AJDK084Speed & Cadence Sensor

ENEN FR Speed & Cadence Sensor SGY-CH500B User’s Manual Manuel de l'utilisateur SGY-CS500 2 EN Table of Contents Features ...................................................................................................................2 Important Safety Information ...................................................................................3 Before Use (Important) ............................................................................................9 Product Configuration .............................................................................................12 Part Names and Functions .....................................................................................13 Installation on Your Bike .........................................................................................14 Installing the Cadence Magnet .............................................................................................14 Installing the Speed & Cadence Sensor ..............................................................................15 Installing the Speed Magnet .................................................................................................16 Fixing the Sensor ..................................................................................................................18 Installing and Removing the Battery ......................................................................19 Troubleshooting ......................................................................................................21 Specifications ........................................................................................................22 Features Trip Data Acquisition This device acquires trip data like speed and cadence, and those data are displayed on the cyclocomputer. This product is ANT+™ certified. Visit http://www.thisisant.com/directory/ for a list of compatible products and apps. 3 EN Important Safety Information Pioneer Speed & Cadence Sensor is not a medical device. Important Information About This Device This device helps provide feedback about cycling. It is intended solely for recreational purposes. THE LIMITED WARRANTY PROVIDED WITH THIS DEVICE CONSTITUTES THE EXCLUSIVE WARRANTIES FOR THE PRODUCT AND THE USER’S EXCLUSIVE REMEDIES. TO THE MAXIMUM EXTENT ALLOWED BY APPLICABLE LAW, ALL OTHER WARRANTIES, WHETHER EXPRESS, IMPLIED, OR STATUTORY, INCLUDING WITHOUT LIMITATION ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED. IN NO EVENT WILL PIONEER, ITS AFFILIATES, OR THEIR RESPECTIVE EMPLOYEES, DIRECTORS, OR OFFICERS, BE LIABLE FOR ANY INDIRECT, INCIDENTAL, CONSEQUENTIAL, SPECIAL, PUNITIVE OR EXEMPLARY DAMAGES IN CONNECTION WITH THIS DEVICE, REGARDLESS OF THE THEORY OF LIABILITY AND EVEN IF SUCH DAMAGES ARE FORESEEABLE. BECAUSE SOME STATES OR JURISDICTIONS MAY NOT ALLOW LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, OR LIMITATIONS ON OR EXCLUSIONS OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, SOME OF THE ABOVE LIMITATIONS MAY NOT APPLY TO A USER DEPENDING ON HER, HIS, OR ITS STATE OF RESIDENCE. 4 EN Important Safety Information WARNING BEFORE BEGINNING OR • MODIFYING ANY EXERCISE ACTIVITY, ALWAYS CONSULT YOUR PHYSICIAN FIRST. IF YOU ARE USING A PACEMAKER OR ANY OTHER IMPLANTED DEVICE, CONSULT YOUR PHYSICIAN BEFORE USING A HEART RATE SENSOR. THIS PRODUCT IS NOT A • MEDICAL DEVICE, AND COULD EXPERIENCE INTERFERENCE FROM EXTERNAL ELECTRICAL SOURCES. WARNING Follow these guidelines as well to ensure safe Cycling: Always use your best judgement, • and ride in a safe manner. Do not become distracted by this device while riding, and always be fully aware of your surroundings. Secure your bicycle in a safe place • before replacing batteries as the bicycle could fall causing injury. Upon replacing the battery, install • the the battery cover securely to ensure water resistance and prevent potential injury if the cover falls off. Do not leave small parts such as • screws or the battery in an area that infants and small children can reach to prevent accidental swallowing. If you think this may have happened, call 911 for a medical emergency. Before riding, check that the Speed • & Cadence sensor does not contact with a crank or spoke. 5 EN Important Safety Information Before riding, check that the sensor • and magnets are installed securely. Also check that the speed detector arm’s screw is not loose, there are no cracks in the band, and the band’s fixing tape is not coming off. Do not leave this device in places • that are exposed to direct sunlight, high temperature, high humidity, or a lot of dust as it may cause the device to malfunction. Never dismantle, refurbish, or repair • this device or any attached parts as it could cause electrical shock or the device to malfunction. Do not use this device if any unusual • conditions exist such as penetration by a foreign object, water submersion, smoke is detected, or an unusual odor is detected. Stop using this device immediately and have it repaired. Do not subject this device to • extreme shock by riding on rough roads. Doing so could damage this device or cause it to malfunction. This device communicates using ANT+ • radio communication. Do not use in areas that forbid the use of electronic devices such as hospitals or airplanes as unintended interference from this device could cause serious accidents. CAUTION Do not wipe this device with • detergents, chemical duster, or volatile compounds such as benzine or thinner as they may cause the device to malfunction. Thoroughly remove any excess • bicycle lubricants or cleaners from this device as it could cause damage. Avoid overly violent impacts on • this device as it may cause it to malfunction. Do not wash this device with a high • pressure water sprayer as water may penetrate into this device causing it to malfunction. Do not touch or deform the battery • contacts. This could cause a faulty connection or short circuit. 6 EN Important S…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 2014-10-27 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name AJDK084 SGY-CS500 For the product stated above, we request permanent confidentiality for exhibits which contain Operational Description, Block Diagram, Schematics. The above exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact me at the address shown below. Sincerely, (signed) Name:Makoto Kaieda Company: Pioneer Corporation

