AZ499FT58792-way Portable Radio with BT, BTLE, WIFI, NFC and LTE

en-US fr-CA es-LA pt-BR RF Energy Exposure Training and Product Safety Information for Portable Two-Way Radios Formation sur l’exposition aux RF et information sur la sécurité du produit pour radios bidirectionnelles portatives Capacitación sobre la exposición a energía de radiofrecuencia e información de protección del producto para radios de dos vías portátiles Treinamento sobre a Exposição à Energia de RF e Informações de Segurança do Produto para Rádios Portáteis Bidirecionais https://motr.la/docs Caution Before using this radio, read this booklet which contains important operating instructions. F or information on product details, brochures, user manuals and approved accessories. Please refer to www.motorolasolutions.com. Compliance with RF Exposure Standards National and international regulations require manufacturers to comply with the RF ener gy exposure limits for portable two-way radios before they can be marketed.Your Motorola Solutions two-way radio is designed, manufactured, and tested to comply with all applicable national and international regulations for human exposure to radio frequency electromagnetic energy. RF Energy Exposure Awareness and Control Information and Operational Instructions for General Population and Uncontrolled Environment Use For more information on what RF energy exposure is, consult the following websites: ●https:/ /www.fcc.gov/ ●https://www.who.int/health-topics/electromagnetic-fields/ ●https://www.arpansa.gov.au/ For additional user training information on exposure requirements, consult the following websites: ●http://responsibility.motorolasolutions.com/index.php/ourapproach/ wirelesscommhealth/ ●https://motr.la/docs ●https://learningcenter.motorolasolutions.com/ RF Exposure Compliance and Control Guidelines ●Do not r emove any of the RF Exposure Labels if present from this device or its related accessories. ●Attach these instructions to the device when you transfer it to other users. ●Do not use this device if the operational requirements described herein are not met. Notice to Users (FCC) This device complies with Part 15 of the FCC rules per the following conditions: ●This de vice may not cause harmful interference. ●The device must accept any interference received, including interference that may cause undesired operation. ●Changes or modifications made to this device, not expressly approved by Motorola Solutions, could void the authority of the user to operate this equipment. Operating Instructions ●T ransmit no more than 50% of the time. To transmit (talk), press the Push-To-Talk (PTT) button. To receive calls, release the PTT button. ●Hold the radio in a vertical position in front of the face with the microphone (and other parts of the radio including the antenna) at least 1 in. (2.5 cm) away from the nose or lips. Antenna should be kept away from the eye. ●When worn on the body, always place the radio in a Motorola Solutions-approved clip, holder, holster, case, or body harness for this product. ●DO NOT hold the antenna when the radio is transmitting. ●DO NOT use any portable radio that has a damaged antenna. If a damaged antenna comes into contact with your skin, a minor burn can result. English 1 ●T o ensure continued compliance with applicable RF exposure limits, use only Motorola Solutions approved, supplied or replacement antennas, batteries, and accessories. ●For a list of Motorola Solutions approved accessories please refer to your user manual or visit www.motorolasolutions.com. Acoustic Safety Exposure to loud noises from any source for extended periods of time may temporarily or permanently aff ect your hearing. The louder the volume of the radio, the sooner your hearing will be affected. Hearing damage from loud noise is sometimes undetectable at first, and can have a cumulative effect. To protect your hearing: ●Use the lowest volume necessary to do your job. ●Turn up the volume only if you are in noisy surroundings. ●Turn down the volume before adding headset or earpiece. ●Limit the amount of time you use headsets or earpieces at high volume. ●When using the radio without a headset or earpiece, do not place the radio speaker directly against your ear. Medical Devices If you use a personal medical device, such as a pacemaker or hearing aid, consult the manufactur er of your device to determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information. Holsters Incorporating Magnets Some Motorola Solutions holsters incorporate strong, neodymium magnets. If you use a personal medical de vice, such as a pacemaker or hearing aid, consult the manufacturer of your device to determine if it can be used in close proximity to magnets. Your physician may be able to assist you in obtaining this information. Also be aware that magnets can damage other products, including cell phones, computers, hard drives, and other electronic devices, as well as credit cards and magnetic media. Keep the holster away from any mechanical device that could be affected by a magnetic field. Consult the manufacturer of your product to determine if your device or product can be used in close proximity to magnets. Operational Warnings The following explains the operational warnings: F or Vehicle With Air Bags WARNING: ●Ref er to vehicle manufacturer's manual prior to installation of electronic equipment to avoid interference with air bag wiring. ●DO NOT place a portable radio in the area over an air bag or in the air bag deployment area. Air bags inflate with great force. If a portable radio is placed in the air bag deployment area and the air bag inflates, the radio may be propelled with great force and cause serious injury to occupants of the vehicle. English 2 Potentially Explosive Atmospheres WARNING: ●Do not carr y a radio that is not certified for Hazardous Locations into a potentially explosive atmosphere. It could result in a serious injury or death. You should only use a radio certified for hazard…

