A98-XGU3296PCS GSM and Cellular WCDMA Phone with NFC

1 Making a call/videophone call As N-03D is not equipped with the front camera, during a videophone call, you can send only the substitute image (Chara-den) or image from the rear camera to the other party. Making a call by entering the phone number Enter the phone number starting with the area code, then r (voice call) / u (V.phone) After the call ends, y Making a call from phonebook Add the phone number of the other party to the phonebook in advance. g (Search phonebook) to select a search condition and search the phonebook s b to select an entry, then r (voice call) / u (1 second or longer) (V.phone) Making a call with redials/received calls j (Redial) or h (Received calls) to select the other party, then r (voice call) / u (V.phone) Using Koe-no-Takuhaibin This is a service to record a voice message and deliver it to the other party. Enter the other party's phone number, then o (Koetaku) Follow the operation guidance and record a message The other party will be notified that a message is waiting. To play a recorded message On the Recording notification SMS detail screen, "" (Play) s "YES" Also, it can be played from: is"TEL function" s "Koe-no-Takuhaibin" s "Play messages" s"YES". Call Telephone 2 Making an international call Use WORLD CALL to make international calls from Japan. For WORLD CALL, please contact "General Inquiries". 010sCountry codesArea code (City code)sThe other party's phone number s r (voice call) / u (V.phone) After the call ends, y Dial the other party's phone number excluding "0" at the beginning of the area code (city code). However, to make a call to some countries/areas, such as in Italy, "0" is required. You can make calls from overseas. ( p.5) Receiving a call/videophone call When you receive an incoming call, the ring tone sounds and the illumination flashes. When you receive an incoming call, r or d (Answer) / (Subst.) You can only answer a videophone call with the substitute image. After the call ends, y Adjusting earpiece volume is "TEL function" s "Dial/Receive setting" s "In-call setting" s "Volume" sAdjust with csd (Set) During a call, you can adjust the volume with Xc. 3 When you can not answer a call Setting record message When you cannot answer a voice or videophone call, the FOMA terminal can record a voice or videophone message. i s "TEL function"s"Rec. msg./Voice memo"s"Record message setting" s"ON"s"Phone" or "Videophone"sSelect an item Set ring time (3-digit number between 000 and 120 seconds) If you receive a call with Record message setting ON Record message activates if the set time ends. Press r to answer a voice/videophone call while recording. To play a recorded message On the standby screen, ds"Record message" icon or "Record VP message" icon sSelect an item Setting Public mode (Drive mode) When Public mode (Drive mode) is set, a caller hears a message that you cannot answer the call because you are driving or in a place where you have to refrain from using a mobile phone (on a train or bus, in a theater, etc.), then the call ends automatically. On the standby scree n, w (1 second or longer) appears on the standby screen. To release the setting On the standby screen, w (1 second or longer) Setting Public mode (Power OFF) When Public mode (Power OFF) is set, a caller who made a call while the power is off hears a message that you cannot answer the call because you are in a place where you have to turn off the mobile phone (in a hospital, on an airplane, around a priority seat on a train, etc.), then the call ends automatically. w25251sr To release the setting w25250sr 4 Using various network services Available network services Useful DOCOMO network services are available. The network services are not available when you are outside the service area or in a place where the signal is weak. For details, refer to "Mobile Phone User's Guide [Network Services]". For the application and inquiries, please contact "General Inquiries". Service nameApplicationMonthly charge Voice Mail ServiceRequiredCharged Turned Off or Out of Range Notification Call ServiceNot requiredFree Call WaitingRequiredCharged Call Forwarding ServiceRequiredFree Nuisance Call BlockingNot requiredFree Caller ID NotificationNot requiredFree Caller ID RequestNot requiredFree Dual Network ServiceRequiredCharged English GuidanceNot requiredFree Multi NumberRequiredCharged 2in1Requir edCharged Public mode (Drive mode)Not requiredFree Public mode (Power OFF)Not requiredFree OFFICEEDRequiredCharged Melody callRequiredCharged Koe-no-TakuhaibinNot requiredFree For details on "OFFICEED", refer to the NTT DOCOMO corporate website (http://www.docomo. biz/html/service/officeed/) (in Japanese only). Setting voice mail service is "TEL function" s "Voice mail service" sSelect an item Setting call waiting is "TEL function" s "Other network serv." s "Call waiting" sSelect an item Setting call forwarding is "TEL function" s "Other network serv." s "Call forwarding" sSelect an item 5 Emergency call Emergency callPhone number Police emergency110 Fire brigade/Ambulance emergency119 Maritime distress call118 Your FOMA terminal supports "Emergency Location Report". Calls made to emergency service organizations (e.g. by dialing 110, 119 or 118) disclose information on the caller's location to the organization receiving th e call. The locati on information may not be correctly sent depending on the current location or signal quality. When the location information is disclosed, the organization name appears on the standby screen. The location information and phone number are not disclosed when, before each individual call made, "184" or another blocking prefix is dialed first. If the information is deemed necessary for the protection of life, etc., this inf ormation may be acquired by the organization being called. Locations/timing planned for adoption of this fea ture vary according to the status of the preparations by the relevant emergency service organizations. When calling 110, 119 or 118 from t…

