6V SPIDERMAN TRUCK 49.860 MHz Mattel Part # 80412 Transmitter FCC ID: APB80412-02A4T 04/08/02 6V SPIDERMAN MONSTER TRUCK # 80412 49.860 MHz TRANSMITTER OPERATIONAL DESCRIPTION The 6V Spiderman Monster Truck radio control transmitter is a low powered, hand held unit for controlling the movement of a toy truck. The transmitter is powered by a 9 volt battery. It is designed to operate on a single fixed frequency in the 49.82-49.90 MHz band. See the attached block diagram and schematic. Input switches trigger an integrated circuit ( TX2 ) which produces the digital control signals which will modulate the carrier signal. The carrier signal is generated by a crystal oscillator/ amplifier circuit comprised of a 49.860 MHz crystal ( X1 ) and a npn transistor ( Q1 ). The RF carrier signal is modulated by the digital control signal at the base of an RF amplifier stage ( Q2 ). The modulated output of the RF amplifier stage is capacitively coupled ( via C5 ) to the antenna through a “ pi “ matching network comprised of C7, T1 and C8. The whip antenna is 11 inches long and permanently attached. All tuning and verifications are performed by the manufacturer and there are no adjustments which can be made by the user. No external ground is required or used with this transmitter.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 49MHz RADIO CONTROL TRANSMITTER MODEL NO: 80412-49T BRAND NAME: TYCO R/C-6V SPIDERMAN MONSTER TRUCK FCC ID NO: APB80412-02A4T REPORT NO: 02U1184-1 ISSUE DATE: APRIL 8, 2002 Prepared for MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO:02U1184-2 FCC ID: APB80412-02A4T DATE: APRIL 8, 2002 EUT: 49MHZ RADIO CONTROL TRANSMITTER Page 2 of 18 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1.VERIFICATION OF COMPLIANCE.......................................................................3 2.PRODUCT DESCRIPTION.........................................................................................4 3.TEST FACILITY.............................................................................................................4 4.MEASUREMENT STANDARDS...............................................................................4 5.TEST METHODOLOGY..............................................................................................4 6.MEASUREMENT EQUIPMENT USED..................................................................5 7.TEST PROCEDURES AND TEST RESULTS.......................................................6 RADIATED EMISSION TEST: ( 15.235 (A)).........................................................................6 RADIATED EMISSION TEST: ( 15.235 (B)).........................................................................6 9.APPENDIX.......................................................................................................................14 EUT PHOTOGRAPHS.........................................................................................................14 SCHEMATICS.....................................................................................................................18 BLOCK DIAGRAM.............................................................................................................18 USER’S MANUAL..............................................................................................................18 REPORT NO:02U1184-2 FCC ID: APB80412-02A4T DATE: APRIL 8, 2002 EUT: 49MHZ RADIO CONTROL TRANSMITTER Page 3 of 18 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1.VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA CONTACT PERSON : FRANK WINKLER, SENIOR PROJECT ENGINEER TELEPHONE NO. : (856) 840-1259 EUT DESCRIPTION : 49MHz RADIO CONTROL TRANSMITTER MODEL NAME/NUMBER : 80412-49T BRAND NAME : TYCO R/C-6V SPIDERMAN MONSTER TRUCK SERIAL NUMBER : N/A FCC ID : APB80412-02A4T DATE TESTED : APRIL 5, 2002 REPORT NUMBER : 02U1184-2 TYPE OF EQUIPMENT RADIO CONTROL EQUIPMENT TYPE 49.86 MHz TRANSMITTER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 SUBPART C The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15 SUBPART C. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Tested By: Reviewed & Released For CCS By: JERRY HOVEY MIKE HECKROTTE ASSOCIATE EMC ENGINEER EMC CHIEF ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO:02U1184-2 FCC ID: APB80412-02A4T DATE: APRIL 8, 2002 EUT: 49MHZ RADIO CONTROL TRANSMITTER Page 4 of 18 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 2.PRODUCT DESCRIPTION The 6V Spiderman Monster Truck transmitter is a full function radio control transmitter for controlling the movement of a toy truck. It is powered by a 9Volt battery and operates at a single fixed frequency of 49.860MHz. The transmitter has two joysticks. The left joystick is for forward or reverse control. The right joystick is for left or right control. CHASSIS TYPE PLASTIC Fundamental Frequency 49.86 MHz Power Derived From 9VOLT BATTERY Type of Transmission CONTINUOUS Antenna Requirement PERMANENTLY AFFIXED Usage TOY Associated Receiver APB80412-02A4R 3.TEST FACILITY The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27, 1994. 4.MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5.TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) REPORT NO:02U1184-2 FCC ID: APB80412-02A4…
