Digital Security Code The Model TC-945 uses digital security coding to provide protection against unintentional access to the public switched telephone network by the base unit and unintentional ringing by the handset as specified in Section 15.214(d). The Model TC-945 uses the following means and/or procedure to achieve the required protection. The Model TC-945 automatically selects a different code from at least 256 possible discrete digital codes each time the handset is placed in the base.

FCC ID: AAL-TC-945 Report Number: B80904D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 1 of 15 FCC PART 15, SUBPART C TEST METHOD: ANSI C63.4-1992 for 2-LINE 900 MHZ CORDLESS TELEPHONE Model: TC-945 Prepared for CASIO PHONEMATE, INC. P.O. BOX 2914 TORRANCE, CALIFORNIA 90509-2914 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ SCOTT McCUTCHAN COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: SEPTEMBER 10, 1998 REPORTAPPENDICESTOTAL BODY ABC D PAGES15221522 56 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. FCC ID: AAL-TC-945 Report Number: B80904D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 2 of 15 TABLE OF CONTENTS Section / TitlePAGE GENERAL REPORT SUMMARY4 SUMMARY OF TEST RESULTS4 1. PURPOSE5 2. ADMINISTRATIVE DATA6 2.1 Location of Testing6 2.2 Traceability Statement6 2.3 Cognizant Personnel6 2.4 Date Test Sample was Received6 2.5 Disposition of the Test Sample6 2.6 Abbreviations and Acronyms6 3. APPLICABLE DOCUMENTS7 4. DESCRIPTION OF TEST CONFIGURATION8 4.1 Description of Test Configuration - EMI8 4.1.1 Cable Construction and Termination9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT10 5.1EUT and Accessory List10 5.2 EMI Test Equipment11 6. TEST SITE DESCRIPTION12 6.1 Test Facility Description12 6.2 EUT Mounting, Bonding and Grounding12 7. TEST PROCEDURES13 7.1 RF Emissions13 7.1.1 Conducted Emissions Test13 7.1.2 Radiated Emissions Test14 8. CONCLUSIONS15 FCC ID: AAL-TC-945 Report Number: B80904D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 3 of 15 LIST OF APPENDICES APPENDIXTITLE AModifications to the EUT BAdditional Models Covered Under This Report CDiagrams, Charts and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors DData Sheets LIST OF TABLES TABLETITLE 1 Conducted Emissions Test Results 2 Radiated Emissions Test Results LIST OF FIGURES FIGURETITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Test Site FCC ID: AAL-TC-945 Report Number: B80904D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 4 of 15 GENERAL REPORT SUMMARY This electromagnetic emission and immunity test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced in any form unless done so in full with the written permission of Compatible Electronics. This report must not be used to claim product endorsement by NVLAP or any other agency of the U.S. Government. Device Tested:2-Line 900 MHz Cordless Telephone Model: TC-945 S/N: N/A Product Description:The EUT is an analog 900 MHz cordless telephone with 2 lines and digital answering machine.. Modifications:The EUT was not modified during the testing. Manufacturer:Casio Phonemate, Inc. P.O. Box 2914 Torrance, California 90509-2914 Test Dates:September 3 and 4, 1998 Test Specifications : EMI requirements FCC Title 47, Part 15 Subpart C, Sections 15.205, 15.207 and 15.249 Test Procedure:ANSI C63.4: 1992 Test Deviations:The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TESTDESCRIPTIONRESULTS 1Conducted RF Emissions, 450 kHz - 30 MHzComplies with the limits of FCC Title 47, Part 15 Subpart C, section 15.207 2Radiated RF Emissions, 10 kHz - 9300 MHzComplies with the of FCC Title 47, Part 15 Subpart C, sections 15.205 and 15.249 FCC ID: AAL-TC-945 Report Number: B80904D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 5 of 15 1.PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the 2-Line 900 MHz Cordless Telephone Model: TC-945. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4: 1992. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the specification limits defined by FCC Title 47, Part 15, Subpart C, sections 15.205, 15.207, and 15.249. . FCC ID: AAL-TC-945 Report Number: B80904D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 6 of 15 2.ADMINISTRATIVE DATA 2.1Location of Testing The EMI/EMC tests described herein were performed at the test facility of Compatible Electronics, 114 Olinda Drive, Brea, California 92823. 2.2Traceability Statement The calibration certificates of all test equipment used during the test are on file at the location of the test. The calibration is traceable to the National Institute of Standards and Technology (NIST) . 2.3Cognizant Personnel Casio Phonemate, Inc. Lananh T. TranCompliance Engineer Compatible Electronics Inc. Kyle FujimotoTest Engineer Scott McCutchanLab Manager 2.4Date Test Sample was Received The test sample was received on September 3, 1998 2.5Disposition of the Test Sample The test sample was returned to Casio Phonemate, Inc. on September 10, 1998. 2.6Abbreviations and Acronyms The following abbreviations and acronyms may be used in this document. RFRadio Frequency EMIElectromagnetic Interference EUTEquipment Under Test P/NPart Number S/NSerial Number HPHewlett Packard ITEInformation Technology Equipment CMLCorrected Meter Limit LISNLine Impedance Stabilization Network FCC ID: AAL-TC-945 Report Number: B80904D1 114 OLINDA DRIVE, BREA, CALIFORNIA 92823 PHONE: (714) 579-0500 FAX: (714) 579-1850 Page 7 of 15 3.APPLICABLE DOCUMENTS The fo…
