APB50345-01A2TRemote Control Toy Transmitter

PROPOSED FCC ID LABEL AND LOCATION MATTEL TOYS, INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB50345-01A2T FCC ID LABEL LOCATION

Word circuit description –50345TX 06:40 PM 01/03/01 Circuit Description 50345 TX (27.145MH Z ) Q3,Q4, R5,R6,R8,R9,C9 and C10 is a low frequency oscillator to generate a control signal ; R4, L2, Y1,Q2,C8 and R2 is a high frequency oscillator (27.145MH Z ) , it generate the high frequency wave to carry the control signal . These two signals are mixed and amplified by Q1. The modulated high frequency wave is fed in to the filter consist of C2 ,T1,C1 ,and then it radiate to air by the ANT1.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 27 MHz REMOTE CONTROL CAR TRANSMITTER MODEL NO: 50345 BRAND NAME: RC ANGELICA CHATMOBILE FCC ID NO: APB50345-01A2T REPORT NO: 01U0667-1 ISSUE DATE: FEBRUARY 16, 2001 Prepared for MATTEL TOYS, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245-5012 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 01U0667-1 FCC ID: APB50345-01A2T DATE: FEBRUARY 16, 2001 EUT: 27 MHz REMOTE CONTROL CAR TRANSMITTER COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE................................................................... 1 2. PRODUCT DESCRIPTION................................................................................. 2 3. TEST FACILITIES ........................................................................................... 2 4. MEASUREMENT STANDARDS ....................................................................... 2 5. TEST METHODOLOGY .................................................................................... 2 6. MEASUREMENT EQUIPMENT USED .............................................................. 3 7. PPOWERLINE RFI LIMITS .............................................................................. 4 8. RADIATED EMISSION LIMITS ....................................................................... 4 9. TEST SETUP AND CONFIGURATION ............................................................. 5 10. EQUIPMENT MODIFICATIONS ....................................................................... 6 11. TEST PROCEDURE AND RESULT .................................................................. 6 EXHIBIT 1. Proposed FCC ID Label Format 2. Agent Authorization Letter Attachment • EUT Photographs • Schematic Diagram REPORT NO: 01U0667-1 FCC ID: APB50345-01A2T DATE: FEBRUARY 16, 2001 EUT: 27 MHz REMOTE CONTROL CAR TRANSMITTER PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL TOYS, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245-5012, USA CONTACT PERSON : KEVIN MULLALLY/ SENIOR ELECTRONIC ENGINEER TELEPHONE NO. : 310-252-3828 EUT DESCRIPTION : 27 MHz REMOTE CONTROL CAR TRANSMITTER MODEL NAME/NUMBER : 50345 BRAND NAME : RC ANGELICA CHATMOBILE SERIAL NUMBER : N/A FCC ID : APB50345-01A2T DATE TESTED : FEBRUARY 16, 2001 REPORT NUMBER : 01U0667-1 TYPE OF EQUIPMENT REMOTE CONTROL EQUIPMENT TYPE 27 MHZ TRANSMITTER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15.227 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Tested and/or Reviewed By: Released For CCS By: THU CHAN T. N. COKENIAS SENIOR EMC ENGINEER ENGINEERING DIRECTOR COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 01U0667-1 FCC ID: APB50345-01A2T DATE: FEBRUARY 16, 2001 EUT: 27 MHz REMOTE CONTROL CAR TRANSMITTER PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC Fundamental Frequency 27.145 MHz Power Source ONE 9 VOLT BATTERY CHIPSET BRAND AND PART NO MATTEL. 50345/TX Transmitting Time CONTINUOUS Type of antenna PERMANENTLY ATTACHED NO. OF LAYER 1 Local Osc. 27.145MHz 3. TEST FACILITY The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27,1994. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) REPORT NO: 01U0667-1 FCC ID: APB50345-01A2T DATE: FEBRUARY 16, 2001 EUT: 27 MHz REMOTE CONTROL CAR TRANSMITTER PAGE NO: 3 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be alte…

Text truncated - open the document above for the full version.

REPORT NO: 01U0667-1 FCC ID: APB50345-01A2T DATE: FEBRUARY 16, 2001 EUT: 27 MHz REMOTE CONTROL CAR TRANSMITTER PAGE NO: 5 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9. SYSTEM TEST CONFIGURATION The EUT was configured for testing in a typical fashion (as a customer would normally use it). Push-to-Transmit switch is held in transmit position using electrician’s (PVC) tape for transmit mode. The tape is removed for receive mode. Please refer to the following photograph for actual setup. Radiated Open Site Test Set-up