Text truncated - open the document above for the full version.

CB900D Digital 900 MHz Call Bo x Installation Guide PROFESSIONAL DIGITAL TWO-WAY RADIO JANUARY 2026 © 2026 Motorola Solutions, Inc. All Rights Reserved. *MN011830A01* MN011830A01-AA Legal and Support Intellectual Property and Regulatory Notices Cop yrights The Motorola Solutions products described in this document may include copyrighted Motorola Solutions computer programs. Laws in the United States and other countries preserve for Motorola Solutions certain exclusive rights for copyrighted computer programs. Accordingly, any copyrighted Motorola Solutions computer programs contained in the Motorola Solutions products described in this document may not be copied or reproduced in any manner without the express written permission of Motorola Solutions. No part of this document may be reproduced, transmitted, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without the prior written permission of Motorola Solutions, Inc. Trademarks MOTOROLA, MOTO, MOTOROLA SOLUTIONS, and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. License Rights The purchase of Motorola Solutions products shall not be deemed to grant either directly or by implication, estoppel or otherwise, any license under the copyrights, patents or patent applications of Motorola Solutions, except for the normal nonexclusive, royalty-free license to use that arises by operation of law in the sale of a product. Open Source Content This product may contain Open Source software used under license. Refer to the product installation media for full Open Source Legal Notices and Attribution content. European Union (EU) and United Kingdom (UK) Waste of Electrical and Electronic Equipment (WEEE) Directive The European Union's WEEE directive and the UK's WEEE regulation require that products sold into EU countries and the UK must have the crossed-out wheelie bin label on the product (or the package in some cases. As defined by the WEEE directive, this crossed-out wheelie bin label means that customers and end users in EU and UK countries should not dispose of electronic and electrical equipment or accessories in household waste. Customers or end users in EU and UK countries should contact their local equipment supplier representative or service center for information about the waste collection system in their country. Disclaimer Please note that certain features, facilities, and capabilities described in this document may not be applicable to or licensed for use on a specific system, or may be dependent upon the characteristics of a specific mobile subscriber unit or configuration of certain parameters. Please refer to your Motorola Solutions contact for further information. © 2026 Motorola Solutions, Inc. All Rights Reserved MN011830A01-AA Legal and Support 2 Legal and Compliance Statements Notice t o Users (FCC) This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: ●This device may not cause harmful interference, and ●The device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made to this device, not expressly approved by Motorola Solutions, could void the authority of the user to operate this equipment. Notice to Users (Innovation, Science and Economic Development Canada (ISED)) This device complies with Innovation, Science and Economic Development Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: ●This device may not cause interference, and ●This device must accept any interference, including interference that may cause undesired operation of the device. Supplier's Declaration of Conformity Supplier's Declaration of Conformity P er FCC CFR 47 Part 2 Section 2.1077(a) Responsible Party Name: Mot orola Solutions, Inc. Address: 2000 Progress Pkwy, Schaumburg, IL. 60196 Phone Number: 1-800-927-2744 Hereby declares that the product: Model Name: CB900D conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d), and section 15.109(a) Class B Digital Device As a personal computer peripher al, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and MN011830A01-AA Legal and Support 3 2. This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that in‐ terference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the inter‐ ference by one or more of the following measures: ●Reorient or relocate the receiving antenna. ●Increase the separation between the equipment and receiver. ●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ●Consult the dealer or an experienced radio or TV technician for help. Important Safety Instructions This document contains important safety and operating instructions. Read these instructions carefully and save them for future reference. CAUTION: ●To reduce the risk of damage to the power cord or the cable, pull the plug rather than the power cord or the cable wh…

Text truncated - open the document above for the full version.

