TYPE OF EXHIBIT:INSTALLATION AND OPERATING INSTRUCTION MANUAL FCC PART:2.1033 (c)(3) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:December 9, 2002 Included in this exhibit is a draft of the User Manual for the Ritron Patriot Model PBS-446D UHF-FM Base Transceiver. A copy of this manual will be included with every radio. This manual provides the end user with installation and operating instructions. Signed: Michael A. Pickard - Project Engineer Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com PATRIOT ® PBS "D-SERIES" OWNER'S MANUAL "D-SERIES" DESKTOP BASE RADIO "D-SERIES" DESKTOP BASE RADIO "D-SERIES" DESKTOP BASE RADIO "D-SERIES" DESKTOP BASE RADIO "D-SERIES" DESKTOP BASE RADIO RUGGED, PR RUGGED, PR RUGGED, PR RUGGED, PR RUGGED, PR OFESSIONAL TW OFESSIONAL TW OFESSIONAL TW OFESSIONAL TW OFESSIONAL TW O- O- O- O- O- W W W W W A A A A A Y BASE RADIOS Y BASE RADIOS Y BASE RADIOS Y BASE RADIOS Y BASE RADIOS • Up to 10 channel capability • Vehicle 12 VDC or wall outlet 120 VAC operation • Weather Channel feature (VHF only) • Emergency Weather Alert feature (VHF only) • Easy-to-hear, high audio output • Built-in Quiet Call ® and Digital Quiet Call ® Interference Eliminator • 2-Tone Paging decode • DTMF ANI encoding • Channel scan • 2.5 Watts of power New CHANNEL DISPLAY 14500036_111902.p65 11/25/02, 10:01 AM 1 ACCESSORIES ii OPTIONAL / REPLACEMENT ACCESSORIES: TO ORDER, CALL 1-800-USA-1-USA AFB-1545 .... Molded Flex, Dual-band Replacement Antenna RAM-1545 ... Magnet-mounted, Dual-band Antenna w/ BNC RPS-1A ....... Replacement 110 VAC Power Supply CCL-M ......... 12 VDC, Cigarette Lighter Adaptor REP-2 .......... Low Profile Earphone RHD-1X ....... Single Ear Headset RHD-4X ....... Dual Ear Headset RHD-5X ....... Lightweight Over-the-ear Earset /w In-line PTT RHD-6X ....... Lightweight Behind-the-head Earset w/ In-line PTT RSM-3X ...... Remote Speaker Microphone RSM-7 ......... Hand Microphone & Hang-up Bracket RPS-5 ......... External Speaker w/5 Watt Audio Capability JBS-MMK ... Mobile Mounting Kit (Does not include screws to mount bracket to wall or vehicle) Call RITRON for a complete listing. RHD-1X Single Ear Headset RHD-4X Dual Ear Headset RSM-3X Remote Speaker Mic The NEW "D-Series" model base radio contains updated programming features, and programs differently than other Ritron BaseStations. These radios provide more channels, allow you to change channel programming contents individually, and also allowyou to delete one or more channels, and add it back in, if needed. RHD-5X Over-the-ear Earset RHD-6X Behind-the-ear Earset Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com RAM-1545 Magnet-mounted, Dual-band Antenna 14500036_111902.p65 11/25/02, 10:01 AM 2 Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com DESCRIPTION PAGE !! CAUTIONS — ALL RADIOS !! Observe Caution in the Following Environments to Maximize the Life ofYour Radio Equipment ...................................................................................... 9Exposure to Radio Frequency Energy ............................................................. 9 TROUBLESHOOTING Notes ................................................................................................................. 1 0Chart .................................................................................................................. 1 0 FCC LICENSE REQUIRED FCC Regulations .............................................................................................. 11Service .............................................................................................................. 11 How to Obtain an FCC Radio License ........................................................... 11 LIMITED WARRANTY ......................................................... INSIDE BACK COVER FIGURES: 1. Radio Controls and Connectors .................................................................... 22. Transmit / Busy Lamp ................................................................................... 43. Presetting Your Local NOAA Weather Broadcasts ...................................... 74. NOAA Frequencies ........................................................................................ 75. How To Place the Radio in Program / Readout Mode .............................. 8 TABLE OF CONTENTS DESCRIPTION PAGE ACCESSORIES Optional Accessories ......................................................................................... i i INTRODUCTION PBS "D-Series" Model Numbers ...................................................................... 1Features .............................................................................................................. 1 CONTROL & OPERATION ..................................................................................... 2 FIG-1: Radio Controls and Connectors .......................................................... 2 OPERATION On-off/ Volume Adjust ....................................................................................... 3Channel Selection ............................................................................................ 3Receive .............................................................................................................. 3 QC and DQC Tone Codes (Interference Eliminator Codes) .......................... 3Transmit ............................................................................................................. 4 FIG-2: Transmit / Busy Lamp .......................................................................... 4Radio Alert Tones ............................................................................................. 4Optional Alert Tones ......................................................................................... 4Sc…
Text truncated - open the document above for the full version.
