ADV0602903Scanning Receiver

200018 User’s Guide Draft R adioShack 2000018/PRO-18 User’s Guide iSCAN Digital Trunking Scanner Thank you for purchasing your iScan Digital Trunking Scanner from RadioShack. Please read this user’s guide before installing, setting up, and using your new scanner. Table of Contents will add Introduction Welcome to iSCAN Digital, an exciting new way to enjoy the hobby of scanning two-way digital and analog radio communications, including police, fire, EMS, amateur, government, and other channels. iSCAN Digital combines the simplicity and ease-of-use of a portable media player with the power and sophistication of a state-of-the-art scanning receiver. iSCAN Digital is easy to use for both beginners and experts. In addition, iSCAN Digital is equipped with the entire USA RadioReference database in a special on-board Library, giving you instant access to the frequencies and systems used by public safety, local government, and business all over the United States! Please take a few moments to read this manual carefully before using iSCAN Digital. iSCAN Digital is unlike any other scanner ever produced, and we want you to fully understand how it can maximize your enjoyment of the scanning hobby. Package Contents iSCAN Digital Antenna USB Cable MicroSD Card (inside the scanner) CD-ROM User’s Guide Quick Start Warning Always protect iSCAN Digital from exposure to extreme heat or cold temperatures iSCAN Digital is not waterproof. Do not expose it to rain, extreme high humidity, or moisture. Page 1 200018 User’s Guide Draft F eatures Easy to Understand User Interface - A simplified keypad and display with familiar Play (Scan), Pause, Skip and Navigation controls make it easy for you to use your PRO-18. The Complete RadioReference USA Database On MicroSD Card - The entire USA database from www.radioreference.com is stored on a standard MicroSD Card that is included with the PRO-18, giving you access to the most comprehensive radio data available without connecting the PRO-18 to a computer or the Internet! Improved P25 Functionality - The PRO-18 detects and masks encrypted voice audio, and decodes RadioID/TalkgroupID data embedded in voice packets. Upgradeable CPU Firmware, DSP Firmware and Library - Keep your radio’s CPU and DSP firmware current with enhancements and updates as they become available using the included PRO-18 PC Application. Full USB Interface - Industry standard Composite Device USB interface with USB Mass Storage Device (MSD) and Serial Data (CDC) support. Access the MicroSD card without removing it from the radio, stream decoded Control Channel data and upgrade your radio’s firmware over USB. Powerful PRO-18 PC Application Software Included - Customize existing programming or add new objects to scan, and keep your PRO-18 firmware and Library data up to date. SKYWARN Storm Spotter Functionality - Instant access to frequencies used by storm spotter networks. You can monitor storm conditions as they occur, and become aware of dangerous conditions before the media or emergency management officials are able to announce them to the general public. SAME and All Hazards Weather Alerting - The PRO-18 features a SAME Standby Mode, alerting you to severe weather and other hazards in the specific area(s) that you select. The PRO-18 can also check your local NOAA weather frequency periodically, even while scanning, and alert you when an All Hazards alert occurs. Multi-System Trunking - Scans most common digital and analog trunked radio system signaling formats, including P25, Motorola, EDACS and LTR. Both talkgroup and individual call monitoring are supported. Powerful Signal Stalker II - Quickly sweeps the PRO-18’s frequency ranges for transmissions from nearby sources. When a nearby transmission is found, the PRO-18 automatically tunes to that frequency. 101 Playlists - The PRO-18 provides the unprecedented ability to group your stored objects using up to 100 Playlists plus a special Skywarn playlist. Objects can be mapped to as many Playlists as desired, giving you complete flexibility for grouping objects and selecting groups in any combination for Page 2 200018 User’s Guide Draft scan ning. Built-in Service Searches - Predefined service search ranges make it easy to find activity in your area. Audible alarms - Programmable audible alarms can be configured to sound when certain objects are active. Signal Strength Meter – Shows relative strength of received signals. Slim, compact case design and large speaker - Designed for durability, one-handed operation and ease of use. The FCC Wants You To Know This equipment has been tested and found to comply with the limits for a scanning receiver, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. There is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: . Reorient or relocate the receiving antenna. . Increase the separation between the equipment and receiver. . Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Scanning Legally Your scanner covers frequencies used by many different groups including police and fire departments, ambulance services, government agencies, priv…

Text truncated - open the document above for the full version.

