APPLICANT: FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc. Exhibit 2 Index for Exhibit Exhibit #Description 2AProtection Against Unauthorized ESN and Firmware Upgrades 2BCertification of Data APPLICANT: FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc. As per 22.919, Electronic Seal Numbers Protection Against Unauthorized ESN and Firmware Upgrades The Cellular portable phone use Electronic Serial Numbers (ESN). The ESN is a unique identification number to each phone which is contained in a component and is automatically transmitted to the base station whenever a cellular call is placed. The ESN is stored in NVEEprom and is isolated from fraudulent contact and tampering. Any attempt to change the ESN will render the portable inoperative.

APPLICANT: FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc. Exhibit 2 Index for Exhibit Exhibit #Description 2AProtection Against Unauthorized ESN and Firmware Upgrades 2BCertification of Data 2CCompliance Statement to Part 22.921, 911 Call Processing Procedures APPLICANT: FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc. As per 22.919, Electronic Seal Numbers Protection Against Unauthorized ESN and Firmware Upgrades The Cellular portable phone use Electronic Serial Numbers (ESN). The ESN is a unique identification number to each phone which is contained in a component and is automatically transmitted to the base station whenever a cellular call is placed. The ESN is stored in NVEEprom and is isolated from fraudulent contact and tampering. Any attempt to change the ESN will render the portable inoperative. APPLICANT: FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc. EXHIBIT 2B CERTIFICATION OF DATA The technical data contained in this application has been taken under my supervision, and is certified true and correct. _________________________________________ Neil Anderson Development Manager for Product and Engineering Date I certify that this application was made at my direction. I attest to the proper function of the switching and signal-processing portion of this transmitter. It meets the system compatibility specifications as detailed in the EIA document EIA/TIA IS-98 Rev A, OET 53 as referred to in Part 22.933 of the Commissions Rules. The data and statements made herein are to the best of my knowledge true and accurate. ___________________________________ Jeff Armantrout, Project Manager Date APPLICANT: FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc. Exhibit 2C Compliance Statement Pursuant to CC Docket No. 94-102, Section 22.921 Ericsson certifies that it is in full compliance with Section 22.921 of the FCC's Rules. Ericsson has received approval for its call processing method and has incorporated required modifications rendering it fully compliant with 47 C.F.R. Section 22.921 of the FCC's Rules. (See DA 00-253 released February 11, 2000)

June 30, 2000 Federal Communications Commission Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Attention: Equipment Authorization Branch Subject:Type Acceptance for FCC ID:AXATR-410-A2 Gentlemen, Ericsson Inc. requests a grant for Certification for the above mentioned FCC Identifier. This portable transceiver is designed for use in the AMPS/CDMA cellular telephone system. The mobile operates in the 800 MHz Domestic Public Cellular Radiotelephone Communications Services per Subpart H of Part. It meets the requirements of IS95A and IS-98 for operation in cellular systems. Documents governing CDMA was used as a guide. Measurements and calculations for SAR have been made on this radio. This unit complies with IEEE C95.1-1991 (ANSI/IEEE C95.1-1992). Ericsson Inc. requests confidentiality under 47 CFR 0.459 for the following exhibit listed: Exhibit 4Block Diagrams Exhibit 5Circuit Diagrams Exhibit 10Tune-up/Alignment procedure Exhibit 12Operational Description Justification of this request is that in order to facilitate the circuit miniaturization of the AXATR- 410-A2, certain proprietary techniques were implemented to reduce the board space required for the RF circuitry layout. The Operational Description and alignment exhibits provide unique information regarding Service/Alignment Codes. To protect Ericsson’s competitive advantage on these proprietary techniques and alignment codes, we request the above listed exhibits be held as confidential and withheld from the Public Information File. Sincerely, Jim Sponsler STL, Regulatory Services Research Triangle Park, NC [email protected] Tel No:(919) 472-6460 Fax No:(919) 472-7452

APPLICANT:Exhibit 3 FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc. APPLICANT:Exhibit 3 FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc.

APPLICANT:Exhibit 1 FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc.

