User Guide Stream TV F3544K49201 Product & Accessories Information OK INPUT GUIDE INFOAPPS 12 3 4 5 6 7 89 0 Verizon Stream TV Device HDMI Cable USB Cable + Power Adapter Batteries ( T h e r e m o t e c o n t r o l u s e s t w o A A A h e a v y d u t y b a t t e r i e s ) RCU Yo u r Stream TV Top Side Front Side Rear Side USBHDMI System LED Reset Button HDMI Out POWER USB 2.0 Top Button OK INPUT GUIDE INFOAPPS 12 3 4 5 6 7 8 9 0 Set Up Device Before you start, confirm you have: • A Wi-Fi internet connection. • A Google account. A Google account is recommended but not required. The user will be able to skip the Google ‘sign in’ step. Step1 1. Connect the HDMI cable from your Stream TV to your TV. 2. Connect the power cord from your Stream TV to an electrical outlet. 3. Turn on your TV. 4. Set your TV to the correct HDMI input. Refer to the TV manufacturer for help verifying HDMI input. 5. Pair your Stream TV Voice Remote as described in pairing screen Pairing Your Stream TV Voice Remote 1. Press and hold the Remote “ Play\Pause” and “0” buttons simultaneously for 6 seconds. 2. Release the buttons to enter pairing mode. 3. If the 'pairing your remote' screen doesn't display, place the Stream TV in Bluetooth® discovery mode with the existing voice remote USBHDMI Router Manually Add a Wi-Fi Network 1. From the Stream TV Home screen, select the Settings menu Utilize 5-way navigation pad on the remote to highlight and the center (OK) button to select. 2. Select View more 3. Select Network & Internet . 4. From the 'Available networks' section, select the preferred Wi-Fi network. If the preferred network is not listed, it can be added manually. 5. If presented, enter the appropriate password then select CONNECT. Manually Pairing Your Stream TV Voice Remote Note: Only needed when replacing previously paired Steam TV Voice Remote 1. Press and hold the To p button for 3 seconds. 2. Press and hold the “Play\Pause” and “0” buttons on remote control simultaneously for 6 seconds. 3. Release the buttons to enter pairing mode. 4. If the 'pairing your remote' screen doesn't display, place the Stream TV in Bluetooth ® discovery mode with the existing voice remote or the remote control app. Top Button Function key Information Find my remote Double click top button in 1 seconds BT paring Press and hold top button for 3 seconds for manually pairing System LED USB HDMI Reset Button Top Button Status Detail Indication Priority Indication Duration No power Not connected to power Off Until turned On Bootup Connected to power Soft Blink White Not connected to internet Solid Red Until connected to internet Accepting remote commands User clicks buttons on remote LED OFF (blink) For 100ms after each remote click Error (FW or HW critical failure) Hard Blink Red WALL MOUNTING Information The device can be mounted onto a flat surface such as a wall or the back of a TV. For wall mounting, the device must not be mounted higher than 2 meters above the floor. Inside the product package for the outdoor mounting bracket, you should find the following: 3-24#2 Screws x 2 Anchor x 2 Wall mount bracket x 1 WALL MOUNTING Install Guidance 1 1. Using 2pcs screws to fix bracket onto wall 2. Assemble with bracket To make sure the device is seated properly, users will feel a “click” 1 Step 2 Step 1 Step 2 Step WALL MOUNTING Install Guidance 2 1. Assemble with bracket 2. Tear off the release papers of two adhesive strip (the adhesives are intended to be used once) 3. Mount onto wall Regulatory Information 1 Step 2 Step FCC Statement: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, use and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This product contains a radio transmitter and accordingly has been certified as compliant with 47 CFR Part 15 of the FCC Rules for intentional radiators. RF Exposure Statement: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Safety Statement: Only use the Power Supply provided with this product If you need further assistance, please contact Verizon for further information. Dolby, Dolby Atmos, and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. Manufactured under license from Dolby Laboratories. Confidential unpublished works. Copyright © 2012-2020 Dolby Laboratories. All rights reserved. Verizon uses and contributes to open source. For information about the open source used in the software included in this product as well as other Verizon software visit verizon.com/opensource

