ABZ99FT5101BNon Broadcast Transmitter

APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B EXHIB IT D User Information User I nformation Tune-up and user / operational manual information are provided in the following exhibits. EXHIBIT DESCRIPTION D1 Tune-Up Procedure D2 User / Operational Manual APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B EXHIB IT D1 Tune-Up Procedure Tune-Up Procedure A procedure to ensure that the device is tuned to the correct frequency / frequency range and that it is operating at the proper level. This exhibit is only required for licensed transmitters. Content from Chapter 10 of the document “MOTOTRBO™ SLR 8000 Repeater Basic Service and Installation Manual” (part number MN002253A01-AH, November 2022) is included in the following pages. Chapter 10 SLR 8000 Programming and Tuning 10.1 Programming and Tuning Introduction This section provides an overview of the MOTOTRBO Customer Programming Software (CPS) and the MOTOTRBO Tuner application for use on Windows 7, Windows 8, or Windows 8.1. These two MOTOTRBO applications are used for the configuration and alignment of the SLR 8000 Base Station/ Repeater. 10.2 Customer Programming Software Setup The Customer Programming Software setup, shown in Figure 50: Customer Programming Software Setup on page 97 is used to program the base station/repeater. See Figure 51: Front view of SLR 8000 Base Station/Repeater on page 98 and Figure 52: Rear view of SLR 8000 Base Station/ Repeater on page 98 for the actual connectors on the front and rear panels of the base station/ repeater. NOTE: See appropriate program on-line help files for the programming procedures. CAUTION: Computer USB ports can be sensitive to Electronic Discharge. Employ proper ESD practices (wrist strap, grounding, etc.) and do not touch exposed contacts on cables when connected to a computer. Figure 50: Customer Programming Software Setup Front Panel USB AC USB 120 / 240 VAC * OPTIONAL Station Tx Port (N-type Female) Rx Port (BNC Female) AUX WL1* DC 13.6 VDC ( typical ) or 27.2 VDC ( typical ) Either One or Both Standard Type “A” to Type “B” USB cable Rear Panel MN002253A01-AH SLR 8000 Programming and Tuning 97 Applicant: Motorola SolutionsEquipment Type: ABZ99FT5101B / 109AB-99FT5101B Tune-Up ProcedureExhibit D1 1 of 19 Figure 51: Front view of SLR 8000 Base Station/Repeater 21 Table 49: Callout Legend LabelDescription 1Microphone Connector 2USB Connector Figure 52: Rear view of SLR 8000 Base Station/Repeater 4 5 321 TxRx Rx 21 REF ANT AUX Table 50: Callout Legend LabelDescription 1AC Inlet Connector 2DC Inlet Connector 3Rx RF Connector 4Aux Connector 5Tx RF Connector MN002253A01-AH Chapter 10 : SLR 8000 Programming and Tuning 98 Applicant: Motorola SolutionsEquipment Type: ABZ99FT5101B / 109AB-99FT5101B Tune-Up ProcedureExhibit D1 2 of 19 10.3 Tuning the Reference Oscillator Alignment This feature is used to adjust the reference oscillator of the SLR 8000 Base Station/Repeater. This alignment process should be done as maintenance schedules and regulations require or if the Modem FRU has been replaced in the base station/repeater. Procedure: 1Connect the base station/repeater's transmitter antenna port to the Communication Analyzer. 2Power the base station/repeater from either an AC or DC source. 3Launch the Tuner application. 4To begin reading the base station/repeater's tuning softpot values, click Read 5Under the TX menu in the tree view, select Ref Oscillator Figure 53: Tx Menu Tree (Ref. Oscillator) 6Configure the current operating frequency into the Communications Analyzer. 7To key up the base station/repeater, click PTT Toggle 8Adjust the working softpot value until the frequency is within the performance specifications (+/-40 Hz for UHF and VHF) from the frequency point. 9To de-key the base station/repeater, click PTT Toggle 10To save the tuned softpot value into the base station/repeater codeplug. click Write 10.4 Base Station/Repeater Tuning Setup A personal computer (PC), Windows ™ operating system, and the MOTOTRBO Tuner application are required to align the base station/repeater. To perform the tuning procedures, the base station/repeater must be connected to the PC and test equipment setup as shown in the following figure. Figure 54: SLR 8000 Base Station/Repeater Tuning Equipment Setup Transmit Service Monitor or Counter 20 dB Pad Front Panel AC USB 120 / 240 VAC Station Tx Port (BNC Female) AUX DC 13.6 VDC * OPTIONAL Either One or Both Rear Panel Standard Type “A” to Type “B” USB cable WL2* USB Wattmeter MN002253A01-AH Chapter 10 : SLR 8000 Programming and Tuning 99 Applicant: Motorola SolutionsEquipment Type: ABZ99FT5101B / 109AB-99FT5101B Tune-Up ProcedureExhibit D1 3 of 19 10.5 Tuning the Rx Audio Level Set The procedure outlined in this section is used to set the receive output audio level from the SLR 8000 Base Station/Repeater for a given RF deviation of the received RF signal. Perform this procedure any time the Rx audio level needs adjustment. NOTE: The sequence of steps in this procedure is crucial in order to observe the effect of softpot setting on the Rx output at pin #7 during the adjustments. Procedure: 1Connect the base station/repeater's receiver antenna port to the Communication Analyzer. 2Power the base station/repeater from either an AC or DC source. 3Set the Communication Analyzer to output a -47 dBm RF signal modulated with a 1 kHz tone at 60% of full deviation on the tuning frequency. The tuning frequency is the value displayed on the Tuner GUI under the heading of "Frequency Points". NOTE: The Tuner aligns this parameter in a 12.5 kHz channel spacing, so 60% is 1.5 kHz of deviation. If the CPS is set for 25 kHz operation, the base station/repeater automatically scales the deviation by a factor of two when it is outside the Tuner application. Programmed TPL and DPL squelch requirements are automatically disabled for the tuning frequency while in the Tuner application. 4Launch the Tuner application. 5To read the…

