Page 1 RQX-156M_Attest.pdf TYPE OF EXHIBIT: DESCRIPTION OF MEASUREMENT FACILITY FCC PART: 2.948 MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 The ERP and field strength of spurious emissions measurements filed with this application were made on a site certified by RITRON, Inc. Data pertaining to this site are on file with the FCC and Industry Canada. This site is used on a continuing basis exclusively by RITRON, Inc. and is utilized only for RF field strength measurements of equipment designed and manufactured by RITRON, Inc. It is not used for measurements by, or for, any other party on a contract basis or otherwise. All other measurements were taken at RITRON’s engineering laboratory in Carmel, IN. Signed: Michael A. Pickard - Project Engineer Page 2 RQX-156M_Attest.pdf TYPE OF EXHIBIT: MANUFACTURER’S STATEMENT FCC PART: 2.1033(c)(1)(2) MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 The RITRON models RQX-156M and RQX-156M-XT are designed for operation strictly limited to MURS frequencies as defined in FCC Part 95.1309 with a channel bandwidth defined in FCC Part 95.632. Its output power is set at 2.0 watts maximum. This product will be manufactured and marketed on a continuing basis in the United States of America by the applicant, RITRON, Inc. of Carmel, IN. Signed: Michael A. Pickard - Project Engineer Page 3 RQX-156M_Attest.pdf TYPE OF EXHIBIT: STATEMENT OF CERTIFYING ENGINEER FCC PART: 2.947 MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 I, Michael A. Pickard, have been employed by RITRON, Inc. since November 1979, working in the Engineering Department since June 1981 as a radio frequency Project Engineer. I hereby certify that all the measurements and data herein were taken by me, or under my direct supervision and that they were obtained using sound and accepted engineering principles and that they accurately reflect the performance and characteristics of the unit tested. Further, I attest that manufacturing controls exist such that this data are representative of units which will be manufactured by RITRON. Signed: Michael A. Pickard - Project Engineer Page 4 RQX-156M_Attest.pdf TYPE OF EXHIBIT: ANTI-DRUG ABUSE CERTIFICATION FCC PART: MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 I, Michael A. Pickard, certify that RITRON is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862 because of a conviction for possession or distribution of a controlled substance. Signed: Michael A. Pickard - Project Engineer

Page 1 RQX-156M_ConfidReq.pdf Ritron, Incorporated 505 W. Carmel Drive · Carmel, IN 46032 P. O. Box 1998 · Carmel, IN 46082 Ph: 317-846-1201 Email: [email protected] Web Site: www.ritron.com August 21, 2014 Ritron Inc. 505 West Carmel Dr. Carmel, IN 46032 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: AIERIT38-156M Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request long term confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Schematics Operational Description Semiconductor List Tune-up Procedure RQX-156M_BlkDia.pdf RQX-156M_Schem.pdf RQX-156M_OpDes.pdf RQX-156M_PartsLst.pdf RQX-156M_TunPro.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Sam L. Dulaney Chief Engineer Ritron, Inc. Email: [email protected]

Ritron, Inc. 505 W. Carmel Drive  Carmel, IN 46032-7564 P.O. Box 1998  Carmel, IN 46082-1998 Ph: 317-846-1201 Fax: 317-846-4978 Email: [email protected] Web Site: www.ritron.com Page 1 RQX-156M_FreqAttest.pdf August 21, 2014 Ritron Inc. 505 West Carmel Dr. Carmel, IN 46032 Timco Engineering Inc. 849 NW State Road 45 Newberry, Florida 32669 Dear Sir/Madam: The Part 95J MURS radio AIERIT38-156M has no provisions for programming on any except the 5 MURS frequencies. Frequencies are programmed exclusively from a table that only contains the 5 MURS frequencies. No other frequency programming is possible. Sincerely, Michael A. Pickard Project Engineer Ritron, Inc.

