AIERIT18-156VHF-FM CALLBOX TRANSCEIVER

ii TYPE OF EXHIBIT:INSTALLATION AND OPERATING INSTRUCTION MANUAL FCC PART:2.1033 (c)(3) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODELS:RQX-156, RQX-156-XT FCC ID:AIERIT18-156 DATE:November 6, 2003 IC STANDARDS:RSP-100, Issue 8, Section 7.2(b) INDUSTRY CANADA:1084A-RIT18156 MODELS:RQX-156-CANADA, RQX-156-XT-CANADA, RQX-156-BC, RQX-156-XT-BC Included in this exhibit is a draft of the User Manual for the Ritron Models RQX-156 and RQX-156-XT VHF-FM Callbox Transceiver. A copy of this manual will be included with every radio. This manual provides the end user with installation and operating instructions. Signed:_______________________________ Kevin G. Matson - Project Engineer OUTPOST    Wireless Callbox Basic Owner’s Manual Ritron Pub. 14500042 Rev. A 03/04 Copyright  2004 RITRON, INC. – ALL RIGHTS RESERVED RITRON  , PATRIOT  , JOBCOM  , Quick Assist  , and Quiet Call  are registered trademarks of RITRON, INC. OUTPOST  and Quick Talk  are trademarks of RITRON, INC. P.O. Box 1998, Carmel, IN 46082-1998 • •• • 505 W. Carmel Dr., Carmel, IN 46032 • •• • USA Phone: 317-846-1201 or 800-USA-1-USA (800-872-1872) • •• • FAX: 317-846-4978 Web: www.radiocallbox.com • •• • E-mail: [email protected] ii Have questions? Call 800-USA-1-USA (800-872-1872) or visit our website at www.ritron.com TABLE OF CONTENTS DescriptionPage WHAT THIS MANUAL COVERS ........................................................................................................................ ii Basic Operation OUTPOST CALLBOX MODEL NUMBERS..................................................................................................1 ABOUT THE OUTPOST WIRELESS CALLBOX ......................................................................................... 1 OPERATING THE OUTPOST CALLBOX .................................................................................................... 2 EXPOSURE TO RADIO FREQUENCY ENERGY ....................................................................................... 2 LICENSE REQUIRED FCC Licensing ...................................................................................................................................... 3 How to Obtain an FCC License ............................................................................................................ 3 Safety Standard .................................................................................................................................... 3 INDUSTRY CANADA Regulations........................................................................................................ 3 INDUSTRY CANADA License Application............................................................................................3 Service.................................................................................................................................................. 3 INSTALLATION INSTRUCTIONS Callbox Controls and Connectors ................................................................................................................ 4 FIG-1: Callbox Assembly, Controls and Connectors .................................................................................... 4 OUTPOST Installation Instructions .............................................................................................................. 5 XT OUTPOST Installation Instructions......................................................................................................... 5 FIG-2: XT Callbox Mounting Brackets – Vertically Installed ......................................................................... 5 FIG-3: XT Callbox Assembly........................................................................................................................ 6 PROGRAMMING HOW TO READOUT CURRENT RADIO PROGRAMMING ........................................................................ 7 HOW TO FIELD PROGRAM FREQUENCY & TONE CODES .................................................................... 8 HOW TO FIELD PROGRAM 2-TONE DECODE ......................................................................................... 9 HOW TO FIELD PROGRAM RADIO FEATURES ..................................................................................... 10 Table 1: Programmable Frequency Codes ................................................................................................ 11 Table 2: Programmable QC Tone Codes................................................................................................... 12 Table 3: Programmable DQC Codes ......................................................................................................... 12 Table 4: Programmable 2-Tone Codes ...................................................................................................... 12 Table 5: Programmable Features .............................................................................................................. 12 Advanced Features FIELD PROGRAMMING GATE GUARD ...................................................................................................13 OPTIONAL OUTPOST CALLBOX FEATURES ......................................................................................... 13 XT Gate Guard Installation Instructions ..................................................................................................... 14 FIG-4: Charge Jumper in Charge Position ................................................................................................. 14 FIG-5: XT Callbox Gate Guard Assembly with Battery Back-Up............................................................... 15 OPTIONAL GATE GUARD PROGRAMMING............................................................................................ 16 INTERCOM (ALWAYS-ON) PROGRAMMING .......................................................................................... 16 HOW TO SEAL THE ANTENNA ...............................…

