1 ■ Muting your voice to the other party ▶ "Mute" • Tap to toggle the mute ON/OFF. ■ Using the Bluetooth function ▶ "Bluetooth" • Tap to toggle the function ON/OFF. Available when connected to a Bluetooth device compatible with your headset, handsfree, etc. 4 When the call is finished, "" NOTE ⿟ Tap " " or touch and hold "1" to make a call to 1417 (Voice Mail service). ■ Emergency call Emergency callPhone number Police emergency110 Fire brigade/Ambulance emergency 119 Maritime distress call118 Making/Receiving Calls Making a call 1 From the application list screen, "Phone" 2 Enter the phone number • If you enter a wrong number, tap to delete the number. • Enter "186"/"184" before entering the number to notify/not notify your number, for that call only. ■ Entering a push tone (pause) ▶ MENU key ▶ "Add 2-sec pause"/"Add wait pause" 3 "" ■ Adjusting the call volume ▶ Press the volume key ■ Muting the microphone ▶ "Hold" • Tap "Unhold" to cancel call hold. • To place a call on hold, a subscription to Call Waiting service is required. ■ Putting the other party on the speaker ▶ "Speaker" • Tap to toggle the speaker ON/OFF. Calling 2 ⿟ This terminal supports "Emergency Location Report". Calls made to emergency service organizations (e.g. by dialing 110, 119 or 118) disclose information on the caller's location to the organization receiving the call. The location information and phone number are not disclosed when, before each individual call made, "184" or another blocking prefix is dialed first. If the information is deemed necessary for the protection of life, etc., this information may be acquired by the organization being called. Locations/timing planned for adoption of this feature vary according to the status of the preparations by the relevant emergency service organizations. ⿟ When calling 110, 119 or 118 from this terminal, first say you are calling from a mobile phone, give your number, and state your location clearly, because the police or fire department may call you back for confirmation. Also, do not move around when making the call. Do not turn off the power immediately after ending the call, but leave it turned on for ten minutes or so, so that you can receive a call. ⿟ Depending on the area you are calling from, you may not be connected with the nearest police or fire department, etc. NOTE ⿟ When you have set PIN1 code entry and Airplane mode, you need to enter the PIN1 code to make an emergency call. ⿟ When you have locked the screen, you can make an emergency call without drawing screen unlock pattern and entering Lock No. for each screen. On each screen, tap "Emergency call". The "Emergency Dialer" screen appears; you can make phone calls only to the emergency phone numbers. ⿟ In Japan, the 110, 119, and 118 emergency numbers cannot be dialed from this terminal when the miniUIM is not set to it. ⿟ In Japan, the 110, 119, and 118 emergency numbers cannot be dialed by tapping "Emergency call" from the PIN code input screen on startup. Making an international call (WORLD CALL) WORLD CALL is an international phone service that can be used from DOCOMO mobile phones. ⿟ For details on WORLD CALL, refer to DOCOMO "International Services website". 1 From the application list screen, "Phone" 2 Touch and hold "0" • A plus sign "+" appears. 3 3 Enter the country code → area code (city code) → recipient's phone number ▶ " " NOTE ⿟ If the area code begins with "0", omit "0". However, "0" may be required for calling some countries or areas, such as Italy. Receiving a call 1 When a call is received, drag to (to the right) ■ Declining a call ▶ Drag to (to the left) 2 When the call is finished, "" NOTE ⿟ If you decline an incoming call when Voice Mail service or Call Forwarding service are set to "Activate", the call is forwarded to the Voice Mail service center or the designated forwarding number.

