APB91497-02A4RRemote Control Toy Receiver

B0407-0720 CAUTION:Surfaces may become hot and cause burns if electronics get wet. Do not operate vehicle through water or snow. PRECAUCIÓN:Si las piezas electrónicas se mojan, es posible que las superficies se calienten y causen quemaduras. No usar el vehículo en agua ni nieve. MISE EN GARDE: Les surfaces peuvent devenir chaudes et causer des brûlures si les composantes électroniques sont mouillées. Ne pas faire rouler ce véhicule sur des surfaces mouillées ou enneigées. U.S.A. 90-DAY LIMITED WARRANTY TYCO® R/C PRODUCTS Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for ninety (90) days (unless specified in alternate warranties) from the date of purchase. Mattel will repair or replace the product, at our sole option, in the event of such a defect within the warranty period. In the event of a defect covered under this warranty, first call the toll-free number listed below. Many problems can be solved in this manner. If necessary, you will be instructed to return the product, postage prepaid and insured, to the address below. Enclose your name, address, dated sales receipt, and a brief explanation of the defect. Repair or replacement, and return shipment, will be free of charge. Please return only the defective part or unit, packed securely. This warranty does not cover damage resulting from unauthorized modification, accident, misuse or abuse. If the product is returned without a dated sales receipt the product may be excluded from coverage under this warranty. Mattel’s liability for defects in material and workmanship under this warranty shall be limited to repair or replacement, at our sole option, and in no event shall we be responsible for incidental, consequential, or contingent damages (except in those states that do not allow this exclusion or limitation). This warranty is exclusive, and is made in lieu of any express or implied warranty. Valid only in U.S.A.This warranty gives you specific legal rights and you may have other rights, which vary from state to state. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusions or limitations may not apply to you. TOLL-FREE NUMBER: 1-888-557-TYCO (8926) (valid only in U.S.A.) Hours: 8:00 A.M. - 5:00 P.M. Eastern Time; Monday - Friday. Expect some delay in January following the holiday season. Please be patient and keep trying the toll-free number. ADDRESS FOR RETURNS: CONSUMER RELATIONS, 636 GIRARD AVENUE, EAST AURORA, NY 14052 Mattel de México, S.A. De C.V., garantiza sus productos por un periodo de 90 días en todas sus partes y mano de obra, a partir de la fecha de entrega. Condiciones: 1.- El consumidor presentará el producto en el lugar donde lo adquirió y/o presentarlo o enviarlo a nuestro centro de ser- vicio ubicado en Lebrija 296-a, Col. Cerro de la Estrella, Iztapalapa C.P. 09880, México, D.F. Tels: 426-44-87 y 426-44-38 2.- Durante la vigencia de esta póliza nos comprometemos a efectuar sin cargo la reparación, en un plazo que no excederá de 30 días a partir de la fecha de recepción del producto en nuestro sentro de servicio, o al cambio del producto defectu- oso en su caso. Así mismo cubrimos gastos que se deriven de la presen- ta garantía. 3.- Refacciones para este producto podrán ser adquiridas en nuestro centro de servicio. Esta garantía se invalida en los siguientes casos: si ha sufrido un deterioro esencial, grave o irreparable por causa del consumidor, por daños causados por maltrato, mal uso, golpes acci- dentales o intencionales, o que el artículo se hay expuesto a elementos como agua (a excepción de que el instructivo indique otra cosa), ácidos, fuego, intemperie, así como daños causados por baterías que se dejen dentro del juguete por largos periodos de tiempo sin uso. NOMBRE DEL CONSUMIDOR: LÍNEA DE PRODUCTO: ________________________________________ SERIE: ____________________________________________________ MODELO: __________________________________________________ NOMBRE DEL DISTRIBUIDOR: _________________________________ DIRECCIÓN: ________________________________________________ SELLO O FIRMA DEL DISTRIBUIDOR: ____________________________ FECHA DE COMPRA: _________________________________________ FECHA DE ENTREGA: _________________________________________ CANADA 90-DAY LIMITED WARRANTY Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and workman- ship for ninety (90) days (unless specified in alternate war- ranties) from the date of purchase. If defective, return the product along with proof of the date of purchase, postage pre- paid to Mattel Canada Inc., Consumer Service, 6155 Freemont Blvd., Mississauga, Ontario L5R 3W2 for replacement with an identical toy or a similar toy of equal or greater value according to availability. This warranty gives you specific legal rights and you may have other rights which vary from province to province. This warranty does not cover damage resulting from accident, misuse or abuse. Valid for products sold in Canada only. YOU MAY CALL US FREE AT 1-800-665-6288 Monday – Friday, 8:00 a.m. – 5:00 p.m. EST; 5:00 a.m. – 2:00 p.m. PST. CANADA GARANTIE LIMITÉE DE 90 JOURS Mattel garantit à l’acheteur initial que le produit est couvert contre les vices de matériau ou de fabrication pour une période de 90 jours (à moins d’indication contraire dans d’autres garanties) à compter de la date d’achat. Tout produit défectueux doit être retourné, accompagné d’une preuve de la date d’achat et dûment affranchi, au Service à la clientèle de Mattel Canada Inc., 6155, Freemont Blvd., Mississauga (Ontario) L5R 3W2, où il sera remplacé par un produit iden- tique ou un produit semblable de valeur égale ou supérieure, selon la disponibilité. La présente garantie procure certains droits légaux à l’acheteur, qui peut également bénéficier de droits supplémentaires qui varient d’une province à l’autre. La présente garanti…