Text truncated - open the document above for the full version.

file:///T|/R/RITRON_AIE/367AUC4/oet%2012046/cust%20reply%2022%20apr%2004.txt From: Sam Dulaney [[email protected]] Sent: Thursday, April 22, 2004 4:44 PM To: 'Eric' Subject: RE: FCC audit of application for Ritron Inc FCC ID: AIERIT18-156 Follow Up Flag: Follow up Flag Status: Flagged Eric: The subject device is designed such that it would not be operating closer than 20 cm to a person's body. It is NOT a portable device and would not, in normal operation, be held near the body. The gain of the microphone, the speaker audio level and the nature of the front panel button are such a person would be at least 20 cm from the front face of the unit. Further, the antenna is located another 8-10 cm behind the front panel. This would place a person at least 28 cm from the radiating element of the device. The RF Exposure warning statement in the Users Manual specifies that persons should not be closer than 20 cm (RF exposure limits are acutally met at 18 cm) when the internal antenna is used and must stay at least 28 cm away from magnet mount antenna when it is used. The magnetic mount antenna would not normally be located near the unit or persons operating the unit, certainly not within 28 cm. Sam L. Dulaney Chief Engineer Ritron, Inc. -----Original Message----- From: Eric [mailto:[email protected]] Sent: Thursday, April 22, 2004 3:02 PM To: [email protected] Cc: Bruno Clavier Subject: FCC audit of application for Ritron Inc FCC ID: AIERIT18-156 Hello, Sam: The FCC has performed an audit of the subject application and had the following comments: file:///T|/R/RITRON_AIE/367AUC4/oet%2012046/cust%20reply%2022%20apr%2004.txt (1 of 3)4/23/2004 11:21:00 AM file:///T|/R/RITRON_AIE/367AUC4/oet%2012046/cust%20reply%2022%20apr%2004.txt FCC quote: "MPE estimate using OET 65 equation 3 is not applicable for FCC RF exposure evaluation purposes for devices that operate at closer than 20cm to a person's body. Please revise RF exposure exhibit." Our Chief Engineer, Bruno Clavier, has reviewed the FCC comments with regard to this application and had the following to say: "This device may be used at distances closer than 20cm from the body during normal operation. The MPE calculations should be removed. According to page 1 of the user's manual, the call box is intended for occupational users. As a portable device, the RFx exhibit should contain such information: a/ Portable operating configuration b/ RF exposure conditions - Occupational user/controlled environment. c/ This transmitter is exempted from SAR evaluation to qualify for TCB approval according to TCB exclusions list of July 17, 2002. The low threshold (in mW) for distances greater than or equal 2.5cm is 900/f (GHz)= 900/0.155 = 5,807 mW ~ 5.8W d/ label on device visible to the operator indicating specific RF exposure training required - the label should use fonts that are legible to all users under normal circumstances, without reading aids, and printed on durable material with permanent ink (Please, see attached) e/ The user's manual must contained instructions for the occupational use only. - device is for occupational use only in the course of employment - identify the location of all training material - identify the training is required to satisfy FCC RF exposure compliance requirements. Training - to make the user fully aware of the potential for exposure and how to exercise control over their exposure - Caution, Warning, Notice etc., as appropriate for the exposure conditions and compliance requirements" The sample label that Bruno speaks of is attached. Please let me know if you concur or if you have any comments or questions. It looks like we would need a revised manual, revised MPE exhibit and a sample of the RF exposure label. Eric Dobson Quality Manager Timco Engineering, Inc. file:///T|/R/RITRON_AIE/367AUC4/oet%2012046/cust%20reply%2022%20apr%2004.txt (2 of 3)4/23/2004 11:21:00 AM file:///T|/R/RITRON_AIE/367AUC4/oet%2012046/cust%20reply%2022%20apr%2004.txt [email protected] 352-472-5500 www.timcoengr.com *************************************************************** Privileged/Confidential Information may be contained in this message. If you are not the addressee indicated in this message (or responsible for delivery of the message to such person), you may not copy or deliver this message to anyone. In such case, you should destroy this message and kindly notify the sender by reply email. Please advise immediately if you or your employer do not consent to Internet email for messages of this kind. Opinions, conclusions and other information in this message that do not relate to the official business of my firm shall be understood as neither given nor endorsed by it. file:///T|/R/RITRON_AIE/367AUC4/oet%2012046/cust%20reply%2022%20apr%2004.txt (3 of 3)4/23/2004 11:21:00 AM

