APB97577-01A4RRadio Control Toy Receiver

I II III IV V Please read thoroughly and retain for future reference. º ¹ · ̧¶ FORWARD RIGHT TURN REVERSE LEFT TURN STUNT PAK BARREL BLAST STUNT PAK BARREL BLAST ™ ¶ · ̧ CAUTION: Surfaces may become hot and cause burns if electronics get wet. Do not operate vehicle through water or snow. 97577-0920G1 © 2000 Mattel, Inc., Mt. Laurel, NJ 08054 U.S.A. PRINTED IN CHINA. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. Retain this address for future reference: Mat- tel U.K., Ltd., Vanwall Business Park, Maiden- head SL6 4UB. Mattel Australia Pty., Ltd., Richmond, Victoria 3121 - Consumer Advisory Service: 1800 800 812 (valid only in Australia). Mattel East Asia Limited, 930 Ocean Centre, Harbour City, HK, China. COMPLIANCE WITH FCC REGULATIONS THIS DEVICE COMPLIES WITH PART 15 OF FCC RULES. OPERATION OF THIS DEVICE IS SUBJECT TO THE FOLLOWING TWO CONDI- TIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY HARM- FUL INTERFERENCE THAT MAY CAUSE UNDE- SIRED OPERATION. This device generates and uses radio fre- quency energy and if not used properly may cause interference to radio and television reception. It has been tested and found to comply with the limits set by the FCC, which are designed to provide reasonable protec- tion against such interference. CAUTION:Changes or modifica- tions not expressly approved by the manufac- turer responsible for compliance could void the user’s authority to operate the equipment. 90-DAY LIMITED WARRANTY TYCO ® R/C PRODUCTS Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for ninety (90) days (unless specified in alternate warranties) from the date of purchase. Mattel will repair or replace the product, at our sole option, in the event of such a defect within the warranty period. In the event of a defect covered under this warranty, first call the toll-free number listed below. Many problems can be solved in this manner. If necessary, you will be instructed to return the product, postage prepaid and insured, to the address below. Enclose your name, address, dated sales receipt, and a brief explanation of the defect. Repair or replacement, and return shipment, will be free of charge. Please return only the defective part or unit, packed securely. This warranty does not cover damage resulting from unauthorized modification, accident, misuse or abuse. If the product is returned with- out a dated sales receipt the product may be excluded from coverage under this warranty. Mattel’s liability for defects in material and workmanship under this warranty shall be limited to repair or replacement, at our sole option, and in no event shall we be responsible for incidental, consequential, or contingent damages (except in those states that do not allow this exclusion or limitation). This warranty is exclusive, and is made in lieu of any express or implied warranty. Valid only in U.S.A.This warran- ty gives you specific legal rights and you may have other rights, which vary from state to state. Some states do not allow the exclusion of incidental or consequential damages, so the above exclusions or limitations may not apply to you. TOLL-FREE NUMBER: 1-888-557-TYCO (8926) (valid only in U.S.A.) Hours: 8:00 A.M. - 6:00 P.M. Eastern Time; Monday - Friday. Expect some delay in January following the holiday season. Please be patient and keep trying the toll-free number. ADDRESS FOR RETURNS: CONSUMER RELATIONS, 636 GIRARD AVENUE, EAST AURORA, NY 14052, I. BATTERY INSTALLATION (Transmitter & Vehicle) ¶Push vehicle battery door in direction of arrow and swing open. Install 2 AA alka- line batteries, with polarity (+/-) as shown inside battery compartment. Close battery door. ·Push transmitter battery door open. Install 1 9V battery, with polarity (+/-) as shown inside battery compartment. Close battery door. II. OPERATION ¶FORWARD · REVERSE ̧ LEFT TURN ¹ RIGHT TURN III. COOL DAREDEVIL STUNTS You can assemble your Stunt Pak™ set in lots of different ways – for wild stunts and jumps! ¶ · ̧ Try these cool layouts and stunts – then invent your own! Use the ramps with the hoops – or by themselves! For the coolest stunts and jumps, back up a few feet and then drive forward toward the ramp! Your maximum jump distance depends on vehicle speed, battery power and driving surface. Experi- ment to see how far you can jump! IV. BATTERY INFORMATION Bent or dirty contacts may result in loss of power. If battery does not fit correctly, gen- tly bend back metal contact as shown. BATTERY SAFETY INFORMATION • Insure that battery polarity is correct. • Use only batteries of the type recommend- ed (or equivalent). • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon- zinc), or rechargeable (nickel-cadmium) batteries. • Remove used-up batteries immediately. Remove batteries if vehicle will not be used for a long period. • Do not recharge non-rechargeable batter- ies. • Do not short-circuit terminals. • Remove rechargeable batteries before recharging (if the batteries are designed to be removable). • Recharge batteries only under adult super- vision (if the batteries are designed to be removable). • Dispose of batteries safely. Do not dispose of batteries (or products containing non- replaceable batteries) in fire, as batteries may explode or leak. Battery Performance Note: For best performance use alkaline batteries (where disposable batteries are called for). If your vehicle is supplied with standard (carbon-zinc) batteries for initial use and/or demonstration purposes, we recommend replacing them with alkaline batteries when necessary. Battery life may vary depending on battery brand. V. QUICK TIPS ¶When your vehicle starts to lose power, it may lose functions or performance. It's time for fresh batteries. Your vehicle's running time may change depending on your driving style. ·Radio interference can make your vehicle run badly. Interference ca…

Text truncated - open the document above for the full version.