CB900D Digital 900 MHz Call Bo x Quick Reference Guide OCTOBER 2025 © 2025 Motorola Solutions, Inc. All Rights Reserved. *MN011435A01* MN011435A01-AA CB900D Digital 900 MHz Call Box Quick Reference Guide This Quick Reference Guide covers the basic operation of the device. F or manuals on operational details and information, see MN011830A01, CB900D Digital 900 MHz Call Box Installation Guide and MN011831A01, CB900D Digital 900 MHz Call Box User Guide at https://motr.la/docs. For Australia, New Zealand, and the Pacific Islands only, see http:// www.motorolasolutions.com/cb900d-resources. Important Safety Information IMPORTANT: Befor e using this product, read the following instructions: ●RF Energy Awareness and Acoustic Safety information and operating instructions. ●MN009958A01, RF Energy Exposure Training and Product Safety Information for Portable Two-Way Radios which contains important operating instructions for safe usage and RF Energy awareness and control for compliance with applicable standards and Regulations. NOTE: This de vice has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ●Reorient or relocate the receiving antenna. ●Increase the separation between the device and receiver. ●Connect the device into an outlet on a circuit different from that to which the receiver is connected. ●Consult the dealer or an experienced radio/TV technician for help. Call Box Overview 1-Way Call Box2-Way Call BoxBase Station Figure 1: Call Box 3 7 8 2 1 6 5 4 9 10 LabelDescription 1End escalation 2Front plate cover 3LED indicator (Crescent) 4Graphic paper 5Speaker 6Microphone 7Battery module English 1 LabelDescription 8Power port 9Micro-USB port 10Battery connector pin Figure 2: Base Station 2 5 1 9 8 7 4 3 6 LabelDescription 1Top programmable button 2Base Station front plate 3LCD display 4Channel button (up and down) 5Volume button (left and right) 6Speaker 7PTT button 8Microphone 9LED indicator Table 1: LED Indicators LabelDescription BlueConnection is established. Device is ready for use. GreenTransmitting audio communication. RedCritical error, warnings, and power states. Getting Started FeatureDescription Field Programming Programs a radio in the field without a computer . License-free 900 MHz Depending on the regions, the call box operates on the following license-free frequencies. North America 902 MHz-928 MHz Australia/New Zealand 915 MHz-928 MHz Latin America and Caribbean region 902 MHz-907 MHz 915 MHz-928 MHz Volume LevelAdjustable from 1–10 through computer pr ogramming or field programming. Battery Power●Operates on 6X AA Lithium cells with 0.5 W transmit power. ●Lasts approximately one year with seven daily button presses and one call cycle. Low Battery Alert Transmits an alert when batteries are low, allowing for timely replacement. External Power Powers the device through an external direct power supply using a USB-C cable. English 2 FeatureDescription Voice Messages Records the following custom voice messages: ●Assur ance message announced through CB900D speaker. ●Radio voice alerts that transmit to your Mototalk radio. ●Low battery status during operation. 2-Way Call Box or Base Station Mode Enables the feature through computer programming, with no separate hardware required. Call Box Main Body The call box includes a battery module. NOTE: F or continuous operation, use a Motorola Solutions approved power supply and USB cable, PMKN4294_. Only Motorola Solutions approved accessories must be used to ensure device safety and compliance. Use of non-compliant third-party accessories can damage the device and void the warranty. For a list of approved accessories, see MN011831A01, CB900D Digital 900 MHz Call Box User Guide at https://motr.la/docs. Table 2: Call Box With Battery ModuleWith Direct Power Table 3: Base Station With Battery ModuleWith Direct Power NOTE: Not r ecommended using a battery operated Base Station. NOTE: The Base Station is r ecommended for use on the desktop cradle PMLN8796_. Call Box Mounting A PMLN8799_ wall bracket is provided as a standard accessory. F or operational details and information on mounting options, see MN011830A01 CB900D Digital 900 MHz Call Box Installation Guide at https://motr.la/docs. NOTE: Mount the de vice at a height of 6 ft (2 m) or less. English 3 Wall Mount (Inbox/ AAD)–PMLN8799_ With Battery Module With Direct Power Call Box Basic Operations Table 4: Call Box Interaction 1-Way Call Box 2-Way Call Box Base Station First short pr ess Send help alert to the radio and play assurance message. Not applicable First press and hold Send help alert to the radio and play assur ance message. Not applicable Second short press Send help alert if the time since the first press exceeds the configured Hold Off Period time. Not applicable Press and hold Not applicable Transmit call to the channel. Transmit call to the channel. Table 5: Programmable Button–Short Press 1-Way Call Box 2-Way Call Box Base Station Depending on the following pr ogrammable setting: Depending on the following programmable setting: Depending on the following programmable setting: 1-Way Call Box 2-Way Call Box Base Station ●If set t o End alert or call, the alert is terminated. ●If the setting is not configured, no action is taken. ●If set to End alert or call, the alert or the call s…