3 TYPE OF EXHIBIT:RF WARNING STATEMENT FCC PART:1.1310 MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:May 6, 2003 PLEASE NOTE THE FOLLOWING WITH REGARD TO RF EXPOSURE FOR THIS PRODUCT: 1. The User’s Manual contains the following text: EXPOSURE TO RADIO FREQUENCY ENERGY: JBS/PBS-146D: This product generates radio frequency (RF) energy when the PTT button on the front of the unit is depressed. This product has been evaluated for compliance with the maximum permissible exposure limits for RF energy at the maximum power rating of the unit when using antennas available from RITRON. To comply with the General Population/Uncontrolled limits, all persons must be at least 7.9 inches (20 cm) from the AFB-1545 antenna which is supplied by RITRON to be attached directly to the rear of the unit. For the RITRON RAM-1545 magnet mount antenna which can be located away from the unit, all persons must be at least 10.8 inches (28 cm) from the antenna. Antennas other than the two mentioned above have not been tested for compliance and may or may not meet the exposure limits at the distances given. Higher gain antennas are capable of generating higher fields in the strongest part of their field and would, therefore, require a greater separation from the antenna. JBS/PBS-446D: This product generates radio frequency (RF) energy when the PTT button on the front of the unit is depressed. This product has been evaluated for compliance with the maximum permissible exposure limits for RF energy at the maximum power rating of the unit when using antennas available from RITRON. To comply with the General Population/Uncontrolled limits, all persons must be at least 8.7 inches (22 cm) from the AFB-1545 antenna which is supplied by RITRON to be attached directly to the rear of the unit. For the RITRON RAM-1545 magnet mount antenna, at the 20 cm (7.9 inches) minimum expected separation distance and greater, the maximum RF exposure is well below the General Population/Uncontrolled limits. Antennas other than the two mentioned above have not been tested for compliance and may or may not meet the exposure limits at the distances given. Higher gain antennas are capable of generating higher fields in the strongest part of their field and would, therefore, require a greater separation from the antenna. To limit your exposure to levels at, or below, the levels tested, please observe the following: • Use only the antenna(s) available from RITRON for this model. • Keep talk times as short and infrequent as possible. DO NOT depress the PTT button when not actually wishing to transmit. The radio is equipped with an internal timer to limit continuous transmit times. • When transmitting, maintain at least the minimum distance from the antenna as stated above. DO NOT hold the radio in such a manner that the antenna is next to, or touching, exposed parts of the body, especially the face or eyes while transmitting. • DO NOT allow children to operate the radio. 2. The FCC serial label contains a statement referring the user to the User’s Manual for information on exposure to RF energy. 4 RITRON, INC. • 505 West Carmel Drive • Carmel, Indiana 46032 TEL: 317-846-1201 • FAX: 317-846-4978 • http://www.ritron.com Ritron Item: 14200130 Description: LABEL, FCC/SERIAL, PBS-446D Vendor Part Numbers: Identco# TTL307-700, Identco# TTRR-D3.54ZJ Revision Date: November 18, 2002 Description: The FCC ID, serial label will be made in house by manufacturing. The ELP 310 thermal transfer printer will be used with glossy white polyester labels (RTN# 14290001). Identco# TTL307-700, a three (3) inch by two (2) inch label, is the approved material. The approved ribbon is Identco# TTRR-D3.54ZJ. Labels will be numbered sequentially, with an initial 5-digit number of B1234. Records are maintained to track the next available serial number. All PBS-446D models share the same serial sequence. Labels will contain an updated