PROPOSED FCC ID LABEL AND LOCATION MATTEL MT. LAUREL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB90962-02A2T FCC ID LABEL

WAVERIPPER TX 27.145 MHz Transmitter FCC ID: APB90962 – 02A2T 8/05/02 WAVERIPPER 27.145MHz TRANSMITTER OPERATIONAL DESCRIPTION The Waveripper R/C transmitter is a low powered, hand held unit for controlling the movement of a toy boat. The single function transmitter is powered by a 9 volt battery. It is designed to operate on a single fixed frequency in the 26.96 – 27.28 MHz band. See the attached block diagram and schematic. A single push button switch activates a multi vibrator circuit (Q3 and Q4) which produces the digital control signal which will modulate the carrier signal. The carrier signal is generated by a LC oscillator amplifier circuit comprised of a T2,C13,C15,C12 and a npn transistor (Q2). The RF carrier signal is modulated by the digital control signal at the base of an RF amplifier stage ( Q1). The modulated output of the RF amplifier stage is capacitively coupled (via C3) to the antenna through a “ pi “ matching network comprised of C1, T1 and C2. The antenna is ~ 7 inches long and permanently attached. All tuning and verifications are performed by the manufacturer and there are no adjustments that can be made by the user. No external ground is required or used with this transmitter.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 27.145MHZ RC TRANSMITTER MODEL NO: 90962 BRAND NAME: TYCO RC-WAVERIPPER FCC ID NO: APB90962-02A2T REPORT NO: 02U1436-1 ISSUE DATE: AUGUST 7, 2002 Prepared for MATTEL MT. LAUREL 6000 MIDLANTIC DRIVE MT. LAUREL, NEW JERSEY 08054 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 02U1436-1 FCC ID: APB90962-02A2T DATE: AUGUST 7, 2002 EUT: 27.145MHz RC TRANSMITTER COMPLIANCE CERTIFICATION SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE...............................................................................3 2. PRODUCT DESCRIPTION................................................................................................4 3. TEST FACILITY..................................................................................................................4 4. MEASUREMENT STANDARDS.......................................................................................4 5. TEST METHODOLOGY....................................................................................................4 6. MEASUREMENT EQUIPMENT USED...........................................................................5 7. POWERLINE RFI LIMIT...................................................................................................5 8. RADIATED EMISSION LIMITS.......................................................................................5 9. SYSTEM TEST CONFIGURATION.................................................................................6 10. EQUIPMENT MODIFICATION....................................................................................8 11. TEST PROCEDURE AND RESULT.............................................................................8 12. APPENDIX......................................................................................................................11 EXTERNAL & INTERNAL PHOTOS...............................................................................................11 SCHEMATICS..............................................................................................................................15 BLOCK DIAGRAM.......................................................................................................................15 USER MANUAL..........................................................................................................................15 REPORT NO: 02U1436-1 FCC ID: APB90962-02A2T DATE: AUGUST 7, 2002 EUT: 27.145MHz RC TRANSMITTER Page 3 of 15 COMPLIANCE CERTIFICATION SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL MT. LAUREL 6000 MIDLANTIC DRIVE MT. LAUREL, NEW JERSEY 08054 USA CONTACT PERSON : FRANK WINKLER/SENIOR ELECTRONICS ENGINEER TELEPHONE NO. : 856-840-1259 EUT DESCRIPTION : 27.145MHz RC TRANSMITTER MODEL NAME/NUMBER : 90962 BRAND NAME : TYCO RC-WAVERIPPER SERIAL NUMBER : N/A FCC ID : APB90962-02A2T DATE TESTED : JULY 29, 2002 REPORT NUMBER : 02U1436-1 TYPE OF EQUIPMENT RADIO CONTROL EQUIPMENT TYPE 27 MHz TRANSMITTER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 SUBPART C The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15 SUBPART C. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Tested By: Approved & Released For CCS By: CHIN PANG THU CHAN EMC TECHNICAIN SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 02U1436-1 FCC ID: APB90962-02A2T DATE: AUGUST 7, 2002 EUT: 27.145MHz RC TRANSMITTER Page 4 of 15 COMPLIANCE CERTIFICATION SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. PRODUCT DESCRIPTION CHASSIS TYPE Plastic Fundamental Frequency 27.145 MHz Power Requirement 9VDC Power Derived From 9V Battery Type of Transmission Data/Continuous Rated RF Output (mW) Less than 30uW (average) Type of Modulation On Off Keying of a fixed frequency carrier wave- OOK AM Channel Bandwidth & Number of Channels Single Channel in the 26.96 to 27.28MHz Band Duplex Method and Duplex Distance Not Applicable-Simple Transmission Channel Access Method Single Channel Duty Cycle of Transmitter 50% Duty Cycle Antenna Type(s) and Number of Each ∼∼7” long, permanently attached whip antenna Antenna Gain, dBi (for each A…

Text truncated - open the document above for the full version.

REPORT NO: 02U1436-1 FCC ID: APB90962-02A2T DATE: AUGUST 7, 2002 EUT: 27.145MHz RC TRANSMITTER Page 6 of 15 COMPLIANCE CERTIFICATION SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9. SYSTEM TEST CONFIGURATION The EUT was configured for testing in a typical fashion (as a customer would normally use it). X-POSITION Y-POSITION REPORT NO: 02U1436-1 FCC ID: APB90962-02A2T DATE: AUGUST 7, 2002 EUT: 27.145MHz RC TRANSMITTER Page 7 of 15 COMPLIANCE CERTIFICATION SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. Z-POSTION Radiated Open Site Test Set-up
