AUJPXDZPD508DPMR RADIO

 406.1 MHz-470MHz RF Exposure Compliance and Control Guidelines and Operating Instructions To control your exposure and ensure compliance with the occupational/controlled environment adhere to the following procedures. Guidelines: • Do not remove the RF Exposure Label from the device. • User awareness instructions should accompany device when transferred to other users. • Do not use this device if the operational requirements described herein are not met. Operating Instructions: • Transmit no more than the rated duty factor of 50% of the time. To transmit push the Push-To-Talk (PTT) button. To receive calls, release the PTT Transmitting 50% of the time, or less, is important because this radio measurable RF ener gy exposure only when transmitting (in terms of standards compliance). • Hold the radio in a vertical position in front of face with the microphone (and the other a including the antenna) at least one inch (2.5 cm) away from the nose. radio at the proper distance is important because RF di stance from the antenna. Antenna should be kept away from eyes. • When worn on the body, always place the radio in a approved clip, holder, holster, case, or body harness for this product. approved body-worn accessories is important because the use of or other manufacturer’ s may result in exposure levels, which exceed the FCC’s occupational/controlled environment RF exposure limits. • If you are not using a body-worn accessory and are not using the radio in the front of the face, then ensure the antenna and the radio are kept at least 2.5 cm (one inch) om the body when transmitting. Keeping the radio at the proper distanc because RF exposures decrease with increasing distance from the antenna. • Use only replacement antennas, batteries, and accessories. Use of non- approved antennas, the FCC RF exposure guidelines. This equipment complies with FCC radiation exposure limits set forth for a controlled environment . exposure limits always (talk), button. generates measuring for parts of the radio, Keeping the exposures decrease with Xiamen Puxing Electronics Science& Technology Co., Ltd Using Puxing Electronics Science& accessories Technology Co., Ltdnon-approved Xiamen position in fr e is important Xiamen Puxing Electronics Science&Technology Co., Ltd approved supplied or Science&Technology Co., Ltd Xiamen Puxing Electronics batteries, and accessories may exceed

Xiamen Puxing Electronics Science & Technology Co., Ltd. FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Tel: +86-592-7769969 Fax: +86-592-7769958 DATE 05-19-2015 FCC ID: AUJPXDZPD508 Subject: Part 90.203 (j) (5) Certification Statement We declare that Digital Portable device FCC ID: AUJPXDZPD508, meets the spectrum efficiency standard of one voice channel per 6.25 kHz of channel bandwidth. Additionally, we declare this equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. Dated this 05-19-2015 By: Kevin Xie Signature Printed Title: Manager On behalf of : Xiamen Puxing Electronics Science & Technology Co., Ltd. Telephone: +86-592-7769969

Xiamen Puxing Electronics Science & Technology Co., Ltd. FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Tel: +86-592-7769969 Fax: +86-592-7769958 DATE 05-19-2015 FCC ID: AUJPXDZPD508 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen CTL Testing Technology Co., Ltd.(MR. Tracy Qi) at Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Xiamen Puxing Electronics Science & Technology Co., Ltd. at FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China. Dated this 05-19-2015 Agency agreement expiration date: 05-18-2016 By: Kevin Xie Signature Printed Title: Manager On behalf of : Xiamen Puxing Electronics Science & Technology Co., Ltd. Telephone: +86-592-7769969

Xiamen Puxing Electronics Science & Technology Co., Ltd. FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Tel: +86-592-7769969 Fax: +86-592-7769958 DATE 05-19-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: AUJPXDZPD508 Product Name: DPMR RADIO Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description • Tune up Procedure • BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 05-19-2015 By: Kevin Xie Signature Printed Title: Manager On behalf of : Xiamen Puxing Electronics Science & Technology Co., Ltd. Telephone: +86-592-7769969

