AU792U12616852MultiConnect Embedded PCIe Cellular Modem

MultiConnect TM PCIe MTPCIE-H5/MTPCIE-BWDeveloperGuide MULTICONNECTPCIEDEVELOPERGUIDE MultiConnectPCIeDeveloperGuide Models:MTPCIE-H5-xx,MTPCIE-BW Part Number:S000538,Version1.2 USA and CanadaEdition Copyright This publicationmay not be reproduced,in wholeor in part,withoutthe specificand expresspriorwrittenpermissionsignedby an executiveofficerof Multi-TechSystems,Inc. All rightsreserved.Copyright© 2013by Multi-TechSystems,Inc. Multi-TechSystems,Inc. makesno representationsor warranties,whetherexpress,impliedor by estoppels,withrespectto the content,information, materialand recommendationshereinand specificallydisclaimsany impliedwarrantiesof merchantability,fitnessfor any particularpurposeand non- infringement. Multi-TechSystems,Inc. reservesthe rightto revisethis publicationand to makechangesfromtimeto timein the contenthereofwithoutobligationof Multi-TechSystems,Inc. to notifyany personor organizationof suchrevisionsor changes. Trademarks Multi-Tech,SocketModem,and the Multi-Techlogo are registeredtrademarksof Multi-TechSystems,Inc. MultiConnectis a trademarkof Multi-Tech System.All otherbrandand productnamesare trademarksor registeredtrademarksof theirrespectivecompanies. LegalNotices The Multi-Techproductsare not designed,manufacturedor intendedfor use, and shouldnot be used,or sold or re-soldfor use, in connectionwith applicationsrequiringfail-safeperformanceor in applicationswherethe failureof the productswouldreasonablybe expectedto resultin personalinjuryor death,significantpropertydamage,or seriousphysicalor environmentaldamage.Examplesof suchuse includelife supportmachinesor otherlife preservingmedicaldevicesor systems,air trafficcontrolor aircraftnavigationor communicationssystems,controlequipmentfor nuclearfacilities,or missile,nuclear,biologicalor chemicalweaponsor othermilitaryapplications(“RestrictedApplications”). Use of the productsin suchRestricted Applicationsis at the user’s sole risk and liability. MULTI-TECHDOESNOTWARRANTTHATTHE TRANSMISSIONOF DATABY A PRODUCTOVERA CELLULARCOMMUNICATIONSNETWORKWILLBE UNINTERRUPTED,TIMELY,SECUREOR ERRORFREE,NORDOESMULTI-TECHWARRANTANY CONNECTIONOR ACCESSIBILITYTO ANY CELLULAR COMMUNICATIONSNETWORK.MULTI-TECHWILLHAVENO LIABILITYFOR ANY LOSSES,DAMAGES,OBLIGATIONS,PENALTIES,DEFICIENCIES,LIABILITIES, COSTSOR EXPENSES(INCLUDINGWITHOUTLIMITATIONREASONABLEATTORNEYSFEES)RELATEDTO TEMPORARYINABILITYTO ACCESSA CELLULAR COMMUNICATIONSNETWORKUSINGTHE PRODUCTS. The Multi-Techproductsand the final applicationof the Multi-Techproductsshouldbe thoroughlytestedto ensurethe functionalityof the Multi-Tech productsas usedin the final application.The designer,manufacturerand resellerhas the sole responsibilityof ensuringthat any end user productinto whichthe Multi-Techproductis integratedoperatesas intendedand meetsits requirementsor the requirementsof its director indirectcustomers.Multi- Techhas no responsibilitywhatsoeverfor the integration,configuration,testing,validation,verification,installation,upgrade,supportor maintenanceof suchend user product,or for any liabilities,damages,costsor expensesassociatedtherewith,exceptto the extentagreeduponin a signedwritten document.To the extentMulti-Techprovidesany commentsor suggestedchangesrelatedto the applicationof its products,suchcommentsor suggested changesis performedonly as a courtesyand withoutany representationor warrantywhatsoever. ContactingMulti-Tech KnowledgeBase The KnowledgeBaseprovidesimmediateaccessto supportinformationand resolutionsfor all Multi-Techproducts.Visithttp://www.multitech.com/kb.go. SupportPortal To createan accountand submita supportcasedirectlyto our technicalsupportteam,visit:https://support.multitech.com. Support BusinessHours:M-F,9amto 5pmCT CountryBy EmailBy Phone Europe,MiddleEast,Africa:[email protected]+(44)118 959 7774 U.S.,Canada,all others:[email protected](800)972-2439or (763)717-5863 Warranty To readthe warrantystatementfor yourproduct,visit www.multitech.com/warranty.go. For otherwarrantyoptions,visit www.multitech.com/es.go. WorldHeadquarters Multi-TechSystems,Inc. 2205WoodaleDrive,MoundsView,MN 55112 Phone:(800)328-9717or (763)785-3500 Fax (763)785-9874 2MultiConnect TM PCIeMTPCIE-H5/MTPCIE-BWDeveloperGuide CONTENTS Contents ProductOverview....................................................................................................................................................6 AboutMultiConnectPCIe..............................................................................................................................................6 Documentation...........................................................................................................................................................6 ProductBuildOptions...................................................................................................................................................6 DeveloperKit Contents................................................................................................................................................6 AttachingPowerSupplyBlades....................................................................................................................................7 PowerSupplyand Blades............................................................................................................................................7 Attachingthe Blades...................................................................................................................................................7 Pinout......................................................................................................................................................................8 Multi-TechMiniPCIePinout.........................................................................................................................................8 StandardMini-PCIExpressPinout..................................................................…

