APB92769-00A2TRadio Control Toy Transmitter

CONTENTS Vehicle Transmitter Power Clip (if supplied) 6.0V Jet Turbo ® Battery Pack (if supplied) 6.0V Jet Turbo ® Charger (if supplied) CHASSIS Your vehicle’s chassis may look slightly different, depending on the vehicle’s design. Refer to label on transmitter and vehicle for frequency. Do not race vehicles with the same frequency. VEHICLE OPERATION FORWARD REVERSE LEFT RIGHT 92769-0920 ON/OFF switch battery latch high/low gear selector steering adjuster Keep these instructions for future reference: they contain important information. 6.0V R/C 6.0V R/C CAUTION:Surfaces may become hot and cause burns if electronics get wet. Do not operate vehicle through water or snow. POWER CLIP Unscrew Power Clip cover screw and remove cover. Insert 4 "AA" batteries, with polarity (+/-) as shown inside Power Clip. Replace cover. VEHICLE BATTERY INSTALLATION 1. Rotate battery latch to open position. 2. Insert the battery you’re using into battery compartment and slide it away from latch. 3. Make sure battery snaps securely in place and rotate latch to locked position. 4. To remove: turn latch, slide toward latch and lift out. TRANSMITTER BATTERY INSTALLATION NOTE: Your transmitter is equipped with a special automatic ON battery-saving feature. Just turn your vehicle ON. Then push either transmitter stick and you will be able to run and control your vehicle. 1. To install transmitter battery, open battery cover as shown. 2. Install one 9V battery with polarity (+/-) as shown inside battery compartment. 3. Replace battery cover. vehicle controls battery cover battery compartment power indicator light POWER SYSTEMS This vehicle can operate on 2 different power systems: the Power Clip (which uses 4 "AA" batteries) or the 6.0V NiCd rechargeable battery pack. For detailed information regarding NiCd vehicle battery charging and safety, please follow the specific instructions that came with your battery pack and charger. BATTERY CHARGING/CARE – 6.0V JET TURBO ® BATTERY 1. Plug wall pack charger into standard wall outlet. 2. Click the battery pack into the charger. Make certain the battery pack is secure in charger. 3. To disconnect, push the red button on the side of charger and simultaneously slide battery pack out. 4. After charging for 4 hours, the battery will feel warm. This condition is normal for fully charged batteries. 5. New battery packs must be charged for 51/2 hours the first two times charged. Subsequent charges will require only 4 hours. Charging the battery pack for more than 4 hours will not give you a longer running time. 4 hours is all that is required for a fully charged battery pack. 6. Unlike alkaline batteries, where the power loss is gradual, a NiCd (Nickel-Cadmium) battery will run for its normal running time and then lose most of its power at once. It is time to recharge the battery pack. 7. After use, the battery pack will be hot! Wait at least 20 minutes until the battery pack cools before recharging. Recharging a warm or hot battery pack will greatly reduce the number of times your battery pack can be recharged. RECHARGEABLE BATTERY INFORMATION:  DO NOT RECHARGE BATTERY PACK IF IT’S HOT. ALLOW IT TO COOL BEFORE RECHARGING.  DO NOT RECHARGE A BATTERY PACK THAT SHOWS LEAKAGE OR CORROSION.  DO NOT DISASSEMBLE THE BATTERY PACK. THE BATTERY PACK IS A SEALED RECHARGEABLE NICKEL-CADMIUM BATTERY.  DO NOT DISPOSE OF THE BATTERY PACK IN FIRE.  EXERCISE CAUTION IN HANDLING A HOT BATTERY PACK.  IF BATTERY PACK AND/OR CHARGER ARE WET, THOROUGHLY DRY BEFORE CHARGING.  DO NOT RECHARGE NON- RECHARGEABLE BATTERIES.  DO NOT USE THE POWER CLIP WITH THE 6.0V JET TURBO CHARGER. Note to Adults: • Remove rechargeable batteries before recharging. Recharge batteries only under adult supervision. • Regularly examine for damage to the plug, enclosure and other parts. In the event of any damage, the toy must not be used with the transformer until the damage has been repaired. • This toy is not intended for children under 3 years old. The transformer is not a toy. Additional 6.0V Jet Turbo ® NiCd Battery Pack Tyco ® R/C 6.0V Jet Turbo ® NiCd Battery Pack and Charger ALSO AVAILABLE NiCd BATTERY INFORMATION THIS PRODUCT USES A NICKEL-CADMIUM RECHARGEABLE BATTERY PACK. BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY. FOR FURTHER INFORMATION REGARDING BATTERIES OR THEIR DISPOSAL PLEASE CALL 1-800-348-0751. SAFETY INFORMATION Note to Adults: To ensure that the child’s play is both safe and fun, please review all operating instructions and safety rules with your child. Safety Tips • NEVER drive your vehicle on streets! They’re for real cars! • DO NOT pick up vehicle while in motion. • Keep fingers, hair and loose clothing away from the tires and the wheel hubs while the vehicle is switched ON. • Adult supervision is recommended when this vehicle is being operated. • To avoid accidental operation, remove all batteries when not in use. IMPORTANT BATTERY INFORMATION • Insure that battery polarity is correct. • Use only batteries of the type recommended (or equivalent). • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. • Remove used-up batteries immediately. Remove batteries if vehicle will not be used for a long period. • For best performance use alkaline batteries (where disposable batteries are called for). Battery life may vary depending on battery brand. • Do not recharge non-rechargeable batteries. • Do not short-circuit terminals. • Remove rechargeable batteries before recharging. Recharge batteries only under adult supervision. • Dispose of batteries safely. QUICK TIPS ❶When your vehicle starts to lose power, it may lose functions or performance. It's time for fresh batteries (or a recharge). Your vehicle's running time may change depending on your driving style. ❷Radio interference can make your vehicle run badly. Interference can be caused by other R/C vehicles running on the same frequency; electrical wires; large buildings; …