Text truncated - open the document above for the full version.

1 Radio Frequency (RF) Signals THIS MODEL PHONE MEETS THE U.S. GOVERNMENT'S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone contains a radio transmitter and receiver. Your phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate (SAR). The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted using standard operating positions accepted by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the U.S. government-adopted requirement for safe exposure. The tests are performed on position and locations (for example, at the ear and worn on the body) as required by FCC for each model. The highest SAR value for this model phone as reported to the FCC when tested for use at the ear is 0.93 W/kg, and when worn on the body, is 0.52 W/kg. (Body-worn measurements differ am ong phone models, depending upon available accessories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the U.S. government requirement. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section at https://gullfoss2.fcc.gov/oetcf/ eas/reports/GenericSearch.cfm after search on FCC ID A98-XGU3296. For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used with an accessory designated for this product or when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body. Non-compliance with the above restrictions may result in violation of FCC RF Exposure guidelines. * In the United Sta tes, the SAR limit for wireless mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. SAR values may vary depending upon national reporting requirements and the net work band. 2 FCC Regulations This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This mobile phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequenc y e nergy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A External Photos EUT Type: Portable Handset Page 1 of 5 © 2011 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A External Photos EUT Type: Portable Handset Page 2 of 5 © 2011 PCTEST Engineering Laboratory Inc. NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A External Photos EUT Type: Portable Handset Page 3 of 5 © 2011 PCTEST Engineering Laboratory Inc. NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A External Photos EUT Type: Portable Handset Page 4 of 5 © 2011 PCTEST Engineering Laboratory Inc. NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A External Photos EUT Type: Portable Handset Page 5 of 5 © 2011 PCTEST Engineering Laboratory Inc.

FCC ID Label Placement Pl f b tt Label placement Pl ace f or b a tt ery Rear View of the phone NEC CASIO MOBILE COMMUNICATIONS Confidential IMEI Label Layout Model Name App licant / Manufacturer Vendor Name Year/month of manufacture Color pp Japanese Accreditation Mark TELEC Certification Manufacturer No. Manufacturer Barcode TELEC Certification Numbers Numbers JATE Certification Numbers Warning: Please switch off this mobile phone on the airplane FCC ID on the airplane . Please do not remove this sticker.

NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Internal Photos EUT Type: Portable Handset Page 1 of 1 © 2011 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Internal Photos EUT Type: Portable Handset Page 2 of 2 © 2011 PCTEST Engineering Laboratory Inc. NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Internal Photos EUT Type: Portable Handset Page 3 of 3 © 2011 PCTEST Engineering Laboratory Inc. NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Internal Photos EUT Type: Portable Handset Page 4 of 4 © 2011 PCTEST Engineering Laboratory Inc. NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Internal Photos EUT Type: Portable Handset Page 5 of 5 © 2011 PCTEST Engineering Laboratory Inc. NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Internal Photos EUT Type: Portable Handset Page 6 of 6 © 2011 PCTEST Engineering Laboratory Inc.

