APB92961-00A4TRemote control transmitter

OPERATIONAL DESCRIPTION The Sea Arrow R/C transmitter is a low powered, hand held unit for controlling the movement of a toy boat. The transmitter is powered by a 9 volt battery. It is designed to operate on a single fixed frequency in the 49.82 – 49.90 MHz band. See the attached block diagram and schematic. Joystick inputs trigger an integrated circuit ( U1) which produces the digital control signals which will modulate the carrier signal. The carrier signal is generated by a crystal oscillator/ amplifier circuit comprised of a 49.860 MHz crystal ( X1) and an npn transistor (Q2). The RF carrier signal is modulated by the digital control signal at the base of an RF amplifier stage ( Q1). The modulated output of the RF amplifier stage is capacitively coupled ( via C10) to the antenna through a “ pi “ matching network comprised of C11, T1 and C17. The whip antenna is 12 inches long and permanently attached. All tuning and verification are performed by the manufacture and there are no adjustments which can be made by the user. No external ground is required or used with this transmitter.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for INTENTIONAL RADIATOR 49MHz RC BOAT AND TRANSMITTER MODEL NO: 92961 FCC ID NO: APB92961-00A4T REPORT NO: 00U0425-1 ISSUE DATE: SEPTEMBER 18, 2000 Prepared for MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 REPORT NO:00U0425-1 FCC ID: APB92961-00A4T DATE: SEPTEMBER 18, 2000 EUT: 49 MHz RC BOAT AND TRANSMITTER PAGE NO: 1 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4026B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS PAGE 1.VERIFICATION OF COMPLIANCE............................................................ 2 2.PRODUCT DESCRIPTION.......................................................................... 3 3.TEST FACILITIES ..................................................................................... 3 4.MEASUREMENT STANDARDS ................................................................. 3 5.TEST METHODOLOGY ............................................................................. 3 6.MEASUREMENT EQUIPMENT USED ........................................................ 4 7.TEST PROCEDURES AND TEST RESULTS................................................. 4 Radiated Emission Test Result( 15.235 (a)) Radiated Emission Test Result( 15.235 (b)) 8.RADIATED EMISSION TEST SETUP PHOTO.............................................. 6 EXHIBITS 1. Proposed FCC ID Label Format 2. Authorization Letter 3. EUT Photographs 4. Schematic Diagram 5. User Manual REPORT NO:00U0425-1 FCC ID: APB92961-00A4T DATE: SEPTEMBER 18, 2000 EUT: 49 MHz RC BOAT AND TRANSMITTER PAGE NO: 2 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4026B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 1.VERIFICATION OF COMPLIANCE COMPANY NAME:MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA CONTACT PERSON:NATHAN BLOCH, SENIOR PROJECT ENGINEER TELEPHONE NO.:(856) 840-1262 EUT DESCRIPTION:49MHz RC BOAT AND TRANSMITTER MODEL NAME/NUMBER:92961 BRAND NAME:SEA ARROW SERIAL NUMBER:N/A FCC ID:APB92961-00A4T DATE TESTED :SEPTEMBER 18, 2000 REPORT NUMBER:00U0425-1 EQUIPMENT TYPE49.86 MHz TRANSMITTER MEASUREMENT PROCEDUREANSI 63.4 / 1992 LIMIT TYPECERTIFICATION FCC RULECFR 47, PART 15.235 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. T. N. COKENIAS / ENGIEERING DIRECTOR COMPLIANCE ENGINEERING SERVICES, INC. REPORT NO:00U0425-1 FCC ID: APB92961-00A4T DATE: SEPTEMBER 18, 2000 EUT: 49 MHz RC BOAT AND TRANSMITTER PAGE NO: 3 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4026B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 2.Product Description CHASSI S TYP E PLASTIC Fundamental Frequency 49.86 MHz Power Source 4 AA ALKALINE BATTERY, 6V RECHARGABLE NICAD, OR 9V BATTERY Transmitting Time CONTINUOUS Type of Antenna PERMANENTLY ATTACHED No. of Channel 1 NO. OF LAYER 1 Associated Receiver APB92961-00A4R 3.Test Facility The 3/10/30 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facility was submitted to the Commission on May 27, 1994. 4.Measurement Standards The site is constructed and calibrated in conformance with the requirements of ANSI C63.4/1992. 5.Test Methodology For an intentional radiator, the spectrum shall be investigated from the lowest radio frequency signal generated in the device, without going below 9 KHz, up to at least the tenth harmonic of the highest fundamental frequency or to 40 GHz, whichever is lower. (CFR 47 Section 15.33) REPORT NO:00U0425-1 FCC ID: APB92961-00A4T DATE: SEPTEMBER 18, 2000 EUT: 49 MHz RC BOAT AND TRANSMITTER PAGE NO: 4 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4026B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 6.Measurement Equipment Used ManufacturerModel Number DescriptionCal Due Date H.P.8568BSpectrum Analyzer (100Hz - 1.5GHz) 11/18/00 SCHAFFNER- CHASE CBL6112BAntenna (30-2000 MHz) 11/23/00 BATTERYN/A9 VOLT ALKALINE BATTERYN/A 7.Test Procedures and Test Results Radiated Emission Test: ( 15.235 (a)) Test Procedure 1. The EUT was placed on a wooden table on the outdoor ground plane. The search antenna was placed 3 meter from the EUT. The EUT was placed in X,Y, and Z position to simulate the actual usage. 2.The turntable was slowly rotated to locate the direction of maximum emission at each EUT position. Once the maximum direction and EUT position was determined, the search antenna was raised and lowered in both vertical and horizontal polarization. The maximum reading so obtained are recorded in the data list below. Test Result: Peak emission was under average limit. Refer to attached plots. REPORT NO:00U0425-1 FCC ID: APB92961-00A4T DATE: SEPTEMBER 18, 2000 EUT: 49 MHz RC BOAT AND TRANSMITTER PAGE NO: 5 COMPLIANCE ENGINEERING SERVICES, INC.CCS DOCUMENT NO:CCSUP4026B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USATEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. Radiated Emission Test: ( 15.235 (b)) Test Requirement : Th…

Text truncated - open the document above for the full version.

REPORT NO:00U0425-1 FCC ID: APB92961-00A4T DATE: SEPTEMBER 18, 2000 EUT: 49 MHz RC BOAT AND TRANSMITTER PAGE NO: 6 COMPLIANCE ENGINEERING SERVICES, INC. CCS DOCUMENT NO:CCSUP4026B 1366 BORDEAUX DRIVE, SUNNYVALE, CA 94089, USA TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without the written approval of CCS. 8. Radiated Emission Test Setup Photo
