APB92959-00A4TRADIO CONTROL TOY TRANSMITTER

Keep these instructions for future reference: they contain important information. 92141-0921 I. READY...SET...GO! 1. Unscrew vehicle battery door. 2. Insert 2 AA alkaline batteries with polarity as shown inside battery compartment. Replace battery door. 3. Push transmitter battery door open. 4. Insert 1 9V alkaline battery as shown. Replace battery door. 5. Turn vehicle switch ON. 6. Push either transmitter button to activate. II. OPERATION ❶ FORWARD ❷ REVERSE ❸ LEFT TURN ❹ RIGHT TURN ❺ TIGHT SPIN LEFT ❻ TIGHT SPIN RIGHT Your transmitter is also a cool display stand. Store your vehicle on it when you’re done playing. WARNING:Never allow young children to play in or around water without adult supervision. HYDRO RACER HYDRO RACER ™ ❶ On-Off Switch ❷ ❹❻❺ ❸ Antenna 6LR61 9 V d.c. III. QUICK TIPS ❶When your vehicle starts to lose power, it may lose func- tions or performance. It’s time for fresh batteries. Your vehi- cle’s running time may change depending on your driving style. ❷Radio interference can make your vehicle run badly. Interfer- ence can be caused by other R/C vehicles running on the same frequency; electrical wires; large buildings; or CB radios. Try to stay away from these! ❸ Point your transmitter antenna up - not down toward your vehicle. If your vehicle gets too far away, it won’t work proper- ly. DO NOT EXPOSE THE TRANSMITTER TO WATER. If the transmitter is accidentally exposed to water, remove the transmitter battery and allow the transmitter to air-dry. Replace with a fresh battery before resuming operation. ❹Your vehicle is designed for operation in calm, fresh water. Pools and shallow ponds are recommended. Do not expose vehicle to water unless the bat- tery compartment cover is prop- erly closed and latched. AVOID SALT WATER OPERATION. ❺Don’t store your vehicle near heat or in direct sunlight. Always turn switches OFF and remove all batteries for storage. After each use, remove any water or moisture from vehicle using a clean dry cloth. Note to Adults Adults, this toy is recommended for children 5 years of age and older. To ensure that the child’s play is both safe and fun, please review the operating instructions and these general safety rules with your child. Safety Tips • DO NOT pick up vehicle while in motion. • Keep fingers, hair and loose cloth- ing away from the propeller drive while the vehicle is switched ON. • Adult supervision is recommended when this vehicle is being operated. • To avoid accidental operation, remove all batteries when not in use. • Do not operate near swimmers. Stand away from the water’s edge when operating. IMPORTANT BATTERY INFORMATION "Insure that battery polarity is correct. "Use only batteries of the type recommended (or equivalent). "Do not mix old and new batter- ies. "Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. "Remove used-up batteries imme- diately. Remove batteries if vehi- cle will not be used for a long period. "For best performance use alka- line batteries (where disposable batteries are called for). Battery life may vary depending on bat- tery brand. "Do not recharge non-recharge- able batteries. "Do not short-circuit terminals. "Remove rechargeable batteries before recharging. Recharge batteries only under adult super- vision. "Dispose of batteries safely. ©2000 Mattel, Inc., Mt. Laurel, NJ 08054 U.S.A. PRINTED IN CHINA. All Rights Reserved. ® and ™ designate U.S. trade- marks of Mattel, Inc. Retain this address for future reference: Mattel U.K., Ltd., V anwall Business Park, Maidenhead SL6 4UB. Mattel Australia Pty., Ltd., Richmond, Victoria 3121 - Con- sumer Advisory Service: 1800 800 812 (valid only in Australia). Mattel East Asia Limited, 930 Ocean Centre, Harbour City, HK, China. COMPLIANCE WITH FCC REGULATIONS THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION OF THIS DEVICE IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARM- FUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY HARMFUL INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. This device generates and uses radio fre- quency energy and if not used properly may cause interference to radio and television reception. It has been tested and found to comply with the limits set by the FCC, which are designed to provide reasonable protec- tion against such interference. CAUTION: Changes or modifica- tions not expressly approved by the man- ufacturer responsible for compliance could void the user’s authority to operate the equipment. ❺❹❶❷❸

PROPOSED FCC ID LABEL AND LOCATION MATTEL MT. LAUREL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB92959-00A4T FCC ID LABEL