TYPE OF EXHIBIT: TABLE OF CONTENTS FCC PART: MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 Following is a list of exhibits required by the Federal Communications Commission for the application to and grant of FCC Certification. File / Exhibit FCC Part RQX-156M_731Form.pdf Timco Form 731 ............................................................................................................ 2.1033 (a) RQX-156M_ConfidReq.pdf Letter of request for confidentiality ................................................................................ 0.457, 0.459 RQX-156M_FreqAttest.pdf MURS frequency Letter ................................................................................................. RQX-156M_Attest.pdf Description of Measurement Facility ............................................................................. 2.948 Manufacturer’s Statement ............................................................................................. 2.1033 (c) (1-2) Statement of Certifying Engineer................................................................................... 2.947 Anti-Drug Abuse Certification ........................................................................................ RQX-156M_RFExp.pdf Transmitter Effective Radiated Power ........................................................................... 1.1310 Maximum Permissible Exposure Evaluation .................................................................. 2.1091 (d) (4) RF Warning Statement .................................................................................................. 1.1310 RQX-156M_BlkDia.pdf Block Diagram .............................................................................................................. 2.1033 (b) (5) RQX-156M_Schem.pdf Schematic Drawings ..................................................................................................... 2.1033 (c) (10) RQX-156M_IntPho.pdf Internal Photographs ..................................................................................................... 2.1033 (c) (12) RQX-156M_ExtPho.pdf External Photographs.................................................................................................... 2.1033 (c) (12) RQX-156M_LabelLoc.pdf FCC ID Label Location .................................................................................................. 2.1033 (c) (11) RQX-156M_LabelSmpl.pdf FCC ID Label Sample ................................................................................................... 2.1033 (c) (11) RQX-156M_OpDes.pdf Operational Description ................................................................................................. 2.1033 (c) (4, 5, 7, 8, 10) RQX-156M_TunePro.pdf Tune-Up Procedure ...................................................................................................... 2.1033 (c) (9) RQX-156M_PartsLst.pdf Semiconductor Function ............................................................................................... 2.1033 (b) (4) RQX-156M_TestRpt.pdf List of Test Equipment Used ......................................................................................... 2.947 (d) Description of Measurement Facility ............................................................................. 2.948 Radio Frequency Power Output .................................................................................... 2.1046 (a), 95.639 (h) Transmitter Audio Overall Response ............................................................................. 2.1047 (a) Transmitter Audio Lowpass Filter .................................................................................. 2.1047 (a) Modulation Limiting ....................................................................................................... 2.1047 (b) Emissions Designator ................................................................................................... 2.1049 (c)(1), 95.631 (j) Occupied Bandwidth ..................................................................................................... 2.1049 (c)(1), 95.635 (e)(1)(2) Spurious Emissions at Antenna Terminals .................................................................... 2.1051 Field Strength of Spurious Emissions ............................................................................ 2.1053 Frequency Stability vs. Temperature ............................................................................. 2.1055 (a)(1), 95.632 (c) Frequency Stability vs. Battery Voltage ......................................................................... 2.1055 (d)(1), 95.632 (c) Transient Frequency Behavior ...................................................................................... 90.214 RQX-156M_UserMan.pdf Installation and Operating Instruction Manual ................................................................ 2.1033 (c) (3)

Page 1 RQX-156M_ExtPho.pdf TYPE OF EXHIBIT: EXTERNAL PHOTOGRAPHS FCC PART: 2.1033(c)(12) MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 Included in this exhibit are photographs of the RITRON Model RQX-156M and RQX-156M-XT case assembly. Additional photographs of the radio printed circuit board construction and installation are included with this certification request as separate exhibits. SIGNED: Michael A. Pickard - Project Engineer Page 2 RQX-156M_ExtPho.pdf EXHIBIT: RQX-156M front view showing controls FCC ID: AIERIT38-156M Page 3 RQX-156M_ExtPho.pdf EXHIBIT: RQX-156M back view FCC ID: AIERIT38-156M Page 4 RQX-156M_ExtPho.pdf EXHIBIT: RQX-156M-XT front view showing controls FCC ID: AIERIT38-156M

Page 1 RQX-156M_LabelLoc.pdf TYPE OF EXHIBIT: FCC ID LABEL LOCATION FCC PART: 2.1033 MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 Photographs indicate the location of the FCC label on the case and do not represent the actual FCC label. A label drawing is included with this certification request as a separate exhibit. EXHIBIT: RQX-156M back view showing FCC Identification label location FCC ID: AIERIT38-156M LOCATION OF FCC SERIAL LABEL Page 2 RQX-156M_LabelLoc.pdf TYPE OF EXHIBIT: FCC ID LABEL LOCATION FCC PART: 2.1033 MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 2.925(d) states “In order to validate the grant of equipment authorization, the nameplate or label shall be permanently affixed to the equipment and shall be readily visible to the purchaser at the time of purchase.” For Ritron model RQX-156M-XT the FCC label is affixed to the enclosure in which the radio is housed. The label is readily visible during normal installation as the faceplate must be removed to install batteries or apply power. This is accomplished using the T-25 Torx bit attached to the product when purchased. The yellow XT case is a ruggedized outside cover in which the actually radio enclosure is placed. EXHIBIT: RQX-156M-XT with ruggedized outside faceplate removed to show location of FCC identification label on the radio case. FCC ID: AIERIT38-156M SIGNED: Michael A. Pickard - Project Engineer LOCATION OF FCC SERIAL LABEL

