Serial-to-Bluetooth Adapter MTS2BTA MTS2BTA-R User Guide Copyright and Technical Support Multi-Tech Systems, Inc. Serial-to-Bluetooth Adapter User Guide (S000370A) 2 User Guide MTS2BTA and MTS2BTA-R MultiConnect Serial-to-Bluetooth Adapter S000370A Rev. A Copyright This publication may not be reproduced, in whole or in part, without prior expressed written permission from Multi- Tech Systems, Inc. All rights reserved. Copyright © 2005 Multi-Tech Systems, Inc. Multi-Tech Systems, Inc. makes no representations or warranty with respect to the contents hereof and specifically disclaims any implied warranty of merchantability or fitness for any particular purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes. Revision Date Description A 02/22/05 Initial release. Patents This device is covered by one or more of the following patents: 6,031,867; 6,012,113; 6,009,082; 5,905,794; 5,864,560; 5,815,567; 5,815,503; 5,812,534; 5,809,068; 5,790,532; 5,764,628; 5,764,627; 5,754,589; 5,724,356; 5,673,268; 5,673,257; 5,644,594; 5,628,030; 5,619,508; 5,617,423; 5,600,649; 5,592,586; 5,577,041; 5,574,725; 5,559,793; 5,546,448; 5,546,395; 5,535,204; 5,500,859; 5,471,470; 5,463,616; 5,453,986; 5,452,289; 5,450,425; D353,598; 5,355,365; 5,309,562; 5,301,274. Other patents pending. Trademarks Multi-Tech, the Multi-Tech logo, and MultiConnect are registered trademarks of Multi-Tech Systems, Inc. All other brand and product names mentioned in this publication are trademarks or registered trademarks of their respective companies. Technical Support Country By Email By Phone France: [email protected] (33) 1-64 61 09 81 India: [email protected] 91 (124) 6340778 U.K.: [email protected] (44) 118 959 7774 U.S. and Canada: [email protected] (800) 972-2439 Rest of the World: [email protected] (763) 717-5863 Internet Address: http://www.multitech.com World Headquarters Multi-Tech Systems, Inc. 2205 Woodale Drive Mounds View, Minnesota 55112 U.S.A. (763) 785-3500 or (800) 328-9717 Fax (763) 785-9874 http://www.multitech.com Table of Contents Multi-Tech Systems, Inc. Serial-to-Bluetooth Adapter User Guide (S000370A) 3 Contents Chapter 1 – Description and Specifications ..............................................................................................................4 Product Description ....................................................................................................................................................4 Applications ................................................................................................................................................................4 Features .....................................................................................................................................................................4 Product Build Options .................................................................................................................................................5 MultiConnect Package Contents ................................................................................................................................5 AT Commands............................................................................................................................................................5 Handling Precautions .................................................................................................................................................5 General Safety............................................................................................................................................................6 Installation Instructions for Hazardous Locations ..................................................Error! Bookmark not defined. Vehicle Safety........................................................................................................................................................6 Maintenance of the Serial-to-Bluetooth Adapter ....................................................................................................6 Technical Specifications .............................................................................................................................................7 LED Indicators ............................................................................................................................................................8 Chapter 2 – Installation and Cabling ..........................................................................................................................9 Step 1 – Attaching the Adapter to a Fixed Location....................................................................................................9 Step 2 – Connect the Adapter to Your System .........................................................................................................10 Setup Example ....................................................................................................................................................10 Connections for MultiModem Using AC Power....................................................................................................10 Connections for MultiModem Using DC Power....................................................................................................10 Chapter 3 – AT Commands, S-Registers and Result Codes ..................................................................................11 Chapter 4 – Peripheral Devices.................................................................................................................................12 Antenna Requirements .............................................................................................…

Text truncated - open the document above for the full version.