Phone: +813-5439-3611 SHIBA NO.3 AMEREX BLDG. 3-12-17 MITA, MINATO-KU TOKYO 108-0073, JAPAN Fax: +813-5439-3644 GENERAL RESEARCH OF ELECTRONICS, INC. December 13, 2010 Federal Communications Commission Authorization and Evaluation Division Laboratory Division 7435 Oakland Mills Road Colombia, MD 21046 Ref.: FCC ID: ADV0602903 This is to clarify that the above equipment is incapable of operating (tuning) or readily being altered by the user to operate, within the frequency bands to the Cellular Radiotelephone Service. The frequencies in question are deleted from the ROM during manufacture, and cannot be restored through any readily available process or component such as: installation of cuts, jumper wires, resistors, diodes, or plug-in IC’s; deletion of such items; or reprogramming via access codes or external devices such as a personal computer. The receiver is incapable of converting digital cellular transmissions to analog voice audio. Assessing the vulnerability of the receiver to possible modification The receiver has the possibility of reducing the threshold value to discern transmissions from the Cellular Radiotelephone Service by making modification such as adding jumper wire to the UHF RF tuning circuit and UHF mixer circuit. Design features that prevent modification of the receiver to receive Cellular Service The scanning receiver is designed to prevent any attempt for the user to modify the receiver to receive transmissions from the Cellular Radiotelephone Service by using epoxy to cover the required parts of the UHF RF tuning circuit. PRODUCT DEVELOPMENT & MANUFACTURING GENERAL RESEARCH OF ELECTRONICS, INC. Testing method used to determine compliance with the 38 dB rejection ratio Test set-up: Equipment Setup Block Diagram Test Test frequencies: 869.00MHz, 877.03MHz, 885.06MHz, 893.09MHz easurement method (1) o perform initial screening, adjust EUT’s for the Squelched Threshold to suppress audio output. quelch Threshold sensitivity of -6 dBuV.) This is approximately 66-38=28dB above the FCC limit.) (3) Turn EUT on and search cellular frequencies on all of the receiving ranges. (4) List all detected frequencies if EUT detects any. (5) Reprocedure for each of the other cellular test frequencies. (6) To determine actual image rejection ratio for a detected frequency, perform the following steps. (7) Set both of EUT and SSG’s frequency to the frequency gained by the above screening. INAD and record the gained level. Note the gained SG’s level is EUT‘s receiving sensitivity. conditions: AF Signal : 1 kHz FM Deviation : +/- 3kHz AM Modulation : 60 % 824.00MHz, 832.03MHz, 840.06MHz, 848.09MHz M T (2) Set SSG’s frequency to a cellular band test frequency and apply 60dBuV RF level to EUT. (The 60dBuV signal level corresponds to approximately 66dB above the S eat the above p (8) Adjust SSG’s RF output on EUT for 12dB S S

External EUT Photos ADV0602903

CAT. NO. 2000018PRO-18 HANDHELD iSCAN DIGITAL TRUNKING SCANNER FCC ID: ADV0602903 POWER: 4 "AA" BATTERIES OR EXT POWER DC 5V 500mA FREQ. RANGE: 25-54, 108-174, 216.0025-512, 764-823.9875, 849-868.9875, 894-960, 1240-1300 MHz CUSTOM MANUFACTURED IN CHINA FOR RADIOSHACK CORPORATION, FORT WORTH, TX 76102 WARNING: MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR RADIOTELEPHONE SERVICE SIGNALS IS PROHIBITED UNDER FCC RULES AND FEDERAL LAW. S/NO. ® 50.5mm 31.5mm 4-R2 REMARKS 1. MATERIAL: PLASTIC FOIL (0.1+0.03mm) 2. FINISH: BLACK BASE/SILVER LETTERS MATT COATING #0602903 (PRO-018/iSCAN Digital) MODEL LABEL AUG. 20 2010 Nov. 19 2010 GR-10D-2330 S. Yamamoto M. Ishizuka Tolerance: -0.5mm THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. SHEET DRAWING No. REVISION DRAWN APPRVD Signature Signature Date Date TITLE GENERAL RESEARCH OF ELECTRONICS, INC. A B C Revision Note Date Changed by Date Approved by Rev. No. TOLERANCE ABCD ANGLE CLASS DIVISION ≦５ ５＜ ≦２０ ２０＜ ≦５０ ５０＜ ≦１００ １００＜ 0.05 0.1 0.15 0.2 0.3 0.20 0.1 0.15 0.2 0.3 0.4 0.40 0.15 0.2 0.3 0.4 0.5 1.5 0.2 0.3 0.4 0.5 0.6 3