PROPOSED FCC ID LABEL AND LOCATION MATTEL MT. LAUREL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB97577-01A4R FCC ID LABEL

Stunt Pack Truck 49.860 MHz Mattel Part # 97577 Receiver FCC ID: APB97577-01A4R 09/17/01 STUNT PACK TRUCK # 97577 49.860MHz RECEIVER OPERATIONAL DESCRIPTION The Stunt Pack Truck is a full function radio controlled toy truck . It operates on 3 volts supplied by two 1.5 volt alkaline AA batteries. It is designed to operate on a single fixed frequency in the 49.82- 49.90 MHz band. See the attached block diagram and schematic. The modulated RF signal from the transmitter induces an electrical signal into the truck’s permanently attached internal wire antenna . The electrical signal is selectively amplified by a super regenerative input circuit ( Q1,L3,L4,C2-C6 ). The signal is then capacitively coupled ( via C7 ) to an integrated circuit ( U2 ) were the signal is further amplified and decoded. A pair of digital outputs from the integrated circuit ( U2 ) drives a full H-bridge drive circuit ( Q4,Q5,Q8,Q9 ) for controlling the speed and rotational direction of the drive motor. A second pair of digital outputs from the integrated circuit ( U2 ) drives a second full H-bridge drive circuit ( Q10,Q11,Q13,Q15 ) for controlling the steering motor. All tuning and verifications are performed by the manufacturer and there are no adjustments which can be made by the user. No external ground is required or used with this receiver.

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for UNINTENTIONAL RADIATOR 49MHz RADIO CONTROL TOY TRUCK (RECEIVER) MODEL NO: 97577-49R BRAND NAME: TYCO R/C-STUNT PACK TRUCK FCC ID NO: APB97577-01A4R REPORT NO: 01U0946-3 DATE: SEPTEMBER 5, 2001 Prepared for MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE...........................................................................................................1 2. PRODUCT DESCRIPTION.................................................................................................................................2 3. TEST FACILITY.........................................................................................................................................................2 4. MEASUREMENT EQUIPMENT USED......................................................................................................3 5. TEST CONFIGURATION....................................................................................................................................3 6. TESTS CONDUCTED..............................................................................................................................................3 7. RADIATED EMISSION TEST PROCEDURE.......................................................................................4 8. COHERENT TESTS..................................................................................................................................................4 9. EQUIPMENT MODIFICATIONS...................................................................................................................5 10. TEST CONFIGURATION PHOTOS (RADIATED EMISSION TEST).................................6 • TEST DATA o Cohered Emission Plot o Radiated Emission Data • PROPOSED FCC ID LABEL FORMAT • AUTHORIZATION LETTER • SCHEMATIC DIAGRAM • USER MANUAL • EUT PHOTOGRAPHS REPORT NO: 01U0946-3 FCC ID: APB97577-01A4R DATE: SEPTEMBER 5, 2001 EUT: 49 MHz RADIO CONTROL TOY TRUCK (RECEIVER) PAGE NO: COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL MT. LAUREL 6000 MIDATLANTIC DRIVE MOUNT LAUREL, NJ 08054 USA CONTACT PERSON : FRANK WINKLER, SENIOR PROJECT ENGINEER TELEPHONE NO. : (856) 840-1259 EUT DESCRIPTION : 49MHz RADIO CONTROL TOY TRUCK (RECEIVER) MODEL NAME/NUMBER : 97577-49R BRAND NAME : TYCO R/C-TMH TONY HAWKS SKATEBOARDER SERIAL NUMBER : N/A FCC ID : APB97577-01A4R DATE TESTED : August 30, 2001 REPORT NUMBER : 01U0946-3 TYPE OF EQUIPMENT RADIO CONTROL RECEIVER (UNINTENTIONAL RADIATOR) EQUIPMENT TYPE 49 MHz SUPERREGENERATE RECEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15.109 The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. Warning: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Tested By: Reviewed & Released For CCS By: PETE KREBILL THU CHAN ASSOCIATE EMC ENGINEER SENIOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 01U0946-3 FCC ID: APB97577-01A4R DATE: SEPTEMBER 5, 2001 EUT: 49 MHz RADIO CONTROL TOY TRUCK (RECEIVER) PAGE NO: COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2 2. PRODUCT DESCRIPTION MATTEL MT. LAUREL, Model TYCO R/C-Stunt Pack Truck is the receiving portion of a remote control toy. The associated Transmitter is manufactured by MATTEL MT. LAUREL, Model No 97577-49T: FCC ID APB97577-01A4T. 3. TEST FACILITY The 3 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facilities was submitted to the Commission on May 27, 1994. The measuring instrument, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. REPORT NO: 01U0946-3 FCC ID: APB97577-01A4R DATE: SEPTEMBER 5, 2001 EUT: 49 MHz RADIO CONTROL TOY TRUCK (RECEIVER) PAGE NO: COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 3 4. MEASUREMENT EQUIPMENT USED TEST EQUIPMENTS LIST Name of Equipment Manufacturer M…

Text truncated - open the document above for the full version.

REPORT NO: 01U0946-3 FCC ID: APB97577-01A4R DATE: SEPTEMBER 5, 2001 EUT: 49 MHz RADIO CONTROL TOY TRUCK (RECEIVER) PAGE NO: COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 6 10. TEST CONFIGURATION PHOTOS (Radiated Emission Test)