Text truncated - open the document above for the full version.

PROPOSED FCC ID LABEL AND LOCATION MATTEL MT. LAUREL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB91497-02A4R FCC ID LABEL

WHIPLASH CAR 49.860 MHz Mattel Part # 91497 Receiver FCC ID: APB91497-02A4R 07/26/02 WHIPLASH # 91497 49.860MHz RECEIVER OPERATIONAL DESCRIPTION The Whiplash car is a full function radio controlled toy car . It operates on 6volts supplied by four 1.5 volt alkaline AA batteries. It is designed to operate on a single fixed frequency in the 49.82-49.90 MHz band. See the attached block diagram and schematic. The modulated RF signal from the transmitter induces an electrical signal into the car’s permanently attached wire hoop antenna . The electrical signal is selectively amplified by a super regenerative input circuit ( Q1,T1,L2,C2-C5 ). The signal is then capacitively coupled ( via C8 ) to an integrated circuit ( U2 ) were the signal is further amplified and decoded. A pair of digital outputs from the integrated circuit ( U2 ) drives a full H-bridge drive circuit ( Q5-Q8 ) for controlling the speed and rotational direction of the drive motor. A second pair of digital outputs from the integrated circuit ( U2 ) drives a second full H-bridge drive circuit ( Q11-Q14 ) for controlling the steering motor. All tuning and verifications are performed by the manufacturer and there are no adjustments that can be made by the user. No external ground is required or used with this receiver.

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size B Date: 17-Jul-2002 Sheet of File: \\..\RX-49M-FCC00.sch Drawn By: ANT C14PFL1 1.5uH Q1 2SC380 O/Y R1910 T1 7..5T C5 4.7UF ZD1 3V3 4*AABATTERY V02 OSC0 GND RIGHT SC LEFT OSC1 RCB V12 TURBO V01 FWD V11 BACK VDD LDB 1 234 567 89 10 11 12 13 14 15 16 U2 RX2C S1 C130.047UF C3 27PF L2 3.3UH C4 0.0022U R2 100K C6 0.01uFC2 6PF R44.3K R5 2.2K R3330 C12 100UF C14 100UF C8 0.1U C9 120P C100.1U R72.2K R62.2M R8 2.2M R9 2.2K R10140K R11820 R13820 C11 0.001U R17820 R19820 Q9 2SC2712GR Q14 SS8050C/D Q11 SS8550C/D Q13SS8550C/DQ12 SS8050C/D Q102SC2712GR R2147 R2247 Q3 2SC2712GR Q8 2SC3279M/N Q5 2SA1300Y/GR Q7 2SA1300Y/GR Q6 2SC3279M/N Q4 2SC2712GR R1547 M1 C16 0.1uF R1647 Q2 2SA1980S R23 4.3K R124.3K R144.3K R18 4.3k R20 4.3k 91497 Receiver (49MHZ) FCC (00) C17 0.1uF C15 0.1uF M2 C19 0.1uF C20 0.1uF C18 0.1uF D5 1N4001 D6 1N4001 D7 1N4001 D8 1N4001 D1 1N4001 D2 1N4001 D3 1N4001 D4 1N4001 WHIPLASH ly 11 POWER ON -OFF (2SA1160B/C) (2SA1160B/C)(2SC2500B/C) (2SA2500B/C)

