B32V400M2Point of Sale Terminal

Draft www.verifone.com V400m Terminal & Base Installation Guide DOC475-003-EN-A, Revision A02.1 Draft Installation Guide V400m 2 © VeriFone Inc. All rights reserved. V400m Terminal & Base Installation Guide © 2023 VeriFone, Inc. All rights reserved. No part of the contents of this document may be reproduced or transmitted in any form without the written permission of VeriFone, Inc. The information contained in this document is subject to change without notice. Although Verifone has attempted to ensure the accuracy of the contents of this document, this document may include errors or omissions. The examples and sample programs are for illustration only and may not be suited for your purpose. You should verify the applicability of any example or sample program before placing the software into productive use. This document, including without limitation the examples and software programs, is supplied “As-Is.” Verifone and the Verifone logo are registered trademarks of Verifone. Other brand names or trademarks associated with Verifone’s products and services are trademarks of VeriFone, Inc. All other brand names and trademarks appearing in this manual are the property of their respective holders. Comments? Please e-mail all comments on this document to your local Verifone Support Team. VeriFone, Inc 1-800-Verifone www.verifone.com Verifone Part Number DOC475-003-EN-A, Revision A02.1 Draft Installation Guide V400m 3 © VeriFone Inc. All rights reserved. Contents Preface 7 Audience 7 Organization 7 Related Documentation 8 Conventions and Acronyms 8 1. Device Overview 11 Front Functions 12 Back Functions 12 V400m Bases 13 V400m Charging Base 13 V400m Full-Feature Base 13 Features and Benefits 14 Ease of Use 14 Critical Security Protection 15 2. Setup 16 Selecting Location 16 Environmental Factors 17 Electrical Considerations 17 Contactless Considerations 18 PIN Protection Measures 18 Unpacking Shipping Carton 18 Installing MSAM, SIM and Micro SD Cards 19 Accessing Card Compartments 20 Draft Installation Guide V400m 4 © VeriFone Inc. All rights reserved. Changing or Installing an MSAM Card 21 Changing or Installing a SIM Card 21 Changing or Installing a Micro SD Card 23 Loading Printer Paper 24 Power Supply 25 Cable Connections 26 Cable Connections Using the Full-Feature Base 26 Smart Card Reader 28 Conducting a Smart Card Transaction 28 Magnetic Stripe Card Reader Use 29 Conducting a Credit/Debit Card Transaction 30 Contactless Transaction 30 Performing Contactless Transactions 31 Optional Accessories 31 FF Base 31 Charging Base 32 Periodic Inspection 32 3. Specifications 33 V400m Terminal 33 Unit Power Requirements 33 Temperature 33 Humidity 33 External Dimensions 33 Weight 34 Processor 34 Memory 34 SD Memory 34 Security 34 Draft Installation Guide V400m 5 © VeriFone Inc. All rights reserved. Display 34 SAM Card Reader 34 CTLS Reader 34 Magnetic Card Reader 35 Primary Smart Card 35 Speaker 35 Communication 35 Battery Pack 36 Power Pack 36 Integrated Printer 36 Security 37 V400m Bases 37 Unit Power Requirements 37 Temperature 37 Humidity 37 Communication 37 Security 38 4. Troubleshooting Guidelines 39 Display Panel Does Not Work 40 Keypad Does Not Respond 40 Transactions Fail to Process 40 5. Service and Support 42 Maintenance and Cleaning 42 Service Returns 43 Accessories and Documentation 46 Cables 46 Base 46 Draft Installation Guide V400m 6 © VeriFone Inc. All rights reserved. Power Supply 46 Cleaning Kit 46 Documentation 46 6. Caution and Warning Messages 47 Caution and Warning Messages 47 Draft Installation Guide V400m 7 © VeriFone Inc. All rights reserved. Preface This guide is the primary source of information for setting up and installing the V400m and V400m Bases. Audience This guide provides simple descriptions of the product features and information for installing and configuring V400m terminals and the V400m Charging and Full-Function Bases. Organization This guide is organized as follows: • Chapter 1, Device Overview. Provides an overview of the V400m device. • Chapter 2, Setup. Explains how to set up and install the V400m and establish connections with other devices. • Chapter 3, Specifications. Discusses the power requirements and dimensions of V400m. • Chapter 4, Troubleshooting Guidelines Provides troubleshooting tips. • Chapter 5, Service and Support Provides information on contacting your Verifone service provider, ordering accessories or documentation from Verifone, and maintaining the V400m unit. • Appendix A, Caution and Warning Messages Shows the UL/cUL certification-compliant translations of all Warning and Caution messages in this installation guide. Draft Installation Guide V400m 8 © VeriFone Inc. All rights reserved. Related Documentation To learn more about the V400m and V400m Bases, please refer to the following documents and their associated Verifone Part Numbers (VPN): • V400m Quick Installation Guide DOC475-002-EN • V400m Reference Guide DOC475-004-EN • V400m B-Charging Quick Installation Guide DOC475-006-EN • V400m B-FF Quick Installation Guide DOC475-007-EN • V400m Base C and FF Certifications & Regulations Sheet DOC475-011-EN • V400m Plus 4G Certifications and Regulations DOC475-031-EN Conventions and Acronyms This section describes the conventions and acronyms used in this guide. Various conventions are used to help you quickly identify special formatting. Table 1 describes these conventions and provides examples of their use. Table 1: Document Conventions Convention Meaning Example Blue Text in blue indicates terms that are cross referenced. See Conventions and Acronyms. The light bulb icon is used to highlight important information. If exchanging cables use a Verifone-approved cable. Draft Installation Guide V400m 9 © VeriFone Inc. All rights reserved. The caution symbol indicates possible hardware or software failure, or loss of data. Avoid placing metallic objects at the front of the card reader The lightning symbol is used as a warning when bodily injury m…

