AHV-SID2BHMI Controller

Load Assist Incorporating SID 2.0 Foreword This appendix is intended to serve as a supplement to the Operator’s Manual of the machine and should be read together with the manual. Keep the appendix, together with the Operator’s Manual of the machine, in the cab, so that it is always at hand. Replace it immediately, if it is lost. NOTE! If this appendix covers more than one machine, the information applies to all machines unless otherwise indicated. A lot of work has been spent on the machine's design and manufacture to make it as effective and safe as possible. Accidents that occur in despite of this can most often be contributed to the human factor. A safety-conscious person and a well-maintained machine make a safe, efficient, and profitable combination. Therefore, read the safety instructions and follow them. We continuously strive to improve our products and to make them more effective by changes to their design. We reserve the right to do this without committing ourselves to introduce these improvements on already delivered products. We also reserve the right to change data and equipment, as well as instructions for service and maintenance without prior notice. OPERATOR'S MANUAL Table of contents Load Assist TPMS Safety regulations It is the operator's obligation to know and follow the applicable national and local safety regulations. The safety instructions in this manual only apply to cases where there are no national or local regulations. Alphabetical index PUB 20049540-G The original language is English. Original instructions. 2021.05 Copyright © 2021, Volvo Construction Equipment. All rights reserved. 2 Foreword DANGER The safety symbol combined with this signal word indicates a hazardous situation which, if not avoided, will result in death or serious injury. Danger is limited to the most extreme situations. WARNING The safety symbol combined with this signal word indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION The safety symbol combined with this signal word indicates a hazardous situation which, if not avoided, could result in moderate or minor injury. NOTICE Indicates a potentially hazardous situation which may result in machine damage. NOTE! It is used to highlight information for installing, use, or maintenance that is important but is not safety-related. Table of contents 3 Table of contents Foreword .........................................................1 Load Assist.....................................................5 Screen views ................................................... 6 Settings ......................................................... 12 Load weighing ............................................... 38 Task mode .................................................... 61 Map ............................................................... 69 Rear vision system ...................................... 117 View selector ............................................... 118 Messages .................................................... 119 Maintenance ................................................ 121 TPMS ............................................................ 122 Settings ....................................................... 124 Alphabetical index .................................. 129 Load Assist 5 A B V1151437 A Display B Recommended location for printer Load Assist Load Assist is intended to be used as an information system to facilitate the user’s tasks. This appendix does not release the operator from following the instructions and cautionary measures described in the ordinary operator’s manual to the machine. Load Assist is a feature in the Co-pilot. It is basing on the load weighing system and can be complemented with features like: Task mode, see page 61. Map, see page 69. Rear vision system, see page 117. Load Weighing is a system that weighs the load in/ on the attachment during a continuous lifting motion. An audible signal confirms that the weight is measured correctly. The system summarizes the load in every cycle and the progress can be followed in the display. For more information, see page 40. Running-in instructions New machines may need up to 200 working hours to reach a stable accuracy due to the initially higher friction in the boom linkage but should be used as normal during the running-in period. Known weight calibration is recommended after the first 200 working hours to maintain a good weighing accuracy when using these buckets. Regular greasing is important to maintain a low friction in the lift arm system. Follow the greasing intervals in the machine Operator's Manual. Central lubrication system is recommended. Load Assist 6 Screen views Screen views Load Assist 8 Screen views Main screen NOTE! The appearance of the main screen differs depending on the current settings etc. NOTE! The main screen information here is shown as when Known weight calibrated buckets are used. There are two decimals on load value when Known weight calibrated buckets are used and one decimal when other attachments are used. Appearance and items also differ slightly between these two accuracy levels. Load Assist 9 Screen views Settings 1. Settings, see page 12. Load weighing 2. Current load, see page 42. 3. Locked/unlocked load, see page 43. 4. Forced unload, see page 45. 5. Forced partial unloading, see page 46. 6. Attachment type, see page 43. 7. Attachment angle, see page 43. 8. Known weight calibrated buckets, see page 44. 9. Weight adjustment of the current attachment, see page 57. 10. Machine inclination, transversal (“roll”), see page 44. 11. Boom angle, see page 45. 12. Machine inclination, longitudinal (“pitch”), see page 45. Task mode 13. Task mode, see page 61. 14. Delete last load, see page 65. 15. Pause view, see page 65. 16. Print receipt, see page 65. Map 17. Centering/Compass view, see page 77. Rear vision system 18. Rear vision system, see page 117. Others 19. View selector, see page…

