B4SSRF2Universal Remote Control

SRF2 Owner’s Manual PLAY STOPPAUSE REC POWER SCANSCAN TV DVD AUX GUIDE GAME R G ID FREEZE AUDIO SE AR CH CALLER VOL OK/I HELP EXIT WHO quick BACK MENU B TV/ VIDEO PAGE CHAN VO L CHAN SET DIREC TV INFO VCR INPU T PAGE 32 IntroductionTable of Contents Congratulations on your purchase of a Samsung Universal Remote Control. Samsung Universal Remotes let you replace a broken or lost remote or combine more than one remote into one. This remote control operates the common features of most but not all models and brands of IR Infrared Controlled Video Equipment. This remote may provide functions that are not available on your equipment. Some functions of your particular equipment (e.g. menu functions) may not be controlled by this remote. In such cases, use the original remote control for your equipment. Please use this manual to become familiar with your Samsung Universal Remote. After you are familiar with your remote the first thing you need to do is to install batteries and setup your remote for your particular product and brand. Introduction...................................................... 3 Setup............................................................... 4 Battery Installation....................................... 4 Battery Saver............................................... 4 Code Saver ................................................. 4 Power-On default........................................ 4 TV Punch Through Feature.......................... 5 VCR/DVD Punch Through Feature.............. 5 Code Setup ................................................. 5 Button Functions............................................... 6 Advanced Functions......................................... 8 DirecTV Functions....................................... 8 DVD Functions............................................ 9 VCR/DVD Punch Through Feature.............. 9 TV/VCR/INPUT....................................... 10 TV/VCR and TV/DVD Combo units......... 10 Code Entry..................................................... 11 Direct Code Entry...................................... 11 Code Search ............................................. 12 Brand Search............................................. 13 Code Identification Feature........................ 15 Product Operation.......................................... 16 RF Receiver................................................... 17 Troubleshooting.............................................. 18 The remote also transmits wireless Radio Frequency (RF) commands. The wireless receiver (included) receives these commands and converts them to regular Infrared (IR) commands. These IR commands are then emitted from the IR Extender (also included) to control your A/V components. This lets you control your A/V components from ANY room in your home - you don’t need to aim the remote at your component! Thank you for buying a Samsung remote and we hope it will give you many years of service. FCC Caution THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOW- ING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFER- ENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. This equipment generates and uses radio frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturers instructions, it may cause interference to radio and television reception. It has been type tested and found to comply with the limits for remote control devices in accordance with the specifications in Sub-Parts B and C of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interfer- ence will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by unplugging the equipment, try to correct the interference by one or more of the following measures. • Reorient the antenna of the radio/TV experiencing the interference. • Relocate the interface with respect to the radio/TV. • Move the interface away from the radio/TV. • Plug the interface into an outlet on a different electrical circuit from the radio/TV experiencing the interference. • If necessary, consult your local Dealer for additional suggestions. NOTE: Modifications to any of the components in this kit will void the user’s authority to operate this equipment. 54 TV Volume/Mute Punch-Through Feature The TV Volume/Mute punch-through feature lets you control the Volume and Mute function of your TV in any mode programmed to be a VCR, DVD, CABLE or SAT device, without needing to change to TV mode. VCR/DVD Punch-Through Feature Punch-through to VCR/DVD mode i.e. the 6 keys (PLAY, PAUSE, STOP, FF, REWIND, and REC) is only allowed in modes programmed for TV or Cable codes. Code Setup The SET button is used to setup the remote. You can either setup the remote using the code for your brand of product, from the code tables (on separate sheet), or you can search through the library of codes until you find a code that works for your product. Please refer to “Programming with Code Search” on page 12 for more information on using the code search feature to learn how to search through the library of codes for your products. NOTE: You can store any kind of code under any mode (except TV). I.E. you can store a VCR code under the DVD button, or a DVD code under the VCR button, etc. However, you can only store TV codes under the TV button. SET Battery Installation 1. On the back of the remote, push down on the tab and lift the cover off. 2. Match the batteries to the + and - marks inside the battery case, then insert 2 AAA Alkaline batteries. 3. Press the battery cover back into place. Battery Saver Your remote automatically turns off if the buttons are depressed more than 30 seconds. This will save your batte…

Text truncated - open the document above for the full version.