54 付録 Radio Frequency (RF) Signals THIS MODEL PHONE MEETS THE U.S. GOVERNMENT'S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone contains a radio transmitter and receiver. Your phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate (SAR). The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the U.S. government-adopted requirement for safe exposure. The tests are performed on position and locations (for example, at the ear and worn on the body) as required by FCC for each model. The highest SAR value for this model phone as reported to the FCC when tested for use at the ear is 0.66 W/kg, and when worn on the body, is 1.06 W/kg. (Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the U.S. government requirement. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section at https://gullfoss2.fcc.gov/oetcf/eas/reports/ GenericSearch.cfm after search on FCC ID A98- QOE9653. For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with an accessory designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 1.0 cm from the body. 55 付録 Non-compliance with the above restrictions may result in violation of FCC RF Exposure guidelines. ---------------------------------------------------------------------------- *⿟In⿟ the⿟ United⿟States,⿟the⿟ SAR⿟ limit⿟ for⿟ wireless⿟mobile⿟phones⿟used⿟by⿟the⿟public⿟is⿟ 1.6⿟ watts/kg⿟(W/kg)⿟averaged⿟over⿟ one⿟ gram⿟of⿟ tissue.⿟SAR⿟values⿟may⿟ vary⿟ depending⿟upon⿟national⿟reporting⿟ requirements⿟and⿟the⿟network⿟band. FCC Regulations This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. •⿟Increase⿟the⿟ separation⿟between⿟the⿟ equipment⿟and⿟receiver. •⿟Connect⿟the⿟ equipment⿟into⿟ an⿟ outlet⿟on⿟ a⿟ circuit⿟different⿟from⿟that⿟ to⿟ which⿟the⿟ receiver⿟is⿟connected. •⿟Consult⿟the⿟ dealer⿟or⿟ an⿟ experienced⿟radio/ TV⿟technician⿟for⿟help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Declaration of Conformity Hereby, NEC CASIO Mobile Communications, Ltd. declares that this product is compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Declaration of Conformity can be found on http://www.n-keitai.com/lineup/index.html (Japanese only). This product uses non-harmonised frequency and is intended for use in all European countries. The WLAN can be operated in the EU without restriction indoors, but cannot be operated outdoors in France. 56 付録 This mobile phone complies with the EU requirements for exposure to radio waves. Your mobile phone is a radio transceiver, designed and manufactured not to exceed the SAR* limits** for exposure to radio-frequency (RF) energy, which SAR* value, when tested for compliance against the standard was 0.471 W/kg. While there may be differences between the SAR* levels of various phones and at various positions, they all meet*** the EU requirements for RF exposure. *⿟ The⿟ exposure⿟standard⿟for⿟ mobile⿟phones⿟ employs⿟a⿟ unit⿟ of⿟ measurement⿟known⿟as⿟ the⿟Specific⿟Absorption⿟Rate,⿟or⿟SAR. ** ⿟ The⿟ SAR⿟ limit⿟ for⿟ mobile⿟phones⿟used⿟ by⿟ the⿟ public⿟is⿟ 2.0⿟ watts/kilogram⿟(W/kg)⿟ averaged⿟over⿟ten⿟ grams⿟of⿟ tissue,⿟ recommended⿟by⿟ The⿟ Council⿟of⿟ the⿟ Europea…

Text truncated - open the document above for the full version.

FCC ID Label Placement Label placement (on the device) Rear View of the phone Place for battery IMEI Label Layout Serial Number Barcode Year / Month of Manufacture Serial Number TELEC Certification Number Color Applicant / Manufacturer Model Name Warning:Please switch off this mobile phone on the airplane.Please do not remove this sticker. Japanese Accreditation Mark FCC ID Vendor Name JATE Certification Number Bluetooth NEC CASIO MOBILE COMMUNICATIONS Confidential

Test report No. : 32EE0075-HO-I-R1 Page : 1 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 13-EM-F0429 SAR TEST REPORT Test Report No. : 32EE0075-HO-I-R1 Applicant :NEC Corporation of America Type of Equipment :Digital Portable Cellular Telephone Model No. :KMP7N4AC1-3A FCC ID :A98-QOE9653 Test regulation :FCC47CFR 2.1093 FCC OET Bulletin 65, Supplement C (Edition 01-01) Test Result :Complied FCC Part 22H Head : 0.47W/kg Body-hotspot : 0.72W/kg (10mm distance) FCC Part 24E Head : 0.66W/kg Body-hotspot : 1.06W/kg (10mm distance) FCC Part15.247 Head : 0.11W/kg Body-hotspot : 0.02W/kg (10mm distance) 1. This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc. 2. The results in this report apply only to the sample tested. 3. This sample tested is in compliance with the limits of the above regulation. 4. The test results in this report are traceable to the national or international standards. 5. This test report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. 6. This report is a revised version of 32EE0075-HO-I . 32EE0075-HO-I is replaced with this report. Date of test: December 16 to 21, 2011 Representative test engineer: Miyo Kishimoto Engineer of WiSE Japan, UL Verification Service Approved by : Takahiro Hatakeda Leader of WiSE Japan UL Verification Service NVLAP LAB CODE: 200572-0 This laboratory is accredited by the NVLAP LAB CODE 200572-0, U.S.A. The tests reported herein have been performed in accordance with its terms of accreditation. *As for the range of Accreditation in NVLAP, you may refer to the WEB address, http://www.ul.com/japan/jpn/pages/services/emc/about/m ark1/index.jsp#nvlap Test report No. : 32EE0075-HO-I-R1 Page : 2 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 SECTION 1: Customer information ................................................................................................................................................................... 3 SECTION 2: Equipment under test (E.U.T.) ..................................................................................................................................................... 3 2.1 Identification of E.U.T. ....................................................................................................................................... 3 SECTION 3 : Test standard information ........................................................................................................................................................... 6 3.1 Test Specification ............................................................................................................................................... 6 3.2 Procedure ............................................................................................................................................................ 6 3.3 Exposure limit .................................................................................................................................................... 7 3.4 Test Location ...................................................................................................................................................... 7 SECTION 4 : Test result ....................................................................................................................................................................................... 8 4.1 Stand-alone SAR result....................................................................................................................................... 8 4.2 Simultaneous transmission SAR result ............................................................................................................... 8 SECTION 5 : Description of the operating mode .............................................................................................................................................. 10 5.1 Output power operating modes ........................................................................................................................... 10 5.2 SAR testing operating modes ............................................................................................................................. 11 5.3 SAR testing operating modes ............................................................................................................................. 15 5.4 Confirmation before SAR testing ....................................................................................................................... 18 5.5 Confirmation after SAR testing .......................................................................................................................... 18 SECTION6 : Description of the Head/ Body / Body-Worn setup .................................................................................................................... 19 6.1 Test position for Head setup ............................................................................................................................... 19 6.2 Description of the Body setup ............................................................................................................................ 21 6.3 Description of the Body-worn setup ................................................................................................................... 21 SECTION 7 : Test surrounding ...................................................................................................................…

