A98-TBP4266Cellular WCDMA/ GSM and PCS GSM Phone with WLAN, RFID and Bluetooth

1 Radio Frequency (RF) Signals THIS MODEL PHONE MEETS THE U.S. GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone contains a radio transmitter and receiver. Your phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate (SAR). The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the U.S. government-adopted requirement for safe exposure. The tests are performed on position and locations (for example, at the ear and worn on the body) as required by FCC for each model. The highest SAR value for this model phone as reported to the FCC when tested for use at the ear is 0.999 W/kg, and when worn on the body, is 0.799 W/kg. (Body- worn measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the U.S. government requirement. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section at https:// gullfoss2.fcc.gov/oetcf/eas/reports/GenericSearch.cfm after search on FCC ID A98-TBP4266. For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with an accessory designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body. Non-compliance with the above restrictions may result in violation of FCC RF Exposure guidelines. * In the United States, the SAR limit for wireless mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. SAR values may vary depending upon national reporting requirements and the network band. 2 FCC Regulations This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Calling You can use the Phone application to make a call. You can dial an incoming, outgoing, or missed call number recorded in the call log. You can use the FOMA terminal to make international calls and emergency calls, as well as standard calls. 1 Tap [Phone] icon on the Home screen. 2 Enter the phone number → tap [Phone] icon. ・If you enter a wrong number, tap [Back] icon to delete the number. 1 Tap [Phone] icon on the Home screen. 2 Enter any emergency number (110; Police, 119; Fire department or ambulance service, 118; Japan Coast Guard) → tap [Phone] icon. <Note> ・ While the Screen lock is set, you cannot use FOMA terminal without releasing the Screen lock. However, you can only make an emergency call. ・ In Japan, making an emergency call (110, 119 and 118) is not possible without a UIM. ・ In Japan, making an emergency call (110, 119 and 118) is not possible from the PIN code input screen. 1 Tap [End a call] icon during a call. Ending a call Making an emergency call Making a call Making a call 1 Making an international call (WORLD CALL) WORLD CALL is an international phone service that can be used from DOCOMO mobile phones. Customers who have subscribed to the FOMA service would also have automatically subscribed to "WORLD CALL" at the same time. However, if you declined to use "WORLD CALL" when you subscribed to the FOMA services, you need to make a sep…

Text truncated - open the document above for the full version.

FCC ID Label Placement Label placement Place for battery Rear View of the phoneRear View of the phone IMEI Label Layout NEC CASIO MOBILE COMMUNICATIONS Confidential Vendor NameVendor Name Colo r Japanese Accreditation Mark Year / Month of Manufacture Model Name Serial N mberSerial Number Barcode Common Battery Mark TELEC Certification Number Serial N u mber JATE Certification Number FCC ID Warning: Pl it h ff thi bil h Applicant / Manufacturer WLAN Mark Pl ease sw it c h o ff thi s mo bil e p h one on the airplane.Please do not remove this sticker.