IR Driver MCU Block Diagram for SRF2 RF Remote Key Matrix 418MHz Transmitter 418MHz

SRF2 remote rating label 2: 1 9/25/03 5 in 1 Wireless Universal Remote Use with ZN551R, RF Receiver. Use two AAA alkaline batteries. 1. Press and hold CODE SEARCH until red light stays on. 2. Press and release mode button (TV, VCR, DVD, etc. 3. Enter 3 digit code from code list. FCC ID: B4SSRF2 Model SRF2 Samsung Electronics, Richfield Park, NJ 07660 Made in China CAN: 1632-SRF2

SFR2 Operational Description The SFR2 is a 418 MHz pulsed RF transmitter and an infrared remote control. The remote can control a variety of TVs and Audio Systems. It is used in conjunction with an RF receiver which is used as an IR extender. The internal MCUs receive information from the keypad and convert the keystrokes into a pulse code. The pulse code is then sent to the 418 MHz RF transmitter and is used to pulse modulate the 418 MHz carrier.

0SRF1T(B)-77U5IN1 EL/RF REMOTE,418,0411 EA 1037006H10101EL SPACER1 EA 1038010H11093PLAIN WHITE LABEL(20X5)MM2 EA 1183010H21230BATTERY DOOR1 EA 1185000H21870BOTTOM CABINET1 EA 1185000H22330TOP CABINET1 EA 1221-00000012EL PANEL1 EA 1275000H12222RUBBER KEYPAD1 EA 1391-20103040SCR C'SINK M/C M2.6X81 EA 1392008H10021SPRING WASHER M31 EA 1392010H10040FIBRE WASHER M31 EA 1394-00300011NUT M2.6 P=0.451 EA 1851001H11889PCB ASSY RF 418MHZ(3V)1 EA 0.2 038010H10513-1LABEL-FREQUENCE (418MC)1 EA 0.2 042010H11118BPCB1 EA 0.2 076-10000012CAP-MCC 10P .25P NPO 06032 EA C6,12 0.2 076-10400014CAP-MCC 100N 10% X7R 06032 EA C4,14 0.2 076-10900012CAP-MCC 1P .25P NPO 06032 EA C18,21 0.2 076-15000012CAP-MCC 15P 5% NPO 06031 EA C9 0.2 076-15900012CAP-MCC 1P5 .25P NPO 06031 EA C5 0.2 076-18900012CAP-MCC 1P8 .25P NPO 06031 EA C17 0.2 076-22000012CAP-MCC 22P 5% NPO 06031 EA C15 0.2 076-30900012CAP-MCC 3P .25P NPO 06031 EA C13 0.2 076-35900012CAP-MCC 3P5 .25P NPO 06031 EA C3 0.2 076-47900012CAP-MCC 