Text truncated - open the document above for the full version.

VeriFone, Inc. 1-800-Verifone www.verifone.com V400m Certifications and Regulatio ns Verifone Part Number: DOC475-031-EN-B , Revision © 2023 VeriFone, Inc. A ll rights reserved. *DOC475-031-EN-B* ElectricalSeparate Power SourcesBefore you connect the terminal power pack to an electrical outlet, check that the on/off power switch on the terminal is off. If the terminal does not have an on/off switch, check that the power cable connector is removed from the terminal's power port. Or, when c onnecting the terminal to a power pack, always connect the plug of the power pack to an electrical wall outlet first. Then con nect the power cable to the terminal's power port.The reference input power ratings are as follows: • Input Voltage: 1 00-240V AC, 5 0/60Hz • Output Voltage: 5V DC, 2.2A Model V400m Plus 4G/V400m Plus 4G WW and V400m-2 is intended to be provided with a Listed Power Supply module having an output rating of 5V DC, minimum 2.2A, Tma 40°C, Class II and evaluated as a Limited Power Source or PS2 or equivalent. Location – Electrical ConsiderationsCAUTION: Due to the risk of electric shock or damage to the terminal, do not use this equipment near a water source, for example near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. Likewise, avoid using this product during thunderstorms causing power cuts. Avoid placing th e terminal near electrical devices or other units that could cause large voltage fluctuations o r electrical interference, su ch as air conditioners, neon signs, high frequency safety devic es or electrical equipment. ATTENTION: Du fait d’un risqué d’électgrocution ou d’une deterioration du terminal, ne pas utiliser cet équipement prés d’une source d’eau , par example prés d’une baignoire, d’un lavabo, d’un évier de cuisine ou d’un bac de lavage, dans un sous-sol humide ou à proximité d’une piscine. De même, éviter d’utiliser ce produit l ors des orages provaquant des coupures électriques. Éviter de placer le terminal à proximité d’appare ils électriques ou autres unités pouvant entra îner des fluctuations de tension import antes ou des interférences électriques, tells que les climatiseurs, enseignes au néon, dispositifs de sé curité à haute fréquence ou équipments électriques. AC AdapterThe AC adapter is designed to ensure your personal safety and t o be compatible with this equipment. Please follow these guidel ines: • Do not use the adapter in a high moisture environment. Never t ouch the adapter when your hands or feet are wet. • Allow adequate ventilation around the adapter. Avoid locations with restricted airflow. • Connect the adapter to a proper power source. The voltage and grounding requirements are found on the product case and/or pac kaging. • Do not use the adapter if the cord is damaged.• Do not attempt to service the adapter. There are no serviceabl e parts inside. Replace the unit if it is damaged or exposed to excess moisture. Disconnecting PowerDisconnecting power during a trans action may cause transaction data files that are not yet stored in the terminal memory to be lost. EquipmentLocation – Environme ntal Considerations Do not plug the power pack into an outdoor outlet. The terminal is not waterproof. Any damage to the unit from exposure to wat er or dust may void your warrant y. Do not use the device where there is high heat, dust, humidity, moisture, or caustic chemicals or oils. K eep the device away from direct sunlight and anything that radi ates heat, such as a stove or a motor. WARNING! Your device contains sensitive electronic components that can b e permanently damaged if exposed to excessive shock or vibratio n. To minimize the risk of damage to your device, avoid dropping your device and operating it in high-shock and high-vi bration environments. Do not store the device where prolonged e xposure to extreme temperature can occur, because it can cause permanent damage. Do not expose the device to water. Contact with water can cause this unit to malfunction. AVERTISSEMENT! Votre terminal de point de vente contient des composants électr oniques sensibles, susceptibles de subir des dommages définitifs en cas d'exposition à des chocs ou à des vibrations excessives. Pour minimiser le risque de dommages pour votre term inal, éviter de le faire tomber ou de l'exposer à des environne ments pouvant provoquer des chocs et des vibrations excessives. Ne pas stocker le terminal dans des lieux suscept ibles d'entraîner une exposition prolongée à des températures extr êmes, du fait des dommages définitifs que cette situation peut provoquer. Ne pas exposer le terminal à l'eau. Un contact avec de l'eau peut prov oquer un dysfonctionnement de l 'unité. RepairsDo not, under any circumstances , attempt any service, adjustmen ts, or repairs on this equipment. Instead, contact your local V erifone distributor or service provider for assistance. Failure to comply may void the product warranty. Battery Pack/Coin Cell Instruc tions for Portable Products Dispose of the battery pack/coin cell in accordance with all na tional, state, and local laws and regulations as regionally req uired. Some batteries may be recycled and may be accepted for d isposal at local recycling centers.CAUTION: There is risk of explosion if the battery is replaced by an inc orrect type. ATTENTION: Il existe un risque d'explosion si la batterie est remplacée par un modèle incompatible. • Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explos ion. • Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas. • A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas.The highest specified charging temperature of battery pack is 5 0+/-3°C. The lowest specified charging temperature of battery pack is 0+ /-3°C. Notice for WLANFor…