12 TYPE OF EXHIBIT:EXTERNAL PHOTOGRAPHS FCC PART:2.1033 (c)(12) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODELS:RQX-156, RQX-156-XT FCC ID:AIERIT18-156 DATE:November 6, 2003 IC STANDARDS:RSP-100, Issue 8, Section 5.1(e) RSP-100, Issue 8, Section 7.2(d) INDUSTRY CANADA:1084A-RIT18156 MODELS:RQX-156-CANADA, RQX-156-XT-CANADA, RQX-156-BC, RQX-156-BC-XT Included in this exhibit are photographs of the RITRON Models RQX-156 and RQX-156-XT VHF-FM Callbox Transceiver case assemblies. Additional photographs of the equipment of sufficient clarity to reveal internal construction and define component placement are included with this Certification request as a separate exhibit. Signed:_______________________________ Kevin G. Matson - Project Engineer 13 EXHIBIT:RQX-156 front view of facade with ON/PTT button and speaker grille FCC ID:AIERIT18-156 IC: 1084A-RIT18156 14 EXHIBIT:RQX-156 front view with facade removed FCC ID:AIERIT18-156 IC: 1084A-RIT18156 15 EXHIBIT:RQX-156-XT front view with ON/PTT button and speaker grille FCC ID:AIERIT18-156 IC:1084A-RIT18156 16 EXHIBIT:RQX-156-XT with front plate off to show installation of RQX-156 case assembly FCC ID:AIERIT18-156 IC:1084A-RIT18156

8 TYPE OF EXHIBIT:FCC DATA LABEL FCC PART:2.1033 (c)(11) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODELS:RQX-156, RQX-156-XT FCC ID:AIERIT18-156 DATE:November 6, 2003 IC STANDARDS:RSP-100, Issue 8, Section 4 RSP-100, Issue 8, Section 5.1(g) RSS-119, Issue 6, Section 5.1 INDUSTRY CANADA:1084A-RIT18156 MODELS:RQX-156-CANADA, RQX-156-XT-CANADA, RQX-156-BC, RQX-156-BC-XT The following drawing specifies the FCC Label for the RQX-156 and RQX-156-XT. Photographs are included to indicate the position of the label on each model’s case. Each serial number is recorded along with the date of manufacture and is kept on file at RITRON, Inc. Serialization will begin with the serial number 12345. The size of the serial label is 1.50” x 0.625”. Signed: ___________________________________ Kevin G. Matson - Project Engineer 9 EXHIBIT:RQX-156 case bottom showing location of FCC ID Label (photo is for location only, actual label is per attached drawing) FCC ID:AIERIT18-156 IC:1084A-RIT18156 10 EXHIBIT:RQX-156-XT with faceplate removed to show location of FCC ID Label (photo is for location only, actual label is per attached drawing) FCC ID:AIERIT18-156 IC:1084A-RIT18156 RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 REVISIONS TOLERANCES (EXCEPT AS NOTED) DECIMAL–FRACTIONAL–ANGULAR– DRAWN BY NO. 12345 DATE BY CHECKEDTRACED SCALEDATE MATERIALDRAWING NUMBER APPROVED MAP MAP RQX-156 FCC/MODEL LABEL 14200142 2 : 1 02/26/04 03/08/04 TYPE SPECIFICATIONS:1. All characters black, Helvetica, 6 point, 90% width except where noted below 2. "Telephone: " , "FCC ID:" , "IC:", "Model:", and "SN:" Black characters, Helvetica Bold, 6 point, 90% width. 3. "FCC ID: AIERIT18-156" will be enclosed in a box border (bold/black) centered around the text. 4. All lines of text centered horizontally on the label. MATERIAL SPECIFICATIONS:1. MATERIAL - Topcoated metallized silver polyester. (FLEXmark MM 200 Silver TC-249 L-23 spec 50K/Q-8) 2. ADHESIVE - A permanent Acrylic adhesive appx. 0.8-0.9 mils thick with a Kraft Release Liner 3.1 mils thk. 3. GRAPHICS - Indoor/Outdoor Smudge and Abrasion resistant images. 4. DURABILITY - Service temperature of -40 F to 200 F 5. OVERLAMINATION - Clear Matte film with acrylic adhesive. NOTES:1. Number Serialization to start with 12345 with number incrementedby one on each label. 1. The FCC/Model label for the RQX-156 will use the above materials/specifications or a RITRON approved equivalent. 2. Vendor will suppy photoproofs for RITRON Engineering approval prio to manufacturing production labels. 3. No changes to label without RITRON engineering approval. * FLEXmark is a registered trademark of FLEXcon Company, Inc. RITRON, INC. (www.ritron.com) 505 W. Carmel Dr. Carmel, IN 46032 Telephone: 800-872-1872 FCC ID: AIERIT18-156 IC: 1084A-RIT18156 MODEL: RQX-156 SN: 12345 0.625" 1.500" R 0.062" TYP. RQX-156 FCC/MODEL LABEL PN: 14200142 SCALE: 2:1