Text truncated - open the document above for the full version.

FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.37 Page 1 of 64 DECLARATION OF COMPLIANCE SAR ASSESSMENT Motorola Solutions Inc. EME Test Laboratory Motorola Solutions Malaysia Sdn Bhd Plot 2A, Medan Bayan Lepas, Mukim 12 SWD 11900 Bayan Lepas Penang, Malaysia. Date of Report: 08/28/2025 Report Revision: B Responsible Engineer: Alfred Hoe (EME Engineer) Report Author: Muhammad Zakwan Bin Zaidi (EME Senior Technician) Date/s Tested: Test Location: 07/21/2025-07/24/2025, 07/24/2025, 08/11/2025, 08/19/2025 Penang EME Laboratory Manufacturer: Motorola Solutions Malaysia Sdn Bhd. Manufacturer Location: Plot 2A, Medan Bayan Lepas Mukim, 12 SWD, 11900 Bayan Lepas, Penang, Malaysia DUT Description: CB900D 0.5W 900MHZ CALL BOX (US/CAN) Test TX mode(s): CW (PTT) Max. Power output: Refer table 3 Tx Frequency Bands: Refer table 3 Signaling type: Refer table 3 Model(s) Tested: CBS101NBKLBA Model(s) Certified: (HVIN/PMN) Refer 1.0 Introduction Serial Number(s): 08722BN0081 Classification: General Population / Uncontrolled Environment Applicant Name: Applicant Address: Motorola Solutions Inc. Plot 2A, Medan Bayan Lepas Mukim, 12 SWD, 11900 Bayan Lepas, Penang, Malaysia Firmware Version (FVIN): A0.00.06 FCC ID: AZ499FT5879 FCC Test Firm Registration Number: 823256 IC: 109U-99FT5879 ISED Test Site registration: 24843 The test results clearly demonstrate compliance with General Population / Uncontrolled Environment RF Exposure limits of 1.6 W/kg averaged over 1 gram per the requirements of FCC 47 CFR § 2.1093 and RSS-102 (Issue 6) Based on the information and the testing results provided herein, the undersigned certifies that when used as stated in the operating instructions supplied, said product complies with the national and international reference standards and guidelines listed in section 4.0 of this report (no deviation from standard methods). This report shall not be reproduced without written approval from an officially designated representative of the Motorola Solutions Inc EME Laboratory. I attest to the accuracy of the data and assume full responsibility for the completeness of these measurements. The results and statements contained in this report pertain only to the device(s) evaluated. Saw Sun Hock (Approval Signatory) Approved Date: 08/28/2025 FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Rev. 13.37 Page 2 of 64 Table of Contents: 1.0 Introduction .................................................................................................................... 4 2.0 FCC SAR Summary ......................................................................................................... 4 3.0 Abbreviations / Definitions ............................................................................................ 5 4.0 Referenced Standards and Guidelines .......................................................................... 5 5.0 SAR Limits ...................................................................................................................... 6 6.0 Description of Device Under Test (DUT)........................................................................ 6 7.0 Optional Accessories and Test Criteria ......................................................................... 7 7.1 Antenna ................................................................................................................ 7 7.2 Battery.................................................................................................................. 7 7.3 Additional Accessories........................................................................................ 7 8.0 Description of Test System ............................................................................................ 8 8.1 Descriptions of Robotics/Probes/Readout Electronics .................................... 8 8.2 Description of Phantom(s) .................................................................................. 9 8.3 Description of Simulated Tissue......................................................................... 9 9.0 Additional Test Equipment ........................................................................................... 10 10.0 SAR Measurement System Validation and Verification .............................................. 11 10.1 System Validation ............................................................................................. 11 10.2 System Verification ........................................................................................... 11 10.3 Equivalent Tissue Test Results ......................................................................... 12 11.0 Environmental Test Conditions .................................................................................... 13 12.0 DUT Test Setup and Methodology ............................................................................... 14 12.1 Measurements ................................................................................................... 14 12.2 DUT Configuration(s) ........................................................................................ 15 12.3 DUT Positioning................................................................................................. 15 12.3.1 Body ..................................................................................................... 15 12.3.2 Head ..................................................................................................... 15 12.3.3 Face ...................................................................................................... 15 12.4 DUT Test Channels ............................................................................................ 15 12.5 SAR Result Scaling Methodology ..................................................................... 16 12.6 DUT Test Plan ..........…