Text truncated - open the document above for the full version.

CPAC SYSTEMS AB Bergskroken 3 SE-431 37 Mölndal Phone: +46 (0)31 352 16 00 Fax: +46 (0)31 352 16 99 www.cpacsystems.se Copyright by CPAC Systems AB. All rights reserved Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: CPAC Systems AB FCC ID: AHV-SID2B To whom it may concern, CPAC Systems AB (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Nemko Scandinavia AS if there is any change in the status identified above. Emma Lindqvist Regulatory Affairs Manager CPAC Systems AB 2023/11/29

CPAC SYSTEMS AB Bergskroken 3 SE-431 37 Mölndal Phone: +46 (0)31 352 16 00 Fax: +46 (0)31 352 16 99 www.cpacsystems.se Copyright by CPAC Systems AB. All rights reserved Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both Volvo Construction Equipment North America, LLC (“Agent”) and CPAC Systems AB (“Applicant”) acknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I, Emma Lindqvist HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Nemko Scandinavia AS if there is any change in the status identified above. Applicant Company Name: CPAC Systems AB Contact Name : Emma Lindqvist Address: Bergskroken 3, 401 26 Gothenburg, Sweden Telephone No : +467055948961 Email: [email protected] Applicant FRN: 0025650813 Signature: ____________________________________ Date: 2023/05/02___________________________________ I John Bartz, HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to all certification applications to the FCC submitted by above applicant and agree to immediately notify the FCC and Nemko Scandinavia AS if there is change in this representation. Agent Company Name: Volvo Construction Equipment North America, LLC Contact Name: John Bartz Address: 304 Volvo Way, Shippensburg, PA, 17257 Telephone No: 828 674-5456 Email: [email protected] Agent FRN: 0025715467 Signature: Date: 5/3/2023

CPAC SYSTEMS AB Bergskroken 3 SE-431 37 Mölndal Phone: +46 (0)31 352 16 00 Fax: +46 (0)31 352 16 99 www.cpacsystems.se Copyright by CPAC Systems AB. All rights reserved 1/9/2023 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 AUTHORITY TO ACT AS AGENT - FCC On our behalf, I appoint Nemko North America, Inc., to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko North America Inc., still resides still resides with us. Sincerely, Printed name: Emma Lindqvist

CPAC SYSTEMS AB Bergskroken 3 SE-431 37 Mölndal Phone: +46 (0)31 352 16 00 Fax: +46 (0)31 352 16 99 www.cpacsystems.se Copyright” by CPAC Systems AB. All rights reserved 11/29/2023 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: AHVͲSID2B Pursuant to Sections 0.4 57(d) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT LONG-TERM CONFIDENTIALITY: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation When the device is marketed before the requested number of days listed above, the grantee will inform the TCB to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. The above information contains trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Sincerely, Signed : Printed name: Emma Lindqvist Title: Regulatory Affairs Manager