4P7 .25P NPO 06032 EA C10,11 0.2 076-50800012CAP-MCC 0P5 .25P NPO 06031 EA C16 0.2 076-56000012CAP-MCC 56P 5% NPO 06031 EA C8 0.2 076-70900012CAP-MCC 7P .25P NPO 06031 EA C19 0.2 080001H10021SAW 418MHZ SIEMENS1 EA SAW1 0.2 160-33800001INDUCTOR 330NH 10%1 EA L2 0.2 160-47700011INDUCTOR 47N 2% 0603 SMD1 EA L1 0.2 209-00000003TRS-NPN 2SC3356 SMD2 EA Q1,2 0.2 241-00000003RES-TFC 0R 5% 1/10W 06031 EA R4 0.2 241-10100003RES-TFC 100R 5% 1/10W06032 EA R3,6 0.2 241-68200003RES-TFC 6K8 5% 1/10W 06033 EA R1,2,5 0.2 358-60821001WIRE-JUMPER D=0.6MM3 EA 1851001H11903PCB ASSY,LEARN,HE0411 EA 0.2 055-10400000CAP-C 100N +8-2 25V Y5V1 EA C3 0.2 057-10100019CAP-E 100U 20% 10V1 EA C2 0.2 057-22100014CAP-E 220U 20% 10V1 EA C9 0.2 076-10400014CAP-MCC 100N 10% X7R 06031 EA C3 0.2 076-33300007CAP-MCC 33N 10% 50V X7R1 EA C1 0.2 080001H100504MHZ RESONATOR W/2 CAP2 EA Y1,2 0.2 209117H10004TRS-NPN 9014C1 EA Q2 0.2 210010H10010TRS-H90131 EA Q1 0.2 210117H10000TRS-PNP 9015C1 EA Q8 0.2 210117H10080TRANSISTOR-ZTX7901 EA Q7 0.2 220-00200220IR EMITTING LED 5MM1 EA IR1 0.2 220-00200350LED 2MM-TOWER RED1 EA LED1 0.2 240-10306011RES-CF 10K +/-5% 1/8W1 EA R14 0.2 240-27106011RES-CF 270R +/-5% 1/8W1 EA R18 0.2 240-33106022RES-CF 330R +/-5% 1/4W1 EA R2 0.2 240-33906022RES-CF 3R3 +/-5% 1/4W1 EA R3 0.2 241-10400003RES-TFC 100K 5% 1/10W06032 EA R16,19 0.2 241-10500003RES-TFC 1M 5% 1/10W 06031 EA R1 0.2 241-15200003RES-TFC 1K5 5% 1/10W 06031 EA R15 0.2 241-33300003RES-TFC 33K 5% 1/10W 06031 EA R19 0.2 241-47200003RES-TFC 4K7 5% 1/10W 06031 EA R17 0.2 241-68100003RES-TFC 680R 5% 1/10W06031 EA R4 0.2 241-82100003RES-TFC 820R 5% 1/10W06031 EA R10 0.2 307001H10112TRAN 45T:1000T F-CORE1 EA T1 0.2 358-60821001WIRE-JUMPER D=0.6MM1 EA 0.2 403011H10272SPRING CONTACT (+VE)1 EA 0.2 403011H10304SPRING CONTACT (-VE)1 EA 0.2 851001H11903-APCB ASSY, DIE, HE0411 EA ..3 042010H11200APCB1 EA ..3 211328H10317-DIC DIE RC008-HE0411 EA