Text truncated - open the document above for the full version.

VeriFone Inc 1400 West Stanford Ranch Road Suite 150, Rocklin, California United States 95765 Tel: 886-23789-7334 ; Fax: 886-2-26553168 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: September 4, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may conc ern, VeriFone Inc (“the applicant”) certifies that the equipment FCC ID: B32V400M2 for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. VeriFone Inc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is no t identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ________________ Kenji Chao / Sr. Director, Hardware Engineering Verifone, Inc. Tel.: 886-2-3789-7334 Fax: 886-2-2655-3168 E- mail:[email protected]

VeriFone Inc 1400 West Stanford Ranch Road Suite 150, Rocklin, California United States 95765 Tel: 886-23789-7334 ; Fax: 886-2-26553168 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: September 4, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may conc ern, VeriFone Inc (“the applicant”) certifies that the equipment FCC ID: B32V400M2 for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. VeriFone Inc (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is no t identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ________________ Kenji Chao / Sr. Director, Hardware Engineering Verifone, Inc. Tel.: 886-2-3789-7334 Fax: 886-2-2655-3168 E- mail:[email protected]

VeriFone Inc 1400 West Stanford Ranch Road Suite 150, Rocklin, California United States 95765 Tel: 886-23789-7334 ; Fax: 886-2-26553168 Date: September 4, 2023 FCC Laboratory 7435 Oakland Mills Rd Columbia MD 21046 Subj ect: Request for Confidentiality FCC ID: B32V400M2 To Who m It May Concern, Pur suant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following documents from public disclosure indefinitely. Schematic Diagram Block Diagram Part List Operational Description Tune-up Procedure Above mentioned documents which contain detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format cannot be granted as confidential documents and that information will be available for public review once the grant of equipment authorization is issued. Best Regards, __________________ Kenji Chao / Sr. Director, Hardware Engineering Verifone, Inc. Tel.: 886-2-3789-7334 Fax: 886-2-2655-3168 E- mail:[email protected]

