APB97993-02A4RRemote Control Toy Receiver

CONTENTS Vehicle Transmitter 9.6V NiCd Battery Pack 9.6V NiCd Charger CHASSIS Refer to label on transmitter and vehicle for frequency. Do not race vehicles with the same frequency. Keep these instructions for future reference: they contain important information. IMPORTANT: Please read all “Consumer Information” (last page) before operating your vehicle. 9.6V R/C 9.6V R/C CAUTION:Surfaces may become hot and cause burns if electronics get wet. Do not operate vehicle through water or snow. NOT RECOMMENDED FOR CHILDREN UNDER 6 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS,PRECAUTIONS SHOULD BE OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK. CAUTION-ELECTRIC TOY: INPUT: 120VAC, 0.10VDC, 60Hz, 0.05A. OUTPUT: 11.5VDC, 1.05VA. 97471-0920 On/Off Switch Gear Selector (high/low) Steering Adjuster (adjust, if necessary, to keep vehicle running straight) BOTTOM VIEW TOP VIEW BatteryDoor Latch IMPORTANT: Please read before operating your vehicle. SAFETY INFORMATION Note to Adults: To ensure that the child’s play is both safe and fun, please review all operating instructions and safety rules with your child. Safety Tips • NEVER drive your vehicle on streets! They’re for real cars! • DO NOT pick up vehicle while in motion. • Keep fingers, hair and loose clothing away from the tires and the wheel hubs while the vehicle is switched ON. • Adult supervision is recommended when this vehicle is being operated. • To avoid accidental operation, remove all batteries when not in use. BATTERY SAFETY INFORMATION Insure that battery polarity is correct. Use only batteries of the type recommended (or equivalent). Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries. Remove used-up batteries immediately. Remove batteries if vehicle will not be used for a long period. Do not recharge non-rechargeable batteries. Do not short-circuit terminals. Remove rechargeable batteries before recharging (if the batteries are designed to be removable). Recharge batteries only under adult supervi- sion (if the batteries are designed to be removable). Dispose of batteries safely. Do not dispose of batteries (or products containing non-replace- able batteries) in fire, as batteries may explode or leak. Battery Performance Note: For best performance use alkaline batteries (where disposable batteries are called for). If your vehicle is supplied with standard (car- bon-zinc) batteries for initial use and/or demonstration purposes, we recommend replacing them with alkaline batteries when necessary. Battery life may vary depending on battery brand. ❶When your vehicle starts to lose power, it may lose functions or perform- ance. It's time for fresh batteries (or a recharge). Your vehicle's running time may change depending on your driv- ing style. ❷Radio interference can make your vehicle run badly. Interference can be caused by other R/C vehicles running on the same frequency; electri- cal wires; large buildings; or CB radios. Try to stay away from these! ❸ Point your transmitter anten- na up - not down toward your vehicle. If your vehicle gets too far away, it won't work properly. If your trans- mitter has a carry-loop fea- ture, make sure the antenna tip is removed from the carry- loop holder and straightened before operating. ❺Don’t store your vehicle near heat or in direct sun- light. Always turn switch- es OFF and remove all batteries for storage. ❹Don’t drive your vehicle in sand or through water or snow. QUICK TIPS SYMPTOM Vehicle runs slowly or will not run. Power indicator light on transmitter does not light. Erratic operation or only short range possible. Vehicle doesn’t work after going through water or snow. • PROBABLE CAUSE • Loose battery connection or vehicle switch not ON. • Weak or uncharged rechargeable NiCd battery • Weak transmitter battery. • Transmitter battery weak or not connected. • Radio interference likely. • Antenna snapped into carry-loop holder (if equipped). • Water in the electronics area. • CORRECTION • Check battery connector and vehicle switch. • Charge battery or replace. • Replace with fresh alkaline battery. • Check connections and replace battery if required. • Change location - see Point 2, “Quick Tips.” • Remove antenna tip from carry-loop holder and straighten. • Vehicle will take several hours to dry. Allow to dry thor- oughly overnight before trying again. • Avoid driving in water or snow. TROUBLESHOOTING - PROBLEM? - SOLUTIONS CONSUMER INFORMATION: ❺❹ ❶ ❷ ❸ POWER SYSTEMS Please follow the specific instructions on the next page for detailed information regarding NiCd vehicle battery charging and safety. VEHICLE BATTERY INSTALLATION 1. Rotate battery latch to open position. 2. Insert battery pack into battery compartment and slide it away from latch. 3. Make sure battery pack snaps securely in place and rotate latch to locked position. 4. To remove battery pack: turn latch, slide battery pack toward latch and lift out. Battery Door Latch 9.6v Battery Battery Door TRANSMITTER BATTERY INSTALLATION Your transmitter has special shifting features. Please refer to the “SPECIAL FEATURES” page for detailed instructions. 1. To install transmitter battery, open battery door as shown. 2. Install one 9V battery with polarity (+/-) as shown inside battery compartment. 3. Swing battery door closed and snap shut. battery compartment battery door power indicator light On/Off Switch antenna makes a cool carry loop! vehicle controls SPECIAL FEATURES Your transmitter can operate in 3 different modes...for ultimate driving action! I. SPEEDSHIFTER™ MODE – 3-speed shifting and cool driving sounds 1. Turn the vehicle switch ON. Turn the transmitter ON. Don’t press either control button. 2. After 3 seconds you’ll hear a shifting sound. You’re now in SpeedShifter™ mode! Just like a real driver, you’ll have to shift up through the “gears“...from first to third! 3. Press and release either control button to "start" your vehicle. 4. Press …