1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 15-Sep-2003 Sheet of File: A:\SAMSUN~1.SCH Drawn By: R1 6K8 R2 6K8 R4 10P R3 150R R5 6K8 R7 * SAW1 418MHz PCB2 L1 47N PCB1 C1 * C34P7 C51P5 C6 0R C4 100N Q1 3356 3V C8 56P C7 * C915P C10 4P7 C1210P C13 3P C11 4P7 Q2 2SC3356 R6 100R C14100N 3V C1522P C160P5C171P8 RF IN ANTENNA C19 7P C181P C20 * 418MHz RF Tx C21 1P L2 0.33u ASSY NOS. : 851001H11889 -> SAMSUNG REMOTE 851001H11881 -> B&D TV REMOTE D C B A 12345678 A B C D 87654321 PICO ELECTRONICS Ltd., Eastfield Industrial Estate, Glenrothes, Fife, KY7 4NZ, SCOTLAND SHEET No. DATE DATE REVISION DATE FIRST DRAWN FILE DRN APPD. DO NOT SCALE DRAWINGTITLE: REV. Error : PICO.WMF File Not Found D:\SCH\GSAMDSSB.SCH 11of B SAMSUNG DSS REMOTE PRINT DATE 16:14:1016-Sep-2003 BKW29/5/03 29/5/03 1/8/03 LED1 R2 330R C3 100NF VSS C2 100UF 6.3V Y1 4MHZ R1 1M VSS 2 x AAA BATTERIES BATT1 BATT2 NOTES:- 1/ ALL UNSPECIFIED DIODES 1N4148 OR EQUIVALENT. 2/ ALL UNSPECIFIED RESISTORS ARE 0.125W 5%. 3/ ALL UNSPECIFIED CAPACITORS ARE AXIAL MLC TYPE. "*" DENOTES COMPONENT NOT INSTALLED +3V 11-7 26 D-0 11 D-1 12 11-6 25 11-5 24 C-1 35 C-0 34 TSTP_P 32 RSTP_N 29 SXI 31 SXO 30 D-7 18 D-6 17 D-5 16 D-4 15 D-3 14 D-2 13 10-1 2 10-0 1 10-3 4 10-2 3 10-5 6 10-4 5 10-7 8 10-6 7 11-1 20 11-0 19 11-3 22 11-2 21 C-3 37 VDD 33 C-2 36 FXI 28 FXO 27 GND 10 11-4 23 IR-OUT 9 U1 ROO8-USA VSS KEY13 AUX 13/3 KEY19 DIRECTV 13/4 KEY26 INFO 14/5 KEY37 DVD 13/7 KEY7 VCR 13/2 KEY1 TV 13/1 KEY2 MUTE 14/1 KEY8 VOL.DOWN 14/2 KEY14 VOL.UP 14/3 KEY45 TV/VIDEO 15/8 KEY50 UP 14/19 KEY67 YELLOW 13/22 KEY63 GREEN 15/21 KEY52 OK/i 16/19 KEY3 CH.DOWN 15/1 KEY15 RECORD 15/3 KEY16 STOP 16/3 KEY17 PAUSE 17/3 KEY21 1 15/4 KEY22 2 16/4 KEY23 3 17/4 KEY27 4 15/5 KEY28 5 16/5 KEY29 6 17/5 KEY39 7 15/7 KEY41 9 17/7 KEY5 CH.UP 17/1 KEY9 REWIND 15/2 KEY10 PLAY 16/2 KEY11 FF 17/2 KEY4 POWER 16/1 KEY47 GAME 17/8 KEY40 8 16/7 KEY46 0 16/8 KEY51 LEFT 15/19 KEY53 RIGHT 17/19 KEY57 MENU 15/20 KEY59 EXIT 17/20 KEY58 DOWN 16/20 KEY32 BACK 14/6 HE041 KEY20 SET 14/4 KEY35 HELP 17/6 (CC/SUBTITLE) KEY57 GUIDE 14/20 SMD KEY48 BLUE 18/8 KEY66 QUICK 18/21 KEY72 WHO 18/22 (TV/VCR) FREEZE (PIP) KEY34 RED 16/6 KEY49 "-" 13/19 CALLER ID AUDIO SEARCH(ENTER) (SKIP DN.) (SKIP UP) IR1 TR1 9013G VSS VSS SIGNAL ENABLE SHOWN FOR REFERENCE ONLY VSS R11 * C4 * C5 * C6 * C7 * C8 * R12 * TR4 * R13 * D2 L1 * L2 * * DAUGHTER BOARD R3 3R3 R4 680R BACKLIGHT C10 33NF R10 820R R14 10K R15 1K5 TR8 9015 TR2 9014 T1 R16 100K R17 4K7 R18 270R TR9 ZETEX 790 +3V J1 J2 EL DISPLAY PANEL R19 100K BLUE VSS C11 220UF 10V VSS R30 * KEY6 BACKLIGHT 18/1

Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 APPLICANT X-10 USA, Inc. 19823, 58 th Place S. Kent, WA 98032 MANUFACTURER X-10 Electronics Shenzhen Co. Ltd. X-10 Building Labour Industrial District Shenzhen, Xixiang, Bao An Guang Dong, China, 518102 TEST SPECIFICATION:FCC Rules and Regulations Part 15, Subpart C, Para. 15.231 TEST PROCEDURE:ANSI C63.4:2001 TEST SAMPLE DESCRIPTION BRANDNAME: X-10 USA, Inc.MODEL: SRF2 TYPE: Pulsed Transmitter POWER REQUIREMENTS:2 "AAA" Batteries FREQUENCY OF OPERATION: 418 MHz TESTS PERFORMED Para. 15.231(b), Radiated Emissions, Fundamental and Harmonics Para. 15.231(b), Radiated Emissions, Spurious Case Para. 15.35, Duty Cycle Determination Para. 15.231(c), Occupied Bandwidth Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 REPORT OF MEASUREMENTS Applicant: X-10 (USA), Inc. Device:Pulsed Transmitter FCC ID: B4SSRF2 Power Requirements: 2 "AAA" Batteries Applicable Rule Section:Part 15, Subpart C, Section 15.231 TEST RESULTS 15.231 (a):This device is used as a remote control transmitter. 15.231 (a)(1) &The transmitter is manually operated and ceases transmission within 5 15.231(a)(2):seconds after deactivation. 15.231 (a)(3):The transmitter does not perform periodic transmissions. 15.231 (b):The fundamental field strength did not exceed 10,333 μV/M (Average) at a test distance of 3 meters. In addition, the requirements of section 15.35 for averaging pulsed emissions and for limiting peak emissions were met. The field strength of harmonic and spurious emissions did not exceed 1,033 μV/M (AVERAGE). DETERMINATION OF FIELD STRENGTH LIMITS The field strength limits shown below are found in Section 15.231. Frequency Limit F1=2603750=L1 Fo=418Lo F2=47012500 =L2 Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 REPORT OF MEASUREMENTS (continued) The formula below was utilized to determine the limits: Limit = L1 + [(Fo-F1)(L2-L1)/(F2-F1)] Solving yields: Fundamental Limit= 10,333 μV/M (AVERAGE) @ 3 Meters Harmonic Limit= 1,033 μV/M (AVERAGE) @ 3 Meters DUTY CYCLE DETERMINATION The unit’s RF output was directly coupled to the input of the spectrum analyzer. The analyzer was set for a frequency span of 0Hz. The sweep time was then adjusted in order to display one full pulse train. The transmitter on time was then summed and compared to the time for one full cycle in order to obtain the duty cycle. Transmitter On Time=26 milliseconds (maximum) Transmitter Cycle Time =108.8 milliseconds Transmitter Duty Cycle =26 % See separate e-file plots named dutycycle.pdf for additional information. Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 SPECTRUM ANALYZER DESENSITIZATION CONSIDERATIONS Due to the nature of the emissions being measured, care was taken to ensure that the resolution bandwidth of the spectrum analyzer was adequate to provide accurate measurements. The following formula was utilized: Setting pulse desensitization equal to zero and utilizing the minimum observed pulse width of 650 μs yields a minimum required bandwidth of 1,026 Hz. FCC specified bandwidths of 100 kHz and 1 MHz were utilized below and above 1 GHz, respectively. GENERAL NOTES 1.All readings were taken utilizing a peak detector function at a test distance of 3 meters. 2.The duty cycle was applied to the peak readings in order to determine the average value of the emissions. 3.The frequency range was scanned from 30 MHz to 4.18 GHz. All emissions not reported were more than 20 dB below the specified limit. Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 EQUIPMENT LIST FCC 15.231 Testing ENTypeManufacturerDescriptionModel No.Cal DateDue 067ATest Site AttenuationRetlif3 MeterRNY8/11/20038/11/2004 128Double Ridged GuideElectro-Mechanics1 GHz - 18 GHz31056/13/20036/13/2004 133Broadband Pre-AmplifierElectro-Metrics10 kHz - 1 GHz, 26dBBPA-10006/12/20036/12/2004 141Spectrum AnalyzerHewlett Packard100 Hz - 40 GHz8566B7/23/20031/23/2004 141AGraphics PlotterHewlett PackardN/A7470A3/5/20033/5/2004 141BQuasi-Peak AdaptorHewlett Packard100 Hz - 1 GHz85650A7/23/20031/23/2004 206B6.0 dB AttenuatorTexscan0 - 1.0 GHzFP-50 - 6 dB6/12/20036/12/2004 543PreamplifierHewlett Packard1.0 GHz - 26.5 GHz8449B7/24/20037/24/2004 617Interference AnalyzerElectro-Metrics10 kHz - 1 GHzEMC-308/23/20029/30/2003 767BiconilogEMCO26 - 2000 MHz3142B9/4/20039/4/2004 Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 FCC 15.231(b) RADIATED EMISSIONS, FUNDAMENTAL & SPURIOUS CASE (See separate e-file named Refundharm & REspur.pdf) Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 FCC 15.231(c) OCCUPIED BANDWIDTH (See separate e-file named occbw.pdf) Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 FCC 15.231(c) DUTY CYCLE (See separate e-file named dutycycle.pdf) Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 Test Setup Photograph

Retlif Testing Laboratories R Test Report No. R-10067-1 FCC ID: B4SSRF2 Test Setup Photograph
