PROPOSED FCC ID LABEL AND LOCATION MATTEL, INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB89900-99A2T FCC ID LABEL FCC ID

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR RC CAR TRANSMITTER MODEL NO: 89900 FCC ID NO: APB89900-99A2T REPORT NO: 99U0598 ISSUE DATE: OCTOBER 5, 1999 Prepared for MATTEL TOYS, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO: 99U0598 FCC ID: APB89900-99A2T DATE: OCTOBER 5, 1999 EUT: RC CAR TRANSMITTER COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1.VERIFICATION OF COMPLIANCE ............................................................................................................ 1 2.PRODUCT DESCRIPTION............................................................................................................................. 2 3.TEST FACILITY .............................................................................................................................................. 2 4.MEASUREMENT STANDARDS .................................................................................................................... 2 5.TEST METHODOLOGY ................................................................................................................................. 2 6.MEASUREMENT EQUIPMENT USED ........................................................................................................ 3 7.POWERLINE RFI LIMIT ............................................................................................................................... 3 8.RADIATED EMISSION LIMITS.................................................................................................................... 3 9.SYSTEM TEST CONFIGURATION.............................................................................................................. 4 10.EQUIPMENT MODIFICATIONS .................................................................................................................. 5 11.TEST PROCEDURE AND RESULT .............................................................................................................. 5 11.1R ADIATED EMISSION TEST PROCEDURE AND RESULT................................................................................ 6 EXHIBIT 1. Proposed FCC ID Label Format 2. Agent Authorization Letter Attachment • EUT Photographs • Schematic Diagram REPORT NO: 99U0598 FCC ID:APB89900-99A2TDATE: OCTOBER 5, 1999 EUT: RC CAR TRANSMITTER PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1.VERIFICATION OF COMPLIANCE COMPANY NAME:MATTEL TOYS, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245, USA CONTACT PERSON:VLADIMIR SOSNOVSKY / SENIOR ELECTRONIC ENGINEER, CES TELEPHONE NO.:(310) 252-5595 EUT DESCRIPTION:RC CAR TRANSMITTER MODEL NAME/NUMBER :89900 SERIAL NUMBER:1 BRAND NAME:MICRO KEY FOB FCC ID:APB89900-99A2T DATE TESTED :October 5, 1999 REPORT NUMBER:99U0598 TYPE OF EQUIPMENTREMOTE CONTROL EQUIPMENT TYPE27 MHz TRANSMITTER MEASUREMENT PROCEDUREANSI 63.4 / 1992 APPLICATION PROCEDURECERTIFICATION FCC RULECFR 47, PART 15.227,15.209,15.205 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE ENGINEERING SERVICES, INC. REPORT NO: 99U0598 FCC ID:APB89900-99A2TDATE: OCTOBER 5, 1999 EUT: RC CAR TRANSMITTER PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2.Product Description CHASSIS TYPE PLASTIC Fundamental Frequency 27.145 MHz Power Source 9V Battery Transmitting Time CONTINUOUS NO. OF LAYER 1 Local Osc. 27.145 MHz 3.Test Facility The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27,1994. 4.Measurement Standards The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5.Test Methodology For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) REPORT NO: 99U0598 FCC ID:APB89900-99A2TDATE: OCTOBER 5, 1999 EUT: RC CAR TRANSMITTER PAGE NO: 3 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 6.Measurement Equipment Used ManufacturerModel Number DescriptionCal Due Date H.P.8566BSpectrum Analyzer (100Hz - 22GHz) 7/01/00 EMCO3110Antenna (25 - 200MHz) 8/12/00 EMCO3146Antenna (200-1000 MHz) 8/12/00 H.P.8447DPreamplifier (0.1 - 1300 MHz) 09/3/00 7.POWERLINE RFI LIMIT CONNECTED TO AC POWER LINE SECTION 15.207 BATTERY POWER NOT REQUIRED. 8.RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTION 15.209, 15.205. OPERATION WITHIN THE BAND 26.96 - 27.28 MHZ SECTION 15.227 REPORT NO: 99U0598 FCC ID:APB89900-99A2TDATE: OCTOBER 5, 1…
