APB92018-00A2T27MHz RF RC Toy Car Transmitter

PROPOSED FCC ID LABEL AND LOCATION MATTEL, INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB92018-00A2T FCC ID LABEL

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 27MHz RF RC TOY CAR TRANSMITTER MODEL NO: 92018 FCC ID NO: APB92018-00A2T REPORT NO: 00U0166 ISSUE DATE: MARCH 30, 2000 Prepared for MATTEL, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO: 00U0166 FCC ID:APB92018-99A2T DATE:MARCH 30, 2000 EUT: 27MHz RF RC TOY CAR TRANSMITTER COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be repruduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1.VERIFICATION OF COMPLIANCE................................................................... 1 2.PRODUCT DESCRIPTION................................................................................. 2 3.TEST FACILITIES ........................................................................................... 2 4.MEASUREMENT STANDARDS ....................................................................... 2 5.TEST METHODOLOGY .................................................................................... 2 6.MEASUREMENT EQUIPMENT USED .............................................................. 3 7.PPOWERLINE RFI LIMITS .............................................................................. 3 8.RADIATED EMISSION LIMITS ....................................................................... 3 9.TEST SETUP AND CONFIGURATION ............................................................. 4 10.EQUIPMENT MODIFICATIONS ....................................................................... 5 11.TEST PROCEDURE AND RESULT .................................................................. 5 EXHIBIT 1. Proposed FCC ID Label Format 2. Agent Authorization Letter Attachment • EUT Photographs • Schematic Diagram REPORT NO: 00U0166 FCC ID:APB92018-99A2T DATE:MARCH 30, 2000 EUT: 27MHz RF RC TOY CAR TRANSMITTER PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be repruduced except in full, without the written approval of CCS. 1.VERIFICATION OF COMPLIANCE COMPANY NAME:MATTEL, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245 USA CONTACT PERSON:VLADIMIR SOSNOVSKY / PROJECT ENGINEER TELEPHONE NO.:(310) 252-5595 EUT DESCRIPTION:27MHz RF RC TOY CAR TRANSMITTER MODEL NAME/NUMBER :92018 BRAND NAME:SPEED WRENCH CAR SERIAL NUMBER:1 FCC ID:APB92018-99A2T DATE TESTED :MARCH 30, 2000 REPORT NUMBER:00U0166 TYPE OF EQUIPMENTREMOTE CONTROL EQUIPMENT TYPE27 MHZ TRANSMITTER MEASUREMENT PROCEDUREANSI 63.4 / 1992 LIMIT TYPECERTIFICATION FCC RULECFR 47, PART 15.227 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. T. N. COKENIAS / ENGINEERING DIRECTOR COMPLIANCE ENGINEERING SERVICES, INC. REPORT NO: 00U0166 FCC ID:APB92018-99A2T DATE:MARCH 30, 2000 EUT: 27MHz RF RC TOY CAR TRANSMITTER PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be repruduced except in full, without the written approval of CCS. 2.Product Description CHASSI S TYP E PLASTIC Fundamental Frequency 27.145 MHz Power Source 4 "AA" Alkaline Batteries Transmitting Time CONTINUOUS Chip Set Brand and Model 20DPTXC1 BOARD REVISION NO 1.0 NO. OF LAYER 1 Local Osc. 27.145 MHz 3.Test Facility The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27,1994. 4.Measurement Standards The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5.Test Methodology For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) REPORT NO: 00U0166 FCC ID:APB92018-99A2T DATE:MARCH 30, 2000 EUT: 27MHz RF RC TOY CAR TRANSMITTER PAGE NO: 3 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be repruduced except in full, without the written approval of CCS. 6.Measurement Equipment Used ManufacturerModel Number DescriptionCal Due Date H.P.8568ASpectrum Analyzer (100Hz - 1.5GHz) 7/01/00 EATON94455-1Antenna (25 - 200MHz) 8/12/00 EMCO3146Antenna (200-1000 MHz) 8/12/00 H.P.8447DPreamplifier (0.1 - 1300 MHz) 09/3/00 7.POWERLINE RFI LIMIT CONNECTED TO AC POWER LINE SECTION 15.207 CARRIER CURRENT SYSTEM IN THE FREQUENCY RANGE OF 450 kHZ TO 30 MHz SECTION 15.205 AND SECTION 15.209, 15.221, 15.223, 15.225 OR 15.227, AS APPROPRIATE. BATTERY POWER NO REQUIRED. 8.RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTION 15.209. RESTRICTED BANDS OF OPERATION SECTION 15.205 OPERATION WITHIN THE BAND 26.96 - 27.28 MHZ SECTION 15.227 REPORT NO: 00U0166 FCC ID:APB92018-99A2T DATE:MARCH 30, 2000 EUT: 27MHz RF RC TOY CAR TRANSMITTER PAGE NO: 4 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be repruduced except in full, without the written approval of CCS. 9.SYSTEM TEST CONFIGURATION The EUT was a…