Text truncated - open the document above for the full version.

FCC ID: ABZ99FT5101B ___________________________________________________________________________________________________________ Motorola Solutions Date: March 23, 2023 Rick King Certification Department 1516 Centre Circle Downers Grove, Illinois 60515 Telephone: 630 495-9770 Email: [email protected] ELITE ELECTRONIC ENGINEERING Subject: Extended Frequencies Justification for Certification of Transmitter with FCC ID: ABZ99FT5101B Dear Sir, In accordance with updated requirements pertaining to Publication KDB 634817, Frequency Range Listings for Certification Grants, Motorola Solutions hereby submits attestation that the transmitter described in this submission includes continuous frequencies that are not listed in rule part 90. For the FCC’s Rule Parts 22, 74, 80 and 90 applications, this radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, etc. Please note that Licensed End Users do not have access to any external controls that will allow them to program the equipment. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e) and 80.203(b), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. It is understood that a grant note code may be added to the grant which indicates this required operation. Sincerely, Bob Sarocka Engineering Manager E-mail: [email protected]

FCC ID: ABZ99FT5101B Date: March 21, 2023 Rick King Certification Department 1516 Centre Circle Downers Grove, Illinois 60515 Telephone: 630 495-9770 Email: [email protected] ELITE ELECTRONIC ENGINEERING Subject: Part 90.203 (j) (5) Certification Statement FCC ID: ABZ99FT5101B Dear Sir, Motorola Solutions, Inc certifies that it’s digital base station transmitter FCC ID: ABZ99FT5101B, meets a spectrum efficiency standard of one voice channel per 6.25kHz of channel bandwidth. Additionally, Motorola Solutions, Inc certifies the equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. . Sincerely, Bob Sarocka Engineering Manager E-mail: [email protected]

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 March 17, 2023 Pursuant to FCC 22-84 Report and Order and KDB 986446 D01 Covered Equipment v01, the Commission adopted new FCC requirements to protect the nation’s networks and supply chains from equipment that poses an unacceptable risk to national security or the safety of U.S. persons. Specifically, the Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List. Certification designating a U.S. agent for service of process. As required by section 2.911(d)(7), the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. Robert Sarocka (“the applicant”) acknowledges to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. If the agent changes then the TCB and the FCC must be notified. Robert Sarocka Motorola Solutions 2000 Progress Parkway, Schaumburg, IL 60196 847-344-6075 [email protected] FCC ID: ABZ99FT5101B FRN: 0025009739 Thank you. Regards, 3/17/23 Robert Sarocka Engineering Manager