Model:SGY-CS500 FCC ID:AJDK084 IC:775E-K084 Model:SGY-CS500

2.4G Antenna

Report Number: 60/760.11.318.04 Page 1 of 27 TÜV SÜD HONG KONG LTD., 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 TÜV SÜD HONG KONG LTD., Unit 601, InnoCentre, 72 Tat Chee Avenue, Kowloon Tong, Hong Kong. Tel: +852-2776 1323 Fax: +852-2776 1206 FCC / IC – Test report Report Number : 60/760.11.318.04 Date of Issue: October 23, 2014 Model : SGY-CS500 Product Type : Speed & Cadence Sensor Applicant : Pioneer Corporation. Address : 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa-ken, Japan Production Facility : Kendy Enterprise Ltd. Address : 2-12 Kwai Fat Road, 11-A Kwai Chung, New Territories, Hong Kong Test Result :  Positive  Negative Total pages including Appendices : 29 TÜV SÜD Hong Kong Ltd. is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO 17025. TÜV SÜD Hong Kong Ltd. reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Hong Kong Ltd. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Hong Kong Ltd. issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Report Number: 60/760.11.318.04 Page 2 of 27 TÜV SÜD HONG KONG LTD., 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 TÜV SÜD HONG KONG LTD., Unit 601, InnoCentre, 72 Tat Chee Avenue, Kowloon Tong, Hong Kong. Tel: +852-2776 1323 Fax: +852-2776 1206 1 Table of Contents 1 Table of Contents.............................................................................................. 2 2 Details about the Test Laboratory......................................................................... 3 3 Description of the Equipment Under Test................................................................ 4 4 Summary of Test Standards/ Results..................................................................... 5 5 General Remarks.............................................................................................. 6 6 Emission Test Results........................................................................................ 7 6.1 Radiated Emission Test.............................................................................. 7 6.2 20dB and 99% Bandwidth measurement........................................................ 16 6.3 Band edge measurement........................................................................... 18 7 Appendix A....................................................................................................... 20 Photographs of EUT 8 Appendix B....................................................................................................... 25 Photographs of Test Set Up 9 Appendix C....................................................................................................... 27 Product Information Report Number: 60/760.11.318.04 Page 3 of 27 TÜV SÜD HONG KONG LTD., 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 TÜV SÜD HONG KONG LTD., Unit 601, InnoCentre, 72 Tat Chee Avenue, Kowloon Tong, Hong Kong. Tel: +852-2776 1323 Fax: +852-2776 1206 2 Details about the Test Laboratory Details about the Test Laboratory Company name: TÜV SÜD HONG KONG LTD. 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin HK. Telephone: 852 2776 1323 Fax: 852 2776 1372 Test site Company name: Neutron Engineering Inc. 3,Jinshagang 1st Road, ShiXia, Dalang Town, DongGuan, China FCC Registered Test Site Number 319330 Open area test site Industry Canada Number: 4428B Report Number: 60/760.11.318.04 Page 4 of 27 TÜV SÜD HONG KONG LTD., 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 TÜV SÜD HONG KONG LTD., Unit 601, InnoCentre, 72 Tat Chee Avenue, Kowloon Tong, Hong Kong. Tel: +852-2776 1323 Fax: +852-2776 1206 3 Description of the Equipment Under Test Description of the Equipment Under Test Product: Speed & Cadence Sensor Model no.: SGY-CS500 Serial number: NIL Options and accessories: NIL FCC ID: AJDK084 IC: 775E-K084 Opreating Frequency: 2457MHz Rated Voltage: 3 VDC Rated Current: NIL Rated Power: NIL Frequency: NIL Description of the EUT: EUT Main unit size: 6 cm x 5 cm x 2 cm Supply by 1 x 3 VDC (CR2032 battery cell) Report Number: 60/760.11.318.04 Page 5 of 27 TÜV SÜD HONG KONG LTD., 3/F, West Wing, Lakeside 2, 10 Science Park West Avenue, Science Park, Shatin, HK. Tel: +852-2776 1323 Fax: +852-2776 1206 Rev. no.: 2.0 TÜV SÜD HONG KONG LTD., Unit 601, InnoCentre, 72 Tat Chee Avenue, Kowloon Tong, Hong Kong. Tel: +852-2776 1323 Fax: +852-2776 1206 4 Summary of Test Standards and Results Test Condition Pages Test Result Pass Fail N/A Conducted Emission (47 CFR 15.207, 15.209 & RSS-GEN 7.2.4) NIL * Radiated Emission (47 CFR 15.249, 15.209 & RSS-210 A2.9, GEN 7.2.5 & RSS-GEN 6.1) 7 20dB Bandwidth (47 CFR 15.215) 16 99% occupied bandwidth (RSS-GEN 4.6.1) 16 Bandedge Emission (47 CFR 15.249) 18 Remark: 1. NA: Battery operated only. 2.For Spurious Radiated Emissions test, three set-up directions(X,Y,Z) were pretested, but only direction X test data was recorded in this report for it is the worst case. Report …

Text truncated - open the document above for the full version.

Radiated Emission Above 1 GHz Below 1 GHz