APPLICANT:Exhibit 9 FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc. APPLICANT:Exhibit 9 FCC ID NO: ERICSSON INCAXATR-410-A2 ©2000 Ericsson Inc.

Confidential REPORT 1 (13) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1364/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-06-29A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\A1228c.doc E SAR Test Report: A1228c Date of test: June 29, 2000 Laboratory: Electromagnetic Near Field and Radio Frequency Dosimetry Laboratory Ericsson, Inc. 7001 Development Drive, P.O. Box 13969, Research Triangle Park, NC, 27709, USA Test Responsible: Mark Douglas, Ph.D. Senior Staff Engineer, Antenna Development Group [email protected] (919) 472-6334 Statement of Compliance Ericsson, Inc. declares under its sole responsibility that the that the product Ericsson A1228c to which this declaration relates, is in conformity with the appropriate RF exposure standards, recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) © Ericsson, Inc. 2000 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Ericsson encourages all feedback, both positive and negative, on this test report. Confidential REPORT 2 (13) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1364/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-06-29A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\A1228c.doc E Table of Contents 1. Introduction3 2. Device Under Test3 2.1Antenna description3 2.2Device description3 3. Test equipment3 3.1 Dosimetric system3 3.2Additional equipment4 4. Electrical parameters of the tissue simulating liquid4 5. System accuracy verification4 6. Test results4 References5 Appendix 1: SAR distribution comparison for system accuracy verification6 Appendix 2: SAR distribution plots8 Distribution of maximum SAR in 800 CDMA band.9 Appendix 3: Photographs of the device under test10 Appendix 4: Position of device on Generic Twin Phantom12 Appendix 5: Probe calibration parameters for ET3DV5 SN:132413 Confidential REPORT 3 (13) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1364/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-06-29A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\A1228c.doc E 1. Introduction In this test report, compliance of the Ericsson A1228c portable telephone with RF safety guidelines is demonstrated (applicable RF safety guidelines are given in [1]). The device was tested in accordance with the latest available test guidelines [1]. Detailed procedures of the test are described in the Ericsson SAR Measurement Specification [2]. 2. Device Under Test 2.1 Antenna description Type Fixed stub Location Left side length30 mm Dimensions width at base10 mm Configuration Helix 2.2 Device description Device model A1228c Serial number UA201988XW Mode 800 AMPS800 CDMA Multiple Access Scheme FDMAFH-CDMA Maximum Output Power Setting 1 26.0 dBm23.5 dBm Factory Tolerance in Power Setting ± 0.25± 0.25 Maximum Peak Output Power 2 26.25 dBm23.75 dBm Duty Cycle 11 Transmitting Frequency Range 824 – 837 MHz824 – 837 MHz Prototype or Production Unit Prototype 3. Test equipment 3.1 Dosimetric system SAR measurements were made using the DASY3 professional system (software version 3.1c), manufactured by Schmid & Partner Engineering AG and installed Febuary, 1998. The total SAR assessment uncertainty (K = 1) of the system is ±16% and includes a +15% offset (overestimation). The extended uncertainty (K = 2) is ±32% with a +15% offset. This results in a total uncertainty range of –1% to +31% for K = 1, or –17% to +47% for K = 2. The equipment list is given below. Description Serial NumberDue Date DASY3 DAE V1 3454/01 E-field probe ETDV5 13242/01 Dipole Validation Kit, D900V204912/00 1 This is the conducted power measured at the antenna port when the device is set to its highest power setting. It is measured at the middle of the transmit frequency band. Note that the output power may be different at other frequencies. 2 This equals the maximum output power setting plus the factory tolerance. Confidential REPORT 4 (13) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1364/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-06-29A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\A1228c.doc E 3.2 Additional equipment Description Serial NumberDue Date Signal Generator HP8648C 3537A015989/00 Dielectric probe kit HP 85070B US330202568/00 Network analyzer HP 8752C 3410A031057/00 Power meter HP 437B3125U137292/01 Power sensor HP 8482H3318A070972/01 Tektronix CMD80847946/0482/01 4. Electrical parameters of the tissue simulating liquid Prior to conducting SAR measurements, the relative permittivity, ε r , and the conductivity, σ, of the tissue simulating liquids were measured with the dielectric probe kit. These values are shown in the table below. The mass density, ρ, entered into the DASY3 program is also given. Recommended limits for maximum permittivity, minimum conductivity and maximum mass density are also shown [3]. It is seen that the measured parameters result in an overestimation of SAR compared to the recommended values. Dielectric Parameters f (MHz) Limits / Measured εε r σσ (S/m)ρρ (g/cm 3 ) Measured 40.90.901.00 835 Recommended Limits [3] 46.10.741.03 5. System accuracy verification A system accuracy verification of the DASY3 was performed using the dipole validation kits listed in Section 3.1. The system verification test was conducted on the same day as the measurement of the DUT. The obtained results are displayed in the table below. It is seen that the …