Page 1 RQX-156M_LabelSmpl.pdf TYPE OF EXHIBIT: FCC ID LABEL SAMPLE FCC PART: 2.1033 MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 Ritron drawing 14200207B specifies the FCC label for model RQX-156M. Photographs to indicate the position of the label on the case are included with this certification request as a separate exhibit. Each serial number is recorded, along with the date of manufacture, and is kept on file at RITRON, Inc. Serialization will begin with serial number E1234. The size of the serial label is 2.00” by 1.00”. SIGNED: Michael A. Pickard - Project Engineer Page 2 RQX-156M_LabelSmpl.pdf RITRON, INC. 505 West Carmel Drive Carmel, IN 46032 DRAWN BY CHK’D TRACED SCALE DATE APP’D MATERIAL DRAWING NO. REVISIONS NO. DATE BY 1 2 3 4 5 TOLERANCES (EXCEPT AS NOTED) DECIMAL ± FRACTIONAL ± ANGULAR ± NOTES: 1. MATERIAL IS IDENTCO IDENTIFICATION TTL302-740-6 (RITRON PN 14290016) 2. SILVER BACKGROUND LABEL WITH BLACK GRAPHICS. 3. ALL CHARACTERS ARE ARIAL TYPE STYLE, 4 POINT TYPE SIZE. 4. SERIALIZATION INCLUDES 4-DIGIT RITRON DATE CODE FOLLOWED BY SERIAL NUMBER. 5. MODELS INCLUDED PER THIS DRAWING LISTED AT RIGHT. 1.00” 2.00” SERIAL LABEL / FCC ID: AIERIT38-156M MODEL: RQX-156M, RQX-156M-XT MAP 2:1 08/21/14 14200207B Designed and Manufactured in Carmel, Indiana USA www.ritron.com · 317-846-1201 800-872-1872 Model: CFG: SN: RQX-156M 1422E1234 FCC ID: AIERIT38-156M Product satisfies General Population requirements for RF exposure. See User Manual for operating instructions. MODELS: RQX-156M RQX-156M-XT

Page 1 RQX-156M_IntPho.pdf TYPE OF EXHIBIT: INTERNAL PHOTOGRAPHS FCC PART: 2.1033(c)(12) MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 Included in this exhibit are photographs of the RITRON Model RQX-156M printed circuit board assembly and installation. Additional photographs of the radio construction and layout, labels, and chassis assembly are included with this certification request as separate exhibits. SIGNED: Michael A. Pickard - Project Engineer Page 2 RQX-156M_IntPho.pdf EXHIBIT: RQX-156M complete top side PCB assembly with shields and internal antenna removed FCC ID: AIERIT38-156M Page 3 RQX-156M_IntPho.pdf EXHIBIT: RQX-156M complete top side PCB assembly with shields and internal antenna installed FCC ID: AIERIT38-156M Page 4 RQX-156M_IntPho.pdf EXHIBIT: RQX-156M complete bottom side PCB assembly FCC ID: AIERIT38-156M Page 5 RQX-156M_IntPho.pdf EXHIBIT: RQX-156M with 3 D-cell batteries. Case open to show printed circuit board installation FCC ID: AIERIT38-156M Page 6 RQX-156M_IntPho.pdf EXHIBIT: RQX-156M with 6 AA-cell batteries. Case open to show printed circuit board installation FCC ID: AIERIT38-156M Page 7 RQX-156M_IntPho.pdf EXHIBIT: RQX-156M-XT with 6 D-cell batteries. Case open to show printed circuit board installation FCC ID: AIERIT38-156M

