATA/PLOT(S) SUPPORT EQUIPMENT USED ATTACHMENT E. FCC ID LABEL & LOCATION ATTACHMENT F. BLOCK(S)/ SCHEMATIC(S) DIAGRAM ATTACHMENT G. TEST SETUP PHOTOGRAPHS ATTACHMENT H. EXTERNAL PHOTOGRAPHS ATTACHMENT I. INTERNAL PHOTOGRAPHS ATTACHMENT J. USER’S MANUAL PCTEST™ PT. 15. REPORT MEASUREMENT REPORT FCC Part 15B Reviewed by: Quality Manager Filename: 0604100253 Test Dates: April 19, 2006 EUT: Single-Band PCS GSM/EDGE Phone w/ Bluetooth & USB Data Cable FCC ID: A98-KMP6J1CH Page 1 of 11 © 2006 PCTEST Engineering Laboratory, Inc. MEASUREMENT REPORT A. General Information APPLICANT: NEC AMERICA INC. APPLICANT ADDRESS: 6535 N. State Hwy. 161 Irving, TX 75039-2402 TEST SITE: PCTEST ENGINEERING LABORATORY, IN…
