B32P400PLUSPoint of Sale Terminal

Verifone Part Number DOCXXX-00X-EN-A, Revision A.3 V E R I F O N E C O N F I DE N T I A L P400/P400 PLUS Installation Guide All rights reserved. No part of the contents of this document may be reproduced or transmitted in any form without the written permission of Verifone, Inc. The information contained in this document is subject to change without notice. Although Verifone has attempted to ensure the accuracy of the contents of this document, this document may include errors or omissions. The examples and sample programs are for illustration only and may not be suited for your purpose. You should verify the applicability of any example or sample program before placing the software into productive use. This document, including without limitation the examples and software programs, is supplied “As-Is.” Verifone Inc. 1-800-Verifone www.verifone.com Verifone Part Number DOCXXX-00X-EN-A, Revision A.3 P400/P400 PLUS Installation Guide © 2015 Verifone, Inc. Verifone and the Verifone logo, are registered trademarks of Verifone. Other brand names or trademarks associated with Verifone’s products and services are trademarks of Verifone, Inc. All other brand names and trademarks appearing in this manual are the property of their respective holders. Comments? Please e-mail all comments on this document to your local Verifone Support Team. P400/P400 PLUS INSTALLATION GUIDE3 V E R I F O N E C O N F I DE N T I A L CONTENTS PREFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Audience. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Guide Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Acronym Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 CHAPTER 1 OverviewP400 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Front Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Back Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 CHAPTER 2 SetupSelecting Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Environmental Factors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Electrical Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Contactless Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 PIN Protection Measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Ensuring User Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Unpacking Shipping Carton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 MSAM/MicroSD Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Changing or Installing MSAMs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Changing or Installing a MicroSD Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Attaching a Cable Connector to the P400 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Connection to Another Verifone Terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . 15 RS-232 Connection Using an External Power Brick . . . . . . . . . . . . . . . . . . . 15 Direct USB Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 USB–Download Support using an External Power Brick . . . . . . . . . . . . . . . 16 Ethernet Connection with External Power Brick . . . . . . . . . . . . . . . . . . . . . . 16 Smart Card Reader Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Magnetic Card Reader Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Contactless Transactions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Privacy Shield . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Stylus and Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Mounting Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Mounting P400 to a Flat Surface (Without a Mounting Adapter) . . . . . . . . . 19 Mounting P400 with Mounting Adapter to a Vertical Bracket . . . . . . . . . . . . 19 CHAPTER 3 SpecificationsUnit Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 4P400/P400 PLUS INSTALLATION GUIDE V E R I F O N E C O N F I DE N T I A L Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 External Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Report No.: 150729C24 1 of 15 CONSTRUCTION PHOTOS OF EUT Report No.: 150729C24 2 of 15 Report No.: 150729C24 3 of 15 Report No.: 150729C24 4 of 15 Report No.: 150729C24 5 of 15 Report No.: 150729C24 6 of 15

VeriFone S 2Fl., No. 19 Sanchung R Nankang D Taipei, Tai w Label L Model: Brand: FCC I D FCC ID Back si Systems Pte Ltd. 9-2, Road, ist. wan,11501 R.O.C Location P400 & P4 Verifone D: B32P400P D: B32P400 de of P400 Taiwan Branch . 00 Plus PLUS & P400 Pl u us LLabel locatioon

Report No.: 150729C24 7 of 15 Report No.: 150729C24 8 of 15 Report No.: 150729C24 9 of 15 Report No.: 150729C24 10 of 15 Report No.: 150729C24 11 of 15 Report No.: 150729C24 12 of 15 Report No.: 150729C24 13 of 15 Report No.: 150729C24 14 of 15 Report No.: 150729C24 15 of 15

FCC SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 28 Report No. : SA150729C24 Issued Date : Aug. 20, 2015 FCC SAR Test Report Report No. : SA150729C24 Applicant : VeriFone, Inc. Address : 1400 West Stanford Ranch Road Suite 200 Rocklin CA 95765 USA Product : Point of Sales Terminal FCC ID : B32P400PLUS Brand : Verifone Model No. : P400 Plus Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2003 IEEE 1528a-2005 / KDB 865664 D01 v01r04 / KDB 865664 D02 v01r01 KDB 248227 D01 v02r01 / KDB 447498 D01 v05r02 Sample Received Date : Jul. 29, 2015 Date of Testing : Aug. 10, 2015 ~ Aug. 12, 2015 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Evonne Liu / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 28 Report No. : SA150729C24 Issued Date : Aug. 20, 2015 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY System ................................................................................................................................................. 6 3.2.1 Robot.................................................................................................................................................................. 7 3.2.2 Probes ................................................................................................................................................................ 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................... 8 3.2.4 Phantoms ........................................................................................................................................................... 9 3.2.5 Device Holder ................................................................................................................................................... 10 3.2.6 System Validation Dipoles ................................................................................................................................ 10 3.2.7 Tissue Simulating Liquids ................................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 14 3.4 SAR Measurement Procedure ................................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure ......................................................................................................................... 15 3.4.2 Volume Scan Procedure................................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................................... 16 3.4.5 SAR Averaged Meth…

Text truncated - open the document above for the full version.