Text truncated - open the document above for the full version.

Test report No. : 32EE0075-HO-I-R1 Page : 33 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 APPENDIX 1 : SAR Measurement data 1. Evaluation procedure The evaluation was performed with the following procedure: Step 1: Measurement of the E-field at a fixed location above the ear point or central position of flat phantom was used as a reference value for assessing the power drop. Step 2: The SAR distribution at the exposed side of head or body position was measured at a distance of each device from the inner surface of the shell. The area covered the entire dimension of the antenna of EUT and the horizontal grid spacing was 15 mm x 15 mm (or 10mm x 10mm). Based on these data, the area of the maximum absorption was determined by spline interpolation. Step 3: Around this point found in the Step 2 (area scan) , a volume of 30mm x 30mm x 30mm or more was assessed by measuring 7 x 7 x 7 points at least. And for any secondary peaks found in the Step2 which are within 2dB of maximum peak and not with this Step3 (Zoom scan) is repeated. On the basis of this data set, the spatial peak SAR value was evaluated under the following procedure: (1). The data at the surface were extrapolated, since the center of the dipoles is 1mm(EX3DV3) away from the tip of the probe and the distance between the surface and the lowest measuring point is 1.3 mm. The extrapolation was based on a least square algorithm [4]. A polynomial of the fourth order was calculated through the points in z-axes. This polynomial was then used to evaluate the points between the surface and the probe tip. (2). The maximum interpolated value was searched with a straightforward algorithm. Around this maximum the SAR values averaged over the spatial volumes (1 g or 10 g) were computed by the 3D-Spline interpolation algorithm. The 3D- Spline is composed of three one-dimensional splines with the “Not a knot"-condition (in x, y and z-directions) [4], [5]. The volume was integrated with the trapezoidal-algorithm. One thousand points (10 x 10 x 10) were interpolated to calculate the average. (3). All neighboring volumes were evaluated until no neighboring volume with a higher average value was found. Step 4: Re-measurement of the E-field at the same location as in Step 1. Test report No. : 32EE0075-HO-I-R1 Page : 34 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 2. Measurement data 1. GSM850 Head KMP7N4AC1-3A_GSM850 (GSM)_836.6MHz_Left Cheek Communication System: Generic GSM; Communication System Band: GSM 850 (824.0 - 849.0 MHz); Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.892 mho/m; ε r = 42.081; ρ = 1000 kg/m 3 Phantom section: Left Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration Probe: EX3DV4 - SN3540; ConvF(10.02, 10.02, 10.02); Calibrated: 2011/07/21 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn509; Calibrated: 2011/07/20 Phantom: SAM with CRP; Type: SAM; Measurement SW: DASY52, Version 52.6 (2); Left-Hand-Side HSL/Touch Position - Mid/Area Scan (91x141x1): Measurement grid: dx=10mm, dy=10mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.385 mW/g Left-Hand-Side HSL/Touch Position - Mid/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.095 V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 0.399 W/kg SAR(1 g) = 0.308 mW/g; SAR(10 g) = 0.218 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.363 mW/g Date: 2011/12/20 Ambient Temp. : 24.0 degree.C. Liquid Temp.; 23.5 degree.C. Test report No. : 32EE0075-HO-I-R1 Page : 35 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 KMP7N4AC1-3A_GSM850 (GSM)_836.6MHz_Left tilt Communication System: Generic GSM; Communication System Band: GSM 850 (824.0 - 849.0 MHz); Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium parameters used (interpolated): f = 836.6 MHz; σ = 0.892 mho/m; ε r = 42.081; ρ = 1000 kg/m 3 Phantom section: Left Section Measurement Standard: DASY5 (IEEE/IEC/ANSI C63.19-2007) DASY5 Configuration Probe: EX3DV4 - SN3540; ConvF(10.02, 10.02, 10.02); Calibrated: 2011/07/21 Sensor-Surface: 2mm (Mechanical Surface Detection) Electronics: DAE4 Sn509; Calibrated: 2011/07/20 Phantom: SAM with CRP; Type: SAM; Measurement SW: DASY52, Version 52.6 (2); Left-Hand-Side HSL/Tilt Position - Mid/Area Scan (81x131x1): Measurement grid: dx=10mm, dy=10mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.348 mW/g Left-Hand-Side HSL/Tilt Position - Mid/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 14.642 V/m; Power Drift = -0.10dB Peak SAR (extrapolated) = 0.374 W/kg SAR(1 g) = 0.282 mW/g; SAR(10 g) = 0.205 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.335 mW/g Date: 2011/12/20 Ambient Temp. : 24.0 degree.C. Liquid Temp.; 23.5 degree.C. Test report No. : 32EE0075-HO-I-R1 Page : 36 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 KMP7N4AC1-3A_GSM850 (GSM)_836.6MHz_Right Cheek Communication System: Generic GSM; Communication System Band: GSM 850 (824.0 - 849.0 MHz); Frequency: 836.6 MH…