Text truncated - open the document above for the full version.

Uppgjord -Prepared ERA/T/UD Martin Siegbahn Godkänd -Approved ERA/T/UF Christer Törnevik Kontr. -Checked Datum -Date 2000-05-31 Ert datum -Your date Rev I Dokumentnr -Document no T/U 00:232 Blad -Sheet 1 (1) Tillhör referens -File/reference Tfn -Telephone 75-70811 Dokument -Document Document list INTERNAL LIMITED Ericsson SAR Measurement Specification PartDocument nameDocument numberRev 1Introduction and purposeERA/T/U-98:446C 2Tissue liquid preparationERA/T/U-98:404D 3Measurements of dielectric parametersERA/T/U-98:405F 4System accuracy verificationEUS/TR/X-98:1585F 5Calibration of equipmentEUS/TR/X-98:1586D 6DUT preparation and characterizationERA/T/U-98:439H 7SAR measurement procedureERA/T/U-98:441H 8Documentation of resultsERA/T/U-98:447C 9BibliographyERA/T/U-99:047D 10Glossary of symbolsEUS/TR/X-99:1336A Internal limited INSTRUCTION1 (4) Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other)Nr - No. ERA/T/UF Christer TörnevikT/U-98:446 Dokansv/Godk – Doc respons/ApprovedKontr - CheckedDatum - Date RevFile ERA/T/UF Christer Törnevik2000-03-17C Ericsson SAR measurement specification, part 1: Introduction and purpose 1. Introduction It is an Ericsson policy that all RF transmitting products shall comply with existing recommendations, standards and regulations on human exposure to electromagnetic fields. In the reference section below, the most important RF safety guidelines are listed [1-8]. If no national standard or regulation is available in a country, the international recommendation from ICNIRP [1] shall be applied for Ericsson products. The RF safety guidelines specify basic restrictions and reference levels. In the frequency range of interest for mobile communications, the basic restrictions are expressed as Specific Absorption Rate (SAR) limits and the reference levels as field strength or power density limits. The reference levels are provided for the purpose of simple measurements of compliance with the basic restrictions, and they are primarily applicable in the farfield region of a RF source. Measured values greater than the reference levels do not necessarily mean that the basic restrictions are exceeded. In the nearfield region of mobile communication devices (handsets or base station antennas), field strength values exceeding the reference levels may be observed. Compliance with the basic SAR restrictions has therefor to be verified. SAR (W/kg) is a measure of the rate of RF energy absorption in tissue. The table below shows the localized SAR limits for the general public (uncontrolled environment) and workers (controlled environment) in the ICNIRP and ANSI/IEEE guidelines. Mobile communication equipment are usually used by the general public and should consequently be in compliance with the general public limits, which are 2.0 W/kg averaged in 10 gram of tissue in the ICNIRP guidelines and 1.6 W/kg averaged in 1 gram in the ANSI/IEEE standard. Because of the lower limit