Report No.: RF150729C24-1 1 of 88 Report Format Version 5.3.0 FCC TEST REPORT (15.407) REPORT NO.: RF150729C24-1 MODEL NO.: P400 Plus FCC ID: B32P400PLUS RECEIVED: Jul. 29, 2015 TESTED: Aug. 11, 2015 ~ Aug. 15, 2015 ISSUED: Aug. 21, 2015 APPLICANT: Verifone, Inc. ADDRESS: 1400 West Stanford Ranch Road Suite 200 Rocklin CA 95765 USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150729C24-1 2 of 88 Report Format Version 5.3.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..............................................................................................................4 1. CERTIFICATION ..................................................................................................................................5 2. SUMMARY OF TEST RESULTS .........................................................................................................6 2.1 MEASUREMENT UNCERTAINTY...............................................................................................6 3. GENERAL INFORMATION ..................................................................................................................7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................7 3.2 DESCRIPTION OF TEST MODES ..............................................................................................9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................... 11 3.3 DESCRIPTION OF SUPPORT UNITS ..................................................................................... 14 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ......................................................... 14 3.4 DUTY CYCLE TEST SIGNAL ................................................................................................... 15 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 19 4. TEST TYPES AND RESULTS .......................................................................................................... 20 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 20 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................... 20 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS .............. 20 4.1.3 TEST INSTRUMENTS ................................................................................................. 21 4.1.4 TEST PROCEDURES ................................................................................................. 22 4.1.5 DEVIATION FROM TEST STANDARD ....................................................................... 22 4.1.6 TEST SETUP ............................................................................................................... 23 4.1.7 EUT OPERATING CONDITIONS ................................................................................ 23 4.1.8 TEST RESULTS........................................................................................................... 24 4.2 CONDUCTED EMISSION MEASUREMENT ........................................................................... 61 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................... 61 4.2.2 TEST INSTRUMENTS ................................................................................................. 61 4.2.3 TEST PROCEDURES ................................................................................................. 62 4.2.4 DEVIATION FROM TEST STANDARD ....................................................................... 62 4.2.5 TEST SETUP ............................................................................................................... 63 4.2.6 EUT OPERATING CONDITIONS ................................................................................ 63 4.2.7 TEST RESULTS........................................................................................................... 64 4.3 TRANSMIT POWER MEASUREMENT .................................................................................... 66 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .................................................... 66 4.3.2 TEST SETUP ...........................................................................................................…

Text truncated - open the document above for the full version.

Report No.: RF150729C24-2 Page No. 1 / 23 Report Format Version: 6.1.1 DFS Test Report Report No.: RF150729C24-2 FCC ID: B32P400PLUS Model Name: P400 Plus Received Date: Jul. 29, 2015 Test Date: Aug. 28, 2015 Issued Date: Aug. 31, 2015 Applicant: VeriFone Singapore Pte Ltd. Address: 11 Keppel Road #06-00 RCL Centre Singapore, 089057 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150729C24-2 Page No. 2 / 23 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 EUT Information .................................................................................................................................... 5 2.1 Operating Frequency Bands and Mode of EUT .................................................................................. 5 2.2 EUT Hardware, Software and Firmware Version ................................................................................ 5 2.3 Description Of Available Antennas to The EUT .................................................................................. 5 2.4 EUT Maximum Conducted Power ....................................................................................................... 6 2.5 EUT Maximum E.I.R.P. Power ............................................................................................................ 7 2.6 Transmit Power Control (TPc) ............................................................................................................. 8 2.7 Statement of Maunfacturer .................................................................................................................. 8 3. U-NII DFS Rule Requirements ............................................................................................................. 9 3.1 Working Modes and Required Test Items ........................................................................................... 9 3.2 Test Limits And Radar Signal Parameters ........................................................................................ 10 4. Test & Support Equipment List ......................................................................................................... 12 4.1 Test Instruments ................................................................................................................................ 12 4.2 Description of Support Units ............................................................................................................. 12 5. Test Procedure .................................................................................................................................... 13 5.1 ADT DFS Measurement System ....................................................................................................... 13 5.2 Calibration of DFS Detection Threshold Level .................................................................................. 14 5.3 Deviation From Test Standard ........................................................................................................... 14 5.4 Radiated Test Setup Configuration ................................................................................................... 15 5.4.1 Client Without Radar Detection Mode ............................................................................................... 15 6. Test Results ......................................................................................................................................... 16 6.1 Summary of Test Results .................................................................................................................. 16 6.2 Test Results ....................................................................................................................................... 17 6.2.1 Test Mode: Device Operating In Client Without Radar Detection Mode. .......................................... 17 6.2.2 Channel Closing Transmission And Channel Move Time ................................................................. 18 6.2.3 Non-Occupancy Period .................................…

Text truncated - open the document above for the full version.

FCC SAR Test Report Report Format Version 5.0.0 Issued Date : Aug. 20, 2015 Report No. : SA150729C24 Appendix D. Photographs of EUT and Setup FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA150729C24 <Photographs of EUT> <Antenna Location> The separation distance for antenna to edge: Antenna To Top Side (mm) To Bottom Side (mm) To Left Side (mm) To Right Side (mm) WLAN / BT 157 5 10 34 Top Side Left Side Right Side WLAN / BT Antenna Bottom Side <EUT Rear View> FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA150729C24 <Photographs of SAR Setup> Front Face of EUT with 0 cm Gap Rear Face of EUT with 0 cm Gap Left Side of EUT with 0 cm Gap Bottom Side of EUT with 0 cm Gap

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST (For WLAN 2.4GHz, Bluetooth EDR, Bluetooth LE) <Frequency Range 30MHz ~ 1GHz> 3 <Frequency Range above 1GHz > 4 RADIATED EMISSION TEST (For WLAN 5GHz) <Frequency Range 30MHz ~ 1GHz> 5 <Frequency Range above 1GHz > 6 RADIATED EMISSION TEST (For NFC)

1 PHOTOGRAPHS OF THE TEST CONFIGURATION Set UUT as Client without radar detection mode (Radar injected into Master) Master Radar ( Radiated ) UUT Receiver Antenna to S.A.