Software Security Description – KDB 594280 D02v01r03 Section II General Description 1. Describe how any software/firmware updates for elements than can affect the device’s RF parameters will be obtained, downloaded, validated and installed. For software that is accessed through manufacturer’s website or device’s management system, describe the different levels of security as appropriate. OTA packages will be accessed by the clients play store. Program packages are encrypted by the client store, and the firmwares are encrypted by our private keys and Androids- and QUALCOMM’s security models Firmware is used as delivered from supplier and no modifications are made by development activities or the unit itself. 2. Describe the RF parameters that are modified by any software/firmware without any hardware changes. Are these parameters in some way limited such that any other software/firmware changes will not allow the device to exceed the authorized RF characteristics? We only follow the rf settings defined by the standard android open source project packages. 3. Describe in detail the authentication protocols that are in place to ensure that the source of the RF-related software/firmware is valid. Describe in detail how the RF-related software is protected against modification. The firmwares are encrypted by our private keys and Linux, Androids and qualcomms security models. 4. Describe in detail any encryption methods used to support the use of legitimate RF-related software/firmware. The firmwares are encrypted by our private keys and Linux, Androids and qualcomms security models 5. For a device that can be configured as a master and client (with active or passive scanning), explain how the device ensures compliance for each mode? In particular if the device acts as master in some band of operation and client in another; how is compliance ensured in each band of operation? Settings are configured from factory and unavailable to third party. Third-Party Access Control 1. Explain if any third parties have the capability to operate a U.S.-sold device on any other regulatory domain, frequencies, or in any manner that may allow the device to operate in violation of the device’s authorization if activated in the U.S. No RF configuration is permitted by any user. In order to change such parameters, the device needs to be connected by wire to specific after-market tool available only at authorized dealers. 2. Describe, if the device permits third-party software or firmware installation, what mechanisms are provided by the manufacturer to permit integration of such functions while ensuring that the RF parameters of the device cannot be operated outside its authorization for operation in the U.S. In the description include what controls and/or agreements are in place with providers of third-party functionality to ensure the devices’ underlying RF parameters are unchanged and how the manufacturer verifies the functionality. We do not allow third party software to modify RF parameters. 2. For Certified Transmitter modular devices, describe how the module grantee ensures that host manufacturers fully comply with these software security requirements for U-NII devices. If the module is controlled through driver software loaded in the host, describe how the drivers are controlled and managed such that the modular transmitter RF parameters are not modified outside the grant of authorization. We only follow the rf settings defined by the standard android open source project packages. Software Configuration Description – KDB 594280 D02v01r03 Section III USER CONFIGURATION GUIDE 1. Describe the user configurations permitted through the UI. If different levels of access are permitted for professional installers, system integrators or end-users, describe the differences. No RF configuration is permitted by any kind of user. a. What parameters are viewable and configurable by different parties? No RF configuration is permitted by any kind of user. b. What parameters are accessible or modifiable by the professional installer or system integrators? (1) Are the parameters in some way limited, so that the installers will not enter parameters that exceed those authorized? No RF configuration is permitted by any kind of user. (2) What controls exist that the user cannot operate the device outside its authorization in the U.S.? No RF configuration is permitted by any user. In order to change such parameters, the device needs to be connected by wire to specific after-market tool available only at authorized dealers. c. What parameters are accessible or modifiable by the end-user? (1) Are the parameters in some way limited, so that the installers will not enter parameters t exceed those authorized? No RF configuration is permitted by any kind of user. (2) What controls exist that the user cannot operate the device outside its authoriza in the U.S.? No RF configuration is permitted by any kind of user. d. Is the country code factory set? Can it be changed in the UI? (1) If it can be changed, what controls exist to ensure that the device can only operate within its authorization in the U.S.? Country code will be set at the dealer. Country code will be set using Volvo aftermarket tool and will not be accessible through the UI. e. What are the default parameters when the device is restarted? Default parameters will be as for first activation at dealer. 2. Can the radio be configured in bridge or mesh mode? If yes, an attestation may be required. Further information is available in KDB Publication 905462 D02. No. 3. For a device that can be configured as a master and client (with active or passive scanning), if this is user configurable, describe what controls exist, within the UI, to ensure compliance for each mode. If the device acts as a master in some bands and client in others, how is this configured to ensure compliance? The device cannot be master and client at the same time. 4. For a device that can be configured as di…

Text truncated - open the document above for the full version.