17 TYPE OF EXHIBIT:INTERNAL PHOTOGRAPHS FCC PART:2.1033 (c)(12) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODELS:RQX-156, RQX-156-XT FCC ID:AIERIT18-156 DATE:November 6, 2003 IC STANDARDS:RSP-100, Issue 8, Section 5.1(e) RSP-100, Issue 8, Section 7.2(d) INDUSTRY CANADA:1084A-RIT18156 MODELS:RQX-156-CANADA, RQX-156-XT-CANADA, RQX-156-BC, RQX-156-BC-XT Included in this exhibit are photographs of the RITRON Model RQX-156 VHF-FM Callbox Transceiver printed circuit board assembly and installation. Additional photographs of the equipment of sufficient clarity to reveal equipment construction and layout, labels for controls and meters, and chassis assembly are included with this Certification request as separate exhibits. Signed:______________________________ Kevin G. Matson - Project Engineer 18 EXHIBIT:RQX-156 complete topside PCB assembly with shields installed FCC ID:AIERIT18-156 IC:1084A-RIT18156

19 EXHIBIT:RQX-156 complete topside PCB assembly with shields removed FCC ID:AIERIT18-156 IC:1084A-RIT18156 20 EXHIBIT:RQX-156 complete bottom side PCB assembly with shield removed FCC ID:AIERIT18-156 IC:1084A-RIT18156

21 EXHIBIT:RQX-156 complete bottom side PCB assembly with shield installed FCC ID:AIERIT18-156 IC:1084A-RIT18156

22 EXHIBIT:RQX-156 with case open to show printed circuit board installation EXHIBIT:RQX-156 with printed circuit board removed from front case FCC ID:AIERIT18-156 IC:1084A-RIT18156