Text truncated - open the document above for the full version.

RESET D0D5D1D2D4 VCC C0C1 VSS C2C3 X1 U1 IC SPC21A1 D3 SUPER REGENERATIVE STEERING MOTOR CONTROL & DRIVE CIRCUIT DRIVING MOTOR CONTROL & DRIVE CIRCUIT VOLTAGE RAGULATOR RIPPLE FILTER OVER CURRENT PROTECTION 9.6V PACK CIRCUIT BATTERY AMPLIFIER M1 M2 ANTENNA BLOCK DIAGRAM 97993 RECEIVER PCB RX97992-6518(U49)

PROPOSED FCC ID LABEL AND LOCATION MATTEL MT. LAUREL This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID: APB97993-02A4R FCC ID LABEL

9.6V STREET BEAST TRUCK 49.860 MHz Mattel Part # 97993 Receiver FCC ID: APB97993-02A4R 03/20/02 9.6V STREET BEAST TRUCK # 97993 49.860MHz RECEIVER OPERATIONAL DESCRIPTION The 9.6V Street Beast Truck is a full function radio controlled toy truck . It operates on 9.6 volts supplied by 9.6V Nicad battery pack. It is designed to operate on a single fixed frequency in the 49.82-49.90 MHz band. See the attached block diagram and schematic. The modulated RF signal from the transmitter induces an electrical signal into the truck’s permanently attached internal wire antenna. The electrical signal is selectively amplified by a super regenerative input circuit ( Q1,L2-L3,C2-C6,R1 ). The signal is then capacitively coupled ( via C7 ) to a dual differential amplifier circuit ( Q2-Q5 ) which amplifies the signal . This signal is then sent to the MCU ( U1) were it is decoded. Steering motor position feedback is sent to the MCU has inputs D0-D2. The MCU outputs digital signals to drive a full H-bridge drive circuit ( Q7,Q9,Q10,Q12 ) for controlling the speed and rotational direction of the steering motor. Three digital outputs from the MCU drives two relays( RL1,RL2 ) and a power MOSFET ( Q16 ) for controlling the speed and direction of the drive motor. A current sense resistor ( R42 ) provides a motor current signal which is amplified and time delayed by a dual comparator circuit ( U2 ). This circuit disables the motor drives if the current is over limit for a set time period. All tuning and verifications are performed by the manufacturer and there are no adjustments which can be made by the user. No external ground is required or used with this receiver.