1 Jin Xu From:Emma Lindquist <[email protected]> Sent:Thursday, March 30, 2023 6:30 AM To:Emma Lindqvist 2 3 4 5 6 7 8 9 10 11 12 13 14 Med vänlig hälsning Emma Lindqvist

1 Jin Xu From:Emma Lindquist <[email protected]> Sent:Thursday, March 30, 2023 3:16 AM To:Emma Lindqvist 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 Med vänlig hälsning Emma Lindqvist

FCC ID: AHV-SID2B FCC RF Exposure Compliance for Simultaneous Operations Configurations for Simultaneous OperationsConfiguration 1: BT/BLE + GSM/WCDMA/LTEConfiguration 2: WiFi 2.4GHz + GSM/WCDMA/LTEConfiguration 3: WiFi 5GHz + GSM/WCDMA/LTEPower Density is calculated from Maximum Conducted Power and Antenna Gain at prediction distanceMaximum of Conducted and Radiated Output Power is used in the calculation. Therefore negative values for antenna gain have been replaced by 0 dBi. RF Function BT BLE WiFi 2.4 WiFi 5 GSM850 GSM1900 WCDMA B2 WCDMA B4 WCDMA B5 LTE B2 LTE B4 LTE B5 LTE B7 LTE B12 LTE B13 LTE B25 LTE B26 LTE B38 LTE B41 Frequency (MHz) 2402 2402 2412 5200 824.2 1850.2 1852.4 1712.4 826.4 1850.7 1710.7 824.7 2502.5 699.7 779.5 1850.7 824.7 2572.5 2498.5 Conducted Output Power (dBm) 3.00 1.00 20.00 16.00 26.00 23.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 25.00 Tune Up Tolerance (dB) 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 Output Power (W) 0.002 0.001 0.100 0.040 0.398 0.200 0.316 0.316 0.316 0.316 0.316 0.316 0.316 0.316 0.316 0.316 0.316 0.316 0.316 Antenna Gain (dBi) 7.50 7.50 11.50 11.50 5.00 7.00 7.00 7.00 5.00 7.00 7.00 5.00 6.00 5.00 5.00 7.00 5.00 6.00 6.00 Antenna Gain (Numeric) 5.62 5.62 14.13 14.13 3.16 5.01 5.01 5.01 3.16 5.01 5.01 3.16 3.98 3.16 3.16 5.01 3.16 3.98 3.98 Prediction Distance (cm) 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 Σ of MPE Time Averaged Duty Cycle (%) 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 ratios Calculated Power Density (W/m2) 0.022 0.014 2.810 1.119 2.505 1.989 3.153 3.153 1.989 3.153 3.153 1.989 2.505 1.989 1.989 3.153 1.989 2.505 2.505 Requirement (W/m2) 10.00 10.00 10.00 10.00 5.50 10.00 10.00 10.00 5.51 10.00 10.00 5.50 10.00 4.67 5.20 10.00 5.50 10.00 10.00 MPE ratio (PD/Req.) 0.002 0.001 0.281 0.112 0.455 0.199 0.315 0.315 0.361 0.315 0.315 0.362 0.250 0.426 0.383 0.315 0.362 0.250 0.250 Configuration 1 (MPE Ratio) 0.002 0.001 0.455 0.199 0.315 0.315 0.361 0.315 0.315 0.362 0.250 0.426 0.383 0.315 0.362 0.250 0.250 0.458 Configuration 2 (MPE Ratio) 0.281 0.455 0.199 0.315 0.315 0.361 0.315 0.315 0.362 0.250 0.426 0.383 0.315 0.362 0.250 0.250 0.736 Configuration 3 (MPE Ratio) 0.112 0.455 0.199 0.315 0.315 0.361 0.315 0.315 0.362 0.250 0.426 0.383 0.315 0.362 0.250 0.250 0.567 Requirement: Σ of MPE ratios ≤ 1 The maximum values for GSM/WCDMA/LTE and BT/BLE/WiFi is used in the above calculations.Antenna Gain BT BLE WiFi WiFi 2G+3G+4G Frequency (MHz) 2402 2402 2412 5500 750 850 1800 2550 2J4A50PCFa, Peak Gain (dBi) 3.0 3.0 3.0 3.5 2.0 2.0 2.7 2.0 2J4A50PCFa, Peak Gain, MIMO (dBi) 6.0 7.0 Volvo Base_Ant VT Full_Feat (dBi) 7.5 7.5 7.5 7.5 5.0 5.0 7.0 6.0 Volvo WLAN Interior (dBi) 4.0 4.0 4.0 4.0 Hirschman Interior Phone PK 2.5 3.0 3.5 1.0 The Antennas Volvo Base VT and WLAN Interior are used at the same time, however they will normally be mounted so that they are separated by more than the prediction distance.