i TYPE OF EXHIBIT:OPERATIONAL DESCRIPTION FCC PART:2.1033 (c)(6) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODELS:RQX-156, RQX-156-XT FCC ID:AIERIT18-156 DATE:November 6, 2003 IC STANDARDS:RSP-100, Issue 8, Section 7.2(b) INDUSTRY CANADA:1084A-RIT18156 MODELS:RQX-156-CANADA, RQX-156-XT-CANADA, RQX-156-BC, RQX-156-XT-BC Included in this exhibit is a draft of the Maintenance and Operating Manual for the Ritron Model RQX-156 and RQX-156-XT VHF-FM Callbox Transceiver. Specifically, the manual includes a technical description of the RQX-156 sufficient to establish compliance with the technical standards of the applicable rule part(s). This includes, but is not limited to, the following items required under FCC Part 2.1033(c): (2)FCC Identifier. (3)A copy of the installation and operating instructions. (4)Type of emission. (5)Frequency range. (6)Range of operating power, and means to provide variation in operating power. (7)Maximum power rating. (8)DC voltage chart. (9)Tune-up procedure. (10) A description of all frequency determining and stabilization circuits. A description of the circuits used to suppress spurious radiation, limiting modulation, and limiting power. (12) Drawing with labels for controls and complete circuit diagrams. Signed:________________________________ Kevin G. Matson - Project Engineer MAINTENANCE / REPAIR / OPERATING MANUAL FOR USE BY AUTHORIZED SERVICE/MAINTENANCE PERSONNEL ONLY RQX-156-MRM Rev. A 03/04 Copyright  2004 RITRON, INC. – ALL RIGHTS RESERVED RITRON  , PATRIOT  , JOBCOM  , Quick Assist  , and Quiet Call  are registered trademarks of RITRON, INC. OUTPOST  and Quick Talk  are trademarks of RITRON, INC. P.O. Box 1998, Carmel, IN 46082-1998 • •• • 505 W. Carmel Dr., Carmel, IN 46032 • •• • USA Phone: 317-846-1201 or 800-USA-1-USA (800-872-1872) • •• • FAX: 317-846-4978 Web: www.radiocallbox.com • •• • E-mail: [email protected] Model RQX-156 OUTPOST    Wireless Callbox TABLE OF CONTENTSRQX-156 Have questions? Call 317-846-1201 or visit our website at www.ritron.com1 TOPICPAGE IMPORTANT MAINTENANCE/REPAIR INFORMATION ................................................... 1 SPECIFICATIONS GENERAL.................................................................................................................... 2 RECEIVER................................................................................................................... 2 TRANSMITTER............................................................................................................3 POWER REQUIREMENTS AT 12 VDC ......................................................................3 CONTROLS................................................................................................................. 3 INTRODUCTION GENERAL.................................................................................................................... 4 Model Identification............................................................................................... 4 LICENSING.................................................................................................................. 4 How to Obtain an FCC Radio License.................................................................. 4 EXPOSURE TO RADIO FREQUENCY ENERGY....................................................... 4 OPERATION BASIC RADIO OPERATION Fig. 1 Radio Controls............................................................................................ 5 On-Off................................................................................................................... 5 Receive................................................................................................................. 5 • Carrier Squelch.................................................................................................. 5 • Tone Squelch..................................................................................................... 5 • 2-Tone Paging................................................................................................... 5 QC and DQC Tone Codes.................................................................................... 5 2-Tone Paging...................................................................................................... 5 Transmit................................................................................................................ 6 Battery Saver........................................................................................................ 6 WHAT THE RADIO ALERT TONES MEAN Power On/Transmit............................................................................................... 6 Error Tones........................................................................................................... 6 Transmitter Time Out............................................................................................ 6 Battery Saver Turn Off.......................................................................................... 6 OPTIONAL RADIO TONES......................................................................................... 6 Courtesy Beep...................................................................................................... 6 Busy Channel TX Inhibit....................................................................................... 6 TROUBLESHOOTING General................................................................................................................. 7 Tone Coded Squelch............................................................................................ 7 Error Tones........................................................................................................... 7 CALLBOX CONTROLS AND CONNECTORS............................................................. 8 FIG-2: Callbox Assembly, Controls and Connectors........................................... 8 TABLE OF CONTENTSRQX-1…

Text truncated - open the document above for the full version.

