Advanced Compliance Solutions – 5015 B.U. Bowman Drive, Buford, GA 30518 September 17, 2012 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: Locus Solutions, LLC, respectfully requests confidentiality of certain materials provided with the submission of the Smart Tag under FCC ID: AMH101003 in accordance with 47 CFR 0.457(d) and 47 CFR 0.459. The confidentiality request applies to the following files. 12-2034 – Schematics.pdf 12-2034 – Block Diagram.pdf 12-2034 – Theory of Operation.pdf The Smart Tag has been developed at considerable effort and expense by Locus Solutions, LLC. These items are considered as Trade Secrets and therefore public access to the proprietary material could possible result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this matter. Sincerely, Sam Wismer Vice President, Technology Agent Phone: (770) 831-8048 Fax: (770) 831-8598

5015 B. U. Bowman Dr. Buford, GA 30518 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: AMH101003 To Whom It May Concern: The following application is submitted on behalf of our client, Locus Solutions, LLC, for evaluation of their model Smart Tag for certification under FCC Part 15.247. The Smart Tag, FCC ID: AMH101003, is a 2.4 GHz transceiver used for the tracking and monitoring of goods during transit. The transceiver gathers the locaction, temperature and other conditions of the shipment and communicates them via an IEEE 802.15.4 wireless network. The FCC ID: AMH101003 was tested in full to the aforementioned tests requirements and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

3998 FAU Blvd. Suite 310 Boca Raton, FL 33431 Tel: 561-961-5585 Fax: 561-961-5587 Certification Exhibit FCC ID: AMH101003 IC: 10124A-101003 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project: 12-2034 Manufacturer: Locus Solutions LLC Model: Smart Tag External Photos Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 1: Top View ACS Project: 12-2034 Advanced Compliance Solutions Page 2 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 2: Bottom View ACS Project: 12-2034 Advanced Compliance Solutions Page 3 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 3: Front View ACS Project: 12-2034 Advanced Compliance Solutions Page 4 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 4: Rear View ACS Project: 12-2034 Advanced Compliance Solutions Page 5 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 5: Right Side View ACS Project: 12-2034 Advanced Compliance Solutions Page 6 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 6: Left Side View ACS Project: 12-2034 Advanced Compliance Solutions Page 7

3998 FAU Blvd. Suite 310 Boca Raton, FL 33431 Tel: 561-961-5585 Fax: 561-961-5587 Certification Exhibit FCC ID: AMH101003 IC: 10124A-101003 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project: 12-2034 Manufacturer: Locus Solutions LLC Model: Smart Tag Label Information Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 1: Sample Label (Part 1) Figure 2: Sample Label (Part 2) ACS Project: 12-2034 Advanced Compliance Solutions Page 2 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 3: Sample Label Location ACS Project: 12-2034 Advanced Compliance Solutions Page 3

3998 FAU Blvd. Suite 310 Boca Raton, FL 33431 Tel: 561-961-5585 Fax: 561-961-5587 Certification Exhibit FCC ID: AMH101003 IC: 10124A-101003 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project: 12-2034 Manufacturer: Locus Solutions LLC Model: Smart Tag Internal Photos Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 1: RF Board (Top View) ACS Project: 12-2034 Advanced Compliance Solutions Page 2 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 2: RF Board (Bottom View) ACS Project: 12-2034 Advanced Compliance Solutions Page 3 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 Figure 3: Internal View ACS Project: 12-2034 Advanced Compliance Solutions Page 4

3998 FAU Blvd. Suite 310 Boca Raton, FL 33431 Tel: 561-961-5585 Fax: 561-961-5587 Certification Exhibit FCC ID: AMH101003 IC: 10124A-101003 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Project Number: 12-2034 Manufacturer: Locus Solutions LLC Model: Smart Tag RF Exposure Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 ACS Project: 12-2034 Advanced Compliance Solutions Page 2 General Information: Applicant: Locus Solutions LLC ACS Project: 12-2034 Device Category: Mobile Environment: General Population/Uncontrolled Exposure Technical Information: Antenna Type: Inverted-F PCB Antenna Antenna Gain: 3 dBi Maximum Transmitter Conducted Power: 18.83 dBm Maximum System EIRP: 21.83 dBm, 152.4 mW Exposure Conditions: Greater than 20 centimeters MPE Calculation The Power Density (mW/cm 2 ) is calculated as follows: S = 2 4R PG π Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) MPE Calculator for Mobile Equipment Limits for General Population/Uncontrolled Exposure* 248018.831.0076.3831.995 200.030 Power Density (mW/cm^2) Distance (cm) Transmit Frequency (MHz) Radio Power (dBm) Power Density Limit (mW/Cm2) Radio Power (mW) Antenna Gain (dBi) Antenna Gain (mW eq.) Installation Guidelines The installation manual should contain text similar to the following advising how to install the equipment to maintain compliance with the FCC RF exposure requirements: RF Exposure In accordance with FCC requirements of human exposure to radio frequency fields, the radiating element shall be installed such that a minimum separation distance of 20 centimeters will be maintained. Conclusion This device complies with the MPE requirements by providing adequate separation between the device, any radiating structure and the general population.