2J4A50PCFa Product Datasheet Key Features www.2j-antennae.comwww.2j-antennasusa.com Page: 1/23 2 × 4G LTE/3G/2G MIMO, 2 × 2.4/5.0 GHz ISM MIMO and GNSS Adhesive Mount Cable 1 and 2: 4G LTE/3G/2G - 698-960 MHz - 1710-2170 MHz - 2500-2700 MHz Cable 3 and 4: 2.4/5.0 GHz ISM - 2410-2490 MHz - 4920-5925 MHz Cable 5: GPS/GLONASS/BeiDou/QZSS/Galileo - 1561-1606 MHz Adhesive Mount High Performance Ground Plane Independent Customizable Cable and Connector Dimensions: 61.8 x 155.6 x 17.0 mm Certificates: IP67, IP69, CE, Vibration www.2j-antennae.comwww.2j-antennasusa.com Page: 2/23 1. Antenna Description 2J4A50PCFa “The Condor Series” A stellar performance in a compact system With a size reduction of up to 50% in comparison with other antennas in the market and the highest performance for a 5-in-1 antenna solution, single package the Condor 2J4A50PCFa antenna is the most competitive solution on the market. Users can opt for other configurations in the same enclosure such as 2-in-1, 3-in-1 or 4-in-1 antenna as per their needs, please check our website or contact our sales team for questions and details. If you are looking for an antenna that is sleek in design and makes no compromises on efficiency and performance, then 2J4A50PCFa is the best option. Engineered according to the latest technological advancements, this antenna provides LTE-MIMO (2x), 2.4/5.0GHz-MIMO (2x) and GNSS (1x) applications delivering very high-efficiency uninterrupted data transfers at maximum speed, achieved by the low Envelope Correlation Coefficient at the LTE-MIMO and WIFi-MIMO Antennas. Worldwide solution The key feature here is that 2J4A50PCFa is compatible with all LTE, 4G, 3G or 2G network ecosystems. With countless applications and customer- centric benefits, high-precision, low noise and low power consumption GNSS active ceramic antenna stands out among its competition, compatible for GPS, Glonass, BeiDou, Galileo and QZSS geolocation technologies. Dual high gain WiFi antennas are included in the package for all channels and standards in the 2.4 and 5.0GHz bands. Installation and Durability The 2J4A50PCFa can be easily installed or hidden in any part of your environment and application; on the top or bottom surfaces including windshields, dash, plastic, etc., as it comes equipped with a separate double adhesive pad that secures it safely. This product includes a low loss double shielded cable with fully customized length and connector that provides maximum antenna performance and reliability, avoiding drop connections, higher speed data, higher gain, etc. 5-in-1 feature allows for a quick handling in places where other solutions fail to implement and eliminates the need for the extensive labor involved in the installation of the product, saving time and resources. Not only does this technology assure smooth performance, but it also comes bearing safety guarantee. With IP67 and IP69K ingress rating, our product provides maximum protection against dust and water and allows high