AXATR-400-A2OEM Module

Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 1 of 16 DM-10 OEM INTERFACE MANUAL Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 2 of 16 CONTENTS – OEM INTERFACE MANUAL 1. DM10 TRANSCEIVER MODULE OUTLINE DRAWING.......................................................... 3 1.1.MECHANICAL.............................................................................................................................4 1.2.ELECTRICAL..............................................................................................................................5 1.2.1.ELECTRICAL PERFORMANCE...............................................................................................5 1.2.2.MOBILE STATION POWER CLASS.........................................................................................6 1.3.POWER CONSUMPTION..............................................................................................................6 1.3.1.TRANSMIT/TALK MODE......................................................................................................6 1.3.2.STANDBY MODE.................................................................................................................6 1.3.3.SLEEP MODE (MINIMUM DC POWER CONSUMPTION)..........................................................6 2. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 7 3. SAFETY .......................................................................................................................................... 8 3.1.EXPOSURE TO RADIO FREQUENCY ENERGY.............................................................................8 3.2.MODULE OPERATION................................................................................................................8 3.3.POSTED FACILITIES...................................................................................................................8 3.4.ELECTRONIC DEVICES...............................................................................................................8 3.5.BLASTING AREAS.......................................................................................................................9 3.6.POTENTIALLY EXPLOSIVE ATMOSPHERES...............................................................................9 3.7.VEHICLES...................................................................................................................................9 3.8.FOR VEHICLES EQUIPPED WITH AN AIRBAG..............................................................................9 3.9.RESPONSIBLE USE.....................................................................................................................9 4. TECHNICAL SPECIFICATIONS ............................................................................................... 12 4.1.GENERAL.................................................................................................................................12 4.2.RECEIVER SECTION.................................................................................................................12 4.3.TRANSMITTER SECTION..........................................................................................................13 4.4.CONNECTORS...........................................................................................................................13 4.4.1.30-PIN INTERFACE CONNECTIONS.....................................................................................13 4.4.2.RF INTERFACE CONNECTOR..............................................................................................14 4.4.3.DETAILED SIGNAL DESCRIPTIONS.....................................................................................14 4.4.4.SYSTEM CONNECTOR CMOS INTERFACE LEVELS.............................................................16 4.4.5.ACCESSORY CONNECTOR..................................................................................................16 4.4.6.SYSTEM CONNECTOR.......................................................................................................16 Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 3 of 16 1. DM10 Transceiver Module Outline Drawing Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 4 of 16 1.1. Mechanical The DM-10 module has no mechanical elements other that the main PCB assembly. All critical electronic components are shielded using sheet metal cans to prevent internal/external electromagnetic interference from degrading the module’s performance and to prevent the module from interfering with other nearby devices. The following figure shows a typical mounting configuration of the module with the main motherboard assembly. The module is plugged into the fixed mating connector and secured with four screws to the standoff components. Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 5 of 16 1.2. Electrical The diagram below shows an overview of the electrical interface between the DM-10 module and a typical application. DM-10 Electrical Interface Customer Application HW Voltage Regulator Control Processor Voice & Data Processing üEcho Cancelling üNoise Cancelling üAudio Power AMP üData Conversion DTE Power External Audio Interface Antenna User Interface 6 1 Power & GND Serial Interface Wake Analog Audio Interface 10 1 3 5 4 Clock REF Option SIM Device DM-10 Module PCM Audio Interface 1.2.1. Electrical Performance Electrical performance parameters are valid only when the terminating impedance at the output of the antenna connector exhibits a VSWR of less than 2:1 for all phase angles in the frequency band of operation. High VSWR loads at the antenna connector adversely affect current consumption, linearity, and power efficiency of the module and may prevent operation or cause internal damage. The RF performance of the DM-10 fully meets the following specifications: • IS-136 TDMA Cellular mode …

Text truncated - open the document above for the full version.

Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 1 of 16 DM-10 OEM INTERFACE MANUAL Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 2 of 16 CONTENTS – OEM INTERFACE MANUAL 1. DM10 TRANSCEIVER MODULE OUTLINE DRAWING.......................................................... 3 1.1.MECHANICAL.............................................................................................................................4 1.2.ELECTRICAL..............................................................................................................................5 1.2.1.ELECTRICAL PERFORMANCE...............................................................................................5 1.2.2.MOBILE STATION POWER CLASS.........................................................................................6 1.3.POWER CONSUMPTION..............................................................................................................6 1.3.1.TRANSMIT/TALK MODE......................................................................................................6 1.3.2.STANDBY MODE.................................................................................................................6 1.3.3.SLEEP MODE (MINIMUM DC POWER CONSUMPTION)..........................................................6 2. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 7 3. SAFETY .......................................................................................................................................... 8 3.1.EXPOSURE TO RADIO FREQUENCY ENERGY.............................................................................8 3.2.MODULE OPERATION................................................................................................................8 3.3.POSTED FACILITIES...................................................................................................................8 3.4.ELECTRONIC DEVICES...............................................................................................................8 3.5.BLASTING AREAS.......................................................................................................................9 3.6.POTENTIALLY EXPLOSIVE ATMOSPHERES...............................................................................9 3.7.VEHICLES...................................................................................................................................9 3.8.FOR VEHICLES EQUIPPED WITH AN AIRBAG..............................................................................9 3.9.RESPONSIBLE USE.....................................................................................................................9 4. TECHNICAL SPECIFICATIONS ............................................................................................... 12 4.1.GENERAL.................................................................................................................................12 4.2.RECEIVER SECTION.................................................................................................................12 4.3.TRANSMITTER SECTION..........................................................................................................13 4.4.CONNECTORS...........................................................................................................................13 4.4.1.30-PIN INTERFACE CONNECTIONS.....................................................................................13 4.4.2.RF INTERFACE CONNECTOR..............................................................................................14 4.4.3.DETAILED SIGNAL DESCRIPTIONS.....................................................................................14 4.4.4.SYSTEM CONNECTOR CMOS INTERFACE LEVELS.............................................................16 4.4.5.ACCESSORY CONNECTOR..................................................................................................16 4.4.6.SYSTEM CONNECTOR.......................................................................................................16 Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 3 of 16 1. DM10 Transceiver Module Outline Drawing Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 4 of 16 1.1. Mechanical The DM-10 module has no mechanical elements other that the main PCB assembly. All critical electronic components are shielded using sheet metal cans to prevent internal/external electromagnetic interference from degrading the module’s performance and to prevent the module from interfering with other nearby devices. The following figure shows a typical mounting configuration of the module with the main motherboard assembly. The module is plugged into the fixed mating connector and secured with four screws to the standoff components. Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 5 of 16 1.2. Electrical The diagram below shows an overview of the electrical interface between the DM-10 module and a typical application. DM-10 Electrical Interface Customer Application HW Voltage Regulator Control Processor Voice & Data Processing üEcho Cancelling üNoise Cancelling üAudio Power AMP üData Conversion DTE Power External Audio Interface Antenna User Interface 6 1 Power & GND Serial Interface Wake Analog Audio Interface 10 1 3 5 4 Clock REF Option SIM Device DM-10 Module PCM Audio Interface 1.2.1. Electrical Performance Electrical performance parameters are valid only when the terminating impedance at the output of the antenna connector exhibits a VSWR of less than 2:1 for all phase angles in the frequency band of operation. High VSWR loads at the antenna connector adversely affect current consumption, linearity, and power efficiency of the module and may prevent operation or cause internal damage. The RF performance of the DM-10 fully meets the following specifications: • IS-136 TDMA Cellular mode …

Text truncated - open the document above for the full version.

Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 1 of 16 DM-10 OEM INTERFACE MANUAL Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 2 of 16 CONTENTS – OEM INTERFACE MANUAL 1. DM10 TRANSCEIVER MODULE OUTLINE DRAWING.......................................................... 3 1.1.MECHANICAL.............................................................................................................................4 1.2.ELECTRICAL..............................................................................................................................5 1.2.1.ELECTRICAL PERFORMANCE...............................................................................................5 1.2.2.MOBILE STATION POWER CLASS.........................................................................................6 1.3.POWER CONSUMPTION..............................................................................................................6 1.3.1.TRANSMIT/TALK MODE......................................................................................................6 1.3.2.STANDBY MODE.................................................................................................................6 1.3.3.SLEEP MODE (MINIMUM DC POWER CONSUMPTION)..........................................................6 2. ABSOLUTE MAXIMUM RATINGS ............................................................................................. 7 3. SAFETY .......................................................................................................................................... 8 3.1.EXPOSURE TO RADIO FREQUENCY ENERGY.............................................................................8 3.2.MODULE OPERATION................................................................................................................8 3.3.POSTED FACILITIES...................................................................................................................8 3.4.ELECTRONIC DEVICES...............................................................................................................8 3.5.BLASTING AREAS.......................................................................................................................9 3.6.POTENTIALLY EXPLOSIVE ATMOSPHERES...............................................................................9 3.7.VEHICLES...................................................................................................................................9 3.8.FOR VEHICLES EQUIPPED WITH AN AIRBAG..............................................................................9 3.9.RESPONSIBLE USE.....................................................................................................................9 4. TECHNICAL SPECIFICATIONS ............................................................................................... 12 4.1.GENERAL.................................................................................................................................12 4.2.RECEIVER SECTION.................................................................................................................12 4.3.TRANSMITTER SECTION..........................................................................................................13 4.4.CONNECTORS...........................................................................................................................13 4.4.1.30-PIN INTERFACE CONNECTIONS.....................................................................................13 4.4.2.RF INTERFACE CONNECTOR..............................................................................................14 4.4.3.DETAILED SIGNAL DESCRIPTIONS.....................................................................................14 4.4.4.SYSTEM CONNECTOR CMOS INTERFACE LEVELS.............................................................16 4.4.5.ACCESSORY CONNECTOR..................................................................................................16 4.4.6.SYSTEM CONNECTOR.......................................................................................................16 Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 3 of 16 1. DM10 Transceiver Module Outline Drawing Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 4 of 16 1.1. Mechanical The DM-10 module has no mechanical elements other that the main PCB assembly. All critical electronic components are shielded using sheet metal cans to prevent internal/external electromagnetic interference from degrading the module’s performance and to prevent the module from interfering with other nearby devices. The following figure shows a typical mounting configuration of the module with the main motherboard assembly. The module is plugged into the fixed mating connector and secured with four screws to the standoff components. Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 5 of 16 1.2. Electrical The diagram below shows an overview of the electrical interface between the DM-10 module and a typical application. DM-10 Electrical Interface Customer Application HW Voltage Regulator Control Processor Voice & Data Processing üEcho Cancelling üNoise Cancelling üAudio Power AMP üData Conversion DTE Power External Audio Interface Antenna User Interface 6 1 Power & GND Serial Interface Wake Analog Audio Interface 10 1 3 5 4 Clock REF Option SIM Device DM-10 Module PCM Audio Interface 1.2.1. Electrical Performance Electrical performance parameters are valid only when the terminating impedance at the output of the antenna connector exhibits a VSWR of less than 2:1 for all phase angles in the frequency band of operation. High VSWR loads at the antenna connector adversely affect current consumption, linearity, and power efficiency of the module and may prevent operation or cause internal damage. The RF performance of the DM-10 fully meets the following specifications: • IS-136 TDMA Cellular mode …

Text truncated - open the document above for the full version.

Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 1 of 42 DM-10 OEM INTERFACE MANUAL Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 2 of 42 CONTENTS – OEM INTERFACE MANUAL 1. DM10 TRANSCEIVER MODULE OUTLINE DRAWING.......................................................... 5 1.1.MECHANICAL.............................................................................................................................8 1.2.ELECTRICAL............................................................................................................................11 1.2.1.ELECTRICAL PERFORMANCE.............................................................................................13 1.2.2.MOBILE STATION POWER CLASS.......................................................................................13 1.3.POWER CONSUMPTION............................................................................................................15 1.3.1.TRANSMIT/TALK MODE....................................................................................................15 1.3.2.STANDBY MODE...............................................................................................................16 1.3.3.SLEEP MODE (MINIMUM DC POWER CONSUMPTION)........................................................16 2. ABSOLUTE MAXIMUM RATINGS ........................................................................................... 17 3. SAFETY ........................................................................................................................................ 18 3.1.EXPOSURE TO RADIO FREQUENCY ENERGY...........................................................................18 3.2.MODULE OPERATION..............................................................................................................19 3.3.POSTED FACILITIES.................................................................................................................19 3.4.ELECTRONIC DEVICES.............................................................................................................19 3.5.BLASTING AREAS.....................................................................................................................20 3.6.POTENTIALLY EXPLOSIVE ATMOSPHERES.............................................................................20 3.7.VEHICLES.................................................................................................................................21 3.8.FOR VEHICLES EQUIPPED WITH AN AIRBAG............................................................................21 3.9.RESPONSIBLE USE...................................................................................................................21 4. TECHNICAL SPECIFICATIONS ............................................................................................... 27 4.1.GENERAL.................................................................................................................................27 4.2.RECEIVER SECTION.................................................................................................................28 4.3.TRANSMITTER SECTION..........................................................................................................29 4.4.CONNECTORS...........................................................................................................................30 4.4.1.30-PIN INTERFACE CONNECTIONS.....................................................................................30 4.4.2.RF INTERFACE CONNECTOR..............................................................................................32 4.4.3.DETAILED SIGNAL DESCRIPTIONS.....................................................................................33 4.4.4.SYSTEM CONNECTOR CMOS INTERFACE LEVELS.............................................................40 4.4.5.ACCESSORY CONNECTOR..................................................................................................41 4.4.6.SYSTEM CONNECTOR.......................................................................................................42 Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 3 of 42 1. DM10 Transceiver Module Outline Drawing Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 4 of 42 1.1. Mechanical The DM-10 module has no mechanical elements other that the main PCB assembly. All critical electronic components are shielded using sheet metal cans to prevent internal/external electromagnetic interference from degrading the module’s performance and to prevent the module from interfering with other nearby devices. The following figure shows a typical mounting configuration of the module with the main motherboard assembly. The module is plugged into the fixed mating connector and secured with four screws to the standoff components. Exhibit 8: OEM Interface Manual ©1999 Ericsson Inc.Page 5 of 42 1.2. Electrical The diagram below shows an overview of the electrical interface between the DM-10 module and a typical application. DM-10 Electrical Interface Customer Application HW Voltage Regulator Control Processor Voice & Data Processing üEcho Cancelling üNoise Cancelling üAudio Power AMP üData Conversion DTE Power External Audio Interface Antenna User Interface 6 1 Power & GND Serial Interface Wake Analog Audio Interface 10 1 3 5 4 Clock REF Option SIM Device DM-10 Module PCM Audio Interface 1.2.1. Electrical Performance Electrical performance parameters are valid only when the terminating impedance at the output of the antenna connector exhibits a VSWR of less than 2:1 for all phase angles in the frequency band of operation. High VSWR loads at the antenna connector adversely affect current consumption, linearity, and power efficiency of the module and may prevent operation or cause internal damage. The RF performance of the DM-10 fully meets the following specifications: • IS-136 TDMA Cellular mode – Per IS-137 speci…

Text truncated - open the document above for the full version.

APPLICANT: ERICSSON INC.FCC ID NO: AXATR-400-A2 Exhibit 2A Para. 22.919, Electronic Serial Numbers Protection Against Unauthorized ESN and Firmware Upgrades The Electronic Serial Number (ESN) bits in this OEM module are encoded and spread over various non-sequential memory locations in order to prevent detection and modification. Once the factory has programmed the ESN, the mobile firmware cannot overwrite or alter the ESN memory locations. Both the ESN host and the operation systems components are permanently mounted to the mobile in order to prevent removal and misuse. Unauthorized attempts to alter the mobile’s firmware will cause the unit to become inoperable. APPLICANT: ERICSSON INC.FCC ID NO: AXATR-400-A2 Exhibit 2B ©1999 Ericsson Inc.

