AZ489FT7187Portable 2-Way Radio with Bluetooth, Bluetooth LE, WIFI 2.4GHz, WIFI 5GHz, LTE

en-US es-LA fr-CA pt-BR RF Energy Exposure Training and Product Safety Information for Mission Critical Devices Formation sur l’exposition aux RF et information sur la sécurité du produit pour appareils essentiels aux missions Capacitación sobre la exposición a energía de radiofrecuencia e información de protección del producto para dispositivos de misión crítica Treinamento sobre a Exposição à energia de RF e Informações de Segurança do Produto para Dispositivos de Missão Crítica https://learning.motorolasolutions.com/User_Documentation English Caution Before using this device, read this booklet which contains important operating instructions. For information on product details, brochures, user manuals and approved accessories. Please refer to www.motorolasolutions.com. Compliance with RF Exposure Standards National and international regulations require manufacturers to comply with the RF energy exposure limits for mission critical devices before they can be marketed. Your Motorola Solutions device is designed, manufactured, and tested to comply with all applicable national and international regulations for human exposure to radio frequency electromagnetic energy. When mission critical devices are used as a consequence of employment, applicable regulations may require users to be fully aware of and able to control their exposure to meet occupational requirements. RF Energy Exposure Awareness and Control Information and Operational Instructions for Occupational Use Notice: This device is intended for use in occupational/ controlled conditions where users are aware of their exposure and can exercise control over their exposure to meet the requirements in national and international regulations. This device is not authorized for general population, consumer use. For more information on what RF energy exposure is, and how to control your exposure to ensure compliance with established RF exposure limits, consult the following websites: •https://www.fcc.gov/ •https://www.osha.gov/ •https://osha.europa.eu/en •http://www.who.int/peh-emf/project/en/ •http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf11467.html •http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01904.html For additional user training information on exposure requirements, consult the following websites: •https://www.motorolasolutions.com/en_us/about/company-overview/ corporate-responsibility/governance-and-policies/wireless- communication-and-health-faqs.html •http://learning.motorolasolutions.com/ RF Exposure Compliance and Control Guidelines To control your exposure, and ensure compliance with the relevant RF exposure limits, always adhere to the following guidelines: • Do not remove any of the RF Exposure Labels if present from this device or its related accessories. • Attach these instructions to the device when you transfer it to other users. • Do not use this device if the operational requirements described herein are not met. Notice to Users (FCC) This device complies with Part 15 of the FCC rules per the following conditions: • This device may not cause harmful interference. • The device must accept any interference received, including interference that may cause undesired operation. • Changes or modifications made to this device, not expressly approved by Motorola Solutions, could void the authority of the user to operate this equipment. Operating Instructions • If your mission critical device operates similar to a mobile phone then hold your device at your ear when talking on it. • When using the device's speaker to communicate, hold the device in a vertical position in front of the face with the microphone (and other parts of the device) at least one inch (2.5 centimeters) away from the nose and lips. When engaged in Push-To-Talk (PTT) communications, to transmit (talk), press the PTT button. To receive calls, release the PTT button. • When worn on the body, always place the device in a Motorola Solutions approved clip, holder, holster, case, or body harness for this product. Special use cases for Mission Critical Devices English 1 • Fixed Installation: The device operates from a fixed location with at least 20 cm distance between antennas and bystanders. • Mobile Installation: The device operates on a vehicle with at least 20 cm distance between antennas and passangers or bystanders. For these special use cases, transmit only when people (bystanders and/or passengers) are at least at the minimum distance (as shown in Table 1) away from the antennas. This separation will ensure that there is sufficient distance from a properly installed (according to the installation instructions) antenna to satisfy the relevant RF exposure limits. Table 1: Rated Power of Mission Critical Device and Minimum Distance from Antennas Rated Power Minimum Distance of By- standers and Passengers from Antennas Less than 3.5 W8 in. (20 cm) 3.5 to 7 W1 ft (30 cm) 7 to 20 W2 ft (60 cm) 20 to 55 W3 ft (90 cm) • To ensure continued compliance with applicable RF exposure limits, use only Motorola Solutions approved, supplied or replacement batteries, and accessories. • For a list of Motorola Solutions approved accessories please refer to your user manual or visit www.motorolasolutions.com Acoustic Safety Exposure to loud noises from any source for extended periods of time may temporarily or permanently affect your hearing. The louder the volume, the less time is required before your hearing could be affected. Hearing damage from loud noise is sometimes undetectable at first and can have a cumulative effect. To protect your hearing: • Use the lowest volume necessary to do your job. • Turn up the volume only if you are in noisy surroundings. • Turn down the volume before adding headset or earpiece. • Limit the amount of time you use headsets or earpieces at high volume. • When using the device without a headset or earpiece, do not place the loud speaker directly against your ear. Medical Devices If you use a personal medical device, such as a pacemaker or hea…

Text truncated - open the document above for the full version.