Page 1 RQX-156M_RFExp.pdf TYPE OF EXHIBIT: TRANSMITTER EFFECTIVE RADIATED POWER FCC PART: 1.1310 MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 PROCEDURE: 1. The measurements for effective radiated power were taken at the RITRON, Inc. 3-meter test site, details of which are on file with the FCC. These measurements were via the substitution method. 2. The RQX-156M was aligned for transmitter operation on frequencies represent the lower and upper range of the desired operating band at the rated transmitter output power. 3. The RQX-156M was tested in each of the three configurations:  Installed in the basic enclosure, powered by 3 D-cell batteries for 900mW TX power, operating with the internal antenna installed on the PCB.  Installed in the basic enclosure, powered by 6 AA-cell batteries for 2W TX power, operating with the internal antenna installed on the PCB.  Installed in an XT enclosure, powered by 6 D-cell batteries for 2W TX power, terminated at the antenna port with the Ritron AFB-1545 antenna include with the product. (The user can connect other antennas, however.) 4. The ERP measurements were made with an Advantest R3265A Spectrum Analyzer and an Electro- Metrics LPA-25 log periodic antenna. 5. The height of the LPA-25 receiving antenna and orientation of the RQX-156M were varied to provide maximum field strength at the receiving antenna. 6. A calibrated ½-wave dipole antenna was substituted for the RQX-156M on the turntable 3 meters from the pick up antenna. An Agilent N5181A RF signal generator was set at the 3 frequencies representing the low, middle and upper range of the desired operating band with a 0 dBm output level. 7. The height of the LPA-25 receiving antenna was adjusted for maximum signal strength at the receiving antenna. The level at the field strength antenna was noted. Page 2 RQX-156M_RFExp.pdf TYPE OF EXHIBIT: TRANSMITTER EFFECTIVE RADIATED POWER FCC PART: 1.1310 MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 CALCULATIONS: The substitution antenna is specified by the manufacturer in terms of antenna factor rather than antenna gain. The conversion is: Ga(dBd) = 20 log f (MHz) –AF (dB) -31.9 The effective radiated power can be calculated as: ERP(dBm) = Pr(dBm) - Pref(dBm) + Pgen(dBm) – Ga(dBd) Where:  Pr is the power level of the radio’s emission at the receiving antenna output.  Pgen is the RF signal generator level at the substitution antenna input.  Pref is the power level of the substitution antenna emission at the receiving antenna output.  Ga is the gain of the substitution antenna. The ERP is converted to Watts from dBm by: ERP(watts) = antilog((ERP(dBm) – 30)/10) Basic Enclosure, 3 D-cell batteries, Internal PCB mounted Antenna, 900 mW Frequency Pr Pref Pgen Ga ERP ERP (MHz) (dBm) (dBm) (dBm) (dBd) (dBm) (watts) 151.820 -2.34 -22.32 -1.24 2.63 16.12 0.04 154.600 0.59 -21.83 -1.21 2.64 18.57 0.07 Basic Enclosure, 6 AA-cell batteries, Internal PCB mounted Antenna, 2 W Frequency Pr Pref Pgen Ga ERP ERP (MHz) (dBm) (dBm) (dBm) (dBd) (dBm) (watts) 151.820 3.88 -22.32 -1.24 2.63 22.34 0.17 154.600 4.91 -21.83 -1.21 2.64 22.89 0.19 XT Enclosure, 6 D-cell batteries, AFB-1545 Antenna, 2 W Frequency Pr Pref Pgen Ga ERP ERP (MHz) (dBm) (dBm) (dBm) (dBd) (dBm) (watts) 150.820 -12.74 -16.23 -1.24 2.63 -0.38 0.001 154.600 -12.09 -16.02 -1.21 2.64 +0.08 0.001 Signed: Michael A. Pickard - Project Engineer Page 3 RQX-156M_RFExp.pdf TYPE OF EXHIBIT: MAXIMUM PERMISSABLE EXPOSURE EVALUATION FCC PART: 2.1091(d)(4) MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 PROCEDURE AND EQUATIONS: The ERP values previously calculated will be used to determine the minimum safe distance from the antenna supplied by RITRON in order not to exceed the General Population/Uncontrolled Limits of RF exposure. The ERP must be converted to EIRP to simulate an isotropic radiator. Typical transmit duty cycles are between 5% and 10%. Over the 30 minute averaging period for General Population/Uncontrolled MPE limits, a 50% maximum duty cycle is reasonable, and will be used in the MPE calculations for this device. EIRP = 1.64 (ERP/2) For the RQX-156M with internal PCB mounted antenna: EIRP = 0.1595 W For the RQX-156M-XT with AFB-1545 antenna: EIRP = 0.0008 W Power density is related to EIRP: S(W/m 2 ) = EIRP(W)/4r 2 where r is the distance from the source in meters. Rearranging for distance: r = SQRT (EIRP/4S). The MPE limit for this device operating in a General Population/Uncontrolled environment is 0.2 mW/ cm 2 For the equation above, mW/cm 2 must be converted to W/m 2 . Since 1 mW/cm 2 = 10 W/m 2 , the FCC limit is 2 W/m 2 . Substituting and solving for distance: Model /Antenna Distance for MPE (in. / cm) RQX-156M / Internal PCB mounted 2.40 / 6.1 RQX-156M-XT / AFB-1545 0.19 / 0.5 With the antenna(s) available from RITRON for use with this product, users must remain more than 2.40 inches (6.1 cm) from the Internal PCB mounted antenna while the unit is transmitting. For the Internal PCB mounted antenna, the minimum expected separation of 20 cm (7.9 inches) results in RF exposure levels well below the General Population/Uncontrolled MPE limits. Other antenna may require lesser or greater distances depending upon their gain relative to that available from RITRON. Page 4 RQX-156M_RFExp.pdf TYPE OF EXHIBIT: RF WARNING STATEMENT FCC PART: 1.1310 MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 WARNING STATEMENT: The following statement appears in the Users Manual: PLEASE NOTE THE FOLLOWING WITH REGARD TO RF EXPOSURE FOR THIS PRODUCT: EXPOSURE TO RADIO FREQUENCY ENERGY: RQX-156M, RQX-156M-XT: This product gene…