Text truncated - open the document above for the full version.

Test report No. : 32EE0075-HO-I-R1 Page : 130 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 APPENDIX 3 : System specifications 1. Configuration and peripherals The DASY5 system for performing compliance tests consist of the following items: a) A standard high precision 6-axis robot (Stäubli RX family) with controller and software. An arm extension for accommodating the data acquisition electronics (DAE). b) An isotropic field probe optimized and calibrated for the targeted measurement. c) A data acquisition electronic (DAE), which performs the signal amplification, signal multiplexing, AD-conversion, offset measurements, mechanical surface detection, collision detection, etc. The unit is battery powered with standard or rechargeable batteries. The signal is optically transmitted to the EOC. d) The Electro-optical converter (EOC) performs the conversion between optical and electrical of the signals for the digital communication to the DAE and for the analog signal from the optical surface detection. The EOC is connected to the measurement server. e) The function of the measurement server is to perform the time critical tasks such as signal filtering, control of the robot operation and fast movement interrupts. f) The Light Beam used is for probe alignment. This improves the (absolute) accuracy of the probe positioning. g) A computer running WinXP and the DASY5 software. h) Remote control with teaches pendant and additional circuitry for robot safety such as warning lamps, etc. i) The phantom, the device holder and other accessories according to the targeted measurement. Test report No. : 32EE0075-HO-I-R1 Page : 131 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 2. Specifications a)Robot TX60L Number of Axes : 6 Nominal Load : 2 kg Maximum Load : 5kg Reach : 920mm Repeatability : +/-0.03mm Control Unit : CS8c Programming Language : VAL3 Weight : 52.2kg Manuafacture : Stäubli Robotics b)E-Field Probe Model : EX3DV3 Serial No. : 3507 Construction : Symmetrical design with triangular core Built-in shielding against static charges PEEK enclosure material (resistant to organic solvents, e.g., glycol ether) Frequency : 10 MHz to > 6 GHz Linearity: ± 0.2 dB (30 MHz to 6 GHz) Directivity : +/-0.3 dB in HSL (rotation around probe axis) +/-0.5 dB in tissue material (rotation normal probe axis) Dynamic Range : 10uW/g to > 100 mW/g;Linearity +/-0.2 dB(noise: typically < 1uW/g) Dimensions : Overall length: 337 mm (Tip: 20 mm) Tip diameter: 2.5mm (Body: 12 mm) Typical distance from probe tip to dipole centers: 1 mm Application : Highprecision dosimetric measurement in any exposure scenario (e.g., very strong gradient fields).Only probe which enables compliance testing for frequencies up to 6GHz with precision of better 30%. Manufacture : Schimid & Partner Engineering AG c)Data Acquisition Electronic (DAE4) Features : Signal amplifier, multiplexer, A/D converter and control logic Serial optical link for communication with DASY5 embedded system (fully remote controlled) Two step probe touch detector for mechanical surface detection and emergency robot stop Measurement Range : -100 to +300 mV (16 bit resolution and two range settings: 4mV, 400mV) Input Offset voltage : < 5 μV (with auto zero) Input Resistance : 200 MΩ Input Bias Current : < 50 fA Battery Power : > 10 h of operation (with two 9.6 V NiMH accus) Dimension : 60 x 60 x 68 mm Manufacture : Schimid & Partner Engineering AG d)Electro-Optic Converter (EOC) Version : EOC 61 Descrption : for TX60 robot arm, including proximity sensor Manufacture : Schimid & Partner Engineering AG EX3DV3 E-field Probe Test report No. : 32EE0075-HO-I-R1 Page : 132 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 e)DASY5 Measurement server Features : Intel ULV Celeron 400MHz 128MB chip disk and 128MB RAM 16 Bit A/D converter for surface detection system Vacuum Fluorescent Display Robot Interface Serial link to DAE (with watchdog supervision) Door contact port (Possibility to connect a light curtain) Emergency stop port (to connect the remote control) Signal lamps port Light beam port Three Ethernet connection ports Two USB 2.0 Ports Two serial links Expansion port for future applications Dimensions (L x W x H) : 440 x 241 x 89 mm Manufacture : Schimid & Partner Engineering AG f) Light Beam Switches Version : LB5 Dimensions (L x H) : 110 x 80 mm Thickness : 12 mm Beam-length : 80 mm Manufacture : Schimid & Partner Engineering AG g)Software Item : Dosimetric Assesment System DASY5 Type No. : SD 000 401A, SD 000 402A Software version No. : DASY52, Version 52.6 (1) Manufacture / Origin : Schimid & Partner Engineering AG h)Robot Controll Unit Weight : 70 Kg AC Input Voltage : selectable Manufacturer : Stäubli Robotics Test report No. : 32EE0075-HO-I-R1 Page : 133 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 i)Phantom and Device Holder Phantom Type : SAM Twin Phantom V4.0 Description : The shell corresponds to the specifications of the Specific Anthropomorphic Mannequin (SAM) phantom defined in IEEE 1528 and IEC 62209-1. It enables the dosimetric evaluation of left and right hand phone usage as well as body mounted usage at the flat phantom region. A cover prevents evaporation of the liquid. Reference markings on the phantom allow the comple…