Xiamen Puxing Electronics Science & Technology Co., Ltd. FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Tel: +86-592-7769969 Fax: +86-592-7769958 DATE 05-19-2015 FCC ID: AUJPXDZPD508 Justification for extended frequency range To meet the requirement of FCC publication, KDB 634817- Freq Range Listing for Grants, we submit the following attestation. This handheld device has 1. The design capability to operate in the frequency band 406.1-470 MHz. 2. Complies with 47CFR Part 90.203(e) in that the equipment operator cannot directly program transmits frequencies using the normally accessible external control. Frequency band 406 to 406.1 MHz is reserved for use by distress beacons. Transmissions shall not be made within this frequency band. The Grant Note ‘EF’ shall be appended to the grant, indicating this operation is required. Low frequency High Frequency FCC Rule Part 406 406.1 80 87 95 406.1 410 90 410 420 90 420 450 90 95I 97 450 454 74D 74H 90 95I 454 455 22 80 95I 455 456 74D 74H 95I 456 460 22 80 90 95I 460 462.5375 90 462.5375 462.7375 95 462.7375 467.5375 80 90 467.5375 467.7375 80 95 467.7375 470 80 90 Dated 05-19-2015 By: Kevin Xie Signature Printed Title: Manager On behalf of : Xiamen Puxing Electronics Science & Technology Co., Ltd. Telephone: +86-592-7769969

Xiamen Puxing Electronics Science & Technology Co., Ltd. FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Tel: +86-592-7769969 Fax: +86-592-7769958 Letter for Label Proposal FCC ID: AUJPXDZPD508 May 19, 2015 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Dear Sirs: Xiamen Puxing Electronics Science & Technology Co., Ltd. requests acceptance of the labeling proposal described below for transceivers bearing FCC identifier AUJPXDZPD508. The subject transceivers are compact handheld models as shown in figure 1, authorized under 47CFR FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES. Figure 1. Because the majority of the transceiver housing is composed of display, speaker, operating controls, and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, Xiamen Puxing Electronics Science & Technology Co., Ltd. proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Xiamen Puxing Electronics Science & Technology Co., Ltd. FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Tel: +86-592-7769969 Fax: +86-592-7769958 Proposed Label Location on EUT Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Xiamen Puxing Electronics Science & Technology Co., Ltd. will add the FCC identifier "AUJPXDZPD508" to the outside of the consumer "gift box" packaging. Sincerely yours, Kevin Xie / Manager

External Photos

Applicant: Xiamen Puxing Electronics Science & Technology Co., Ltd. FCC ID: AUJPXDZPD508 Model Name: PD508 Proposed Label Location on EUT

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 SAR TEST REPORT Report Reference No. .................... : FCC ID. ............................................ : CTL1504240995-EMF AUJPXDZPD508 Compiled by ( position+printed name+signature) .. : File administrators Happy Guo Supervised by ( position+printed name+signature) .. : Test Engineer Jacky Chen Approved by ( position+printed name+signature) .. : Manager Tracy Qi Date of issue ..................................... : May 04, 2015 Testing Laboratory Name .............. : Shenzhen CTL Testing Technology Co., Ltd. Address............................................. : Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Testing Laboratory Name .............. : The Testing and Technology Center for Industrial Products of Shenzhen Entry-Exit Inspection and Quarantine Bureau Address............................................. : No.289, 8th Industry Road, NanshanDistrict,Shenzhen,Guangdong Applicant’s name ............................ : Xiamen Puxing Electronics Science & Technology Co., Ltd. Address............................................. : FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Test specification .......................... : Standard ........................................... : ANSI C95.1–1999 47CFR §2.1093 TRF Originator .................................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF ....................................... : Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: DPMR RADIO Trade Mark ....................................... : PUXING Model/Type reference ....................... : PD508 Listed Models .................................. : / Ratings.............................................. : DC 7.40V EUT Type ......................................... : Production Unit Exposure category ............................ : Occupational /Controlled environment Result ................................................ : PASS V1.0 Page 2 of 58 Report No.: CTL1504240995-EMF T E S T R E P O R T Test Report No. : CTL1504240995-EMF May 04, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : DPMR RADIO Model /Type : PD508 Listed Models : / Applicant : Xiamen Puxing Electronics Science & Technology Co., Ltd. Address : FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Manufacturer : Xiamen Puxing Electronics Science & Technology Co., Ltd. Address : FL3-4, No.11, Xianghong Road, Xiang'An District, Xiamen City, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 58 Report No.: CTL1504240995-EMF ** Modifited History ** Revison Description Issued Data Remark Revsion 1.0 Initial Test Report Release 2015-05-04 Tracy Qi V1.0 Page 4 of 58 Report No.: CTL1504240995-EMF Contents 1. T E S T S T A N D A R D S 5 2. S U M M A R Y 6 2.1. General Remarks 6 2.2. Product Description 6 2.3. Summary SAR Results 6 2.4. Equipment under Test 6 2.5. EUT operation mode 6 2.6. TEST Configuration 7 2.7. EUT configuration 7 3. T E S T E N V I R O N M E N T 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 8 3.4. SAR Limits 8 3.5. Equipments Used during the Test 9 4. S A R M E A S U R E M E N T S S Y ST E M C O N F I G U R A T I O N 10 4.1. SAR Measurement Set-up 10 4.2. DASY5 E-field Probe System 11 4.3. Phantoms 11 4.4. Device Holder 12 4.5. Scanning Procedure 12 4.6. Data Storage and Evaluation 13 4.7. SAR Measurement System 14 4.8. Dielectric Performance 15 4.9. System Check 16 4.10. Measurement Procedures 16 5. T E S T C O N D I T I O N S A N D R E S U L T S 22 5.1. Conducted Power Results 22 5.2. Test reduction procedure 22 5.3. SAR Measurement Results 22 5.4. SAR Measurement Variability 23 5.5. Measurement Uncertainty (300-3GHz) 24 5.6. System Check Results 28 5.7. SAR Test Graph Results 30 6. C A L I B R A T I O N C E R T I F I CA T E 32 6.1. Probe Calibration Ceriticate 32 6.2. D450V3 Dipole Calibration Certificate 43 6.3. DAE4 Calibration Certificate 51 7. T E S T S E T U P PH O T O S 54 8. E X T E R N A L P H O T O S O F T H E E U T 56 V1.0 Page 5 of 58 Report No.: CTL1504240995-EMF 1. T E S T S T A N D A R D S The tests were performed according to following standards: IEEE 1528-2003 (2003-04): Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques: IEEE 1528-2013 (2014-06): Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques IEEE Std. C95-3 (2002): IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields – RF and Microwave IEEE Std. C95-1 (1992): IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. IEC 62209-2 (2010): Human exposure to radio frequency fields from hand-held and bodymounted wireless communication devices. Human models, instrumentation, and procedures. Procedure to determine the specific absorption rate (SAR) for wireless communication devices used in close proximity to the human body (frequency ra…