Text truncated - open the document above for the full version.

Page 1 RQX-156M_TestRpt.pdf TYPE OF EXHIBIT: TEST REPORT FCC PART: 2.1033 (c)(14) MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 The following is a list of attached exhibits required by the Federal Communications Commission for the application to and grant of FCC Type Acceptance. All tests are per TIA-603-D (2010) where applicable. TABLE OF CONTENT: EXHIBIT FCC PART(S) PAGE Test Equipment List 2.947 (d) pg 2 Description of Measurement Facility 2.948 pg 3 Radio Frequency Power Output 2.1046 (a), 95.639 (h) pg 4-5 Transmitter Audio Overall Response 2.1047 (a) pg 6-7 Transmitter Audio Lowpass Filter 2.1047 (a) pg 8-9 Modulation Limiting 2.1047 (b) pg 10-12 Emissions Designator 2.1049 (c)(1), 95.631 (j) pg 13 Occupied Bandwidth 2.1049 (c)(1), 95.635 (e)(1)(2) pg 14-16 Spurious Emissions at Antenna Terminals 2.1051 pg 17-18 Field Strength of Spurious Emissions 2.1053 pg 19-22 Frequency Stability vs. Temperature 2.1055 (a)(1), 95.632 (c) pg 23-25 Frequency Stability vs. Voltage 2.1055 (d)(1), 95.632 (c) pg 26 Transient Frequency Behavior 90.214 pg 27-30 Page 2 RQX-156M_TestRpt.pdf TYPE OF EXHIBIT: TEST EQUIPMENT LIST FCC PART: 2.947 (d) MANUFACTURER: RITRON, INC. MODELS: RQX-156M, RQX-156M-XT TYPE OF UNIT: MURS VHF-FM Callbox 2-Way Radio FCC ID: AIERIT38-156M DATE: August 21, 2014 TEST EQUIPMENT: The measured data in this report was obtained using one or more of the following pieces of equipment. The particular equipment used in any one test is detailed in the procedure for that test. ITEM MANUFACTURER MODEL NO. SERIAL NO. Last Cal EXP Cal Comms Test Set Aeroflex IFR COM-120B 485001757 6 DEC 2013 6 DEC 2014 Signal generator Agilent N5181A MY46240065 04 NOV 2013 04 NOV 2016 Spectrum Analyzer Advantest R3265A 75060189 02 OCT 2013 02 OCT 2014 Log Periodic Antenna Electro-Metrics LPA-25 8-102 30 APR 2014 30 APR 2017 Dipole Antenna Electro-Metrics BDA-25 8-101 30 APR 2014 30 APR 2017 Dipole Antenna Electro-Metrics EM-6925 292 8 APR 2014 8 APR 2015 Dipole Antenna Electro-Metrics EM-6927 292 8 APR 2014 8 APR 2015 Gain horn EMCO 3105 2034 22 OCT 2013 22 OCT 2015 SUPPORT EQUIPMENT: ITEM MANUFACTURER MODEL NO. SERIAL NO. Power Supply BK Precision 1630 146-03508 Digital Oscilloscope Philips PM-3335 DM648004 Digital Multimeter Fluke 179 82800086 Temperature Chamber Associated Laboratories ELH-0.5-LC N/A Thermocouple Omega 7035-J-225 8504 272 MHz high pass filter Ritron 30dB Power Attenuator Bird 8306-300-N N/A 10dB Attenuator ELCOM AT-51-10 N/A SIGNED: Michael A. Pickard -…