pressure and steam cleaning. Passing drop test and vibration provides extra robustness ensuring longevity of the product, making it a cost-effective solution. Certificates for independent lab test are available under NDA. The UV coating allows maximum protection against extensive outdoor use in extreme environments and temperatures. Typical applications - Infotainment systems - WiFi hotspot - HD video transmission - Dash cameras - Connected cars - Self-driving cars - Fleet management - Gateways - Routers - Public transportation - Logistics - And others Compatibility Standards LTE Cables - CAT 1 2 3 4 5 6 7 8 9 10 11 12 - NB-IoT, LTE-NB1, CAT-M1, CAT-M2WCDMA, UMTS, HSPA, - EDGE GRPS, GSM, CDMA 2.4/5.0 Cables - WiFi, Bluetooth, BLE, ISM - DSRC, V2V, V2X - Sigfox, LoRa, ZigBee, RPMA, LPWAN GPS/GLO/BEI Cable - GPS, GLONASS, BeiDou - Galileo, QZSS, L1, E1, B1 www.2j-antennae.comwww.2j-antennasusa.com Page: 3/23 2. Antenna and electrical specifications Parameters Standards Band (MHz) Frequency (MHz) Return Loss (dB) VSWR Efficiency (%) Peak Gain (dBi) Average Gain (dB) Impendance (Ohm) Polarisation Radiation Pattern Max. Input Power (W) Connector Type Cable Length Cable Type 700/850/900 698-960 ~-11.7 ~1.8:1 ~49.6 ~2.0 ~-3.1 4G LTE/3G/2G Antenna 2G, 3G, 4G LTE, Cat-X, Cat-M, Cat-NB (NB-IoT) 1700/1800/1900/2100 1710-2170 ~-18.0 ~1.3:1 ~52.6 ~2.7 ~-2.8 50 Linear Omni-Directional 25 SMA-Male Standard (Other Connectors Available) 300 cm Standard (Any Cable Length Available) LMR195 (Other Cables Available) 2600 2500-2700 ~-9.7 ~2.0:1 ~39.1 ~2.0 ~-4.1 Cable 1 Cable 2 Antenna Measurement Conditions: Mounted on Plastic Plate of 30 x 30 cm 200 cm of Cable LMR195 Measured in Certified CTIA 3D Anechoic Chamber Parameters Standards Band (MHz) Frequency (MHz) Return Loss (dB) VSWR Efficiency (%) Peak Gain (dBi) Average Gain (dB) Impendance (Ohm) Polarisation Radiation Pattern Max. Input Power (W) Connector Type Cable Length Cable Type 700/850/900 698-960 ~-11.1 ~2.0:1 ~47.4 ~1.7 ~-3.2 4G LTE/3G/2G Antenna 2G, 3G, 4G LTE, Cat-X, Cat-M, Cat-NB (NB-IoT) 1700/1800/1900/2100 1710-2170 ~-14.5 ~1.5:1 ~50.4 ~4.0 ~-3.0 50 Linear Omni-Directional 25 SMA-Male Standard (Other Connectors Available) 300 cm Standard (Any Cable Length Available) LMR195 (Other Cables Available) 2600 2500-2700 ~-18.5 ~1.3:1 ~41.2 ~3.1 ~-3.9 www.2j-antennae.comwww.2j-antennasusa.com Page: 4/23 Cable 4 Antenna Measurement Conditions: Mounted on Plastic Plate of 30 x 30 cm 200 cm of Cable LMR195 Measured in Certified CTIA 3D Anechoic Chamber Parameters Standards Band (MHz) Frequency (MHz) Return Loss (dB) VSWR Efficiency (%) Peak Gain (dBi) Average Gain (dB) Impendance (Ohm) Polarisation Radiation Pattern Max. Input Power (W) Connector Type Cable Length Cable Type 2.4 GHz 2410-2490 ~-24.0 ~1.1:1 ~45.3 ~3.0 ~-3.4 2.4/5.0 GHz ISM Antenna WiFi, BT, ZigBee, ISM 50 Linear Omni-Directional 25 RP-SMA-Male Standard (Other Connectors Available) 300 cm Standard (Any Cable Length Available) LMR195 Standard (Oth…