Hydro Racer R/C 49.860 MHz Mattel Part # 92959 Transmitter FCC ID: APB92959 – 00A4T 12/1/2000 RC HYDRO RACER 49 MHZ TRANSMITTER OPERATIONAL DESCRIPTION The Hydro Racer R/C transmitter is a low powered, hand held unit for controlling the movement of a toy boat. The transmitter is powered by a 9 volt battery. It is designed to operate on a single fixed frequency in the 49.82-49.90 MHz band. See the attached block diagram and schematic. Switch inputs trigger an integrated circuit ( TX2 ) which produces the digital control signals which will modulate the carrier signal. The carrier signal is generated by a crystal oscillator/ amplifier circuit comprised of a 49.860 MHz crystal ( X1 ) and a pnp transistor ( Q2 ). The RF carrier signal is modulated by the digital control signal at the base of an RF amplifier stage ( Q1 ). The modulated output of the RF amplifier stage is capacitively coupled ( via C6 ) to the antenna through a “ pi “ matching network comprised of C7, L4 and C8. The whip antenna is 12 inches long and permanently attached. All tuning and verifications are performed by the manufacturer and there are no adjustments which can be made by the user. No external ground is required or used with this transmitter.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 49MHz RC BOAT TRANSMITTER MODEL NO: 92959 FCC ID NO: APB92959-00A4T REPORT NO: 00U0578-1 ISSUE DATE: NOVEMBER 30, 2000 Prepared for MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. 561 F MONTEREY ROAD ROUTE 2 MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO:00U0578-1 FCC ID: APB92959-00A4T DATE: NOVEMBER 30, 2000 EUT: 49 MHz RC BOAT TRANSMITTER PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD MORGAN HILL, CA 95037 USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE............................................................ 2 2. PRODUCT DESCRIPTION.......................................................................... 3 3. TEST FACILITIES ..................................................................................... 3 4. MEASUREMENT STANDARDS ................................................................. 3 5. TEST METHODOLOGY ............................................................................. 3 6. MEASUREMENT EQUIPMENT USED ........................................................ 4 7. TEST PROCEDURES AND TEST RESULTS................................................. 4 Radiated Emission Test Result( 15.235 (a)) Radiated Emission Test Result( 15.235 (b)) 8. RADIATED EMISSION TEST SETUP PHOTO.............................................. 6 EXHIBITS 1. Proposed FCC ID Label Format 2. Authorization Letter 3. EUT Photographs 4. Schematic Diagram 5. User Manual REPORT NO:00U0578-1 FCC ID: APB92959-00A4T DATE: NOVEMBER 30, 2000 EUT: 49 MHz RC BOAT TRANSMITTER PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD MORGAN HILL, CA 95037 USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA CONTACT PERSON : VIKAS SINHA, SENIOR PROJECT ENGINEER TELEPHONE NO. : (856) 840-1279 EUT DESCRIPTION : 49MHz RC BOAT TRANSMITTER MODEL NAME/NUMBER : 92959 BRAND NAME : R/C HYDRO RACER SERIAL NUMBER : N/A FCC ID : APB92959-00A4T DATE TESTED : NOVEMBER 29, 2000 REPORT NUMBER : 00U0578-1 EQUIPMENT TYPE 49.86 MHz TRANSMITTER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15.235 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. JESSE SALDIVAR / EMC TECHNICIAN COMPLIANCE ENGINEERING SERVICES, INC. T. N. COKENIAS / ENGIEERING DIRECTOR COMPLIANCE ENGINEERING SERVICES, INC. REPORT NO:00U0578-1 FCC ID: APB92959-00A4T DATE: NOVEMBER 30, 2000 EUT: 49 MHz RC BOAT TRANSMITTER PAGE NO: 3 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD MORGAN HILL, CA 95037 USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION CHASSIS TYPE PLASTIC Fundamental Frequency 49.86 MHz Power Source 9VOLT BATTERY Transmitting Time CONTINUOUS Type of Antenna PERMANENTLY ATTACHED No. of Channel 1 NO. OF LAYER 1 Associated Receiver APB92959-00A4R 3. TEST FACILITY The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27, 1994. 4. MEASUREMENT STANDARDS The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5. TEST METHODOLOGY For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) REPORT NO:00U0578-1 FCC ID: APB92959-00A4T DATE: NOVEMBER 30, 2000 EUT: 49 MHz RC BOAT TRANSMITTER PAGE NO: 4 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD MORGAN HILL, CA 95037 USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 6. MEASUREMENT EQUIPMENT USED Manufacturer Model Number Description Cal Due Date H.P. 8568B Spectrum Analyzer (100Hz - 1.5GHz) 03/15/01 SCHAFFNER- CHASE CBL6112B Antenna (30-2000 MHz) 12/23/00 BATTERY N/A 9 VOLT ALKALINE BATTERY N/A 7. TEST PROCEDURES AND TEST RESULTS RADIATED EMISSION TEST: ( 15.235 (a)) Test Procedure 1. The EUT was placed on a wooden table on the outdoor ground plane. The search antenna was placed 3 meter from the EUT. The EUT was placed in X,Y, and Z position to simulate the actual usage. 2. The turntable was slowly rotated to locate the direction of maximum emission at each EUT position. Once the maximum direction and EUT position was determined, the search antenna was raised and lowered in both vertical and horizontal polarization. The maximum reading so obtained is recorded in the data list below. Test Result: Peak emission was under average limit. Refer to attached plots. REPORT NO:00U0578-1 FCC ID: APB92959-00A4T DATE: NOVEMBER 30, 2000 EUT: 49 MHz RC BOAT TRANSMITTER PAGE NO: 5 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD MORGAN HILL, CA 95037 USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. …

Text truncated - open the document above for the full version.

REPORT NO:00U0578-1 FCC ID: APB92959-00A4T DATE: NOVEMBER 30, 2000 EUT: 49 MHz RC BOAT TRANSMITTER PAGE NO: 6 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 561 F MONTEREY ROAD MORGAN HILL, , CA 95037 USA TEL:(408)463-0885 FAX:(408)463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 8. Radiated Emission Test Setup Photo