VeriFone Inc 1400 West Stanford Ranch Road Suite 150, Rocklin, California United States 95765 Tel: 886-23789-7334 ; Fax: 886-2-26553168 FCC Agent Authorization Dat e: September 4, 2023 To w hom it may concern, VeriFone Inc hereby authorize Sporton International Inc. to act on our behalf in all matters relating to applications for FCC equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by Sporton International Inc. on our behalf shall have the same effect as acts of our own. We a lso hereby certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988. 21 U.S.C. 862. Thi s authorization is limited to the product of as following: FCC ID: B32V400M2 Thi s authorization is valid until further written notice from VeriFone Inc. Sincerely, _______ _____________ Kenji Chao / Sr. Director, Hardware Engineering Verifone, Inc. Tel.: 886-2-3789-7334 Fax: 886-2-2655-3168 E- mail:[email protected]

PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 1 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 1. External Photograph of EUT Brand Name: Verifone Model Name: V400m-2 V400m Plus 4G WW2 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 2 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 3 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 4 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 5 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 6 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 7 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 2. Photograph of Accessory Brand Name: Verifone Model Name: V400m-2 V400m Plus 4G WW2 Specification of Accessory AC Adapter 2 Brand Name Verifone Model Name AM11A-050A AC Adapter 4 Brand Name Verifone Model Name S011EU0520220 Battery Brand Name Verifone Model Name BPK475-001 Remark: For accessories equipped with this EUT, please refer to the following photos. PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 8 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 9 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 AC Adapter 2 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 10 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 AC Adapter 4 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 11 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 Battery PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 12 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02

Label Location Model: V400m-2 Brand: Verifone FCC ID: B32V400M2 IC:787C-V400M2 Back side of V400m-2 Back side of EUT- underneath of battery compartment

PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 13 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 3.Internal Photograph of EUT Brand Name: Verifone Model Name: V400m-2 V400m Plus 4G WW2 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 14 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 15 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 16 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 17 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 18 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 19 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 20 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 21 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 22 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 23 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 24 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 25 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 26 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 27 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 28 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 29 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 30 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 31 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 WWAN Antenna PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 32 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 33 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 Bluetooth and WLAN Antenna PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 34 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP372517 TEL : 886-3-327-3456 Page Number : 35 of 35 FAX : 886-3-328-4978 Issue Date : Oct. 11, 2023 Report Version : 02 ─────THE END──── NFC Antenna