June 18, 1999 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21406 Attention:Equipment Authorization Branch Subject:Certification for FCC ID: AXATR-400-A2 Gentlemen, Ericsson Inc. requests certification (type acceptance) for the AXATR-400-A2. This OEM module transceiver is designed as a mobile for use in the AMPS/DAMPS cellular telephone system operating in the 800 MHz Domestic Public Cellular Radiotelephone Communications Services per Subpart H of part 22. This OEM module meets the requirements of IS-137A for operation in cellular systems. This OEM module is similar to previously type accepted FCC ID: AXATR-372-A2. Ericsson requests an exclusion from routine RF exposure measurements based on the discussion presented in Exhibit 11, RF Exposure Evaluation, and communications with Kwok Chan on 5/18/99. The primary reason for this request is due to hardware limitations of our burst mode making MPE evaluation infeasible because the module does not have a normal operating mode that would support the duration of an RF exposure evaluation. Due to the inherent duty cycle properties of the burst modem mode, the resultant worst case average ERP is 1.27 Watts, which is below the 1.5-watt threshold for excludability. Furthermore, the analysis of the maximum RF exposures under worst-case and typical conditions clearly demonstrates compliance with the amended FCC rules. We have included specific instructions and warnings in Exhibit 8, OEM Interface Manual, regarding minimum separation distance, maximum antenna gain, and that use as a portable transmitter will require separate FCC approval for SAR compliance. Ericsson Inc. requests confidentiality under 47 CFR 0.459 for the following exhibits listed: Exhibit 4Block Diagram Exhibit 5Schematic Diagrams Justification of this request is that in order to facilitate the circuit miniaturization of the AXATR-400-A2, proprietary techniques were implemented in the transmitter, receiver, and baseband circuitry. To protect Ericsson’s competitive advantage on these proprietary techniques, we request the above listed exhibits be held as confidential and withheld from the Public Information File. Sincerely, Jim Sponsler Staff Engineer, Regulatory ServicesTel No:(919) 472-6460 Research Triangle Park, NCFax No:(919) 472-7452 June 18, 1999 Federal Communications Commission Equipment Approval Services PO Box 358315 Pittsburgh, PA 15251-5315 Subject:Enclosed a check for Type Acceptance and Confidentiality follows: FCC IDFEE AXATR-400-A2$ 580.00 Sincerely, John Rothgeb Specialist Regulatory Programs Room 2669 Tel:(804) 592-7476 Fax:(804) 592-6510 Enclosures:Check Filing for Equipment Approval Branch

APPLICANT: ERICSSON INC.FCC ID: AXATR-400-A2 ©1999 Ericsson Inc. Exhibit 3: External Photo (Front View)Page 1 of 2 APPLICANT: ERICSSON INC.FCC ID: AXATR-400-A2 ©1999 Ericsson Inc. APPLICANT: ERICSSON INC.FCC ID: AXATR-400-A2 ©1999 Ericsson Inc.

APPLICANT: ERICSSON INC.FCC ID: AXATR-400-A2 Exhibit 1: Identification Plate ©1999 Ericsson Inc.

APPLICANT: ERICSSON INC.FCC ID: AXATR-400-A2 Exhibit 9: Internal Photos (Front and Back) ©1999 Ericsson Inc.

APPLICANT: ERICSSON INCFCC ID NO: AXATR-400-A2 Exhibit 12APage 1 of 3 ©1999 Ericsson Inc. CIRCUIT & DEVICE DESCRIPTIONS PARA. 2.1033 (b)(4), (c)(10) (10)FREQUENCY STABILIZATION A temperature compensated crystal oscillator (U4) provides a 19.44 MHz reference frequency signal for the transmitter and receiver frequency synthesizers. This reference frequency is internally compensated to be within ±2.5 ppm over the temperature range of -30°C to +75° C. Upon power-up, the receiver searches and acquires a base station signal, and it adjusts the reference oscillator frequency to align itself to the high accuracy time base of the base station. The transmitter does not engage until after the receiver synchronizes to the base station. (11a)ATTENUATION OF SPURIOUS EMISSIONS The 800 MHz band transmitter frequency is obtained from mixing a phase locked VCO operating from 979.53 MHz to 1004.49 MHz with a 155.52 MHz signal. The 155.52 MHz signal is obtained by phase locking an oscillator to the VCTCXO output. The 800 MHz band receiver frequency is obtained by dual conversion. The first conversion is obtained by mixing the incoming signal with the 979.53 MHz to 1004.49 MHz VCO to a first IF frequency of 110.52 MHz. The second conversion mixes the IF frequency with a phase locked VCO at 110.4 MHz to obtain the second IF frequency of 120 kHz. All VCO’s are phase locked to the reference VCTCXO U4. As a result of the above circuitry, the spurious signals are transmitter harmonics, reference oscillator 19.44 MHz harmonics, the local oscillators and the microprocessor clock. The use of multi-layer printed circuit boards, with signal tracks between ground planes, for the radio as well as for the logic areas reduces the radiation to a minimum. Ceramic resonator bandpass filters for the duplexer attenuate conducted transmitter harmonics, reference oscillator and local oscillator signals. A bandpass filter in the receiver front end attenuates the local oscillator signal further. Additional suppression of radiation is achieved by shielding and key isolation between …