Reviewed by: FCC ID: A98-XGU3296 FCC Pt. 15.225 MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Date(s): EUT Type: 0Y1109131623.A98 September 19-21, 2011 Portable Handset Page 1 of 21 © 2011 PCTEST Engineering Laboratory, Inc. REV 2.1RFFI 09/14/2011 Applicant Name: Date of Testing: NEC Corporation of America September 19-21, 2011 Radio Communications Systems Division Test Site/Location: 6535 N. State Highway 161 PCTEST Lab, Columbia, MD, USA Irving, TX 75039-2402 USA Test Report Serial No.: 0Y1109131623.A98 FCC ID: A98-XGU3296 APPLICANT: NEC Corporation of America Model(s): KMP7N2AA1-2A EUT Type: Portable Handset Frequency: 13.56MHz FCC Classification: Low Power Communications Device Transmitter (DXX) FCC Rule Part(s): FCC Part 15 Subpart C (15.225) IC Specification(s): RSS-210 Issue 8 The device bearing the FCC Identifier specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and has been tested in accordance with the measurement procedures specified in ANSI C63.4-2003 (See Test Report). These measurements were performed with no deviation from the standards.Test results reported herein relate only to the item(s) tested. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com MEASUREMENT REPORT FCC Part 15.225 / IC RSS-210 Reviewed by: FCC ID: A98-XGU3296 FCC Pt. 15.225 MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Date(s): EUT Type: 0Y1109131623.A98 September 19-21, 2011 Portable Handset Page 2 of 21 © 2011 PCTEST Engineering Laboratory, Inc. REV 2.1RFFI 09/14/2011 TABLE OF CONTENTS FCC Part 15.225 MEASUREMENT REPORT...............................................................................3 1.0 INTRODUCTION....................................................................................................................4 1.1 SCOPE...................................................................................................................................................................4 1.2 PCTEST TEST LOCATION.................................................................................................................................4 2.0 PRODUCT INFORMATION.....................................................................................................5 2.1 EQUIPMENT DESCRIPTION.............................................................................................................................5 2.2 DEVICE CAPABILITIES......................................................................................................................................5 2.3 OPERATION MODE.............................................................................................................................................5 2.4 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS......................................................................................5 2.5 LABELING REQUIREMENTS ............................................................................................................................5 3.0 DESCRIPTION OF TEST........................................................................................................6 3.1 EVALUATION PROCEDURE.............................................................................................................................6 3.2 CONDUCTED EMISSIONS................................................................................................................................6 3.3 RADIATED EMISSIONS......................................................................................................................................7 4.0 ANTENNA REQUIREMENTS..................................................................................................8 5.0 SAMPLE CALCULATIONS......................................................................................................9 5.1 CONDUCTED EMISSION MEASUREMENT SAMPLE CALCULATION....................................................9 5.2 RADIATED EMISSION MEASUREMENT SAMPLE CALCULATION..........................................................9 6.0 TEST EQUIPMENT CALIBRATION DATA.............................................................................10 7.0 ENVIRONMENTAL CONDITIONS.........................................................................................11 8.0 TEST DATA.........................................................................................................................12 8.1 SUMMARY...........................................................................................................................................................12 8.2 20DB BANDWIDTH MEASUREMENT............................................................................................................13 8.3 IN-BAND RADIATED SPURIOUS EMISSION MEASUREMENTS............................................................14 8.4 RADIATED SPURIOUS EMISSION MEASUREMENTS, OUT-OF-BAND...............................................15 RADIATED SPURIOUS EMISSION MEASUREMENTS, OUT-OF-BAND (CONT’D…

Text truncated - open the document above for the full version.

NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Test Set-Up Photos EUT Type: Portable Handset Page 1 of 3 © 2011 PCTEST Engineering Laboratory Inc. TEST SETUP PHOTOGRAPHS NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Test Set-Up Photos EUT Type: Portable Handset Page 2 of 3 © 2011 PCTEST Engineering Laboratory Inc. NEC FCC ID: A98-XGU3296 Model: KMP7N2AA1-2A Test Set-Up Photos EUT Type: Portable Handset Page 3 of 3 © 2011 PCTEST Engineering Laboratory Inc.