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2023/8/11 System Check_Head_13MHz Communication System: CW; Frequency: 13 MHz;Duty Cycle: 1:1 Medium: HSL_13_230811 Medium parameters used: f = 13 MHz; σ = 0.757 S/m; ε r = 53.4; ρ = 1000 kg/m 3 Ambient Temperature：23.5 °C; Liquid Temperature：22.5 °C DASY5 Configuration: - Probe: EX3DV4 - SN7306;ConvF(16.9, 16.9, 16.9) @ 13 MHz;Calibrated: 2023/7/18 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn853; Calibrated: 2023/7/14 - Phantom: ELI v4.0_Mid; Type: QDOVA001AA; Serial: TP:1026 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=250mW/Area Scan (81x81x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.197 W/kg Pin=250mW/Zoom Scan (8x10x8)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 16.34 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 0.277 W/kg SAR(1 g) = 0.133 W/kg; SAR(10 g) = 0.083 W/kg Maximum value of SAR (measured) = 0.200 W/kg 0 dB = 0.200 W/kg = -6.99 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2023/8/8 System Check_Head_750MHz DUT: D750V3-1012 Communication System: CW ; Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL_750_230808 Medium parameters used: f = 750 MHz; σ = 0.884 S/m; ε r = 42.015; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN7306;ConvF(10.31, 10.31, 10.31) @ 750 MHz;Calibrated: 2023/7/18 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn853; Calibrated: 2023/7/14 - Phantom: SAM_Left; Type: QD 000 P40 CD; Serial: TP:1685 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=50mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.600 W/kg Pin=50mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 26.26 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 0.614 W/kg SAR(1 g) = 0.416 W/kg; SAR(10 g) = 0.273 W/kg Maximum value of SAR (measured) = 0.554 W/kg 0 dB = 0.554 W/kg = -2.56 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2023/8/8 System Check_Head_835MHz DUT : D835V2-4d060 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_850_230808 Medium parameters used: f = 835 MHz; σ = 0.918 S/m; ε r = 41.719; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN7306;ConvF(9.89, 9.89, 9.89) @ 835 MHz;Calibrated: 2023/7/18 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn853; Calibrated: 2023/7/14 - Phantom: SAM_Left; Type: QD 000 P40 CD; Serial: TP:1685 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=50mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 0.663 W/kg Pin=50mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 28.05 V/m; Power Drift = -0.02 dB Peak SAR (extrapolated) = 0.753 W/kg SAR(1 g) = 0.496 W/kg; SAR(10 g) = 0.324 W/kg Maximum value of SAR (measured) = 0.669 W/kg 0 dB = 0.669 W/kg = -1.75 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2023/8/7 System Check_Head_1750MHz DUT: D1750V2-1068 Communication System: CW; Frequency: 1750 MHz;Duty Cycle: 1:1 Medium: HSL_1750_230807 Medium parameters used: f = 1750 MHz; σ = 1.373 S/m; ε r = 40.837; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN7306;ConvF(8.56, 8.56, 8.56) @ 1750 MHz;Calibrated: 2023/7/18 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn853; Calibrated: 2023/7/14 - Phantom: SAM_Left; Type: QD 000 P40 CD; Serial: TP:1685 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=50mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.79 W/kg Pin=50mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 45.83 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 3.24 W/kg SAR(1 g) = 1.8 W/kg; SAR(10 g) = 0.958 W/kg Maximum value of SAR (measured) = 2.72 W/kg 0 dB = 2.72 W/kg = 4.35 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2023/8/7 System Check_Head_1900MHz DUT: D1900V2-5d093 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_230807 Medium parameters used: f = 1900 MHz; σ = 1.389 S/m; ε r = 40.584; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN7306;ConvF(8.37, 8.37, 8.37) @ 1900 MHz;Calibrated: 2023/7/18 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn853; Calibrated: 2023/7/14 - Phantom: SAM_Left; Type: QD 000 P40 CD; Serial: TP:1685 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=50mW/Area Scan (61x61x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 3.16 W/kg Pin=50mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 47.73 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 3.64 W/kg SAR(1 g) = 1.94 W/kg; SAR(10 g) = 1 W/kg Maximum value of SAR (measured) = 3.00 W/kg 0 dB = 3.00 W/kg = 4.77 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2023/8/16 System Check_Head_1900MHz DUT: D1900V2-5d093 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: HSL_1900_230816 Medium parameters used: f = 1900 MHz; σ = 1.385 S/m; ε r = 40.351; ρ = 1000 kg/m 3 Ambient Temperature：23.1 °C; Liquid Temperature：22.1 °C DASY5 Configuration: - Probe: EX3DV4 - SN7306;ConvF(8.37, 8.37, 8.37) @ 1900 MHz;Calibrated: 2023/7/18 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn853; Calib…

Text truncated - open the document above for the full version.

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2023/8/8 #01_GSM850_GPRS (2 Tx slots)_Right Side_0mm_Ch128 Communication System: GSM850; Frequency: 824.2 MHz;Duty Cycle: 1:4.15 Medium: HSL_850_230808 Medium parameters used : f = 824.2 MHz; σ = 0.913 S/m; ε r = 41.772; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN7306;ConvF(9.89, 9.89, 9.89) @ 824.2 MHz;Calibrated: 2023/7/18 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn853; Calibrated: 2023/7/14 - Phantom: SAM_Left; Type: QD 000 P40 CD; Serial: TP:1685 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Area Scan (71x121x1): Interpolated grid: dx=1.500 mm, dy=1.500 mm Maximum value of SAR (interpolated) = 2.37 W/kg Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 52.67 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 2.97 W/kg SAR(1 g) = 1.58 W/kg; SAR(10 g) = 0.851 W/kg Maximum value of SAR (measured) = 2.45 W/kg 0 dB = 2.45 W/kg = 3.89 dBW/kg Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2023/8/7 #02_GSM1900_GPRS (3 Tx slots)_Right Side_0mm_Ch810 Communication System: PCS; Frequency: 1909.8 MHz;Duty Cycle: 1:2.77 Medium: HSL_1900_230807 Medium parameters used: f = 1910 MHz; σ = 1.399 S/m; ε r = 40.545; ρ = 1000 kg/m 3 Ambient Temperature：23.6 °C; Liquid Temperature：22.6 °C DASY5 Config…

Text truncated - open the document above for the full version.