Manufacturing Date using the Ritron 4-digit Date Code. Drawing: Chief Eng: ________________ Project Eng: ________________ Sales: ________________ Manufacturing: ________________ Use of this radio device must be monitored to assure FCC RF exposure compliance. See owner’s manual for specific operating instructions. For service, contact your radio dealer or return product directly to: RITRON, INC. 505 W. CARMEL DR. CARMEL, IN 46032 OR CALL 1-800-USA-1-USA Sample: FCC ID:AIERIT16-446 FREQ:450-470 MHz MODEL:PBS-446D SN:B1234 Mfg Date: 0248 5 TYPE OF EXHIBIT:TRANSMITTER EFFECTIVE RADIATED POWER FCC PART: 1.1310 MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:May 6, 2003 PROCEDURE: 1. The measurement for effective radiated power was taken at the RITRON, Inc. 3-meter test site, details of which are on file with the FCC. 2. The PBS-446D was aligned for transmitter operation on 460.050 MHz at the 2.5 Watt maximum obtainable from the unit per the tune-up procedure outlined in the Preliminary Maintenance Manual. The unit was then terminated at the antenna port with the antennas sold with this product. (The user can connect other antennas, however.) 3. All ERP measurements were made with a Hewlett-Packard Model 8560E Spectrum Analyzer and an Electro-Metrics LP-25 Log Periodic Antenna. 4. The height of the field strength measurement antenna and orientation of the PBS-446D were varied to provide maximum field strength at the receiving antenna. 5. A substitution antenna, a calibrated ½-wave dipole, was substituted for the PBS-446D at the PBS- 446D’s location. An RF signal generator was set for the frequency of the PBS-446D with the level at the substitution antenna noted. 6. The height of the field strength antenna was adjusted for maximum signal strength at the field strength measuring antenna. The level at the field strength antenna was noted. 6 TYPE OF EXHIBIT:TRANSMITTER E…
Text truncated - open the document above for the full version.
11 TYPE OF EXHIBIT:EXTERNAL PHOTOGRAPHS FCC PART:2.1033 (c)(12) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:December 4, 2002 Included in this exhibit are photographs of the RITRON Model PBS-446D UHF-FM Base Transceiver case assembly. Additional photographs of the equipment of sufficient clarity to reveal internal construction and define component placement are included with this Certification request as a separate exhibit. Signed: Michael A. Pickard - Project Engineer 12 EXHIBIT:PBS-446D controls, jacks, connectors, and control label FCC ID:AIERIT16-446 Channel Display Channel Selector Audio Accessory Jack Micro phone Jack Antenna Special Feature “Z” Volume Down/ Off On/ Volume Up Push-To-Talk Microphone Antenna Connector DC Power Connector 13 EXHIBIT:PBS-446D in desktop operation with RPS-1A wall mount power supply connected FCC ID:AIERIT16-446 14 EXHIBIT:PBS-446D in wall mount operation with RPS-1A wall mount power supply connected FCC ID:AIERIT16-446 15 EXHIBIT:PBS-446D case bottom showing location of FCC identification label FCC ID:AIERIT16-446
8 TYPE OF EXHIBIT:FCC DATA LABEL FCC PART:2.1033 (c)(11) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:December 4, 2002 The following drawing specifies the FCC Label for the PBS-446D. A photograph is included to indicate the position of the label on the case bottom. Each serial number is recorded along with the date of manufacture and is kept on file at RITRON, Inc. The FCC ID, serial label will be made in house by manufacturing. The ELP 310 thermal transfer printer will be used with glossy white polyester labels (RTN# 14290001). Identco# TTL307-700, a three (3) inch by two (2) inch label, is the approved material. The approved ribbon is Identco# TTRR- D3.54ZJ. Serialization will begin with the serial number B1234. The size of the serial label is 2.00” x 3.00”. Signed: Michael A. Pickard - Project Engineer 9 RITRON, INC. • 505 West Carmel Drive • Carmel, Indiana 