Text truncated - open the document above for the full version.

V1.0 Page 43 of 58 Report No.: CTL1504240995-EMF 6.2. D450V3 Dipole Calibration Certificate V1.0 Page 44 of 58 Report No.: CTL1504240995-EMF V1.0 Page 45 of 58 Report No.: CTL1504240995-EMF V1.0 Page 46 of 58 Report No.: CTL1504240995-EMF V1.0 Page 47 of 58 Report No.: CTL1504240995-EMF V1.0 Page 48 of 58 Report No.: CTL1504240995-EMF V1.0 Page 49 of 58 Report No.: CTL1504240995-EMF V1.0 Page 50 of 58 Report No.: CTL1504240995-EMF V1.0 Page 51 of 58 Report No.: CTL1504240995-EMF 6.3. DAE4 Calibration Certificate V1.0 Page 52 of 58 Report No.: CTL1504240995-EMF V1.0 Page 53 of 58 Report No.: CTL1504240995-EMF V1.0 Page 54 of 58 Report No.: CTL1504240995-EMF 7. T e s t S e t u p P h o t o s Photograph of the depth in the Head Phantom (450MHz) Photograph of the depth in the Body Phantom (450MHz) Face-held, the front of the EUT towards phantom (The distance was 25mm) V1.0 Page 55 of 58 Report No.: CTL1504240995-EMF Body-worn, the front of the EUT towards ground with A1, B2, BC2 and AA1 (The distance was 0cm) V1.0 Page 56 of 58 Report No.: CTL1504240995-EMF 8. E x t e r n a l P h o t o s o f t h e E U T External Photos V1.0 Page 57 of 58 Report No.: CTL1504240995-EMF V1.0 Page 58 of 58 Report No.: CTL1504240995-EMF .....................End of Report.........................