TLK 200 Portable Radio User Guide WAVE PTX™ TWO-W AY RADIO MARCH 2026 © 2026 Motorola Solutions, Inc. All Rights Reserved. *MN011921A01* MN011921A01-AA Contents Legal and Support........................................................................................................................6 Intellectual Pr operty and Regulatory Notices......................................................................................................6 Legal and Compliance Statements......................................................................................................................7 Supplier's Declaration of Conformity............................................................................................................. 7 ISED WLAN Statement....................................................................................................................................8 Important Safety Information.........................................................................................................................8 Notice to Users (FCC and Innovation, Science and Economic Development Canada (ISED))...................8 Warranty and Service Support..............................................................................................................................9 Batteries and Chargers Warranty................................................................................................................... 9 The Workmanship Warranty......................................................................................................................9 The Capacity Warranty..............................................................................................................................9 Limited Warranty............................................................................................................................................. 9 MOTOROLA SOLUTIONS COMMUNICATION PRODUCTS.......................................................................9 I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG:...................................................................9 II. GENERAL PROVISIONS.......................................................................................................................10 III. STATE LAW RIGHTS:..........................................................................................................................10 IV. HOW TO GET WARRANTY SERVICE..................................................................................................10 V. WHAT THIS WARRANTY DOES NOT COVER..................................................................................... 10 VI. PATENT AND SOFTWARE PROVISIONS...........................................................................................11 VII. GOVERNING LAW..............................................................................................................................11 Chapter 1: Read Me First.........................................................................................................12 1.1 Software Version...........................................................................................................................................13 Chapter 2: Radio Care..............................................................................................................14 2.1 Cleaning and Disinfecting Your Radio.........................................................................................................14 Cleaning Your Radio......................................................................................................................................14 Disinfecting Your Radio.................................................................................................................................15 Chapter 3: Radio Overview.......................................................................................................16 3.1 Programmable Buttons................................................................................................................................17 3.1.1 Assignable Radio Functions................................................................................................................17 Chapter 4: Getting Started.......................................................................................................19 4.1 Inserting a SIM Card.....................................................................................................................................19 4.2 Attaching the Battery....................................................................................................................................19 4.3 Charging the Battery.....................................................................................................................................19 4.4 Attaching or Detaching the Antenna........................................................................................................... 20 Attaching the Antenna..................................................................................................................................20 Detaching the Antenna..................................................................................................................................20 MN011921A01-AA Contents 2 4.5 Turning the Radio On or Off..........................................................................................................................20 4.6 Adjusting the Volume...................................................................................................................................21 4.7 Activating the Preconfigured Wi-Fi Access Point (PWAP).........................................................................21 4.8 Selecting Talkgroups and Area Talkgroups.................................................................................................22 Chapter 5: Home Screen Ove…

Text truncated - open the document above for the full version.

Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7187/ IC: 109U-89FT7187 EXHIBIT 9A Template Revision 4 (14 October 2024) SHEET 1 OF 7 EXHIBIT 9 Internal Photographs (Pursuant to FCC Part 2.1033(b)(7), 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. RF board with Shields (Top) 9A 2. RF board without Shields (Top) 9B 3. RF board with Shields (Bottom) 9C 4. RF board without Shields (Bottom) 9D 5. Boards Assembly with Shields (Top) 9E 6. Boards Assembly with Shields (Bottom) 9F Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7187/ IC: 109U-89FT7187 EXHIBIT 9A Template Revision 4 (14 October 2024) SHEET 2 OF 7 Exhibit 9A - RF board with Shields (Top) HK2229A (TLK200) HK2300A (TLK200) HK2301A (TLK200) Exhibit 9B - RF board without Shields (Top) HK2229A (TLK200) HK2300A (TLK200) HK2301A (TLK200) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7187/ IC: 109U-89FT7187 EXHIBIT 9A Template Revision 4 (14 October 2024) SHEET 3 OF 7 Exhibit 9C - RF board with Shields (Bottom) HK2229A (TLK200) HK2300A (TLK200) HK2301A (TLK200) Exhibit 9D - RF board without Shields (Bottom) HK2229A (TLK200) HK2300A (TLK200) HK2301A (TLK200) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7187/ IC: 109U-89FT7187 EXHIBIT 9A Template Revision 4 (14 October 2024) SHEET 4 OF 7 Exhibit 9E - Boards Assembly with Shields (Top) HK2229A (TLK200) HK2300A (TLK200) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7187/ IC: 109U-89FT7187 EXHIBIT 9A Template Revision 4 (14 October 2024) SHEET 5 OF 7 HK2301A (TLK200) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7187/ IC: 109U-89FT7187 EXHIBIT 9A Template Revision 4 (14 October 2024) SHEET 6 OF 7 Exhibit 9F - Boards Assembly with Shields (Bottom) HK2229A (TLK200) HK2300A (TLK200) Applicant: Motorola Solutions Inc. FCC ID: AZ489FT7187/ IC: 109U-89FT7187 EXHIBIT 9A Template Revision 4 (14 October 2024) SHEET 7 OF 7 HK2300A (TLK200) *** END ***

FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 1 of 9 Exhibit 7B: SAR Test Report Photographs Motorola Solutions Inc EME Test Laboratory Motorola Solutions Malaysia Sdn Bhd Plot 2A, Medan Bayan Lepas Mukim 12 SWD 11900 Bayan Lepas Penang, Malaysia. FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 2 of 9 Report Revision History Date Revision Comments 03/17/2026 A Initial release FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 3 of 9 1.0 Highest SAR Test Position per body location 1.1 Body DUT w/ antenna AN000508A01with offered battery PMNN4578A and body worn kit PMLN7128A against the phantom without an audio accessory attached. Antenna kit # Separation Distances (mm) @ bottom surface of the DUT @ antenna’s base @ antenna’s tip AN000508A01 27 27 27 FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 4 of 9 1.2 Face Front of DUT w/ antenna AN000508A01with offered battery PMNN4578A separated 2.5cm from the phantom without an audio accessory attached. Antenna kit # Separation Distances (mm) @ bottom surface of the DUT @ antenna’s base @ antenna’s tip AN000508A01 30 31 31 2.5cm FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 5 of 9 2.0 Other SAR tested positions at the body 2.1 Body worn DUT with antenna AN000508A01with offered battery PMNN4578A and body worn kit PMLN8795A. against the phantom without an audio accessory attached. Antenna kit # Separation Distances (mm) @ bottom surface of the DUT @ antenna’s base @ antenna’s tip AN000508A01 20 29 31 3.0 DUT and Accessory Photos The purpose of these photos is to illustrate the tested accessories. Refer to Part 1 of 2, section 7.0 for additional details on the offered accessories. 3.1 Antenna dimension and photo(s): Antenna Kit # Physical Length (mm) Electrical Length AN000508A01 37 ¼ wave AN000508A01 FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 6 of 9 Main antenna connector Triband antenna FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 7 of 9 3.2 Body worn accessories DUT Side View Belt Clip PMLN7128A DUT Back View Belt Clip PMLN7128A Belt Clip PMLN7128A FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 8 of 9 DUT Back View Belt Clip PMLN8795A DUT Side View Belt Clip PMLN8795A Belt Clip PMLN8795A FCC ID: AZ489FT7187 / IC: 109U-89FT7187 Report ID: P1490N00-EME-00002/00005 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 9 of 9 3.3 Battery accessories: Side, Back and Front view: PMNN4578A 3.4 DUT Dimensions Height (mm) Width (mm) Depth (mm) Radio only (w/o battery) 140 58 26 Radio with battery PMNN4578A 140 58 26 For illustration purposes only - the following figure reflects the location of the device’s dimensions. Note: H = Height; W = Width; D = Depth W1 = (Width @ Top) / (Width @ PTT) D2 = (Depth @ Bottom) / (Depth @ PTT)