68 TYPE OF EXHIBIT:SEMICONDUCTOR FUNCTION FCC PART:2.1033 (c) (10) MANUFACTURER:RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 MODELS:RQX-156, RQX-156-XT FCC ID:AIERIT18-156 DATE:November 6, 2003 DESCRIPTION: The following list specifies the manufacturer, identification and function of each semiconductor device used in the RQX-156 Callbox Transceiver. REFPN# ManufacturerManufacturer IDFunction CR10148D100A2M/A Com, Inc.MA4CP101ATX/RX switching CR10248E1005GON SemiconductorsMMBD-352LT1Voltage clamp CR10348A1005CON SemiconductorsMMBD7000LT1Biased noise detector CR20148D100A2M/A Com, Inc.MA4CP101ATX/RX switching CR30148A1005CON SemiconductorsMMBD7000LT1Voltage clamp CR40148C1004GON SemiconductorsMMBV-2101LVCO modulation CR40248CB0002Philips SemiconductorsBB149AVCO tuning CR40348A1005CON SemiconductorsMMBD7000LT1Biasing CR40448A1004DON SemiconductorsMMBV3401TITX/RX VCO switching CR50148AA01SAVishayS1B-13Battery charging CR50248B61012Philips Semiconductors BZD27-C12Voltage regulation CR50348A1005BON SemiconductorsMMBD6100LT1Turn-on detection CR50448A1005CON SemiconductorsMMBD7000LT1Voltage clamp CR50548A1005CON SemiconductorsMMBD7000LT1Voltage clamp CR50602450101PanasonicLN514GK-GREEN7-segment LED display CR50748AA01SAVishayS1B-13Reverse voltage protection Q 1014801002APhilips SemiconductorsPMBT3906RX +V switching Q 102482100V0Philips SemiconductorsPBR951RX RF amplifier Q 1044821003BMotorola SemiconductorsMMBT918LT1RX IF amplifier Q 1054821003BMotorola SemiconductorsMMBT918LT1RX 2nd LO multiplier/amp Q 1074841006BON SemiconductorsMMBF5484LT1Analog switch Q 20148180001ON Semiconductors BCP69T1TX +V switching Q 2024801001QON SemiconductorsMMBT-5088LT1TX +V switching Q 203482100P2Philips SemiconductorsBFR92ATX RF amplifier Q 204482800P2Philips SemiconductorsBFR92ATX RF amplifier Q 205482300FFPhilips SemiconductorsBFQ18ATX RF driver amplifier Q 20604801032Motorola SemiconductorsMRF-553TX Final amplifier Q 2074801001QON SemiconductorsMMBT-5088LT1TX +V switching Q 3014841006BON SemiconductorsMMBF5484LT1AGC switch Q 3024801001QON SemiconductorsMMBT-5088LT1AGC audio detection Q 30348010A8AON SemiconductorsMMUN2211T1Audio amplifier enable Q 304480100DHON SemiconductorsBCW68GLT1Audio amplifier +V switching Q 401482100P2Philips SemiconductorsBFR92AVCO buffer amplifier Q 402482100P2Philips SemiconductorsBFR92AVCO buffer amplifier Q 403482100P2Philips SemiconductorsBFR92AVCO oscillator Q 4044801001QON SemiconductorsMMBT-5088LT1VCO voltage de-coupling Q 40548010A6AON SemiconductorsMMUN2111LT1TX/RX VCO switching REFPN# ManufacturerManufacturer IDFunction 69 Q 40648010002ROHM UMG9NTX/RX VCO switching Q 5014801001QON SemiconductorsMMBT-5088LT1External voltage detect Q 50248010A8AON SemiconductorsMMUN2211T1External +V switching Q 5034801002APhilips SemiconductorsPMBT3906External +V switching Q 50448180006Central SemiconductorCZT122External +V switching Q 50548130001Central SemiconductorCBCX69Battery +V switching Q 5064801001QON SemiconductorsMMBT-5088LT1Battery +V switching Q 507480100DHON SemiconductorsBCW68GLT1+5V switching Q 50848010A8AON SemiconductorsMMUN2211T1Relay activation Q 5094821003BMotorola SemiconductorsMMBT918LT1Micro clock amplifier Q 51048010A6AON SemiconductorsMMUN2111LT1+5V regulator turn-off Q 51148010A8AON SemiconductorsMMUN2211T1+5V regulator turn-off U 10131030006Toshiba TA31136FNRX FM-IF subsystem U 1023151AAASMaxim Integrated Products MAX2681EUT-TRX 1 st mixer U 301311K0001Philips Components74LV4066PWAudio signal switching U 302310K0004National SemiconductorsLMV324MTAudio processing U 303310K0004National SemiconductorsLMV324MTAudio processing U 304310K0002Maxim Integrated Products MAX7410CUATone low pass filter U 305310K0001Dallas SemiconductorDS1806EAudio signal level control U 30603131009National SemiconductorsLM-386N-3Audio amplifier U 30731134053Philips Components74HC4053D Audio signal switching U 30831030007Philips ComponentsSA575DAudio processing U 401313K0006National SemiconductorsLMX2306TMFrequency synthesizer U 501314L0003Motorola Semiconductors MC68HC908GR8FA Microcontroller U 50231010001National Semiconductors LP2951ACM+5V regulator U 50331210006Atmel CorporationAT24C08AN-10SCEEPROM U 504311K0004Philips Components74HC595PWMultiplexer U 505311K0004Philips Components74HC595PWMultiplexer