Text truncated - open the document above for the full version.

PageNumber:1of1 ReportVersion:1.0 AntennaReport Antennatestsetupphotograph

FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 1 of 8 Exhibit 7B: SAR Test Report Photographs Motorola Solutions Inc EME Test Laboratory Motorola Solutions Malaysia Sdn Bhd Plot 2A, Medan Bayan Lepas Mukim 12 SWD 11900 Bayan Lepas Penang, Malaysia. FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 2 of 8 Report Revision History Date Revision Comments 08/27/2025 A Initial release 08/28/2025 B Update accessories info used FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 3 of 8 APPENDIX G DUT Test Position Photos FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 4 of 8 1.0 Highest SAR Test Position per location 1.1 Body N/A 1.2 Face Front of DUT w/ C5226-510001-A (internal antenna) with offered Energizer L91 battery separated 2.5cm from the phantom with accessory PMLN8799A attached. Antenna kit # Separation Distances (mm) @ bottom surface of the DUT @ antenna’s base @ antenna’s tip C5226-510001-A 34 34 0 2.5 cm FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 5 of 8 APPENDIX H DUT & Accessory Photos FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 6 of 8 2.0 DUT and Accessory Photos The purpose of these photos is to illustrate the tested accessory. Refer to Part 1 of 2, section 7.0 for additional detail on the offered accessory. 2.1 Antenna dimension and photo Microphone C5226-510001-A (Internal LMR Antenna) FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 7 of 8 2.2 Battery accessories AA Lithium Non-rechargeable battery 2.2 Additional accessories PMLN8799A (Front and Back view) DUT with PMLN8799A (Back and Side view) FCC ID: AZ499FT5879 / IC: 109U-99FT5879 Report ID: P1382N00-EME-00001 Motorola Solutions Inc. EME Form-SAR-Rpt-Ex7B-Rev. 13.19 Page 8 of 8 2.3 DUT Dimensions Height (mm) Width (mm) Depth (mm) Radio only (w/o battery) 109.41 109.41 59.14 Radio with battery 109.41 109.41 59.14 For illustration purposes only - the following figure reflects the location of the device’s dimensions. Note: H = Height; W = Width; D = Depth W1 = (Width @ Top) / (Width @ PTT) D2 = (Depth @ Bottom) / (Depth @ PTT)