and the smaller averaging mass, the ANSI/IEEE limit is slightly more conservative than the ICNIRP limit. The averaging times are also different, 6 minutes in the ICNIRP recommendations and 30 minutes in the IEEE guidelines. The 2.0 W/kg (10 g) SAR limit has also been adopted in a European Prestandard from CENELEC [3] and in guidelines from the Ministry of Post and Telecommunications in Japan [4]. The 1.6 W/kg (1g) SAR limit has been adopted by the FCC as a regulation in the U.S. [6], and also as the basic restriction in preliminary Australian and Canadian standards [5,6]. The FCC requires SAR testing of mobile phones since 1997 [6,10]. Similar requirements were introduced in Australia February 1, 1999 [7] and will be introduced in Canada during 1999. In Europe and Japan regulations are expected within the next few years. SAR test standards for mobile communication equipment are under development by IEC, CENELEC, IEEE and ARIB. In the year 2000, it is expected that the first international standard will be published. Technical documents describing SAR test methods and procedures are already available from CENELEC, ARIB, ACA and the FCC [7-10]. Standard/GuidelineLocalized SAR limit (W/kg) General public (uncontrolled) Localized SAR limit (W/kg) Workers (controlled) ICNIRP (1998)2.0 (10 g)10 (10 g) ANSI/IEEE (1992)1.6 (1 g)8.0 (1g) Internal limited INSTRUCTION2 (4) Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other)Nr - No. ERA/T/UF Christer TörnevikT/U-98:446 Dokansv/Godk – Doc respons/ApprovedKontr - CheckedDatum - Date RevFile ERA/T/UF Christer Törnevik2000-03-17C 2. Purpose of the Ericsson SAR measurement specification The purpose of the Ericsson SAR measurement specification is to describe how SAR tests shall be conducted in the three SAR test laboratories in Ericsson, which are: • The Ericsson EMF Research Laboratory at Ericsson Research in Kista (Contacts: ERA/T/UF Christer Törnevik or ERA/T/UD Martin Siegbahn) • The ECS SAR laboratory at Ericsson Mobile Communications in Lund (Contacts: ECS/TN/FAC Thomas Bolin or ECS/TA/FA Ramadan Plicanic) • The EUS SAR laboratory at Ericsson Inc. in RTP (Contacts: EUS Russ Holshouser or EUS Mark Douglas) All these laboratories are equipped with the DASY3 SAR test system from Schmid & Partner Engineering AG (SPEAG). Since there is not yet an official standard that defines and describes SAR test procedures, it is necessary to specify internal Ericsson procedures for testing of mobile communication equipment. When an international SAR test standard is available, the Ericsson SAR measurement specification will be partly or completely replaced by this standard. The Ericsson SAR measurement specification may be submitted to agencies like the FCC (USA), ACA (Australia) and Industry Canada if requested. 3. Applicability of the Ericsson SAR measurement specification The Ericsson SAR test measurement specification shall always be followed when testing for compliance with SAR limits for handheld radio products o…