Text truncated - open the document above for the full version.

To Whom It May Concern: Subject: Validity of Test Results from Testing / Certification of the integrated Module WE, MULTI-TECH SYSTEMS INC., 2205 Woodale Dr., Mounds View Minnesota 55112 United States, confirm that the results from conducted tests applied to the radio modules a.) cellular radio module Telit H910, FCC ID: RI7HE910, IC ID: 5131A-HE910; b.) WLAN/BT module Murata LBEE5ZSTNC-523, FCC ID: VPYLBTN, IC: 772C-LBTN; which are incorporated in our host equipment PCIe card models - ‘MTPCIE-H5-V-BW’ with FCC ID: AU792U12616836 and IC: 125A-0048, - ‘MTPCIE-H5’ and ‘MTPCIE-H5-V’ both with FCC ID: AU792U12616852 and IC: 125A-0047, and as reported in the respective module test test reports a.) #1112FR12-02 and #1201FR11-02, Feb. 3, 2012, of A Test Lab Techno Corp., Taiwan; b.) #31KE0354-HO-01-A(WLAN) and #31KE0354-HO-01-B-R1(Bluetooth), July 26, 2011, of UL Japan Inc.; accurately represent the test results under the new conditions when the identified radio module is integrated in the identified host equipment. By integration of the said radio modules into the identified host equipment no changes were made to it or by external adaptation circuitry that impacts the validity of the conducted results of the original module’s test reports. For MULTI-TECH SYSTEMS, INC. Jody Lanes, Engineering Manager - Certifications Date: January 17 th , 2014

Receiver Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Subject: Request for Permanent Confidentiality FCC ID: AU792U12616852 To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, Multi-Tech Systems, Inc. requests permanent confidentiality for the following items 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational Description These items contain detailed system and equipment description and related information about the product which Multi-Tech Systems, Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Multi-Tech Systems, Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Best Regards, February 6 th , 2014 Mounds View, MN 55112 On Behalf of Multi-Tech Systems, Inc., Jody Lanes 763-717-5500 [email protected]

Receiver Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Subject: Request for Short Term Confidentiality FCC ID: AU792U12616852 To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, Multi-Tech Systems, Inc. requests Short term confidentiality for the following items 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational Description Until the product will be publicly announced. Short term confidentially release date: 180 days form the Grant date: These items contain detailed system and equipment description and related information about the product which Multi-Tech Systems, Inc. considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Multi-Tech Systems, Inc. also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. Best Regards, February 6 th , 2014 Mounds View, MN 55112 On Behalf of Multi-Tech Systems, Inc., Jody Lanes 763-717-5500 [email protected]