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for UNINTENTIONAL RADIATOR 49.860MHz RC CAR RECEIVER MODEL NO: 91497 BRAND NAME: TYCO RC-WHIPLASH FCC ID NO: APB91497-02A4R REPORT NO: 02U1437-2 DATE: AUGUST 7, 2002 Prepared for MATTEL MT. LAUREL 6000 MIDLANTIC AVENUE MT. LAUREL, NJ 08054 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE.............................................................................................................3 2. PRODUCT DESCRIPTION.............................................................................................................................4 3. TEST FACILITY...............................................................................................................................................4 4. MEASUREMENT EQUIPMENT USED.........................................................................................................5 5. TEST CONFIGURATION................................................................................................................................5 6. TESTS CONDUCTED.......................................................................................................................................5 7. RADIATED EMISSION TEST PROCEDURE..................................................................................6 8. COHERENT TEST.....................................................................................................................................6 9. EQUIPMENT MODIFICATIONS.......................................................................................................7 10. TEST CONFIGURATION PHOTOS (RADIATED EMISSION TEST).........................8 • TEST DATA o Coherent Emission Plot o Radiated Emission Data • PROPOSED FCC ID LABEL FORMAT • AUTHORIZATION LETTER • SCHEMATIC DIAGRAM • USER MANUAL • EUT PHOTOGRAPHS REPORT NO: 02U1437-2 FCC ID: APB91497-02A4R DATE: AUGUST 7, 2002 EUT: 49.860MHz RC CAR RECEIVER Page 3 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL MT. LAUREL 6000 MIDLANTIC AVENUE MT. LAUREL, NJ 08504 USA CONTACT PERSON : FRANK WINKLER, SENIOR PROJECT TELEPHONE NO. : 856-840-1259 EUT DESCRIPTION : 49.860MHz RC CAR RECEIVER MODEL NAME/NUMBER : 91497 BRAND NAME : TYCO RC-WHIPLASH FCC ID : APB91497-02A4R DATE TESTED : JULY 29, 2002 REPORT NUMBER : 02U1437-2 TYPE OF EQUIPMENT REMOTE CONTROL CAR RECEIVER (UNINTENTIONAL RADIATOR) EQUIPMENT TYPE 49 MHz SUPERREGENERATE RECEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 SUBPART B The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15 SUBPART B. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. Warning: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Tested By: Approved & Released For CCS By: CHIN PANG THU CHAN EMC TECHNICAIN SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 02U1437-2 FCC ID: APB91497-02A4R DATE: AUGUST 7, 2002 EUT: 49.860MHz RC CAR RECEIVER Page 4 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. PRODUCT DESCRIPTION MATTEL MT. LAUREL., Model No# 91497 TYCO RC-WHIPLASH is the receiving portion of a remote control toy. The associated Transmitter is manufactured by MATTEL MT. LAUREL., Model No#91497 , FCC ID APB91497-02A4T. 3. TEST FACILITY The 3 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facilities was submitted to the Commission on May 27, 1994. The measuring instrument, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. REPORT NO: 02U1437-2 FCC ID: APB91497-02A4R DATE: AUGUST 7, 2002 EUT: 49.860MHz RC CAR RECEIVER Page 5 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 4. MEASUREMENT EQUIPMENT USED 5. TEST CONFIGURATION Set signal generator to transmit at 49 MHz. Adjusted generator level and frequency to get the maximum coherent and emission of the Eut. The receiver receives the signal. All the wires are placed on the turntable to their maximum length to …

Text truncated - open the document above for the full version.

REPORT NO: 02U1437-2 FCC ID: APB91497-02A4R DATE: AUGUST 7, 2002 EUT: 49.860MHz RC CAR RECEIVER Page 8 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 10. TEST CONFIGURATION PHOTOS (Radiated Emission Test) REPORT NO: 02U1437-2 FCC ID: APB91497-02A4R DATE: AUGUST 7, 2002 EUT: 49.860MHz RC CAR RECEIVER Page 9 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document.