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 March 17, 2023 Pursuant to FCC 22-84 Report and Order and KDB 986446 D01 Covered Equipment v01, the Commission adopted new FCC requirements to protect the nation’s networks and supply chains from equipment that poses an unacceptable risk to national security or the safety of U.S. persons. Specifically, the Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List. Certifications FCC ID: ABZ99FT5101B concerning “covered” equipment. Section 2.911(d)(5)(i)-(ii). Robert Sarocka (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Robert Sarocka (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the covered list as an entity producing covered equipment. Thank you. Regards, 3/17/23 Robert Sarocka Engineering Manager Motorola Solutions 2000 Progress Parkway, Schaumburg, IL 60196 847-344-6075 [email protected]

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 ATTENTION: Federal Communication Commission Equipment Authorization To whom it may concern, We would like to submit for Certification to FCC: ABZ99FT5101B. Please find in the following application all related documentation to support this New Single Certification. We would appreciate your prompt attention to the submittal. Applicant Company name: Motorola Solutions, Inc. Contact Name: Bob Sarocka Address: 2000 Progress Parkway, Schaumburg, IL 60196 Telephone No: 847-344-6075 Email: [email protected] FCC ID Number: ABZ99FT5101B 3/17/23 Robert Sarocka Engineering Manager Motorola Solutions

FCC ID: ABZ99FT5101B HVIN: SLR 8000-800900B CONFIDENTIALITY REQUESTED Date: March 17, 2023 Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams (Included in Exhibit B) Short Term External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation (Included in Exhibit B) Short Term Permanent Parts List & Placement/BOM (Included in Exhibit B) Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics (Included in Exhibit B) Short Term Test Setup Photos Short Term Permanent* User’s Manual Motorola Solutions has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Short Term Confidentiality: The applicant requests the exhibits listed above as Short Term confidential be withheld from public review for a duration of 180 days from the date of submission. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: __________________________ Robert Sarocka (Signature) (Print name) Title: Engineering Manager

Applicant: Motorola Solutions Inc FCC ID: ABZ99FT5101B / IC: 109AB-99FT5101B EXHIBIT C SHEET 1 OF 21 EXHIBIT C: Photographs of the Device Photographs – Index EXHIBIT DESCRIPTION C1-1. Front View of Base Radio C1-2. Front View of Base Radio, Front Panel and Cover Removed C1-3. Back View of Base Radio (FCC/IC Label Location) C1-4. Bottom View of Base Radio, Bottom Panel Removed C2-1. Modem Module, Top C2-2. Modem Module, Top – Shields Removed C2-3. Modem Module, Bottom – Shields Removed C2-4. Power Amplifier Module C2-5. Power Amplifier Module, Top – Cover and Shields Removed C2-6. Power Amplifier Module, Bottom – Heat Sink Removed C2-7. Power Supply Module C2-8. Wireline Board, Top View C2-9. Wireline Board, Bottom View C3-1. Test Setup - Motorola Solutions General Performance Test C3-2. Test Setup - Motorola Solutions TX Conducted Spurious Emissions C3-3. Test Setup - Motorola Solutions TX Conducted Harmonic Emissions C3-4. Test Setup - Elite Engineering Radiated Measurements Test Setup Diagram C3-5. Test Setup - Elite Engineering Radiated Measurement UUT Configuration C3-6. Test Setup - Elite Engineering Radiated Measurement 30MHz-1GHz C3-7. Test Setup - Elite Engineering Radiated Measurement Above 1GHz Applicant: Motorola Solutions Inc FCC ID: ABZ99FT5101B / IC: 109AB-99FT5101B EXHIBIT C SHEET 2 OF 21 Exhibit C1-1 – Front View of Base Radio Applicant: Motorola Solutions Inc FCC ID: ABZ99FT5101B / IC: 109AB-99FT5101B EXHIBIT C SHEET 3 OF 21 Exhibit C1-2 – Front View of Base Radio, Front Panel and Cover Removed Applicant: Motorola Solutions Inc FCC ID: ABZ99FT5101B / IC: 109AB-99FT5101B EXHIBIT C SHEET 4 OF 21 Exhibit C1-3 – Back View of Base Radio (FCC/IC Label Location)

APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B EXHIBIT A Ph otographs of the Device Photogr aphs – Index EXHIBIT DESCRIPTION A1 A2 ID Label Location FCC / IC Identification Label APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B EXHIBIT A1 Ph otographs of the Device ID Label Location APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT3095B 109AB-99FT3095B EXHIBIT A2 Ph otographs of the Device FCC / IC I dentification Label

Mot orola Solut ions Canada, Inc. UPN Number: 99FT5101B Company Number: 1 0 9 AB Model Number: SLR 8000 800900B Page 1 RF Exposure Technical Brief This Technical Brief calculates the minimum separation distance from an antenna, connected to the subject base station, such that the power density value listed in RSS-102, Radio Frequency (RF) Exposure Compliance of Radiocommunications Apparatus (All Frequency Bands) Issue 5 Table 6 is not exceeded. The analysis is for a typical installation using a structure mounted antenna. Within the frequency range that the subject equipment operates, 851-869 MHz and 935-941MHz the permitted exposure limit is frequency dependent per the equation 0.6455*sqrt(f). Table 1 lists the maximum permitted exposure limits for the lowest and highest operating frequencies. The smaller maximum permissible exposure limit will be used for the computation because it requires a larger separation distance from the antenna to the exposed person. Table 1 - Maximum Permissible Exposure Limits Controlled Environment Frequency 851 MHz 869MHz Limit 28.37 W/m 2 28.97 W/m 2 Frequency 935 MHz 941 MHz Limit 31.17 W/m 2 31.37 W/m 2 Example Calculations for SLR 8000, 800-900MHz Transmitter: The example configuration is a single frequency site, with minimal RF network losses, set to zero for this example, between the transmitter output connector and the antenna input connector. The antenna has an omni directional pattern in the horizontal plane and a 13 degree beamwidth in the vertical plane. The largest dimension of the antenna is in the vertical plane. A 6.0 dBd gain antenna was selected as representative of the structure mounted infrastructure antennas used in the 800MHz band, Table 2 - Transmitter Configuration Frequency 851-869 MHz / 935-941 MHz Base Station Output Power 110 W RF Network Loss 0 dB Antenna Type RFS BMR6-O-B1 6.0 dBd / 8.1 dBi (Omni) Antenna length 1.68 m Controlled Environment: Cylindrical Method Using Equation 1 the spatially averaged plane-wave equivalent power density parallel to the antenna in the vertical plane is estimated by dividing the net input power to the antenna by the surface area of an imaginary cylinder at a distance R from the antenna, with the height of the cylinder equal to the length of the antenna 1 . 1 Federal Communications Commission Office of Engineering & Technology, OET Bulletin 65, “Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields”, Edition 97-01, page 32, Tell’s cylindrical model. Mot orola Solut ions Canada, Inc. UPN Number: 99FT5101B Company Number: 1 0 9 AB Model Number: SLR 8000 800900B Page 2 Rh Pnet S 2  (1) Where: S = power density, W/m 2 Pnet = net input power to the antenna, W R = radial distance from the antenna, m h = height of the antenna, m The minimum separation distance can be found by solving Equation 1 for R and setting S to the smaller maximum power density for the environment per Table 1. m (2) m For the example site configuration the minimum separation distance for a controlled environment is 0.33 m (worst case).

APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B Report on Test Measurements for FCC ID ABZ99FT5101B, HVIN SLR 8000-800900B per FCC 47 CFR 90 and IC RSS-119. E-1 Measurements Report The measurement report shows compliance information against applicable standards. Each parameter is measured generally at the low end, middle, and at the high end of the applicable frequency band. Each section of the report contains either verbiage or graphs which show compliance to applicable standards as required, explains testing method used, and indicates what the applicable specification is. Test setup details and certification signoff page are included at the end of the measurement report. INDEX EXHIBIT DESCRIPTION E1-1 Tested Unit Details E1-2 Measurement Uncertainties E1-3 Test Results Summary E1-4 RF Output Power E1-5 Occupied Bandwidth E1-6 Conducted Spurious Emissions E1-7 Radiated Spurious Emissions E1-8 Frequency Stability E1-9 Audio Frequency Response – Modulation Characteristics E1-10 Audio Modulation Limiting – Modulation Characteristics E1-11 Test Setup Details E1-12 Statement of Certification APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B Report on Test Measurements for FCC ID ABZ99FT5101B, HVIN SLR 8000-800900B per FCC 47 CFR 90 and IC RSS-119. E-2 E1-1 Tested Unit Details Model Under Test SLR 8000 Serial Number 433IYY0561 Firmware Version D20.22.03.09 Codeplug Version 226303 Bootloader Version R01.11.02 Manufacturer Motorola Solutions 2540 Galvin Drive, Elgin, IL 60124 APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B Report on Test Measurements for FCC ID ABZ99FT5101B, HVIN SLR 8000-800900B per FCC 47 CFR 90 and IC RSS-119. E-3 E1-2: Measurement Uncertainty Measurement Frequency Expanded Uncertainty RF Power Output 50MHz-10GHz +/-0.132dB Carrier Frequency Stability 9kHz-13GHz +/-0.368Hz Occupied Bandwidth 9kHz-13GHz +/-0.52dB Transmitter Conducted Spurious Emissions 9kHz-13GHz +/-0.64dB Transient Frequency Behavior 9kHz-13GHz +/-2.04dB Modulation Characteristics 100-5000Hz +/-0.40dB Radiated Emissions 30MHz-1000MHz 4.3dB Radiated Emissions 1GHz-6GHz 3.1dB APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B Report on Test Measurements for FCC ID ABZ99FT5101B, HVIN SLR 8000-800900B per FCC 47 CFR 90 and IC RSS-119. E-4 E1.3: Test Results Summary Test 47 CFR Reference RSS-119 Reference Results RF Output Power 2.1046 4.1,5.4 Pass Occupied Bandwidth 2.1049 5.5 Pass Conducted Spurious Emissions 2.1051 4.2,5.8 Pass Radiated Spurious Emissions 2.1053 4.2,5.8 Pass Frequency Stability 2.1055 5.3 Pass Frequency Transient Behavior 90.214 5.9 Pass Modulation Characteristics 2.1047 Pass Test Standards: Title 47 Part 2 of Code of Federal Regulations Title 47 Part 90 of Code of Federal Regulations RSS-119 Land Mobile and Fixed Equipment Operating in the Frequency Range 27.41-960 MHz ANSI C63.26-2015 American National Standard for Compliance Testing of Transmitters Used in Licensed Radio Services ANSI C63.4-2014 American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range 9 kHz to 40 Ghz APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B Report on Test Measurements for FCC ID ABZ99FT5101B, HVIN SLR 8000-800900B per FCC 47 CFR 90 and IC RSS-119. E-5 E1-4 RF Power Output Data per CFR 47 2.1046 and RSS-119 5.4 The RF power output was measured with the indicated voltage applied to and current into the final RF amplifying device(s). The DC current indicated is the total for the final RF amplifier stage. Analog Voice (FM) and Digital MOTOTRBO TM 4-Level Frequency Modulation (4FSK) 851MHz 860MHz 870MHz Measured RF output 110 110 110 Watts DC Voltage, final RF amplifier stage/stages 15.2 15.8 15.9 Volts DC Current, final RF amplifier stage/stages 17 18 20 Amps Input power for final RF amplifying device(s) 258.4 284.4 318 Watts Primary Radio Input Supply Voltage 120 120 120 VAC Minimum Measured RF output 1 1 1 Watts DC Voltage, final RF amplifier stage/stages 11 11 11 Volts Normal DC Current 3.2 3.2 3.2 Amps Input power for final RF amplifying device(s) 35.2 35.2 35.2 Watts Primary Radio Input Supply Voltage 120 120 120 VAC Analog Voice (FM) and Digital MOTOTRBO TM 4-Level Frequency Modulation (4FSK): 935 MHz 940MHz 941MHz Measured RF output 110 110 110 Watts DC Voltage, final RF amplifier stage/stages 15.9 15.9 15.9 Volts DC Current, final RF amplifier stage/stages 22 21 22 Amps Input power for final RF amplifying device(s) 349.8 333.9 349.8 Watts Primary Radio Input Supply Voltage 120 120 120 VAC Minimum Measured RF output 1 1 1 Watts DC Voltage, final RF amplifier stage/stages 11 11 11 Volts Normal DC Current 3.3 3.4 3.3 Amps Input power for final RF amplifying device(s) 36.3 37.4 36.3 Watts Primary Radio Input Supply Voltage 120 120 120 VAC APPLICANT: MOTOROLA SOLUTIONS EQUIPMENT TYPE: ABZ99FT5101B 109AB-99FT5101B Report on Test Measurements for FCC ID ABZ99FT5101B, HVIN SLR 8000-800900B per FCC 47 CFR 90 and IC RSS-119. E-6 E1-5 Occupied bandwidth per CFR 47 2.1051 and RSS-119 5.5 Occupied Bandwidth – MOTOTRBO TM Digital Modulation, 12.5 kHz Channel Spacing MOTOTRBO TM Digital Modulation can be used in a system configuration based upon channel usage as described in Exhibit B. The ‘F7E’ and ‘FXE’ emission designators provide usage for telephony, the ‘F7D’ and ‘FXD’ designators provide usage for data / telecommand, and the ‘F7W’ designator provides for usage as a combination of telephony and telecommand. All are spectrally identical. The occupied bandwidth chart references the following setup and specification requirements. Modulation Type: MOTOTRBO TM Digital Modulation Emission Designator: 7K60F7W, 7K60F7D, 7K60F7E, 7K60FXD, 7K60FXE Channelization: 12.5 kHz Power Setting: 110 Watts Necessary Bandwidth Calculation: The necessary bandwidth of the modulation per the formulas defined in 47 CFR §2.202(g) / T…

