APB96423-99A4R49 MHz RC Toy Receiver

Date: 12/01/99 Subject No: FCC ID No Correction for EA96104 Dear Betty, I made a mistake of the FCC ID No. on the 731 Form. Please help to correct it for us. The correct FCC ID should be: APB96423-99A4R instead of APB96423- A4R. Thank you very much. The FCC ID on the test report and ID label are showing the correct one. Happy Holidays! Anne Liang ***************************************** Anne Liang Compliance Certification Services, Inc. 1366 Bordeaux Drive Sunnyvale, CA 94089 USA Tel: (408)752-8166 FAX: (408)752-8168 E-mail: [email protected] http://www.ccsemc.com ******************************************

PROPOSED FCC ID LABEL AND LOCATION MATTEL TOYS, INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB96423-99A4R FCC ID LABEL FCC ID

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for UNINTENTIONAL RADIATOR 49 MHz RC TOY CAR RECEIVER MODEL: 96423 BRAND NAME: RACIN’ RATZ FCC ID: APB96423-99A4R REPORT NO: 99U0607-1 DATE: NOVEMBER 02, 1999 Prepared for MATTEL TOYS, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245 USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. 1366 BORDEAUX DRIVE SUNNYVALE, CA 94089, USA TEL: (408) 752-8166 FAX: (408) 752-8168 TABLE OF CONTENTS 1.VERIFICATION OF COMPLIANCE............................................................................................... 1 2.PRODUCT DESCRIPTION................................................................................................................... 2 3.TEST FACILITY........................................................................................................................................ 2 4.MEASUREMENT EQUIPMENT USED.......................................................................................... 2 5.TEST CONFIGURATION...................................................................................................................... 3 6.TESTS CONDUCTED.............................................................................................................................. 3 7.CONDUCTED EMISSION TEST PROCEDURE........................................................................ 3 8. RADIATED EMISSION TEST PROCEDURE................................................................................. 4 9.COHERENT TESTS................................................................................................................................. 4 10.EQUIPMENT MODIFICATIONS.................................................................................................. 4 11.TEST CONFIGURATION PHOTOS (RADIATED EMISSION TEST)........................ 5 TEST DATA • Fundamental Frequency Plot • Radiated Emission Data Proposed FCC ID Label.........................Exhibit 1 Agent Authorization Letter....................Exhibit 2 User Manual.........................................Attachment A Block Diagram/Schematics......................Attachment B REPORT NO:99U0607-1 DATE: NOVEMBER 02, 1999FCC ID:APB96423-99A4R PAGE NO: COMPLIANCE CONSULTING SERVICESCCS DOCUMENT NO: CCSUP4021B 1366 BORDEAUX DRIVE, SUNNYVALE CA 94089TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without written approval from CCS. 1 1.VERIFICATION OF COMPLIANCE COMPANY NAME:MATTEL TOYS, INC. 333 CONTINENTAL BLVD. EL SEGUNDO, CA 90245 USA CONTACT PERSON:VLADIMIR BUZGA DIRECTOR OF DEVELOPMENT, CES TELEPHONE NO.:(310) 252-5595 EUT DESCRIPTION:49 MHz RC TOY CAR RECEIVER MODEL NAME/NUMBER :96423 FCC ID:APB96423-99A4R DATE TESTED :NOVEMBER 02, 1999 REPORT NUMBER:99U0607-1 TYPE OF EQUIPMENT SECURITY EQUIPMENT (UNINTENTIONAL RADIATOR) EQUIPMENT TYPE49 MHz SUPERREGENERATE RECEIVER MEASUREMENT PROCEDUREANSI 63.4 / 1992 LIMIT TYPECERTIFICATION FCC RULECFR 47, PART 15.109 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. MIKE C.I. KUO / VICE PRESIDENT COMPLIANCE ENGINEERING SERVICES, INC. REPORT NO:99U0607-1 DATE: NOVEMBER 02, 1999FCC ID:APB96423-99A4R PAGE NO: COMPLIANCE CONSULTING SERVICESCCS DOCUMENT NO: CCSUP4021B 1366 BORDEAUX DRIVE, SUNNYVALE CA 94089TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without written approval from CCS. 2 2.PRODUCT DESCRIPTION MATTEL TOYS, INC., Model 96423 is the receiving portion of a multi-purpose security device. The associated Transmitter is manufactured by MATTEL TOYS, INC., Model No: 96423, FCC ID: APB96423-99A4T. 3.TEST FACILITY The 3 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facilities was submitted to the Commission on May 27, 1994. The measuring instrument which was utilized in performing the tests documented herein has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment which is traceable to recognized national standards. 4.MEASUREMENT EQUIPMENT USED ManufacturerModel Number DescriptionCal Due Date H.P.8640BSignal Generator (0.5 - 1024 MHz) 08/2000 H.P.8566BSpectrum Analyzer (100Hz - 22GHz) 09/2000 EMCO3146Antenna (200-1000 MHz) 10/2000 H.P.8447DPreamplifier (0.1 - 1300 MHz) 09/2000 ARADRG-18/AAntenna(1 - 18GHZ)12/1999 H.P.8449BPreamplifier (1-26.5GHZ)03/2000 REPORT NO:99U0607-1 DATE: NOVEMBER 02, 1999FCC ID:APB96423-99A4R PAGE NO: COMPLIANCE CONSULTING SERVICESCCS DOCUMENT NO: CCSUP4021B 1366 BORDEAUX DRIVE, SUNNYVALE CA 94089TEL:(408)752-8166 FAX:(408)752-8168 This report shall not be reproduced except in full, without written approval from CCS. 3 5.TEST CONFIGURATION Set signal generator to transmit at 49 MHz. The receiver receives the signal. 6.TESTS CONDUCTED CFR 47, 15.107 CODUCTED TESTS CONDUCTED WHEN DEVICE CONNECTED TO AC LINE CFR 47, 15.109 RADIATED EMISSION TESTS CONDUCTED AT 3 METERS 7.CONDUCTED EMISSION TEST PROCEDURE The EUT is located so that the distance between the boundary of the EUT and the closest surface to the LISN is 0.8m. Conducted disturbance shall be measured between the phase lead and the ground, and between the neutral lead and the ground. The frequency 0.450 - 30 MHz shall be investigated. Set the EMI receiver to PEAK detector setting and sweep continuously over the frequency range to be investigated. Set resolution bandwidth to 9kHz minimum. Connect EMI receiver input cable to LINE 1 RF measurement connection on the LISN. Connect a 50ohm terminator to the unused RF connection on the LISN. For each mode of EUT operation, maxi…