Block Diagram 02 / June /200 4 MITSUMI ELECTRIC CO.,LTD MODEL NAME : Bluetooth ModuleMODEL No. : WML-C 30 ## Hardware:Version 1 RF Receiver RF Transmitter 2nd S y nthesizer Baseband ControllerMemor y Mana g ement RAM XT Driver VDD BC2- External 1st S y nthesizer 16bits Micro- Processor PIO SPI CSBSPI CLKSPI _ MOSI SPI MISO SPI PCM/IF MEMORY DRIVER UART TX UART UART _ RX UART _ RTS UART CTSPCM OUTPCM _ IN PCM _ SYNC PCM CLK External- Flash ROM 512 k x 16 bits PIO [ 2...7 ] BL A NT BPF 16MHz cr y stal REG RF SW PA USB D+ USB USB D-

55 44 33 22 11 D D C C B B A A 0 062104 PROTOTYPE 19658 7300170073001750 BTMODULE Serial InterfaceConnection 234S 0 MTS2BTSMI 12 Monday, June 21, 2004 P.CORCORAN <Core Design> Title Size Document Number Rev Date: Sheet of -NOTICE- This drawing may contain proprietary and confi dential information of Multi-Tech Systems Inc. It is loaned for limited purposes onlyand remains the property of Multi-Tech Systems Inc. It may not be reproduced in whole or in part wit hout written consent. The drawing is to be returned upon r equest. Build Level DrawnCheckedApproved B FIDUCIAL REV ECO# DATE DESCRIPTION FIDUCIALGERBER_TITLE_BLOCK TH1128NP PCB113576400Rev = 0 A 20042 113004 PCB REVISON ,A

Date: 06/03/05 Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom Subject: Certification Application FCC ID: AU792U05A28780 It is requested that the following information is to be held confidential on behalf of MultiTech Systems, Inc.. Schematics PCB Layout Parts list The above items must be kept confidential due to trade secrets and competitive purposes. Yours sincerely

Embedded Serial-to-Bluetooth ® Module Complete, Ready-to- integrate Embedded Serial-to-Bluetooth ® Module Benefits Eliminates serial cables Bluetooth V1.2 compliant Transparent to application software AT command software interface SocketWireless Bluetooth is a wireless serial adapter that utilizes Bluetooth technology to provide a secure, standards-based wireless connection between a host and peripheral device. Providing wireless data transfer up to 100 meters, it completely eliminates the need for serial cable connections. This ready-to-integrate, embedded, wireless module is designed around Multi-Tech’s space-efficient, universal socket architecture. Features •Class 1 Bluetooth V1.2 compliant module with a maximum range of 100 meters (330 feet) •Creates wireless serial link transparent to application software •Secure and robust communication link •Operating system independent •Serial interface supporting speeds from 1200 bps to 921.6K bps •AT command software interface •Hardware flow control •Space efficient, universal socket connectivity •LED driver outputs •Auto connect •Two-year warranty Highlights Applications. SocketWireless Bluetooth is targeted at applications that need a serial connection without running cable. It is an ideal solution for: • Retail Environment - POS devices - Bar code scanners - Credit card reader • Restaurant Environment - Order printer - Receipt printer - Credit card reader • Outdoor signs • Gas pumps • Security systems/Surveillance cameras • Emergency vehicles • Delivery trucks • Home healthcare • Connecting to other Bluetooth-enabled devices • Modem • Mobile phone • Headset • Computer • PDA Instant Serial Cable Replacement. Running serial cabling can be expensive and sometimes problematic especially if it is in an outdoor environment. With the SocketWireless Bluetooth, you can eliminate the cable and connect your peripheral devices effortlessly with a Bluetooth wireless network. In a point-to-point connection, one SocketWireless is embedded in a host device, such as a PC; the other is attached to a serial peripheral device such as a bar-code scanner, receipt printer or scale. Now you can use the wireless network to transfer information between the host and the device for up to 100 meters. Wireless Host Connection. SocketWireless Bluetooth can also connect to any other Bluetooth-enabled device, such as a PDA or WAN radio increasing user mobility in mission-critical applications such as emergency vehicles, delivery trucks, medical monitoring, and point-of-sale environments. SocketWireless Bluetooth is operating system independent and can be seamlessly embedded in any peripheral device. No application software is needed. Secure, Robust Communication. SocketWireless Bluetooth complies with the Bluetooth specifications for security and includes 56-bit encryption and 10 alphanumeric Personal Identification Number (PIN) authentication. It utilizes FHSS (Frequency Hopping Spread Spectrum) technology. In addition, SocketWireless Bluetooth uses error correction schemes for guaranteed packet delivery. Universal Socket Connectivity. The Universal Socket flexible comm-port architecture provides dial-up, wireless, ISDN or Ethernet socket connectivity with interchangeable modules. This means you can utilize one system design and populate it with your communication module of choice. In addition, you are assured seamless migration to future technologies. Mechanical Specifications SocketWireless Bluetooth Pin-out. SocketWireless Bluetooth interfaces easily with existing devices through a standard serial interface. The serial DTE channel is capable of transfer speeds up to 921.6 Kbps and can be interfaced directly to a UART or microcontroller. Developers Kit. The SocketWireless Bluetooth Developer’s Kit allows you to plug in the SocketWireless Bluetooth and use it for testing, programming and evaluation. The kit includes one development board with RS-232 DB-25 connector, universal power supply, antenna and RS-232 cable. Comprehensive Service and Support. The Multi-Tech commitment to service means we provide a two-year product warranty and service that includes free technical support, 24-hour web site, and ftp support. SocketWireless ™ Bluetooth ®