Date: 2021/4/27 Federal Communications Commission 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCC ID: ACQ-STREAMTV Product name: StreamTV To whom it may concern: We the undersigned, hereby authorize following person to act as our agent in the preparation of an application f or equipment authorization of model StreamTV to the FCC Rules and Regulations. International Certification Corp. Address : No .3-1, Lane 6, Wen San 3rd St. Kwei Shan Dist., TaoYuan City 333, Taiwan (R.O.C.) Name : Gary Chang Job Title : Manager e- mail : [email protected] Webs We further certifies that neither the applicant nor any party to t his app l ic at io n, as d ef i ned i n 47 CF R Ch. 1.2002(b), is s ubject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant : ARRIS Address : 101 Tournament Drive, Horsham Pennsylvania,United States,19044 Signature : _________________________________ Name and Job Title. : Jorge Villarreal / Product Compliance Director E- mail : [email protected] Te l . : 215-323-1697

Date: April 27, 2021 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for confidentiality FCC ID: ACQ-STREAMTV To whom it may concern: Short-term confidentiality Pursuant to DA 04-1705 of the Commission’s pubic notice, in order to comply with the marketing regulations in 47CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days ☒ Internal Photographs ☒ External Photographs ☒ User's manual ☒ Test Set up photo Permanent confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: ☒ Block Diagram ☒ Schematics ☒ Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Applicant : ARRIS Address : 101 Tournament Drive, Horsham Pennsylvania,United States,19044 Signature : _________________________________ Name and Job Title. : Jorge Villarreal / Product Compliance Director E- mail : [email protected] Te l . : 215-323-1697

Date: April 27, 2021 Subject: Ad Hoc Mode Function Declaration FCC ID: ACQ-STREAMTV To Whom it may concern, We, ARRIS, declare that the device does not support any non-US c ha nne ls, c ountry code selection, or Channel 12 and 13 in 2.4 GHz band in all the operational mode(s). Also, the client sof tware and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master device. The device does not support DFS detection capability. This includes restriction on transmissions for beacons and support f or ad-hoc peer-to-peer modes. Regards, Applicant : ARRIS Address : 101 Tournament Drive, Horsham Pennsylvania,United States,19044 Signature : _________________________________ Name and Job Title. : Jorge Villarreal / Product Compliance Director E-mail : [email protected] Te l . : 215-323-1697

Date: April 27, 2021 UNII Declaration Letter We, ARRIS, declare the following information for FCC equipment authorization, Device FCC ID: ACQ-STREAMTV (1) DFS Device -- Client with Radar detection capability, Client without radar detection capability (2) Active / Passive Scanning, Ad hoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode capability Access point capability 5150 – 5250 Yes , No Yes , No Yes , No Yes , No 5250 – 5350 Yes , No Yes , No Yes , No Yes , No 5470 – 5725 Yes , No Yes , No Yes , No Yes , No 5725 – 5850 Yes , No Yes , No Yes , No Yes , No (3) Country code selection ability - Yes , No If no, pls explain how was implemented : Proprietary Software is restricted from modification by end user (4) Meet 15.202 requirement - Yes , No , pls check below: A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network. (5) For client devices that have software configuration control to operate in different modes (active scanning in some and passive scanning in others) in different bands (devices with multiple equipment classes or those that operate on non-DFS frequencies) or modular devices which configure the modes of operations through software, the application must provide software and operations description on how the software and / or hardware is implemented to ensure that proper operations modes can not be modified by end user or an installer. Apply , No Apply , (If apply , pls help to provide explanation on how it was implement (By hardware or software , and how software was controlled) Jorge Villarreal / Product Compliance Director ARRIS Tel: 215-323-1697 E-mail: [email protected]