64 TYPE OF EXHIBIT :TUNE-UP PROCEDURE FCC PART :2.1033 (c)(9) MANUFACTURER :RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 FCC ID: AIERIT18-156 MODELS :RQX-156, RQX-156-XT DATE: February 24, 2004 The tune-up procedure included in this exhibit is an excerpt of the Maintenance and Operating Manual for RITRON Model RQX-156 VHF-FM Callbox Transceiver. The complete Maintenance and Operating Manual is included with this application for Certification as a separate exhibit. Signed: ________________________________ Kevin G. Matson - Project Engineer 65 RECOMMENDED TEST EQUIPMENT 1) RF Communications Test Set (to 170 MHz) with:2) Oscilloscope (to 20 MHz) - FM Deviation Meter3) VTVM or DMM - RF Wattmeter4) RITRON PC Programming Kit - Frequency Counter (to 170 MHz)5) 0 to +15 VDC, 2A current-limited power supply - SINAD Measuring Device RADIO PREPARATION 1) Connect the power supply to the RQX-156 +12 VDC Input and set it to +12 VDC. 2) Connect the serial programming cable from the PC computer (with the RITRON PC programming kit software installed) to the RJ11 program jack. 3) Remove the RQX-156 antenna and connect the FM communications test set to the BNC antenna connector. 4) Turn on the radio to place it in operating mode. 5) From the PC Programmer on-screen menu, select “Tune Radio” to display the Alignment screen. 6) Set the RF Communications Test set to the Alignment Frequency indicated on the Alignment screen. 7) Press the appropriate “Select” button on the Alignment screen to make the following adjustments: SELECTAlignmentSELECTAlignment FrequencyTransmit frequencyToneQC/DQC tone encode deviation wide and narrow band Mod BalModulation balanceVoiceVoice deviation with no tone wide and narrow band Voice deviation with tone wide and narrow band 8) After you have completed alignment of the RQX-156, turn the radio off. This will remove the test frequencies and return to operation on the customer’s programmed frequencies. REFERENCE FREQUENCY 1) Make sure the unit has been switched on and is at room temperature (approximately +25 ° C) 2) Select “Frequency” from the PC Programmer “Alignment” screen. 3) Set the RF communications test set to the Alignment Frequency on the “Alignment” screen. 4) Press the “Tune” button on the “Alignment” screen to activate the transmitter. 5) Transmitter frequency error should be less than +/- 500 Hz. 6) If frequency adjustment is required, press the left arrow on the tuning bar to lower the frequency or the right arrow to raise the frequency. 7) Press the “Save” button to store the new alignment setting or “Cancel” to leave setting unchanged. WARNING! An authorized RF service technician must perform test and alignment of the RQX-456. Do not attempt service of the RQX-156 if not completely familiar with the operation of frequency synthesized radio operation. The RQX- 156 can operate in both Narrow Band (2.5 KHz deviation) and Wide Band (5 KHz deviation) systems. 66 MODULATION BALANCE Transmitter modulation balance has been set at the factory and should not require adjustment. 1) Select “Mod Bal” from the PC Programmer “Alignment” screen. 2) Set the RF communications test set to the Alignment Frequency on the “Alignment“ screen. 3) Press the “Tune” button on the “Alignment” screen to activate the transmitter. 4) Check the de-modulated waveform for a 20 Hz squa…