Text truncated - open the document above for the full version.

Test report No. : 32EE0075-HO-I-R1 Page : 114 of 157 FCC ID : A98-QOE9653 Issued date : December 29, 2011 Revised date : January 17, 2012 UL Japan, Inc. Head Office EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone: +81 596 24 8116 Facsimile: +81 596 24 8124 5 System validation result for 2450MHz System validation result Head 2450 Simulated Tissue Liquid Parameter confirmation Date Ambient Temp. [deg.c] Relative Humidity [%] Liquid type Liquid Temp. [deg.c] Measured Frequency [MHz] Parameters Target Value*1 Measured Deviation [%] Limit [%] εr 39.238.3-2.3+/-5 σ [mho/m] 1.801.842.2+/-5 εr: Relative Permittivity / σ : Coductivity *1 The Target value is a parameter defined in FCC OET 65. 382450 DIELECTRIC PARAMETERS MEASUREMENT RESULTS 21-Dec23.5 HSL 2450 24 System validation result (for IEEE1528) Forward Power 250mWConversion 1WDeviationLimit MeasuredCalculation[%][%] 21-Dec2450.0013.6054.4052.403.8+/-10 *1 The taget value is the parameter defined in IEEE 1528. SYSTEM VALIDATION Date SAR 1g [W/kg] Target 1W *1 Frequenc y [MHz] Simulated Tissue Liquid Parameter confirmation (for calibration by manufacture) Date Ambient Temp. [deg.c] Relative Humidity [%] Liquid type Liquid Temp. [deg.c] Measured Frequency [MHz] Parameters Target Value*3 Measured Deviation [%] Limit*4 [%] εr 39.038.3-1.8+/-6 σ [mho/m] 1.741.845.7+/-6 εr: Relative Permittivity / σ : Coductivity *4 The limit is for deviation provided by manufacture. *3 The target value is the calibrated dipole Body TSL parameters. (D2450V2 SN:713, Measured Body TSL parameters) 382450 DIELECTRIC PARAMETERS MEASUREMENT RESULTS 21-Dec23.5 MSL 2450 24 System validation result (f…