Project No.: 131101 Page No. : 1 of 20 Photographs of EUT Project No.: 131101 Page No. : 2 of 20 Project No.: 131101 Page No. : 3 of 20 Project No.: 131101 Page No. : 4 of 20 Project No.: 131101 Page No. : 5 of 20 Project No.: 131101 Page No. : 6 of 20 Project No.: 131101 Page No. : 7 of 20 Project No.: 131101 Page No. : 8 of 20

FCC ID:ACQ-STREAMTV Rating:5V 2A FCC ID:ACQ-STREAMTV Rating:5V 2A SKU:F3544K9201SN:MA2042EC0024MAC:DDDDDDDDDDDD H/W VER:00.00F/W:00.00.00.00.00 D/C:20210109 Designed in New York Assembled in Vietnam FCC ID:ACQ-STREAMTV Rating:5V 2A FCC ID:ACQ-STREAMTV Rating:5V 2A E214601 E214601 E214601 E214601 FCC ID: ACQ-STREAMTV

Project No.: 131101 Page No. : 9 of 20 Project No.: 131101 Page No. : 10 of 20 Project No.: 131101 Page No. : 11 of 20 Project No.: 131101 Page No. : 12 of 20 Project No.: 131101 Page No. : 13 of 20 Project No.: 131101 Page No. : 14 of 20 Project No.: 131101 Page No. : 15 of 20 Project No.: 131101 Page No. : 16 of 20 Project No.: 131101 Page No. : 17 of 20 Project No.: 131101 Page No. : 18 of 20 Project No.: 131101 Page No. : 19 of 20 Project No.: 131101 Page No. : 20 of 20 USB chip: GL852G USB chip: GL850G