46032 TEL: 317-846-1201 • FAX: 317-846-4978 • http://www.ritron.com Ritron Item: 14200130 Description: LABEL, FCC/SERIAL, PBS-446D Vendor Part Numbers: Identco# TTL307-700, Identco# TTRR-D3.54ZJ Revision Date: November 18, 2002 Description: The FCC ID, serial label will be made in house by manufacturing. The ELP 310 thermal transfer printer will be used with glossy white polyester labels (RTN# 14290001). Identco# TTL307-700, a three (3) inch by two (2) inch label, is the approved material. The approved ribbon is Identco# TTRR-D3.54ZJ. Labels will be numbered sequentially, with an initial 5-digit number of B1234. Records are maintained to track the next available serial number. All PBS-446D models share the same serial sequence. Labels will contain an updated Manufacturing Date using the Ritron 4-digit Date Code. Drawing: Chief Eng: ________________ Project Eng: ________________ Sales: ________________ Manufacturing: ________________ Use of this radio device must be monitored to assure FCC RF exposure compliance. See owner’s manual for specific operating instructions. For service, contact your radio dealer or return product directly to: RITRON, INC. 505 W. CARMEL DR. CARMEL, IN 46032 OR CALL 1-800-USA-1-USA Sample: FCC ID:AIERIT16-446 FREQ:450-470 MHz MODEL:PBS-446D SN:B1234 Mfg Date: 0248 10 EXHIBIT: PBS-446D case bottom showing location of FCC identification label FCC ID: AIERIT16-446
16 TYPE OF EXHIBIT:INTERNAL PHOTOGRAPHS FCC PART:2.1033 (c)(12) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:December 4, 2002 Included in this exhibit are photographs of the RITRON Model PBS-446D UHF-FM Base Transceiver printed circuit board assembly and installation. Additional photographs of the equipment of sufficient clarity to reveal equipment construction and layout, labels for controls and meters, and chassis assembly are included with this Certification request as separate exhibits. Signed: Michael A. Pickard - Project Engineer 17 EXHIBIT:PBS-446D complete topside PCB assembly FCC ID:AIERIT16-446 18 EXHIBIT:PBS-446D complete bottom side PCB assembly FCC ID:AIERIT16-446 19 EXHIBIT:PBS-446D with case bottom off to show printed circuit board installation FCC ID:AIERIT16-446 EXHIBIT:PBS-446D with printed circuit board removed from case top FCC ID:AIERIT16-446
TYPE OF EXHIBIT:OPERATIONAL DESCRIPTION FCC PART:2.1033 (c)(6) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:December 9, 2002 Included in this exhibit is a draft of the Maintenance and Operating Manual for the Ritron Patriot Model PBS-446D UHF-FM Base Transceiver. Specifically, the manual includes a technical description of the PBS-446D sufficient to establish compliance with the technical standards of the applicable rule part(s). This includes, but is not limited to, the following items required under FCC Part 2.1033(c): (2)FCC Identifier. (3)A copy of the installation and operating instructions. (4)Type of emission. (5)Frequency range. (6)Range of operating power, and means to provide variation in operating power. (7)Maximum power rating. (8)DC voltage chart. (9)Tune-up procedure. (10) A description of all frequency determining and stabilization circuits. A description of the circuits used to suppress spurious radiation, limiting modulation, and limiting power. (12) Drawing with labels for controls and complete circuit diagrams. Signed: Michael A. Pickard - Project Engineer TWO-WAY RADIO BY RITRON RITRON MODEL PBS-446D UHF FM BAND PROGRAMMABLE BASE RADIO MAINTENANCE / REPAIR / OPERATING MANUAL FOR USE BY AUTHORIZED SERVICE/MAINTENANCE PERSONNEL ONLY PBS-446D-MRMREV A COPYRIGHT 2002 RITRON, INC. • ALL RIGHTS RESERVED RITRON , JOBCOM , and QUIET CALL , ARE REGISTERED TRADEMARKS OF RITRON, INC. TABLE OF CONTENTSPBS-446D TOPICPAGE IMPORTANT MAINTENANCE/REPAIR INFORMATION .. 1 SPECIFICATIONS GENERAL......................................................................... 