Motorola Solutions Inc FCC ID: AZ499FT5879 / IC: 109U-99FT5879 EXHIBIT 7A SHEET 1 OF 8 Exhibit 7A FCC/IC Test Setup Photo Report ID : 1382N00-RF-00001 FCC ID : AZ499FT5879 IC : 109U-99FT5879 Model Number : CBS101NBKLBA Motorola Solutions Inc FCC ID: AZ499FT5879 / IC: 109U-99FT5879 EXHIBIT 7A SHEET 2 OF 8 Table of Contents 1.0 Pictures of Test Setup Photo for LMR/BT/BT LE/WLAN 2.4GHz ................................................... 3 1.1. Power Line Conducted Emission Test Setup photo................................................................. 3 1.1.1. Power Line Conducted Emission - Photo Front View .................................................. 3 1.1.2. Power Line Conducted Emission - Photo Side View .................................................... 3 1.2. Radiated Emission test setup photo for LMR (ANSI C63.26:2015) ........................................ 3 1.2.1. Radiated Emission – Below 1GHz ................................................................................ 4 1.2.2. Radiated Emission – Above 1GHz ................................................................................ 4 1.3. Radiated Emission test setup photo for BT/BT LE/WLAN 2.4GHz (ANSI C63.10: 2013) ..... 5 1.3.1. Radiated Emission – Below 1GHz ................................................................................ 5 1.3.2. Radiated Emission – Above 1GHz ................................................................................ 5 1.4. RF Conducted Emission Test Setup photo ............................................................................... 6 1.4.1. RF Conducted Emission (LMR – ANSI C63.26:2015) .................................................. 6 1.4.2. RF Conducted Emission (BT/BT LE/WLAN 2.4GHz – ANSI C63.10: 2013) ............... 7 Motorola Solutions Inc FCC ID: AZ499FT5879 / IC: 109U-99FT5879 EXHIBIT 7A SHEET 3 OF 8 1.0 Pictures of Test Setup Photo for (ANSI C63.4: 2014) 1.1. Power Line Conducted Emission Test Setup photo 1.1.1. Power Line Conducted Emission - Photo Front View Not applicable. 1.1.2. Power Line Conducted Emission - Photo Side View Not applicable. Motorola Solutions Inc FCC ID: AZ499FT5879 / IC: 109U-99FT5879 EXHIBIT 7A SHEET 4 OF 8 1.2. Radiated Emission test setup photo for (ANSI C63.26:2015) 1.2.1. Radiated Emission – Below 1GHz Not applicable. 1.2.2. Radiated Emission – Above 1GHz Not applicable. Motorola Solutions Inc FCC ID: AZ499FT5879 / IC: 109U-99FT5879 EXHIBIT 7A SHEET 5 OF 8 1.3. Radiated Emission test setup photo for (ANSI C63.10: 2013) 1.3.1. Radiated Emission – Below 1GHz Not applicable. 1.3.2. Radiated Emission – Above 1GHz Not applicable. Motorola Solutions Inc FCC ID: AZ499FT5879 / IC: 109U-99FT5879 EXHIBIT 7A SHEET 6 OF 8 1.4. RF Conducted Emission Test Setup photo 1.4.1. RF Conducted Emission (ANSI C63.26:2015) Not applicable. Motorola Solutions Inc FCC ID: AZ499FT5879 / IC: 109U-99FT5879 EXHIBIT 7A SHEET 7 OF 8 1.4.2. RF Conducted Emission (ANSI C63.10: 2013) Motorola Solutions Inc FCC ID: AZ499FT5879 / IC: 109U-99FT5879 EXHIBIT 7A SHEET 8 OF 8 END OF REPORT

Page Number : E1 of E9 FCC RADIO TEST REPORT Report No. : FR572303 Appendix E. Setup Photographs <Conducted Emission> Mode1 Remote View Page Number : E2 of E9 FCC RADIO TEST REPORT Report No. : FR572303 Rear View Page Number : E3 of E9 FC…

Text truncated - open the document above for the full version.