Report No.: FA131101 Page : 1 of 7 Report Version: Rev. 01 FCC RF Exposure Report FCC ID : ACQ-STREAMTV Equipment : Stream TV Model No. : Stream TV Brand Name : Verizon Applicant : ARRIS Address : 101 Tournament Drive, Horsham Pennsylvania, United States,19044 Standard : 47 CFR FCC Part 2.1091 Received Date : Mar. 11, 2021 Tested Date : Mar. 16 ~ Apr. 30, 2021 We, International Certification Corporation, would like to declare that the tested sample has been evaluated and in compliance with the requirement of the above standards. The test results contained in this report refer exclusively to the product. It may be duplicated completely for legal use with the approval of the applicant. It shall not be reproduced except in full without the written approval of our laboratory. Reviewed by: Approved by: Along Chen / Assistant Manager Gary Chang / Manager Report No.: FA131101 Page : 2 of 7 Report Version: Rev. 01 Table of Contents 1 MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4 1.2 MPE EVALUATION FORMULA ............................................................................................................. 4 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE ................................... 4 1.4 MEASUREMENT UNCERTAINTY ......................................................................................................... 4 1.5 MPE EVALUATION RESULTS .............................................................................................................. 5 1.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION ................................................................ 6 2 TEST LABORATORY INFORMATION ................................................................................................. 7 Report No.: FA131101 Page : 3 of 7 Report Version: Rev. 01 Release Record Report No. Version Description Issued Date FA131101 Rev. 01 Initial issue May 13, 2021 Report No.: FA131101 Page : 4 of 7 Report Version: Rev. 01 1 MPE EVALUATION OF MOBILE DEVICES 1.1 LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE Frequency Range (MHz) Power Density (mW /cm 2 ) Averaging Time (minutes) 300~1500 F/1500 30 1500~100000 1.0 30 1.2 MPE EVALUATION FORMULA Pd = 2 **4RPi Pt Where Pd= Power density in mW/cm 2 Pt= EIRP in mW Pi= 3.1416 R= Measurement distance 1.3 DEVIATION FROM TEST STANDARD AND MEASUREMENT PROCEDURE None 1.4 MEASUREMENT UNCERTAINTY The measurement uncertainties given below are based on a 95% confidence level (based on a coverage factor (k=2)). Parameters Uncertainty Conducted power ±0.808 dB Declaration of Conformity: The test results with all measurement uncertainty excluded are presented in accordance with the regulation limits or requirements declared by manufacturers. Comments and Explanations: The declared of product specification for EUT presented in the report are provided by the manufacturer, and the manufacturer takes all the responsibilities for the accuracy of product specification. Report No.: FA131101 Page : 5 of 7 Report Version: Rev. 01 1.5 MPE EVALUATION RESULTS Non-beamforming Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) *Ratio Pass / Fail 2412~2462 (Wi-Fi) 23.52 24.0 3.02 20 0.100 1 0.100 Pass 5150~5250 (Wi-Fi) 23.09 23.5 3.84 20 0.108 1 0.108 Pass 5250~5350 (Wi-Fi) 22.92 23.0 3.84 20 0.096 1 0.096 Pass 5470~5725 (Wi-Fi) 23.51 24.0 3.84 20 0.121 1 0.121 Pass 5725~5850 (Wi-Fi) 25.77 26.0 3.84 20 0.192 1 0.192 Pass 2402-2480 (BT EDR) 2.26 2.5 2.7 20 0.001 1 0.001 Pass 2402-2480 (BT LE) 1.85 2 2.7 20 0.001 1 0.001 Pass *Ratio = Power density / Limit. Beamforming Frequency Range (MHz) Maximum Conducted Power (dBm) Rated Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) *Ratio Pass / Fail 5150~5250 (Wi-Fi) 20.08 20.5 6.84 20 0.108 1 0.108 Pass 5250~5350 (Wi-Fi) 19.91 20 6.84 20 0.096 1 0.096 Pass 5470~5725 (Wi-Fi) 20.50 21 6.84 20 0.121 1 0.121 Pass 5725~5850 (Wi-Fi) 22.76 23 6.84 20 0.192 1 0.192 Pass DG = Directional Gain=10 * log((10 3.84/20 +10 3.82/20 ) 2 /2=6.84 dBi Report No.: FA131101 Page : 6 of 7 Report Version: Rev. 01 1.6 MPE EVALUATION OF SIMULTANEOUS TRANSMISSION Non-beamforming Mode Max Ratio of Each Mode Wi-Fi 2.4 GHz 0.100 Wi-Fi 5 GHz 0.192 BT 0.001 Sum (Wi-Fi 2.4 GHz+ BT) 0.101 Sum (Wi-Fi 5 GHz+ BT ) 0.193 Limit 1 Pass / Fail Pass Beamforming Mode Max Ratio of Each Mode Wi-Fi 2.4 GHz 0.100 Wi-Fi 5 GHz 0.192 BT 0.001 Sum (Wi-Fi 2.4 GHz+ BT) 0.101 Sum (Wi-Fi 5 GHz+ BT ) 0.192 Limit 1 Pass / Fail Pass Report No.: FA131101 Page : 7 of 7 Report Version: Rev. 01 2 Test laboratory information Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and one of the widest certification extents in the business. International Certification Corporation (EMC and Wireless Communication Laboratory), it is our definitive objective is to institute long term, trust-based associations with our clients. The expectation we set up with our clients is based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff. Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our website http://www.icertifi.com.tw. Linkou Kwei Shan Kwei Shan Site II Tel: 886-2-2601-1640 Tel: 886-3-271-8666 Tel: 886-3-271-8640 No.30-2, Ding Fwu Tsuen, Lin Kou District, New Taipei City, Taiwan (R.O.C.) No.3-1, Lane 6, Wen San 3rd St., Kwei Shan Dist., Tao Yuan City 33381, Taiwan (R.O.C.) No.2-1, Lane 6, Wen San 3rd St., Kwei Shan Dist., Tao Yuan City …