FCC Modular Approval Statement 1 Receiver FCC Subject: Modular Approval Statement Date: 9-26-13 FCC ID: AU792U12616852 Model Name/Number: MTPCIE-H5-V, MTPCIE-H5 TO WHOM IT MAY CONCERN Pursuant to FCC part 15.212, we herewith declare for our module as identified above Modular approval requirement Yes No * (a) The radio elements must have the radio frequency circuitry must be shielded. Physical/discrete and tuning capacitors may be located external to the shield, but must be on the module assembly. x *Please provide a detailed explanation if the answer is “No.”: (b) The module shall have buffered modulation/data input(s) (if such inputs are provided) to ensure that the module will comply with the requirements set out in the applicable RSS standard under conditions of excessive data rates or over-modulation. x *Please provide a detailed explanation if the answer is “No.”: (c) The module shall have its own power supply regulation on the module. This is to ensure that the module will comply with the requirements set out in the applicable standard regardless of the design of the power supplying circuitry in the host device which houses the module. x *Please provide a detailed explanation if the answer is “No.”: (d) The module shall comply with the provisions for external power amplifiers and antennas detailed in this standard. The equipment certification submission shall contain a detailed description of the configuration of all antennas that will be used with the module. x *Please provide a detailed explanation if the answer is “No.”: The module is equipped with a standard ufl connector. However, only antennas which are specified in our development guide which is provided with the modules may be installed by professional OEM installers only. Our modules are for OEM installation only. (e) The module shall be tested for compliance with the applicable standard in a stand-alone configuration, i.e. the module must not be inside another device during testing. x *Please provide a detailed explanation if the answer is “No.”: The module was tested while mounted on a development board but does otherwise fulfil the modular approval requirements listed under items a.) to c.) above (f) The module must comply with all specific rules applicable to the transmitter including all the conditions provided in the integration instructions by the grantee; x FCC Modular Approval Statement 2 *Please provide a detailed explanation if the answer is “No.”: (g) The module shall comply with applicable FCC RF exposure requirements, which are based on the intended use/configurations. x *Please provide a detailed explanation if the answer is “No.”: For MULTI-TECH SYSTEMS INC. Jody Lanes, Engineering Manager - Certifications Date: 1-20-14 Signature:

MTPCIE-H5-V Label location and design Figure (1) MTPCIE-H5-V Label location Figure (2) MTPCIE-H5-V label

MTPCIE-H5 Label Position and Design

TECHNICAL MANUAL Telit HE910 HW rev.0 Data Terminal Module Code: 1vv0300990 Rev. 0 Date: 2012/02/02 ANNEX 2 HE910 MODULE PHOTOS Pag.6 of 27 TECHNICAL MANUAL Telit HE910 HW rev.0 Data Terminal Module Code: 1vv0300990 Rev. 0 Date: 2012/02/02 Image #1 (Top Side) Image #2 (Bottom Side) Pag.7 of 27 TECHNICAL MANUAL Telit HE910 HW rev.0 Data Terminal Module Code: 1vv0300990 Rev. 0 Date: 2012/02/02 Image #3 (Inside Top) Pag.8 of 27