3998 FAU Blvd. Suite 310 Boca Raton, FL 33431 Tel: 561-961-5585 Fax: 561-961-5587 Certification Test Report FCC ID: AMH101003 IC: 10124A-101003 FCC Rule Part: 15.247 IC Radio Standards Specification: RSS-210 ACS Report Number: 12-2034.W06.1A Manufacturer: Locus Solutions LLC Model: Smart Tag Test Begin Date: March 22, 2012 Test End Date: April 9, 2012 Report Issue Date: September 12, 2012 FOR THE SCOPE OF ACCREDITATION UNDER CERTIFICATE NUMBER AT-1533 This report must not be used by the client to claim product certification, approval, or endorsement by ACLASS, ANSI, or any agency of the Federal Government. Project Manager: Reviewed by: Steve O'Steen Kirby Munroe EMC Technician Director, Wireless Certifications Advanced Compliance Solutions, Inc. Advanced Compliance Solutions, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 30 pages TABLE OF CONTENTS 1 GENERAL ...................................................................................................... 3 1.1 Purpose .............................................................................................................................................. 3 1.2 Product description .......................................................................................................................... 3 1.3 Test Methodology and Considerations ........................................................................................... 3 2 TEST FACILITIES .......................................................................................... 4 2.1 Location ............................................................................................................................................. 4 2.2 Laboratory Accreditations/Recognitions/Certifications ............................................................... 4 2.3 Radiated & Conducted Emissions Test Site Description .............................................................. 5 3 APPLICABLE STANDARD REFERENCES ................................................... 7 4 LIST OF TEST EQUIPMENT .......................................................................... 8 5 SUPPORT EQUIPMENT ................................................................................ 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM .............................. 9 7 SUMMARY OF TESTS ................................................................................. 10 7.1 Antenna Requirement – FCC: Section 15.203 ............................................................................. 10 7.2 6 dB Bandwidth - FCC: Section 15.247(a)(2) 99% Bandwidth IC: RSS-210 A8.2(a) ............... 10 7.3 Peak Output Power - FCC Section 15.247(b)(3) IC: RSS-210 A8.4(4)....................................... 15 7.4 Band-Edge Compliance and Spurious Emissions-FCC 15.247(d) IC:RSS-210 A8.5 ................ 17 7.5 Power Spectral Density - FCC Section 15.247(e) IC: RSS-210 A8.2(b) ..................................... 28 8 CONCLUSION .............................................................................................. 30 Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 ACS Report: 12-2034.W06.1A Advanced Compliance Solutions Page 3 of 30 1 GENERAL 1.1 Purpose The purpose of this report is to demonstrate compliance with Part 15 Subpart C of the FCC’s Code of Federal Regulations and Industry Canada’s Radio Standards Specification RSS-210. 1.2 Product description The Locus Solutions, LLC. Smart Tag is a 2.4 GHz wireless transceiver. The Smart Tag is used to monitor shipment location, temperature and other conditions as well as shipment sensors. The Smart Tag communicates the information via an IEEE 802.15.4 local wireless network to a central portable or fixed unit. Technical Information: Band of Operation: 2405 MHz - 2480 MHz Number of Channels: 16 Modulation Format: OQPSK Antenna Type/Gain: Printed Inverted-F Antenna, 3 dBi Operating Voltage: 4.2 VDC Manufacturer Information: Locus Solutions LLC 630 Maplewood Drive, Suite 200 Jupiter, FL 33418 Test Sample Serial Number(s): 007003082, 007003120 Test Sample Condition: The unit was in good operating condition with no physical damages. 1.3 Test Methodology and Considerations The Locus Solutions, Inc. Smart Tag was programmed via serial port using the Hyperterminal. The power settings were set to level 3 across the range of operation for the evaluation. The unit was evaluated for radiated and RF conducted measurements. For the radiated emissions evaluation, the unit was setup in three orthogonal orientations. The final measurements were performed using the orientation leading to the highest emissions. The RF conducted measurements were performed with a temporary SMA connector at the RF port of the EUT. The evaluation for the unintentional emissions is documented separately in a Verification Report. Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 ACS Report: 12-2034.W06.1A Advanced Compliance Solutions Page 4 of 30 2 TEST FACILITIES 2.1 Location The radiated and conducted emissions test sites are located at the following address: Advanced Compliance Solutions, Inc. 3998 FAU Blvd, Suite 310 Boca Raton, Florida 33431 Phone: (561) 961-5585 Fax: (561) 961-5587 www.acstestlab.com FCC Test Firm Registration #: 587595 Industry Canada Lab Code: 4175C 2.2 Laboratory Accreditations/Recognitions/Certifications ACS is accredited to ISO/IEC 17025 by ANSI-ASQ National Accreditation Board under their ACLASS program and has been issued certificate number AT-1533 in recognition of this accreditation. Unless otherwise specified, all test methods described within this report are covered under the ISO/IEC 17025 scope of accreditation. Model: Smart Tag FCC ID: AMH101003 IC: 10124A-101003 ACS Report: 12-2034.W06.1A Advanced Compliance Solutions Page 5 of 30 2.3 Ra…
