APB92182-00A2TRC TOY TRANSMITTER

Deluxe Key Start Micro R/C 27.145 MHz Transmitter FCC ID: APB92182 – 00A2T 10/20/2000 OPERATIONAL DESCRIPTION The Deluxe Key Start Micro R/C transmitter is a low powered, hand held unit for controlling the movement of a toy car or truck. The single function transmitter is powered by a 9 volt battery. It is designed to operate on a single fixed frequency in the 26.96 – 27.28 MHz band. See the attached block diagram and schematic. A single push button switch activates a multi vibrator circuit (Q3 and Q4) which produces the digital control signal which will modulate the carrier signal. The carrier signal is generated by a crystal oscillator/ amplifier circuit comprised of a 27.145 MHz crystal (Y1) and a npn transistor (Q2). The RF carrier signal is modulated by the digital control signal at the base of an RF amplifier stage ( Q1). The modulated output of the RF amplifier stage is capacitively coupled (via C3) to the antenna through a “ pi “ matching network comprised of C1, T1 and C2. The antenna is 4 inches long and permanently attached. In addition to RF transmission, this transmitter also plays sound effects when activated. The sound circuit consists of a sound IC ( U1), an amplifier ( Q5) and a small speaker. This circuit is powered by three 1.5 volt button cell batteries and is electrically independent and isolated from the RF circuit. All tuning and verifications are performed by the manufacturer and there are no adjustments which can be made by the user. No external ground is required or used with this transmitter.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 27 MHz RC CAR TRANSMITTER MODEL NO: 92182 FCC ID NO: APB92182--00A2T REPORT NO: 00U0412-1 ISSUE DATE: AUGUST 31, 2000 Prepared for MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO: 00U0412-1 FCC ID: APB92182-00A2T DATE: AUGUST 31, 2000 EUT: 27 MHz RC CAR TRANSMITTER COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USA TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be repruduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE................................................................... 1 2. PRODUCT DESCRIPTION................................................................................. 2 3. TEST FACILITIES ........................................................................................... 2 4. MEASUREMENT STANDARDS ....................................................................... 2 5. TEST METHODOLOGY .................................................................................... 2 6. MEASUREMENT EQUIPMENT USED .............................................................. 3 7. PPOWERLINE RFI LIMITS .............................................................................. 3 8. RADIATED EMISSION LIMITS ....................................................................... 3 9. TEST SETUP AND CONFIGURATION ............................................................. 4 10. EQUIPMENT MODIFICATIONS ....................................................................... 5 11. TEST PROCEDURE AND RESULT .................................................................. 5 EXHIBIT 1. Proposed FCC ID Label Format 2. Agent Authorization Letter Attachment • EUT Photographs • Schematic Diagram REPORT NO: 00U0412-1 FCC ID: APB92182-00A2T DATE: AUGUST 31, 2000 EUT: 27 MHz RC CAR TRANSMITTER PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USA TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA CONTACT PERSON : NATHAN BLOCH, SENIOR PROJECT ENGINEER TELEPHONE NO. : (856) 840-1262 EUT DESCRIPTION : 27 MHz RC CAR TRANSMITTER MODEL NAME/NUMBER : 92182 BRAND NAME : KEY START WITH SOUND SERIAL NUMBER : N/A FCC ID : APB92182-00A2T DATE TESTED : AUGUST 18, 2000 REPORT NUMBER : 00U0412-1 TYPE OF EQUIPMENT REMOTE CONTROL EQUIPMENT TYPE 27 MHZ TRANSMITTER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15.227 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. Warning : This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Approved By T. N. COKENIAS / ENGINEERING DIRECTOR COMPLIANCE CERTIFICATION SERVICES REPORT NO: 00U0412-1 FCC ID: APB92182-00A2T DATE: AUGUST 31, 2000 EUT: 27 MHz RC CAR TRANSMITTER PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USA TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC Fundamental Frequency 27.145 MHz Power Source 9 VOLT BATTERY CHIPSET BRAND AND PART NO MATTEL. 92182/TX Transmitting Time CONTINUOUS NO. OF LAYER 1 Local Osc. 27.145MHz 3. Test Facility The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27,1994. 4. Measurement Standards The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5. Test Methodology For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) REPORT NO: 00U0412-1 FCC ID: APB92182-00A2T DATE: AUGUST 31, 2000 EUT: 27 MHz RC CAR TRANSMITTER PAGE NO: 3 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USA TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 6. Measurement Equipment Used Manufacturer Model Number Description Cal Due Date H.P. 8568A Spectrum Analyzer (100Hz - 1.5GHz) 11/18/00 EMCO 6502 Ac…

Text truncated - open the document above for the full version.

REPORT NO: 00U0412-1 FCC ID: APB92182-00A2T DATE: AUGUST 31, 2000 EUT: 27 MHz RC CAR TRANSMITTER PAGE NO: 4 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USA TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 9. SYSTEM TEST CONFIGURATION The EUT was configured for testing in a typical fashion (as a customer would normally use it). Attached a plastic module to EUT button by using a rubber band to cause continuous transmission. Push-to-Transmit switch is held in transmit position using electrician’s (PVC) tape for transmit mode. The tape is removed for receive mode. Please refer to the following photograph for actual setup. Radiated Open Site Test Set-up