Test report No. : 31EE0214-HO-03-D-R1 Page : 1 of 15 Issued date : February 7, 2011 FCC ID : A98-TBP4266 Revised date : February 15, 2011 UL Japan, Inc. SHONAN EMC Lab. 1-22-3 Megumigaoka Hiratsuka-shi Kanagawa-ken 259-1220 JAPAN telephone: +81 463 50 6400 / facsimile: +81 463 50 6401 EMI TEST REPORT Test Report No. : 31EE0214-HO-03-D-R1 Applicant : NEC CASIO Mobile Communications, Ltd. Type of Equipment : Digital Portable Cellular Telephone Model No. : KMP7N4Y1-2A FCC ID : A98-TBP4266 Test standard : FCC Part 15 Subpart B: 2010 Class B Test Result : Complied 1. This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc. 2. The results in this report apply only to the sample tested. 3. This sample tested is in compliance with the limits of the above regulation. 4. The test results in this test report are traceable to the national or international standards. 5. This test report must not be used by the customer to claim product certification, approval, or endorsement by any agency of the Federal Government. 6. The opinions and the interpretations to the result of the description in this report are outside scopes where UL Japan has been accredited. 7. This report is a revised version of 31EE0214-HO-03-D. 31EE0214-HO-03-D is replaced with this report. Date of test: _____________________________ Representative test engineer: ______________________________ Yohsuke Matsuzawa Engineer of WiSE Japan, UL Verification Service Approved by : ______________________________ Go Ishiwata Assistant Manager of WiSE Japan, UL Verification Service RTL02610 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan. There is no testing item of "Non-accreditation". January 5 and February 14, 2011 MF058d (12.01.11) Test report No. : 31EE0214-HO-03-D-R1 Page : 2 of 15 Issued date : February 7, 2011 FCC ID : A98-TBP4266 Revised date : February 15, 2011 UL Japan, Inc. SHONAN EMC Lab. 1-22-3 Megumigaoka Hiratsuka-shi Kanagawa-ken 259-1220 JAPAN telephone: +81 463 50 6400 / facsimile: +81 463 50 6401 CONTENTS PAGE SECTION 1: Customer information ...................................................................................... 3 SECTION 2: Equipment under test (E.U.T.) ........................................................................ 3 SECTION 3: Test specification, procedures & results ......................................................... 4 SECTION 4: Operation of E.U.T. during testing ................................................................. 6 SECTION 5: Conducted Emission ......................................................................................... 8 SECTION 6: Radiated Emission ............................................................................................ 9 APPENDIX 1: Photographs of test setup............................................................................. 11 APPENDIX 2: Test data .................................................................................................................... 12 APPENDIX 3: Test instruments ....................................................................................................... 15 Test report No. : 31EE0214-HO-03-D-R1 Page : 3 of 15 Issued date : February 7, 2011 FCC ID : A98-TBP4266 Revised date : February 15, 2011 UL Japan, Inc. SHONAN EMC Lab. 1-22-3 Megumigaoka Hiratsuka-shi Kanagawa-ken 259-1220 JAPAN telephone: +81 463 50 6400 / facsimile: +81 463 50 6401 SECTION 1: Customer information Company Name : NEC CASIO Mobile Communications, Ltd. Address : 1753 Shimonumabe, Nakahara-ku, Kawasaki, Kanagawa 211-8666 Japan Telephone Number : +81-44-455-8045 Facsimile Number : +81-44-455-8025 Contact Person : Kazuhiro Kurihara SECTION 2: Equipment under test (E.U.T.) 2.1 Identification of E.U.T. Type of Equipment : Digital Portable Cellular Telephone Model No. : KMP7N4Y1-2A Serial No. : Refer to Section 4, Clause 4.2 Rating : DC 3.8V Receipt Date of Sample : December 23, 2010 Country of Mass-production: Japan Condition of EUT : Production prototype Modification of EUT : No Modification by the test lab 2.2 Product description Model No: KMP7N4Y1-2A, (referred to as the EUT in this report), is the Digital Portable Cellular Telephone. Radio Specification Bluetooth (Ver.2.1 + EDR) Equipment Type Transceiver Frequency of Operation 2402-2480MHz Other Clock Frequency 19.2MHz Type of Modulation FHSS Bandwidth & Channel spacing 1MHz & 1MHz Antenna Connector Type Integrated antenna WLAN (IEEE802.11b/g/n (SISO/HT20) Equipment Type Transceiver Frequency of Operation 2400-2483.5MHz Other Clock Frequency 19.2MHz Type of Modulation DSSS, OFDM Antenna Connector Type Integrated antenna W-CDMA Equipment Type Transceiver Frequency of Operation [Up Link] Band V: 824 – 849MHz [Down Link] Band V: 869 – 894MHz Other Clock Frequency 19.2MHz Type of Modulation QPSK Channel spacing 5MHz Antenna Connector Type Integrated antenna RFID Equipment Type Transceiver Frequency of Operation 13.56MHz Type of Modulation ASK Antenna Connector Type Integrated antenna Equipment Type Transceiver Frequency of Operation [Up Link] GSM850: 824 – 849MHz PCS: 1850 – 1910MHz [Down Link] GSM850: 869 – 894MHz PCS: 1930 – 1990MHz Other Clock Frequency 19.2MHz Type of Modulation GMSK Channel spacing 200kHz Antenna Connector Type Integrated antenna Equipment Type Receiver Receiver Type Direct Downconversion Frequency of Operation 1575.42MHz Other Clock Frequency 19.2MHz Antenna Connector Type Integrated antenna GSM GPS Test report No. : 31EE0214-HO-03-D-R1 Page : 4 of 15 Issued date : February 7, 2011 FCC ID : A98-TBP4266 Revised date : February 15, 2011 UL Japan, Inc. SHONAN EMC Lab. 1-22-3 Megumigaoka Hiratsuka-shi Kanagawa-ken 259-1220 JAPAN telephone: +81 463 50 6400 / facsimile: +81 463 50 6401 SECTION 3: Test specification, procedures & results 3.1 Test specification Test Specification : FCC Part 15 Subpart B: 2010, final revised on December 6, 2010 and effective…

Text truncated - open the document above for the full version.

Test report No. : 31EE0214-HO-03-D-R1 Page : 1 of 2 Issued date : February 7, 2011 FCC ID : A98-TBP4266 Revised date : February 15, 2011 UL Japan, Inc. SHONAN EMC Lab. 1-22-3 Megumigaoka Hiratsuka-shi Kanagawa-ken 259-1220 JAPAN telephone: +81 463 50 6400 / facsimile: +81 463 50 6401 APPENDIX 1: Photographs of test setup Conducted Emission Photo 1 Photo 2 Test report No. : 31EE0214-HO-03-D-R1 Page : 2 of 2 Issued date : February 7, 2011 FCC ID : A98-TBP4266 Revised date : February 15, 2011 UL Japan, Inc. SHONAN EMC Lab. 1-22-3 Megumigaoka Hiratsuka-shi Kanagawa-ken 259-1220 JAPAN telephone: +81 463 50 6400 / facsimile: +81 463 50 6401 Radiated Emission Front Rear (below 1GHz) Rear (above 1GHz)