ADV0602903 MODEL LABEL LOCATION The §15.19(a)(3) statement GENERAL RESEARCH OF ELECTRONICS,INC. FCC ID NO. WARNING RATING LABEL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. OPEN

GENERAL RESEARCH OF ELECTRONICS, INC. FCC ID: ADV0602903 FUNCTION OF EACH SEMICONDUCTOR OR OTHER ACTIVE CIRCUIT DEVICE [2.983(6)] 1. Transistor, FET Q1DTA114EUASWITCHING Q2UMD2NSWITCHING Q32SC4094(R37) or 2SC4094(R38)RF AMP Q42SC4226(R25)RF AMP Q5DTC114YUA or UN5214SWITCHING Q6UMD2NSWITCHING Q72SC4094(R37) or 2SC4094(R38)RF AMP Q82SC4116(Y)AGC AMP Q92SC42502nd MIXER Q102SC4215(O)2nd IF AMP Q112SC4116(GR)AGC AMP Q12DTC114YUA or UN5214SWITCHING Q13DTC114YUA or UN5214SWITCHING Q14DTC114YUA or UN5214SWITCHING Q152SC4215(O) or 2SC4226(R25)2nd IF AMP Q162SC4215(O) or 2SC4226(R25)2nd IF AMP Q17DTA114EUASWITCHING Q18DTC114YUA or UN5214SWITCHING Q192SC4226(R25)SWITCHING Q202SC4226(R25)VCO 1 Q21DTC114YUA or UN5214SWITCHING Q222SC4226(R25)VCO 2 Q23DTC114YUA or UN5214SWITCHING Q242SC4226(R25)BUFFER VCO 1&2 Q252SC4116(GR)LOW PASS FILTER Q262SK880(Y)LOW PASS FILTER Q272SK880(Y)LOW PASS FILTER Q282SC4116(GR)LOW PASS FILTER Q292SC4251 or MT3S16U or KTC4082/PVCO 3 Q302SC4250 or 2SC4251 BUFFER VCO 3 /or MT3S16U or KTC4082/P Q31DTA114EUAFILTER SWITCHING Q322SD2150T100RMuting Q33EMD12SWITCHING Q34EMD12SWITCHING Q35SSM3K101TUSWITCHING Q301DTC114YUASWITCHING Q3022SA1577(Q)LED DRIVER Q3032SA1577(Q)LED DRIVER Q304NOT USED Q3052SC4116(GR)RESET SWITCH Q306NOT USEDLED DRIVER Q307NOT USEDLED DRIVER Q308SSM3K101TUSWITCHING Q309SSM6J53FESWITCHING Q310SSM6J53FESWITCHING Q311DTC114YUASWITCHING Q312DTC114YUASWITCHING Q3132SC4117(GR)SWITCHING Q3142SB1412SWITCHING Q3152SC4116(GR)SWITCHING Q3162SC4116(GR)LED DRIVER Q317SSM6J53FEPOWER SWITCHING Q318SSM6J53FEPOWER SWITCHING Q3192SC4116(GR)POWER SWITCHING GENERAL RESEARCH OF ELECTRONICS, INC. FCC ID: ADV0602903 FUNCTION OF EACH SEMICONDUCTOR OR OTHER ACTIVE CIRCUIT DEVICE [2.983(6)] 2. IC IC1HD74AC164BAND SELECT/ATT.CONT. or TC74VHC164 IC2uPC2757TB1st MIXER IC3NJM2406DETECTOR COMPARATOR IC4MB15F07SLPLL IC5TK11819MDC TO DC CONVERTOR IC6NJM2904MCOMPARATOR / NOISE AMP IC7TK10931V3rd IF AMP / 3rd LO / 3rd MIX / NOISE AMP / QUADRATURE DETECTOR IC8NJM13403VBUFFER/PRE AMP IC9TC74HC4066AFTSWITCHING IC10TC4S66FSWITCHING IC11TK11233CUCBVOLTAGE REGULATOR IC12NJU7086FR3AUDIO AMP IC13NOT USED IC14TC4S66FSWITCHING IC301M30626FHPGP#U5CCPU (GRE-0602903) IC302S-1206B18-M3T1GVOLTAGE REGULATOR IC303NOT USED IC304BA033CC0FPVOLTAGE REGULATOR IC305S-1206B14-M3T1GVOLTAGE REGULATOR IC306TLV320AIC14KIDBTRCODEC IC307S-1206B33-U3T1GVOLTAGE REGULATOR IC308BD8311NUVSW REGULATOR IC309TMS320VC5507PGEDSP IC310PIC18F46J50I/PTPIC MICON