2 CONTROLS ...................................................................... 2 TRANSMITTER................................................................. 3 RECEIVER........................................................................ 3 BATTERY ......................................................................... 3 INTRODUCTION GENERAL......................................................................... 4 Model Identification ..................................................... 4 FCC REGULATIONS Licensing..................................................................... 4 How to Obtain an FCC Radio License ......................... 4 EXPOSURE TO RADIO FREQUENCY ENERGY ............. 4 OPERATION DESCRIPTION OF CONTROLS AND CONNECTORS..... 5 Fig. 3 Controls and Accessory Connectors.................. 5 BASIC RADIO OPERATION On-Off/Volume Adjust ................................................. 6 Channel Selection ....................................................... 6 Receive ....................................................................... 6 • Carrier Squelch....................................................... 6 • Tone Squelch ......................................................... 6 • No Squelch............................................................. 6 • 2-Tone Paging ........................................................ 6 QC and DQC Tone Codes........................................... 6 Transmit ...................................................................... 7 Battery Saver .............................................................. 7 SCAN CHANNEL OPERATION ........................................ 7 How Scanning Works .................................................. 7 Temporary Busy Channel Blocking ............................. 7 Last Channel Scanned Alert Tone............................... 7 Priority Scanning (Optional)......................................... 7 2-TONE PAGING OPERATION ........................................ 7 WHAT THE RADIO TONES MEAN Power On/Self Check “OK........................................... 8 Error Tones ................................................................. 8 Channel Select............................................................ 8 Scan Channel.............................................................. 8 Squelch Mode ............................................................. 8 Transmitter Time Out .................................................. 8 Battery Alert Tone ....................................................... 8 OPTIONAL RADIO TONES Courtesy Beep ............................................................ 8 Busy Channel TX Inhibit .............................................. 8 Transmitter Clear To Talk Beep .................................. 8 TROUBLESHOOTING General ....................................................................... 9 Error Tones ................................................................. 9 Tone Coded Squelch................................................... 9 PROGRAMMING THE RADIO PROGRAMMING METHODS.......................................... 10 FIELD PROGRAMMING Fig. 4 Placing the Radio in Program / Readout Mode 10 How to Readout Field Programmed Frequency and Tone Codes........................................................ 10 How to Field Program Frequency & Tone Codes ...... 11 PTT Programming Mistakes...................................... 11 How to Delete a Channel........................................... 12 How to Turn Channel Scan On / Off .......................... 12 Table 1 – PTT Programming Frequency Table.......... 13 Table 2 – Quiet Call Codes and Frequencies ............ 13 COMPUTER SOFTWARE COPYRIGHTS ...................... 13 PC COMPUTER PROGRAMMING ................................. 13 TOPICPAGE Programmable Features ............................................ 14 Descriptions of Features ............................................ 14 2-Tone Paging Options .............................................. 15 Scan Channel Options ............................................... 15 THEORY OF OPERATION INTRODUCTION ............................................................. 16 POWER SUPPLY AND VOLTAGE DISTRIBUTION........ 16 Power Strobe.....................…