Text truncated - open the document above for the full version.

ProductDataSheetBMR6-O-B1 Penetrator™Antenna,806-869,8.1dBi,360deg All information contained in the present datasheet is subject to confirmation at time of ordering RFSTheClearChoice®BMR6-O-B1 Rev:BPrintDate:06.10.2014 Pleasevisitusontheinternetathttp://www.rfsworld.com/RadioFrequencySystems ProductDescription Thenovelsidefeddipoledesignoftheseantennasprovides6dBd,8dBd,10dBdor12dBd omnidirectionalgainwith63MHzbandwidth.Theyfeatureconstantbeamtilt,heavynullfill,andhave beenVSWRtested.Dependinguponthespecificrequiredareaofcoverage,horizontalpatternsO, A,B,DorHareavailable. BMR*Series Features/Benefits •HighgainmaximizesERP.•Heavynullfillenhancesclose-incoverage.•Customizedbeamtiltminimizesinterferencetoandfrom adjacentsystems.•Variouspatternsavailabletoefficientlycovertargetarea. TechnicalSpecifications FrequencyRange,MHz806-869 HorizontalPatternOmniDirectional AntennaTypePenetrator HorizontalBeamwidth,deg360 ElectricalDowntilt,deg0 Gain,dBi(dBd)8.1(6) VerticalBeamwidth,deg13 1stNullFill,dBIncluded NullFill,dBIncluded Front-To-BackRatio,dBOmni PolarizationVertical VSWR<1.5:1 Impedance,Ohms50 MaximumPowerInput,W500 LightningProtectionTopRodGroundedtoBaseMount ConnectorTypeNFemale ConnectorLocationBottom Weight,kg(lb)12(26) WeightwithB1Bracket,kg(lb)26(58) MountTypeBracket MountingHardwareB1Bracket(included) RatedWindSpeed,km/h(mph)200(125) OverallLength,m(ft)1.68(5.5) Diameter,mm(in)168.3(6.625) RadiatingElementMaterialAluminum ElementHousingMaterialFiberglass MaxWindLoadingArea,m²(ft²)0.195(2.1) SurvivalWindSpeed,km/h(mph)200(125) ShippingWeight,kg(lb)29.5(65) Notes OtherDocumentation ProductDataSheetBMR6-O-B1 Penetrator™Antenna,806-869,8.1dBi,360deg All information contained in the present datasheet is subject to confirmation at time of ordering RFSTheClearChoice®BMR6-O-B1 Rev:BPrintDate:06.10.2014 Pleasevisitusontheinternetathttp://www.rfsworld.com/RadioFrequencySystems VerticalPattern HorizontalPattern