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 90 Test Report Report Reference No. ..................... : CTL1504240995-WF FCC ID .............................................. : AUJPXDZPD508 Compiled by ( position+printed name+signature) .. : File administrators Happy Guo Name of the organization performing the tests ( position+printed name+signature) .. : Test Engineer Happy Guo Approved by ( position+printed name+signature) .. : Manager Tracy Qi Date of issue ..................................... : May 19, 2015 Testing Laboratory Name .............. : Shenzhen CTL Testing Technology Co., Ltd. Address ............................................. : Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Applicant’s name ............................ : Xiamen Puxing Electronics Science & Technology Co., Ltd. Address ............................................. : FL3-4, No.11, Xianghong Road, Xiang’an, Xiamen City, Fujian, China Test specification: Standard ........................................... : FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES TRF Originator .................................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF ....................................... : Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : DPMR RADIO Trade Mark ....................................... : PUXING Model/Type reference ....................... : PD508 Modulation..................................: FM, 4FSK Channel Separation ........................... FM: 12.5KHz, 4FSK: 6.25KHz Power Supply..............................: DC 7.4V Rated Power..............................: 4W Operating Frequency Range............: From 406.1 MHz to 470 MHz Result ................................................ : Positive V1.0 Page 2 of 59 Report No.: CTL1504240995-W T E S T R E P O R T Test Report No. : CTL1504240995-WF May 19, 2015 ______________________________________________________________________________________________ Date of issue Equipment under Test : DPMR RADIO Model /Type : PD508 Applicant : Xiamen Puxing Electronics Science & Technology Co., Ltd. Address : FL3-4, No.11, Xianghong Road, Xiang’an, Xiamen City, Fujian, China Manufacture : Xiamen Puxing Electronics Science & Technology Co., Ltd. Address : FL3-4, No.11, Xianghong Road, Xiang’an, Xiamen City, Fujian, China Test Result according to the standards on page 5: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 59 Report No.: CTL1504240995-W ** Modifited History ** Revison Description Issued Data Remark Revsion 1.0 Initial Test Report Release 2015-05-04 Tracy Qi V1.0 Page 4 of 59 Report No.: CTL1504240995-W Contents 1. T E S T S T A N D A R D S 5 2. S U M M A R Y 6 2.1. General Remarks 6 2.2. Equipment Under Test 6 2.3. Short description of the Equipment under Test (EUT) 6 2.4. Short description of the Equipment under Test (EUT) 7 2.5. EUT operation mode 7 2.6. EUT configuration 7 2.7. Related Submittal(s) / Grant (s) 7 2.8. Modifications 7 2.9. Note 7 3. T E S T E N V I R O N M E N T 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 8 3.4. Configuration of Tested System 8 3.5. Statement of the measurement uncertainty 9 3.6. Equipments Used during the Test 10 3.7. General Technical Requirements and Summary of Test Results 10 4. T E S T C O N D I T I O N S A N D R E S U L T S 11 4.1. Conducted Emissions Test 11 4.2. Occupied Bandwidth and Emission Mask 16 4.3. Radiated Spurious Emission Test 25 4.4. Spurious Emission On Antenna Port 30 4.5. Modulation Characteristics 41 4.6. Frequency Stability Measurement 44 4.7. Conducted Output Power 46 4.8. Transmitter Frequency Behavior 50 5. T E S T S E T U P P H O T O S O F T H E E U T 53 6. E X T E R N A L A N D I N T E R N AL P H O T O S O F T H E E U T 55 V1.0 Page 5 of 59 Report No.: CTL1504240995-W 1. T E S T S T A N D A R D S The tests were performed according to following standards: FCC Part 90: PRIVATE LAND MOBILE RADIO SERVICES TIA/EIA 603: Land Mobile FM or PM Communications Equipment Measurement and Performance Standards. 47 CFR FCC Part 15 Subpart B - Unintentional Radiators FCC Part 2: FREQUENCY ALLOCA-TIONS AND RADIO TREATY MAT-TERS; GENERAL RULES AND REG-ULATIONS V1.0 Page 6 of 59 Report No.: CTL1504240995-W 2. S U M M A R Y 2.1. General Remarks Date of receipt of test sample : Apr. 30, 2015 Testing commenced on : Apr. 30, 2015 Testing concluded on : May 19, 2012 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ○ 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 7.4 V from battery 2.3. Short description of the Equipment under Test (EUT) The Xiamen Puxing Electronics Science & Technology Co., Ltd’s Model: PD508 or the “EUT” as referred to in this report; more general information as follows, for more details, refer to the user’s manual of the EUT. Name of EUT DPMR RADIO Model Number PD508 FCC ID AUJPXDZPD508 Rated Output Power 4 Watts(36.02dBm) Support data rate 4.8kbps Modilation Type FM for Analog Voice 4FSK for Digital Voice/Digital Data 4FSK for Digital Data Analog F3E for 12.5KHz Channel Separation Digital F1E for 6.25KHz Channel Separation / Channel Separation Analog Voice 12.5KHz Digital Voice/Data 6.25KHz Digital Data 6.25KHz Antenna Type External Frequency R…

Text truncated - open the document above for the full version.

Test Setup Photos of the EUT