Text truncated - open the document above for the full version.

REPORT 1 (12) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1667/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-08-02A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\Source\A1228c body.doc EN Addendum to “SAR Test Report: A1228c” Date of test: July 11, 2000 Laboratory: Electromagnetic Near Field and Radio Frequency Dosimetry Laboratory Ericsson, Inc. 7001 Development Drive, P.O. Box 13969, Research Triangle Park, NC, 27709, USA Test Responsible: Mark Douglas, Ph.D. Senior Staff Engineer, Antenna Development Group [email protected] (919) 472-6334 This laboratory is accredited to ISO/IEC Guide 25-1990 to perform the following electromagnetic tests: Specific Absorption Rate (SAR), dielectric parameters, and RF power measurement on the following types of products: Wireless communications devices A2LA certificate Number: 1650-01 Statement of Compliance: Ericsson, Inc. declares under its sole responsibility that the that the product Ericsson A1228c to which this declaration relates, is in conformity with the appropriate RF exposure standards, recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) REPORT 2 (12) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1667/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-08-02A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\Source\A1228c body.doc EN © Ericsson, Inc. 2000 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Ericsson encourages all feedback, both positive and negative, on this test report. REPORT 3 (12) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1667/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-08-02A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\Source\A1228c body.doc EN Table of Contents 1. Introduction4 2. Device Under Test4 2.1Antenna description4 2.2Device description4 3. Test equipment4 3.1 Dosimetric system4 3.2Additional equipment5 4. Electrical parameters of the tissue simulating liquid5 5. System accuracy verification5 6. Test results5 References6 Appendix 1: SAR distribution comparison for system accuracy verification7 Appendix 2: SAR distribution plots9 Appendix 3: Position of Device on Phantom11 Appendix 4: Probe calibration parameters12 REPORT 4 (12) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1667/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-08-02A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\Source\A1228c body.doc EN 1. Introduction In this test report, compliance of the Ericsson A1228c portable telephone with RF safety guidelines is demonstrated (applicable RF safety guidelines are given in [1]). The device was tested in accordance with the latest available test guidelines [1]. Detailed procedures of the test are described in the Ericsson SAR Measurement Specification [2]. 2. Device Under Test 2.1 Antenna description Type Fixed stub Location Left side length30 mm Dimensions width at base10 mm Configuration Helix 2.2 Device description Device model A1228c Serial number UA201988XW Mode 800 AMPS800 CDMA Multiple Access Scheme FDMACDMA Maximum Output Power Setting 1 26.0 dBm23.5 dBm Factory Tolerance in Power Setting ± 0.25± 0.25 Maximum Peak Output Power 2 26.25 dBm23.75 dBm Duty Cycle 11 Transmitting Frequency Range 824 – 837 MHz824 – 837 MHz Prototype or Production Unit Prototype 3. Test equipment 3.1 Dosimetric system SAR measurements were made using the DASY3 professional system (software version 3.1c), manufactured by Schmid & Partner Engineering AG and installed February, 1998. The total SAR assessment uncertainty (K = 1) of the system is ±16% and includes a +15% offset (overestimation). The extended uncertainty (K = 2) is ±32% with a +15% offset. This results in a total uncertainty range of –1% to +31% for K = 1, or –17% to +47% for K = 2. The equipment list is given below. Description Serial NumberDue Date DASY3 DAE V1 3454/01 E-field probe ETDV5 13242/01 Dipole Validation Kit, D900V204912/00 1 This is the conducted power measured at the antenna port when the device is set to its highest power setting. It is measured at the middle of the transmit frequency band. Note that the output power may be different at other frequencies. 2 This equals the maximum output power setting plus the factory tolerance. REPORT 5 (12) Prepared (also subject responsible if other)No. RT/EUS/VR/X Mark Douglas919-472-6334 EUS/VR-00:1667/REP ApprovedCheckedDateRevFile EUS/VR/X Mark DouglasMGD2000-08-02A U:\FCC_TRNS\Fcc_410 Carmencita Linda\Exhibit11\Source\A1228c body.doc EN 3.2 Additional equipment Description Serial NumberDue Date Signal Generator HP8648C 3537A015989/00 Dielectric probe kit HP 85070B US330202568/00 Network analyzer HP 8752C 3410A031057/00 Power meter HP 437B3125U137292/01 Power sensor HP 8482H3318A070972/01 Tektronix CMD80847946/0712/01 4. Electrical parameters of the tissue simulating liquid Prior to conducting SAR measurements, the relative permittivity, ε r , and the conductivity, σ, of the tissue simulating liquids were measured with the dielectric probe kit. These values are shown in the table below. The mass density, ρ, entered into the DASY3 program is also given. Recommended values for permittivity, conductivity and mass density are also shown [3]. It is seen that the measured parameters result in an overestimation of SAR compared to the recommended values. Dielectric Parameters f (MHz) Limits / Measured εε…

Text truncated - open the document above for the full version.

Exhibit 8 addendum FCC Application Processing Branch Re: FCC ID AXATR-389-A2 Applicant: Ericsson Inc Correspondence Reference Number: 15555 731 Confirmation Number: EA98067 Below is our response as mentioned in correspondence 15555. The statement below allows us to meet the requirements for free trade and your concerns on the use of third party accessories. We plan to place this statement on an insert with the manual until we are able to use our existing stock of manuals. Future manuals will have the statement added into the safety section of the manual. Body Worn statement Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (i.e., at the ear and worn on the body) as required by the FCC for each model. Body worn measurements are made while the phone is in use and worn on the body with an Ericsson accessory. The design and composition of an access…