1 2 3 4 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 6-Apr-2002 Sheet of File: \\..\97993RCD.sch Drawn By: RESET D0D5D1D2D4 VCC C0C1 VSS C2C3 X1 U1 IC SPC21A1 R24 1.8K R33 10K R2851K R27 51K Q13 2SC2712GR/Y TO STEERING WIPER PCB R25 51K Q11 2SC2712GR/Y R23 56 R21 51K R20 1.8K R1427K R11 2.7K R2256 Q12 C2328/C3279/C2500/D882 Q10 A928/A1300/A1160/B772 Q7 A928/A1300/A1160/B772 Q9 C2328/C3279/C2500/D882 Q8 2SC2712GR/Y Vbatt + Q5 2SC2712GR/Y Q42SC2712GR/Y R1527K C13 2200PF C14 2200PF C12 0.1uF R13100K R12 100K Q3 2SC2712GR/Y Q2 2SC2712GR/Y Q1 2SC380Y/O R9 10K R7 2.7K C11 0.1uF R1027K C10 2200PF R815K C9 2200PF C7 0.1uF R4 10K R2 180K C5 0.01uF R3 4.3K C16 0.1uF + C15 220uF L3 Coil 0.5*7.5T L1 1.2uH C6 6PF + C44.7uF L2 3.3uH R1 560 C2 2200PF C3 27PF C12PF R5 47K R6 22K + C8 100uF R43 51K + C30 3.3uF + C313.3uF R46 68 R45560 U2 LM393 1 2 3 4 8 1/2 393 R48 390K D7 IN4148 R474.7K R44 1.5K D8 IN4148 1/2 393 5 6 7 Q18 2SC2712Y/GR R49 1.8K R50 51K R31 200K 1% R30 51K C25 0.1uF C22 0.1uF C17 1000PF C18 0.1uF + C19 220uF D13V3 R17 360 + C21 220uF C20 0.1uF R1822 Q6 2SA1162Y/GR R19 1K Vbatt + 9.6V NiCd BATTERY PACK ON OFF SW1SS-22K18G7-T1-G Vbatt + C* 0.1uF C**0.1uF 02 D3 R2651K D9 IN4148 9.6 V Street Beast 97993RX-USA (49 MHz) BATTERY SOCKET (FEMALE) +BATTERY SOCKET (FEMALE) - C28 0.1uF RL1 NT73-2T-12/SRUDH-SH-109D1 RL2 NT73-2T-12/SRUDH-SH-109D1 D6 IN4148 D5 IN4148 R36 2.7K R3751K Q15 2SC2712GR/Y Q14 2SC2712GR/Y D4 6A05 D3 IN4148 D2 IN4148 M2 FS-360SN-XXXX C29 0.1uF C27 0.1uF DRIVE MOTOR R34 2.7KR35 51K R39 10K R3851K Q17 2SA1162Y/GR Vbatt + R41 1K R40 100 R42 Fix Resistor 0.02 OHM 2W Q16 2SK3404 Q19 2SC2712Y/GR R52 2.7K D10 1N4001 R5151K L4100uH C23 0.1uF C260.1uF STEERING MOTOR M1 FN-130CN-XXXX C33 0.1uF C32 0.1uF

ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT CERTIFICATION TO FCC PART 15 REQUIREMENTS for UNINTENTIONAL RADIATOR 49.860MHz RC RECEIVER MODEL NO: 97993 BRAND NAME: TYCO RC-9.6V STREET BEAST TRUCK FCC ID NO: APB97993-02A4R REPORT NO: 02U1284-2 DATE: MAY 14, 2002 Prepared for MATTEL MT. LAUREL 6000 MIDLANTIC AVENUE MT. LAUREL, NJ 08054 USA Prepared by COMPLIANCE CERTIFICATION SERVICES 561 F MONTEREY ROAD MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE................................................................................................3 2. PRODUCT DESCRIPTION....................................................................................................................4 3. TEST FACILITY.........................................................................................................................................4 4. MEASUREMENT EQUIPMENT USED...........................................................................................5 5. TEST CONFIGURATION.......................................................................................................................5 6. TESTS CONDUCTED...............................................................................................................................5 7. RADIATED EMISSION TEST PROCEDURE..............................................................................6 8. COHERENT TESTS..................................................................................................................................6 9. EQUIPMENT MODIFICATIONS.......................................................................................................7 10. TEST CONFIGURATION PHOTOS (RADIATED EMISSION TEST)..............................8 • TEST DATA o Coherent Emission Plot o Radiated Emission Data • PROPOSED FCC ID LABEL FORMAT • AUTHORIZATION LETTER • SCHEMATIC DIAGRAM • USER MANUAL • EUT PHOTOGRAPHS REPORT NO: 02U1284-1 FCC ID: APB97993-02A4R DATE: MAY 14, 2002 EUT: 49.860MHz RC RECEIVER Page 3 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. VERIFICATION OF COMPLIANCE COMPANY NAME : MATTEL MT. LAUREL 6000 MIDLANTIC AVENUE MT. LAUREL, NJ 08504 USA CONTACT PERSON : FRANK WINKLER, SENIOR PROJECT TELEPHONE NO. : 856-840-1259 EUT DESCRIPTION : 49.860MHz RC RECEIVER MODEL NAME/NUMBER : 97993 BRAND NAME : TYCO RC-9.6V STREET BEAST TRUCK FCC ID : APB97993-02A4R DATE TESTED : APRIL 26, 2002 REPORT NUMBER : 02U1284-2 TYPE OF EQUIPMENT REMOTE CONTROL TOY RECEIVER (UNINTENTIONAL RADIATOR) EQUIPMENT TYPE 49 MHz SUPERREGENERATE RECEIVER MEASUREMENT PROCEDURE ANSI 63.4 / 1992 LIMIT TYPE CERTIFICATION FCC RULE CFR 47, PART 15 SUBPART B The above equipment was tested by Compliance Engineering Services, Inc. for compliance with the requirements set forth in CFR 47, PART 15 SUBPART B. This said equipment in the configuration described in this report shows that maximum emission levels emanating from equipment are within the compliance requirements. Warning: This document reports conditions under which testing was conducted and results of tests performed. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification will constitute fraud and shall nullify the document. Tested By: Approved & Released For CCS By: THU CHAN MIKE HECKROTTE SENIOR EMC ENGINEER CHIEF ENGINNER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 02U1284-1 FCC ID: APB97993-02A4R DATE: MAY 14, 2002 EUT: 49.860MHz RC RECEIVER Page 4 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 2. PRODUCT DESCRIPTION MATTEL MT. LAUREL., Model No# 97993 TYCO RC-9.6V STREET BEAST TRUCK is the receiving portion of a remote control toy. The associated Transmitter is manufactured by MATTEL MT. LAUREL., Model No#97993 , FCC ID APB97993-02A4T. 3. TEST FACILITY The 3 meter open area test site and conducted measurement facility used to collect the radiated data is located at 561F Monterey Road, Morgan Hill, California, U.S.A. A detailed description of the test facilities was submitted to the Commission on May 27, 1994. The measuring instrument, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. REPORT NO: 02U1284-1 FCC ID: APB97993-02A4R DATE: MAY 14, 2002 EUT: 49.860MHz RC RECEIVER Page 5 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 4. MEASUREMENT EQUIPMENT USED 5. TEST CONFIGURATION Set signal generator to transmit at 49 MHz. Adjusted generator level and frequency to get the maximum coherent and emission of the Eut. The receiver receives the signal. All the wires are placed on the turntable to their maximum length to simulate the worse emission condition…

Text truncated - open the document above for the full version.

REPORT NO: 02U1284-1 FCC ID: APB97993-02A4R DATE: MAY 14, 2002 EUT: 49.860MHz RC RECEIVER Page 8 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 10. TEST CONFIGURATION PHOTOS (Radiated Emission Test) REPORT NO: 02U1284-1 FCC ID: APB97993-02A4R DATE: MAY 14, 2002 EUT: 49.860MHz RC RECEIVER Page 9 of 12 COMPLIANCE CERTIFICATION SERVICES CCS DOCUMENT NO: CCSUP4021B 561 F MONTEREY, MORGAN HILL CA 95037 TEL:(408)463-0885 FAX:(408)463-0885 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document.