Text truncated - open the document above for the full version.

Datasheet 12.12.20191-4 ANTENNA WLAN INTERIOR Pt no. 23311706 / 920 638-001 ANTENNA INTERIOR WLAN Subject to alterations • Passive transmitting and reception antennas for BT/WLAN(2.4/5 GHz) • Low body height max. 5 mm • Coverage of frequency band BT/WLAN(2.4/5 GHz) • Mounting on plastic and glass materials Technical data* ParameterTR referenceRemarksUnitsValues Dimensions / Package35x45x5 mm Housing Protection ClassREQ 22379848-6 v1 REQ 22379848-8 v1 ISO20653IK 5k2 Operating TemperatureREQ 22379848-9 v1-40- +85°C Storage Temperature-40- +85°C Cable typeREQ 22379848-41 v1Dacar 302dB/m< 0.7 @ 2.5GHz < 1.2 @ 6GHz WLAN ParameterTR referenceFrequency rangesUnitsValues Frequency bandsREQ 22379848-53 v12400 ≤ f ≤ 2485 MHz 5150 ≤ f ≤ 5925 MHz Return LossREQ 22379848-54 v12400 – 2485 MHz 5150 - 5925 MHz typ. dB≥ 8 PolarizationREQ 22379848-60 v1VP (antenna mounted vertically)linear 12.12.20192-4 Datasheet ANTENNA WLAN INTERIOR Pt no. 23311706 / 920 638-001 Technical drawings Technical data* ParameterTR referenceRemarksUnitsValues Antenna Gain (Average)REQ 22379848-55 v12400 – 2485 MHz 5150 - 5925 MHz typ. dBi≥ -1.5 ≥ 0,5 ImpedanceREQ 22379848-54 v1 Ω 50 Diagnosis ResistorREQ 22379848-67 v1kΩ51 Power HandlingREQ 22379848-48 v1dBm≥ 30 * All technical requirements are according to 22379848.06 “Antenna System P2593/P2594 Multifunctional & Single function antennas” 12.12.20193-4 Datasheet ANTENNA WLAN INTERIOR Pt no. 23311706 / 920 638-001 Antenna diagrams Gain Radiation pattern 12.12.20194-4 Datasheet ANTENNA WLAN INTERIOR Pt no. 23311706 / 920 638-001 Subject to alterations Antenna diagrams Radiation pattern 12.12.20195-4 Datasheet ANTENNA WLAN INTERIOR Pt no. 23311706 / 920 638-001 Antenna diagrams Return loss ServiceLower LimitUpper Limit WLAN 2,42400 MHz2485 MHz WLAN 55150 MHz5925 MHz Frequency Table

Datasheet 21.03.20181-5 ANTENNA PHONE-PK INTERIOR Pt no. 23311714 / 920 453-003 ANTENNA INTERIOR PHONE-PK • Passive transmitting and reception antennas for the Cellular phone services 2G/3G/4G • Low body height max. 5 mm • Coverage of frequency bands LTE low (USA+EU), GSM850/900/1800/1900, UMTS, LTE high • Mounting on plastic and glass materials Subject to alterations Technical data* ParameterTR referenceRemarksUnitsValues Package107x54x5 mm Housing MaterialsREQ 22379848-23 v1TPU Elastollan® Konz 917/1, black Housing Prote…

Text truncated - open the document above for the full version.