Motorola Solutions Inc FCC ID: AZ489FT7187 / IC: 109U-89FT7187 EXHIBIT 7A SHEET 1 OF 8 Exhibit 7A FCC/IC Test Setup Photo Report ID : 1490N00-RF-00013, 1490N00-RF-00014, 1490N00-RF-00015, 1490N00-RF-00016, 1490N00-RF-00017, 1490N00-EMC-00037, 1490N00-RF-00018, 1490N00-RF-00020, 1490N00-RF-00021, 1490N00-RF-00022, 1490N00-RF-00023, 1490N00-RF-00024, 1490N00-RF-00025, 1490N00-EMC-00029, 1490N00-EMC-00031 1490N00-EMC-00032, 1490N00-EMC-00033, 1490N00-EMC-00034, 1490N00-EMC-00035, 1490N00-EMC-00036, 1490N00-EMC-00038, 1490N00-EMC-00039, 1490N00-EMC-00040, 1490N00-EMC-00042, 1490N00-EMC-00043, 1490N00-EMC-00044, 1490N00-EMC-00046, 1490N00-EMC-00047, 1490N00-EMC-00050,1490N00-EMC-00051, 1490N00-EMC-00052, 1490N00-EMC-00053 FCC ID : AZ489FT7187 IC : 109U-89FT7187 Model Number : HK2300A Motorola Solutions Inc FCC ID: AZ489FT7187 / IC: 109U-89FT7187 EXHIBIT 7A SHEET 2 OF 8 Table of Contents 1.0 Pictures of Test Setup Photo for (ANSI C63.4-2014) ............................................................. 3 1.1. Power Line Conducted Emission Test Setup photo ................................................................ 3 1.1.1. Power Line Conducted Emission - Photo Front View ....................................... 3 1.1.2. Power Line Conducted Emission - Photo Side View ........................................ 4 1.2. Radiated Emission Test Setup Photo for (ANSI C63.26-2015)............................................... 5 1.2.1. Radiated Emission – Below 1GHz ..................................................................... 5 1.2.2. Radiated Emission – Above 1GHz ..................................................................... 5 1.3. Radiated Emission Test Setup Photo for (ANSI C63.10-2013)............................................... 6 1.3.1. Radiated Emission – Below 1GHz ..................................................................... 6 1.3.2. Radiated Emission – Above 1GHz ..................................................................... 6 1.4. RF Conducted Emission Test Setup Photo .............................................................................. 7 1.4.1. RF Conducted Emission (ANSI C63.26-2015) ................................................... 7 1.4.2. RF Conducted Emission (ANSI C63.10-2013) ................................................... 8 Motorola Solutions Inc FCC ID: AZ489FT7187 / IC: 109U-89FT7187 EXHIBIT 7A SHEET 3 OF 8 1.0 Pictures of Test Setup Photo for (ANSI C63.4-2014) 1.1. Power Line Conducted Emission Test Setup photo 1.1.1. Power Line Conducted Emission - Photo Front View Motorola Solutions Inc FCC ID: AZ489FT7187 / IC: 109U-89FT7187 EXHIBIT 7A SHEET 4 OF 8 1.1.2. Power Line Conducted Emission - Photo Side View Motorola Solutions Inc FCC ID: AZ489FT7187 / IC: 109U-89FT7187 EXHIBIT 7A SHEET 5 OF 8 1.2. Radiated Emission Test Setup Photo for (ANSI C63.26-2015) 1.2.1. Radiated Emission – Below 1GHz BROADBAND/LTE/5G NR/EIRP 1.2.2. Radiated Emission – Above 1GHz BROADBAND/LTE/5G NR/EIRP Motorola Solutions Inc FCC ID: AZ489FT7187 / IC: 109U-89FT7187 EXHIBIT 7A SHEET 6 OF 8 1.3. Radiated Emission Test Setup Photo for (ANSI C63.10-2013) 1.3.1. Radiated Emission – Below 1GHz 1.3.2. Radiated Emission – Above 1GHz Motorola Solutions Inc FCC ID: AZ489FT7187 / IC: 109U-89FT7187 EXHIBIT 7A SHEET 7 OF 8 1.4. RF Conducted Emission Test Setup Photo 1.4.1. RF Conducted Emission (ANSI C63.26-2015) BROADBAND/LTE Motorola Solutions Inc FCC ID: AZ489FT7187 / IC: 109U-89FT7187 EXHIBIT 7A SHEET 8 OF 8 1.4.2. RF Conducted Emission (ANSI C63.10-2013) BT/BTLE/WIFI 2.4GHz/WIFI 5GHz END OF REPORT

