APB34337-98A4RTOY CAR RECEIVER

FCC ID LABEL FORMAT AND LOCATION APPLICANT :MATTEL TOYS, INC. FCC ID :APB34337-98A4R FCC ID:APB34337-98A4R This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for UNINTENTIONAL RADIATOR RC CAR RECEIVER MODEL: 34337 BRAND NAME: HOT ROD ROADSTER FCC ID NO: APB34337-98A4R REPORT NO: 98E7680 ISSUE DATE: AUGUST 18, 1998 Prepared for MATTEL TOYS, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO:98E7680 FCC ID:APB34337-98A4R DATE:08/18/98 PAGE NO: 0 COMPLIANCE CONSULTING SERVICESCCS DOCUMENT NO: CCSUP4021B 1366 BORDEAUX DRIVE, SUNNYVALE CA 94089TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without written approval from CCS. TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE............................... 1 2. PRODUCT DESCRIPTION ..................................... 2 3. TEST FACILITY ........................................... 2 4. MEASUREMENT EQUIPMENT USED .............................. 2 5. TEST CONFIGURATION ...................................... 3 6. TESTS CONDUCTED ......................................... 3 7. CONDUCTED EMISSION TEST PROCEDURE ....................... 3 8. RADIATED EMISSION TEST PROCEDURE ........................ 4 9. COHERENT TESTS .......................................... 4 10. EQUIPMENT MODIFICATIONS ................................. 4 11. TEST CONFIGURATION PHOTO (Radiated Emission Test)........ 5 TEST DATA • Fundemental Frequency Plot • Radiated Emission Data Proposed FCC ID Label......................... EXHIBIT 1 Agent Authorization Letter.................... EXHIBIT 2 User Manual................................... Attachment A Block Diagram/Schematics...................... Attachment B REPORT NO:98E7680 FCC ID:APB34337-98A4R DATE:08/18/98 PAGE NO: 1 COMPLIANCE CONSULTING SERVICESCCS DOCUMENT NO: CCSUP4021B 1366 BORDEAUX DRIVE, SUNNYVALE CA 94089TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without written approval from CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL TOYS, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245 USA CONTACT PERSON : VLADIMIR BUZGA DIRECTOR OF DEVELOPMENT, CES TELEPHONE NO. : 310-252-2000 EUT DESCRIPTION : RC CAR RECEIVER MODEL NAME/NUMBER : 34337 FCC ID : APB34337-98A4R DATE TESTED : AUGUST 18, 1998 REPORT NUMBER : 98E7680 TYPE OF EQUIPMENT TOY EQUIPMENT (UNINTENTIONAL RADIATOR) EQUIPMENT TYPE SUPERREGENERATIVE RECEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15.109 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE ENGINEERING SERVICES, INC. REPORT NO:98E7680 FCC ID:APB34337-98A4R DATE:08/18/98 PAGE NO: 2 COMPLIANCE CONSULTING SERVICESCCS DOCUMENT NO: CCSUP4021B 1366 BORDEAUX DRIVE, SUNNYVALE CA 94089TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without written approval from CCS. 2. PRODUCT DESCRIPTION MATTEL TOYS INC., Model 34337 is the receiving portion of a remote control toy car. The associated Transmitter is manufactured by MATTEL TOYS INC., Model No: 34337, FCC ID: APB34337-98A4T. 3. TEST FACILITY The 3 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facilities was submitted to the Commission on May 27, 1994. The measuring instrument which was utilized in performing the tests documented herein has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment which is traceable to recognized national standards. 4. MEASUREMENT EQUIPMENT USED Manufacturer Model Number Description Cal Due Date H.P. 8640B Signal Generator (0.5 - 1024 MHz) 08/99 H.P. 8566B Spectrum Analyzer (100Hz - 22GHz) 09/98 EMCO 3146 Antenna (200-1000 MHz) 10/98 H.P. 8447D Preamplifier (0.1 - 1300 MHz) 09/98 ARA DRG-18/A Antenna(1 - 18GHZ) 12/98 H.P. 8449B Preamplifier (1-26.5GHZ) 03/99 5. TEST CONFIGURATION Fully charged 6.0V NiCd battery pack is used. EUT is placed on center on turn table. REPORT NO:98E7680 FCC ID:APB34337-98A4R DATE:08/18/98 PAGE NO: 3 COMPLIANCE CONSULTING SERVICESCCS DOCUMENT NO: CCSUP4021B 1366 BORDEAUX DRIVE, SUNNYVALE CA 94089TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without written approval from CCS. 6. TESTS CONDUCTED CFR 47, 15.109 RADIATED EMISSION TESTS CONDUCTED AT 3 METERS 7. CONDUCTED EMISSION TEST PROCEDURE The EUT is located so that the distance between the boundary of the EUT and the closest surface to the LISN is 0.8m. Conducted disturbance shall be measured between the phase lead and the ground, and between the neutral lead and the ground. The frequency 0.450 - 30 MHz shall be investigated. Set the EMI receiver to PEAK detector setting and sweep continuously over the frequency range to be investigated. Set resolution bandwidth to 9kHz minimum. Connect EMI receiver input cable to LINE 1 RF measurement connection on the LISN. Connect a 50ohm terminator to the unused RF connection on the LISN. For each mode of EUT operation, maximize emissions readings by manipulating cable and wire positions. Record the configuration for each EUT power cord which produces emissions closest to the limit. Repeat the same procedure for LINE 2 of each EUT power cord. REPORT NO:98E7680 FCC ID:APB34337-98A4R DATE:08/18/98 PAGE NO: 4 COMPLIANCE CONSULTING SERVICESCCS DOCUMENT NO: CCSUP4021B 1366 BORDEAUX DRIVE, SUNNYVALE CA 94089TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without written approval from CCS. 8. RADIATED EMISSION TEST PROCED…