               !  " # ! # "       "# $%&  !"!!  !"  !"!  !" #$ $%& %& '' ()&*& ()&'+( ()&(,%- ()&.' ()&/& #$ #$ $%& "&# "&'& "' "&# "#,01 " & "# & "# Copyright © 2004 by Multi-Tech Systems, Inc. All rights reserved.11/04 86002058 World Headquarters Tel:(763) 785-3500 (800) 328-9717 www.multitech.com EMEA Headquarters Multi-Tech Systems (EMEA) United Kingdom Tel: +(44) 118-959 7774 Multi-Tech Systems (EMEA) France Tel: +(33) 1 64 61 09 81 Specifications Power Requirements 5VDC or 3.3VDC Power Usage (Typical) Idle: 2mA (0.0066W @ 3.3VDC) (0.01W @ 5VDC) Connected: 7mA (0.0231W @ 3.3VDC) (0.035W @ 5VDC) Fast Data: 45mA (0.1485W @ 3.3VDC) (0.225W @ 5VDC) Inquiry: 70mA (0.231W @ 3.3VDC) (0.35W @ 5VDC) Physical Description 1.045" w x 2.541" h x 0.680" d; 0.6oz (2.65 cm x 6.45 cm x 1.7 cm; 0.017 kg.) Operating Environment Temperature Range: -40 to +70°C Approvals EMC: FCC Part 15 Class B, Canada Class B, EN55022 Class B, EN55024 Safety: UL 60950; EN 60950, CSA 950 Wireless: FCC Part 22, FCC Part 24, Canada Ordering Information ProductDescriptionRegion MTS2BTSMISerial-to-Bluetooth Module, C1 V1.2-5VGlobal MTS2BTSMI-LSerial-to-Bluetooth Module, C1 V1.2-3.3VGlobal Made in Mounds View, MN, U.S.A. Trademarks: SocketWireless, Multi-Tech, and the Multi-Tech logo: Multi-Tech Systems, Inc. / All other products or technologies are the trademarks or registered trademarks of their respective holders. Who’s Multi-Tech? Multi-Tech is an ISO 9001:2000 certified global manufactu…