Radio Frequency Exposure Evaluation Report For Multitech Systems, Inc. MultiConnect Embedded PCIe Cellular Modem FCC ID: AU792U12616836 IC: 125A-0048, model number: MTPCIE-H5-V-BW; FCC ID: AU792U12616852 IC: 125A-0047, model numbers: MTPCIE-H5-V, MTPCIE-H5 Applied Rules and Standards CFR Part Part 1 (1.1307 &1.1310), Part 2 (2.1091), FCC OET Bulletin 65 (1997-01) Supplement C (2001-01), FCC KDB 447498 D01 General 24 RF Exposure Guidance v05r01 Industry Canada RSS-102, Issue 4 of March 2010 Report number: EMC_MULTI_055_13001_MTPCIE-H5_MPE_Rev1 DATE: 2014-01-27 Test Report #: EMC_MULTI_055_13001_MTPCIE-H5_MPE_Rev2 FCC ID: AU792U12616836; AU792U12616852 Date of Report: 2014-01-27 IC ID: 125A-0048; 125A-0047 Page 2 of 9 1 Administrative Data 1.1 Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Address: 411 Dixon Landing Road Milpitas, CA 95035 U.S.A. Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 RF Exposure Lab Manager: Josie Sabado 1.2 Identification of the Client / Manufacturer Applicant’s Name: Multi-Tech Systems, Inc. Street Address: 2205 Woodale Drive City/Zip Code Mounds View, MN 55112 Country USA Contact Person: Jody Lanes Phone No. 763 717 5500 Fax: 763-785-9874 e-mail: [email protected] Test Report #: EMC_MULTI_055_13001_MTPCIE-H5_MPE_Rev2 FCC ID: AU792U12616836; AU792U12616852 Date of Report: 2014-01-27 IC ID: 125A-0048; 125A-0047 Page 3 of 9 2 Equipment under Assessment Marketing Name / Description: MultiConnect Embedded PCIe Cellular Modem Model Number: MTPCIE-H5-V-BW MTPCIE-H5-V, MTPCIE-H5 FCC-ID: AU792U12616836 AU792U12616852 IC ID: IC: 125A-0048 IC: 125A-0047 Product Description: PCIe card module (limited modular) incorporating a pre-certified 3G cellular module and (in model MTPCIE-H5-V-BW only) a 2.4GHz WLAN / Bluetooth combo radio module (see details below) Transmitter information: 1. Telit 3G module HE910; FCC ID: RI7HE910; IC ID: 5131A-HE910  850/900/1800/1900Mhz GSM/GPRS/EDGE; modulation: GSM&GPRS&EDGE(MCS-1-4): GMSK; EDGE(MCS-5-8): 8PSK;  850/900/1700/1900/2100 Mhz WCDMA / HSPA+; HSDPA Category 14 data rate - 21 Mbps; HSUPA Category 6 data rate - 5.76 Mbps; modulation: all QPSK (no QAM in uplink for given data rates); 2. Murata LBEE5ZSTNC, 802.11bgn 2.4 GHz / Bluetooth 4.0 combo module, FCC-ID: VPYLBTN, IC: 772C-LBTN; (contained in model MTPCIE-H5-V-BW only) 3. GPS1575.42 MHz (used in model MTPCIE-H5-V-BW only); Antenna info (antenna as presented for testing with the development board): cellular: external screw mount dipole antenna with SMA connector (Laird Hepta-SM MAF94300); 3dBi peak gain; WLAN/BT: external screw mount dipole antenna with RP-SMA(M) connector (Taoglas GW.11.A153); 2.3dBi peak gain; The antenna is connected to the related UFL connector on board of the PCIe card by an additional cable (loss ca. 0.4dB @ 800MHz, 0.6dB @ 1900MHz, 0.7dB @ 2100MHz). Co-located Transmitters/ Antennas?  Yes (model MTPCIE-H5-V-BW only)  No Device Category:  Fixed Installation  Mobile (mark mobile if both possible)  Portable Exposure Category:  Occupational/ Controlled  General Population/ Uncontrolled Rated Operating Voltage Range: Vmin: 2.7V / Vnom: 3.3V / Vmax: 4.2V, over PCIe card interface; Rated Operating Temperature Range: –35°C ~ +85°C Test Sample Status: Production Test Report #: EMC_MULTI_055_13001_MTPCIE-H5_MPE_Rev2 FCC ID: AU792U12616836; AU792U12616852 Date of Report: 2014-01-27 IC ID: 125A-0048; 125A-0047 Page 4 of 9 3 Assessment This RF Exposure evaluation report provides information about compliance of the below identified device with the RF Exposure limits for mobile or fixed devices as defined in FCC CFR Part 1 (1.1307 &1.1310), Part 2 (2.1091) and IC standard RSS-102 under given conditions (measured or rated RF output power, antenna gain, distance towards human body, multiple transmitter information as presented by the applicant). In addition, maximum antenna gain or minimum distance towards the human body is calculated, respectively, where relevant. The device meets the limits as stipulated by the above given FCC and IC rule parts based on available specifications. Company Description Model # Multitech Systems, Inc. MultiConnect® Embedded PCIe Cellular Modem MTPCIE-H5-V-BW; MTPCIE-H5-V; MTPCIE-H5 Report reviewed by: 2014-01-27 Compliance Franz Engert (Test Lab Manager) Date Section Name Signature Responsible for the Report: 2014-01-27 Compliance Ashley Armenta (EMC Engineer) Date Section Name Signature Test Report #: EMC_MULTI_055_13001_MTPCIE-H5_MPE_Rev2 FCC ID: AU792U12616836; AU792U12616852 Date of Report: 2014-01-27 IC ID: 125A-0048; 125A-0047 Page 5 of 9 4 RF Exposure Limits and FCC and IC Basic Rules For the specific described radio apparatus the following basic limits and rules apply for both, FCC and IC where not indicated differently. 4.1 Maximum Permissible Exposure (MPE) Limits acc. to FCC 1.1310(e) / RSS-102, cl. 4.2: Frequency Range (MHz) Power density (mW/cm 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /1500 30 (IC:6) 1500 – 100.000 (IC:1500 – 150000) 1.0 30 (IC:6) 4.2 Routine Environmental Evaluation Categorical Exclusion Limits acc. to FCC 2.109(c) / RSS-102, cl. 2.5 (rounded to 1 decimal point): Operating frequency < 1.5GHz: excluded if ERP < 1.5W / 31.8dBm (IC: 2.5W / 34.0dBm EIRP); Operating frequency > 1.5GHz: excluded if ERP < 3.0W / 34.8dBm (IC: 5.0W / 37.0dBm EIRP); 4.3 EMC Output Power Limits (ERP/EIRP) acc. to FCC part 22/24/27 / IC RSS-132, RSS- 133, RSS-139 (to be additionally taken into account for maximum antenna gain considerations) part 22: 7W ERP / 38.5dBm (IC: 11.5W / 40.6dBm EIRP) part 24: 2W EIRP / 33.0dBm part 27: 1W EIRP / 30.0dBm Per KDB 447498 D01 FCC allows calculative estimation of RF exposure for mobile applications when routine environmental evaluation categorical exclusion applies and also for fixed applications. When categorical exclusion can not be claimed for mobile applications MPE measurement is required for TCB approval. RSS…