Text truncated - open the document above for the full version.

PROPOSED FCC ID LABEL AND LOCATION MATTEL MT. LAUREL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB92769-00A2T FCC ID LABEL LOCATION

6V Street Luge R/C 27.145 MHz Mattel Part # 92769 Transmitter FCC ID: APB92769 – 00A2T 11/01/2000 TRANSMITTER OPERATIONAL DESCRIPTION The Street Luge R/C transmitter is a low powered, hand held unit for controlling the movement of a toy street luge. The transmitter is powered by a 9 volt battery. It is designed to operate on a single fixed frequency in the 26.96 – 27.28 MHz band. See the attached block diagram and schematic. Joystick inputs trigger an integrated circuit (TX2) which produces the digital control signals which will modulate the carrier signal. The carrier signal is generated by a crystal oscillator/ amplifier circuit comprised of a 27.145 MHz crystal (Y1) and a pnp transistor (Q1). The RF carrier signal is modulated by the digital control signal at the base of an RF amplifier stage ( Q2). The modulated output of the RF amplifier stage is capacitively coupled ( via C10) to the antenna through a “ pi “ matching network comprised of C11, L3 and C12. The whip antenna is 12 inches long and permanently attached. All tuning and verifications are performed by the manufacturer and there are no adjustments which can be made by the user. No external ground is required or used with this transmitter.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 27MHz RC STREET LUGE TRANSMITTER MODEL NO: 92769 FCC ID NO: APB92769-00A2T REPORT NO: 00U0541-1 ISSUE DATE: NOVEMBER 30, 2000 Prepared for MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 00U0541-1 FCC ID: APB92769-00A2T DATE: NOVEMBER 30, 2000 EUT: 27 MHz RC STREET LUGE TRANSMITTER COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTERY ROAD MORGAN HILL, CA 95037, USA TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE.............................................................................1 2. PRODUCT DESCRIPTION.............................................................................................2 3. TEST FACILITY..............................................................................................................2 4. MEASUREMENT STANDARDS....................................................................................2 5. TEST METHODOLOGY.................................................................................................2 6. MEASUREMENT EQUIPMENT USED.........................................................................3 7. POWERLINE RFI LIMIT...............................................................................................3 8. RADIATED EMISSION LIMITS.....................................................................................3 9. SYSTEM TEST CONFIGURATION..............................................................................4 10. EQUIPMENT MODIFICATIONS...............................................................................5 11. TEST PROCEDURE AND RESULT...........................................................................5 11.1 RADIATED EMISSION TEST PROCEDURE AND RESULT.................................5 EXHIBIT 1. Proposed FCC ID Label Format 2. Agent Authorization Letter Attachment • EUT Photographs • Schematic