Text truncated - open the document above for the full version.
65 TYPE OF EXHIBIT:SEMICONDUCTOR FUNCTION FCC PART:2.1033 (c) (10) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:November 27, 2002 DESCRIPTION: The following list specifies the manufacturer, identification and function of each semiconductor device used in the PBS-446D base transceiver. SchemRITRONManufacturer IDPN# ManufacturerIDFunction CR148A1005CON SemiconductorsMMBD7000LT1Voltage clamp CR202450101PanasonicLN514GK-GREEN7-segment LED display CR348A1005CON SemiconductorsMMBD7000LT1Voltage clamp CR10148D100A2M/A Com, Inc.MA4CP101ATX/RX switching CR10248E1005GON SemiconductorsMMBD-352LT1Voltage clamp CR20148D100A2M/A Com, Inc.MA4CP101ATX/RX switching CR30148B61012Philips Semiconductors BZD27-C12Over voltage protection CR30348A1005BON SemiconductorsMMBD6100LT1Turn-on detection CR30448A100A3ON SemiconductorsMMBD2835LT1PTT switching CR30748A60001 General SemiconductorsASBCS1BReverse voltage protection CR40148A1005CON SemiconductorsMMBD7000LT1Biasing CR40248CB0002Philips SemiconductorsBB149AVCO tuning CR40348C1004GON SemiconductorsMMBV-2101LVCO modulation CR40448A1004DON SemiconductorsMMBV3401TITX/RX VCO switching Q 14841006BON SemiconductorsMMBF5484LT1AGC switch Q 24801001QON SemiconductorsMMBT-5088LT1AGC audio detection Q 5480100DHON SemiconductorsBCW68GLT1+5V switching Q 64821003BMotorola SemiconductorsMMBT918LT1Micro clock amplifier Q 3 Central SemiconductorCZT122Over voltage protection Q 1014801002APhilips SemiconductorsPMBT3906RX +V switching Q 102482100V0Philips SemiconductorsPBR941RX RF amplifier Q 1034841006UON SemiconductorsMMBFJ309LT1RX Mixer Q 1044821003BMotorola SemiconductorsMMBT918LT1RX IF amplifier Q 1054821003BMotorola SemiconductorsMMBT918LT1RX 1st LO multiplier/amp Q 106480A0001Rohm ElectronicsUMZ1NTRBiased noise detector Q 1074841006BON SemiconductorsMMBF5484LT1Analog switch Q 20148130001Central SemiconductorCBCX69TX +V switching Q 2024801001QON SemiconductorsMMBT-5088LT1TX +V switching Q 203482100V0Philips SemiconductorsPBR941TX RF amplifier Q 20448280002Philips SemiconductorsBFG-35TX RF driver amplifier Q 2054828PH59Philips SemiconductorsBLT-50TX RF final amplifier Q 30148010A8AON SemiconductorsMMUN2211T1PTT detection Q 3024801002APhilips SemiconductorsPMBT3906PTT detection Q 3034801001QON SemiconductorsMMBT-5088LT1+V switching Q 304480100DHON SemiconductorsBCW68GLT1+V switching Q 30748010A8AON SemiconductorsMMUN2211T1Audio amplifier enable Q 308480100DHON SemiconductorsBCW68GLT1Audio amplifier +V switching 66 SchemRITRONManufacturer IDPN# ManufacturerIDFunction Q 401482100V0Philips SemiconductorsPBR941VCO buffer amplifier Q 402482100V0Philips SemiconductorsPBR941VCO buffer amplifier Q 403482100V0Philips SemiconductorsPBR941VCO oscillator Q 4044801001QON SemiconductorsMMBT-5088LT1VCO voltage de-coupling Q 40548010A6AON SemiconductorsMMUN2111LT1TX/RX VCO switching Q 40648010A8AON SemiconductorsMMUN2211T1TX/RX VCO switching U 1314L0003Motorola Semiconductors MC68HC908GR8FAMicrocontroller U 231210005Atmel CorporationAT24C04AN-10SCEEPROM U 331120003Philips Semiconductors74HC164PWAudio process switching U 531120003Philips Semiconductors74HC164PW7-segment LED driver U 10131030006Toshiba TA31136FNRX FM-IF subsystem U 303310K0004National SemiconductorsLMV324MTAudio processing U 304311K0001Philips Components74LV4066PWAudio signal switching U 305310K0004National SemiconductorsLMV324MTAudio processing U 306310K0001Dallas SemiconductorDS1806EAudio signal level control U 30703131007National SemiconductorsLM380N-8Audio amplifier