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Multi-Tech Systems Inc. MTS2BTSMI Transceiver To: FCC Part 15.247: 2004 (Subpart C) Test Report Serial No: RFI\MPTE1\RP46786JD07A This Test Report Is Issued Under The Authority Of Andrew Brown, Operations Manager: pp Tested By: Steven Wong Checked By: Nigel Davison Report Copy No: PDF01 Issue Date: 14 June 2005 Test Dates: 09 February 2005 to 19 May 2005 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be reproduced in full. Partial reproduction may only be made with the written consent of RFI Global Services Ltd. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46786JD07A Page 2 of 60 Issue Date: 14 June 2005 Test of: Multi-Tech Systems Inc. MTS2BTSMI Transceiver To: FCC Part 15.247: 2004 (Subpart C) This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46786JD07A Page 3 of 60 Issue Date: 14 June 2005 Test of: Multi-Tech Systems Inc. MTS2BTSMI Transceiver To: FCC Part 15.247: 2004 (Subpart C) Table of Contents 1. Client Information .............................................................................................................4 2. Equipment Under Test (EUT) ...........................................................................................5 3. Test Results.......................................................................................................................8 4. Deviations from the Test Specification...........................................................................9 5. Operation of the EUT during Testing ............................................................................10 6. Summary of Test Results ...............................................................................................11 7. Measurements, Examinations and Derived Results ....................................................12 8. Measurement Uncertainty ..............................................................................................45 9. Measurement Methods ...................................................................................................46 Appendix 1. Test Equipment Used ....................................................................................56 Appendix 2. Test Configuration Drawings........................................................................58 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46786JD07A Page 4 of 60 Issue Date: 14 June 2005 Test of: Multi-Tech Systems Inc. MTS2BTSMI Transceiver To: FCC Part 15.247: 2004 (Subpart C) 1. Client Information Company Name: Multi-Tech Systems Inc Address: 2205 Woodale Drive Mounds View MN USA 55112 Contact Name: Mr M Sundeen RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46786JD07A Page 5 of 60 Issue Date: 14 June 2005 Test of: Multi-Tech Systems Inc. MTS2BTSMI Transceiver To: FCC Part 15.247: 2004 (Subpart C) 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Brand Name: Multi-Tech Model Name or Number: MTS2BTSMI Unique Type Identification: MTS2BTSI Serial Number: 0X00a0960cd88b FCC ID Number: AU792U05A28780 Country of Manufacture: USA Date of Receipt: 09 February 2005 Brand Name: Multi-Tech Model Name or Number: MTS2BTA Unique Type Identification: MTS2BTA Serial Number: Rev A 73001900 FCC ID Number: AU792U05A28780 Country of Manufacture: USA Date of Receipt: 09 February 2005 2.2. Description of EUT The equipment under test is a Bluetooth "®"module incorporated onto a test circuit board. Since the Bluetooth module cannot be removed from the host test circuit board, limited modular approval testing was performed. 2.3. Modifications Incorporated in EUT During the course of testing the EUT was not modified. "The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by RFI Global Services Ltd. is under license. Other trademarks and trade names are those of their respective owners." RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46786JD07A Page 6 of 60 Issue Date: 14 June 2005 Test of: Multi-Tech Systems Inc. MTS2BTSMI Transceiver To: FCC Part 15.247: 2004 (Subpart C) 2.4. Additional Information Related to Testing Power Supply Requirement: 9 V DC sourced from a nominal 115 V 60Hz AC Mains adaptor. Intended Operating Environment: Residential, Commercial and Light Industry Equipment Category: Short Range (Low Power) Type of Unit: Modular device (attached to test board) Transmit Frequency Range: 2402 MHz to 2480 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 1 2402 Middle 40 2441 Transmit Channels Tested: Top 79 2480 Receive Frequency Range: 2402 MHz to 2480 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 1 2402 Middle 40 2441 Receive Channels Tested: Top 79 2480 Maximum Power Output (EIRP) 18.7 dBm 2.5. Port Identification Port Description Type/Length Applicable 1 Enclosure - Y 2 RS232 Interface Port - Y 3 Antennal/RF Port SMA cable / 12cm Y 4 Power Supply Interface 2 wire core / 10cm Y RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46786JD07A Page 7 of 60 Issue Date: 14 June 2005 Test of: Multi-Tech Systems Inc. MTS2BTSMI Transceiver To: FCC Part 15.247: 2004 (Subpart C) 2.6. Support Equipment The following support equipment was used to exercise the EUT during testing: Description: AC Adaptor Brand Name: GlobTek Model Name or Number: GT-21089-0909-T3 Serial Number: None Stated Cable Length and Type: 2 Core Wire Connected to Port: DC Supply Interface Description: Lap…