Diagram REPORT NO: 00U0541-1 FCC ID: APB92769-00A2T DATE: NOVEMBER 30, 2000 EUT: 27 MHz RC STREET LUGE TRANSMITTER PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTERY ROAD MORGAN HILL, CA 95037, USA TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL MOUNT LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA CONTACT PERSON : FRANK WINKLER, SENIOR PROJECT ENGINEER TELEPHONE NO. : (856) 840-1259 EUT DESCRIPTION : 27MHz RC STREET LUGE TRANSMITTER MODEL NAME/NUMBER : 92769 BRAND NAME : TYCO R/C-6VDP STREET LUGE SERIAL NUMBER : N/A FCC ID : APB92769-00A2T DATE TESTED : NOVEMBER 06, 2000 REPORT NUMBER : 00U0541-1 TYPE OF EQUIPMENT REMOTE CONTROL EQUIPMENT TYPE 27 MHZ TRANSMITTER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15.227 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. STEVE CHENG / SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES T. N. COKENIAS / ENGINEERING DIRECTOR COMPLIANCE CERTIFICATION SERVICES REPORT NO: 00U0541-1 FCC ID: APB92769-00A2T DATE: NOVEMBER 30, 2000 EUT: 27 MHz RC STREET LUGE TRANSMITTER PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTERY ROAD MORGAN HILL, CA 95037, USA TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC Fundamental Frequency 27.145 MHz Power Source 9 VOLT BATTERY Transmitting Time CONTINUOUS Chip Set Brand and Model MATTEL 92769/TX NO. OF LAYER 1 Local Osc. 27.145MHz 3. TEST FACILITY The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27,1994. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) REPORT NO: 00U0541-1 FCC ID: APB92769-00A2T DATE: NOVEMBER 30, 2000 EUT: 27 MHz RC STREET LUGE TRANSMITTER PAGE NO: 3 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTERY ROAD MORGAN HILL, CA 95037, USA TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 6. MEASUREMENT EQUIPMENT USED Manufacturer Model Number Description Cal Due Date H.P. 8566B Spectrum Analyzer (100Hz-22GHz) 06/16/01 EATON 94455-1 Antenna (30-200MHz) 08/10/01 EMCO 6502 Active Loop Antenna (10K-30MHz) 02/23/01 7. POWERLINE RFI LIMIT CONNECTED TO AC POWER LINE SECTION 15.207 BATTERY POWER NOT REQUIRED. 8. RADIATED EMISSION LIMITS GENERAL REQUIREMENTS SECTION 15.209 RESTRICTED BANDS OF OPERATION SECTION 15.205 OPERATION WITHIN THE BAND 26.96 - 27.28 MHZ SECTION 15.227 REPORT NO: 00U0541-1 FCC ID: APB92769-00A2T DATE: NOVEMBER 30, 2000 EUT: 27 MHz RC STREET LUGE TRANSMITTER PAGE NO: 4 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F…

Text truncated - open the document above for the full version.

REPORT NO: 00U0541-1 FCC ID: APB92769-00A2T DATE: NOVEMBER 30, 2000 EUT: 27 MHz RC STREET LUGG TRANSMITTER PAGE NO: 4 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4022B 561 F MONTERY ROAD MORGAN HILL, CA 95037, USA TEL:(408) 463-0885 FAX:(408) 463-0888 This report shall not be repruduced except in full, without the written approval of CCS. 9. SYSTEM TEST CONFIGURATION The EUT was configured for testing in a typical fashion (as a customer would normally use it). Attached a plastic module to the EUT button by using a rubber band to cause continuous transmission during testing. Push-to-Transmit switch is held in transmit position using electrician’s (PVC) tape for transmit mode. The tape is removed for receive mode. Please refer to the following photograph for actual setup. Radiated Open Site Test Set-up