U 308310K0002Maxim Integrated ProductsMAX7410CUATone low pass filter U 309310E0002National SemiconductorsLP2980AIM5X-5.0+5 VDC voltage regulator U 401313K0006National SemiconductorsLMX2306TMFrequency synthesizer 67 TYPE OF EXHIBIT:PARTS LIST FCC PART:2.1033 (c) (9) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:November 27, 2002 DESCRIPTION: The following is a complete parts list for the PBS-446D base transceiver. REFPN# DESCRIPTIONXY C115181102.001uF CAPACITOR, CHIP, 0402, X7R, 5/10%275783890 Bottom20 081 C1015182103.01uF CAPACITOR, CHIP, 0402,Z5U,5/10/2033143510 Top15 081 C101 151103A33.3pf NPO 0805 CHIP CAPACITOR3238 24370 Bottom20 081 C102 151102A72.7PF NPO 0805 50V CHIP3347 2324270 Bottom20 081 C103 1511012012PF NPO 0805 50V CHIP CAP3128 19590 Bottom20 081 C104 15180101100pF CAPACITOR, CHIP, 0402, COG, 5%2908 240190 Bottom20 081 C105 1511010010PF NPO 0805 50V CHIP CAP3310 2070180 Bottom20 081 C106 1511018018PF NPO 0805 50V CHIP3271 21930 Top20 081 C107 15181102.001uF CAPACITOR, CHIP, 0402, X7R, 5/10%3047 23400 Bottom20 081 C108 15181102.001uF CAPACITOR, CHIP, 0402, X7R, 5/10%2856 240190 Bottom20 081 C109 151106A86.8PF NPO 0805 50V CHIP2897 20840 Bottom20 081 C1115180101100pF CAPACITOR, CHIP, 0402, COG, 5%3402618180 Top15 081 C110 151103A33.3pf NPO 0805 CHIP CAPACITOR2763 219190 Bottom20 081 C111 151103A33.3pf NPO 0805 CHIP CAPACITOR2722 20840 Bottom20 081 C112 151103A33.3pf NPO 0805 CHIP CAPACITOR2559 20840 Bottom20 081 C113 1511010010PF NPO 0805 50V CHIP CAP2682 219190 Bottom20 081 C114 151108A28.2PF NPO 0805 50V CHIP2359 20840 Bottom20 081 C115 1511015015PF 0805 NPO 50V CHIP CAP2249 2043270 Bottom20 081 C116 15182103.01uF CAPACITOR, CHIP, 0402,Z5U,5/10/202004 210890 Top15 081 C117 151101A81.8PF NPO 0805 50V CHIP2004 1835270 Top15 081 C118 151108A28.2PF NPO 0805 50V CHIP2112 1970270 Top15 081 C119 15181472.0047uF CAPACITOR, CHIP, 0402, X7R,5/10%1801 1593270 Bottom20 081 C121511010010PF NPO 0805 50V CHIP CAP18896790 Bottom20 081 C120 151108A28.2PF NPO 0805 50V CHIP2330 1580270 Bottom20 081 C121 15181102.001uF CAPACITOR, CHIP, 0402, X7R, 5/10%2472 1540180 Bottom20 081 C122 152B610610uF 10V 3.4 X 2.8 CHIP TANTALUM 20%tol2226 195490 Top15 081 C123 15181222.0022uF CAPACITOR, CHIP, 0402, X7R,5/10%2653 121390 Bottom20 081 C124 15181222.0022uF CAPACITOR, CHIP, 0402, X7R,5/10…
Text truncated - open the document above for the full version.
61 TYPE OF EXHIBIT:TUNE-UP PROCEDURE FCC PART:2.1033 (c)(9) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODEL:PBS-446D TYPE OF UNIT:UHF-FM Base Transceiver FCC ID:AIERIT16-446 DATE:December 9, 2002 The tune-up procedure included in this exhibit is an excerpt of the Maintenance and Operating Manual for RITRON Model Patriot PBS-446D UHF-FM Base Transceiver. The complete Maintenance and Operating Manual is included with this application for Certification as a separate exhibit. Signed: Michael A. Pickard - Project Engineer ALIGNMENT PROCEDUREPBS-446D 62 WARNING! An authorized RF service technician must perform test and alignment of the PBS-446D. Do not attempt service of the PBS-446D if not completely familiar with the operation of frequency synthesized radio operation. The PBS-446D can operate in both Narrow Band (2.5 KHz deviation) and Wide Band (5 KHz deviation) systems. RECOMMENDED TEST EQUIPMENT 1) 0 to +15 VDC, 2A current-limited power supply 2) RF Communications Test Set (to 470 MHz) with: - FM Deviation Meter - RF Wattmeter - Frequency Counter (to 470 MHz) - SINAD Measuring Device 3) Oscilloscope (to 20 MHz) 4) VTVM or DMM 5) RITRON PC Programming Kit RADIO PREPARATION 1) Connect the RPS-1A wall mounted power supply to the PBS-446D. 2) Connect the serial programming cable from the PC computer (with the RITRON PC programming kit software installed) to the 3.5mm audio accessory jack. 3) Remove the PBS-446D antenna and connect the FM communi…
Text truncated - open the document above for the full version.