Report Template Document Number : FCD-0069 Report ID: 1490N00-RF-00013 Report Template Revision Number : Rev.U FCC ID: AZ489FT7187 IC: 109U-89FT7187 Page 1 of 76 MOTOROLA PENANG ADV. COMM. LABORATORY FCC / ISED TEST REPORT Motorola Solutions Malaysia Sdn. Bhd. Report Revision : Rev.B Plot 2A Medan Bayan Lepas, Mukim 12, S.W.D. 11900 Bayan Lepas, Penang, Malaysia. Date/s Tested Report Issue Date : : 03-February-2026 - 30-March-2026 24-April-2026 Test Location : MOTOROLA PENANG ADV. COMM. LABORATORY Manufacturer/Location : Motorola Solutions Malaysia Sdn Bhd Plot 2A, Medan Bayan Lepas, Mukim 12 SWD, 11900 Bayan Lepas, Penang, Malaysia Requestor : Ooi Vern Yin Product Type Product Marketing Name (PMN) : : Portable TLK 200 Hardware Version Identification Number (HVIN) : HK2300A Frequency Band : 2.402 - 2.480 GHz Max RF Output Power : GFSK - 10mW PI/4 DPSK - 11.22mW 8DPSK - 14.13mW Applicant Name : Motorola Solutions Inc Applicant Address : Plot 2A, Medan bayan Lepas, Mukim 12 S.W.D. 11900 Bayan Lepas, Penang, Malaysia FCC Registrations ISED Registration : : 461337 109AK Firmware Version Identification Number (FVIN) : D01.00.01 (BP), D01.06.08 (AP) The equipment was tested accordance to the requirement listed below: (2.4GHz BT) FCC 47CFR Part 15C ISED RSS 247 Issue 4 PASS This report shall not be reproduced without written approval from an officially designated representative of the Motorola Penang Adv. Comm. Laboratory. The results and statements contained in this report pertain only to the device(s) evaluated. Prepared By: Approved Signatory: _________________________ _________________________ Ahmad Azim Fashan Bin Fadzil Vincent Foong Chuen Kit Test Personnel Responsible Engineer Report Template Document Number : FCD-0069 Report ID: 1490N00-RF-00013 Report Template Revision Number : Rev.U FCC ID: AZ489FT7187 IC: 109U-89FT7187 Page 2 of 76 Table of Contents 1.0. General Information ......................................................................................................................... 3 2.0. Summary of Test Results................................................................................................................. 4 3.0. Measurement Uncertainty ............................................................................................................... 5 4.0. Equipment List .................................................................................................................................. 5 5.0. Test Mode Applicability and Test Channel Detail .......................................................................... 7 6.0. Transmitter Test Parameters .......................................................................................................... 8 6.1. Conducted RF Output Power (Peak) ........................................................................................ 8 6.1.1. Test Setup .......................................................................................................................... 8 6.1.2. Test Limits: ........................................................................................................................ 8 6.1.3. Test Data: ........................................................................................................................... 8 6.2. 20dB Channel Bandwidth ........................................................................................................ 12 6.2.1. Test Setup ........................................................................................................................ 12 6.2.2. Test Limits: ...................................................................................................................... 12 6.2.3. Test Data: ......................................................................................................................... 12 6.3. Band-edge Conducted Spurious Emission ............................................................................ 16 6.3.1. Test Setup ........................................................................................................................ 16 6.3.2. Test Limits ....................................................................................................................... 16 6.3.3. Test Result ....................................................................................................................... 16 6.4. Dwell time on each channel .................................................................................................... 20 6.4.1. Test Setup ........................................................................................................................ 20 6.4.2. Test Limits: ...................................................................................................................... 20 6.4.3. Test Result ....................................................................................................................... 21 6.5. Number of hopping Frequency ............................................................................................... 25 6.5.1. Test Setup ........................................................................................................................ 25 6.5.2. Test Limits: ...................................................................................................................... 25 6.5.3. Test Result ....................................................................................................................... 25 6.6. Channel Separation ................................................................................................................. 27 6.6.1. Test Setup ........................................................................................................................ 27 6.6.2. Test Limits: ...................................................................................................................... 27 6.6.3. Test Result .................…

Text truncated - open the document above for the full version.

Report ID.: 2026-AG-PEN001 TLK200 WIFI ANTENNA GAIN MEASUREMENT REPORT REPORT NO.: MODEL NO.: TESTED DATE: ISSUED: 2026-AG-PEN001 TLK200 2026.02.19 2026.02.26 MANUFACTURER : Motorola Solutions Inc. ADDRESS : 2000 Progress Parkway, SCHAUMBURG IL 60196, UNITED STATES ISSUED BY : Motorola Solutions Malaysia Sdn Bhd. ADDRESS : Motorola Solutions, 11900 Bayan Lepas, Penang, Malaysia TEST LOCATION : Motorola Solutions, 11900 Bayan Lepas, Penang, Malaysia This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report ID.: 2026-AG-PEN001 RELEASE CONTROL RECORD REPORT NO. REASON FOR CHANGE DATE ISSUED 2026-AG-PEN001 Original release 2025.02.26 Table of Contents 1 General Information ................................................................................................................... 3 2 Measurement Setup .................................................................................................................. 4 3 Test Procedure .......................................................................................................................... 4 4 Test Lab Environment Conditions ............................................................................................. 5 5 Test Equipment List ................................................................................................................... 5 6 Device Configuration ................................................................................................................. 5 6.1 Bands and Protocols Supported by Each Antenna ............................................................ 5 7 Evaluation Summary ................................................................................................................. 6 7.1 Conducted Power, TRP, EIRP .............................................................…

Text truncated - open the document above for the full version.
