UR91A Operational Description The UR91A is a 433 MHz pulsed RF transmitter remote control. The RF remote is used in conjunction with the software installed on a remote PC. The remote can activate various audio/video functions in the remote PC through an RF mouse receiver that is connected to the PC’s USB port. In addition the remote can control TVs, DVDs and cable boxes. The remote control’s internal MCUs receive information from the keypad and convert the keystrokes into a pulse code. The pulse code is then sent to the 433 MHz RF transmitter and is used to pulse modulate the 433 MHz carrier.

LEVEL PART IDENTIFIERDESCRIPTIONQTYUOMREF ---------------------------------------------------------- --- 0 RM97685T-50UJASCO PC REMOTE,NOPACK200305291EA 1 038010H10513-2433 MC LABEL200305291EA 1 038010H11093PLAIN WHITE LABEL(20X5)MM200305291EA 1 038020H12182RATING LABEL200305291EA 1 183010H18580BATTERY COVER (SILVER)200305291EA 1 185000H17860BOTTOM CABINET (SILVER)200305291EA 1 185000H20353TOP CABINET,SILVER200305291EA 1 275000H11131RUBBER KEYPAD200305291EA 1 403011H10201BSPRING CONTACT200305291EA 1 851001H11836PCB ASSY,6V,HE021200305291EA 0.2 055-10400000CAP-C 100N +8-2 25V Y5V200305291EAC3 0.2 057-10100019CAP-E 100U 20% 10V200305291EAC2 0.2 080001H100504MHZ RESONATOR W/2 CAP200305291EAY1 0.2 210010H10010TRS-H9013200305291EAQ1 0.2 212107H10000DIODE-SI 1N4148200305293EAD2-4 0.2 220-00200220IR EMITTING LED 5MM200305291EAIR1 0.2 220-00200350LED 2MM-TOWER RED200305291EALED1 0.2 240-10506011RES-CF 1M +/-5% 1/8W200305291EAR1 0.2 240-33106011RES-CF 330R +/- 5% 1/8W200305291EAR2 0.2 240-33906011RES-CF 3R3 +/-5% 1/8W200305291EAR3 0.2 240-68106011RES-CF 680R +/-5% 1/8W200305291EAR4 0.2 358-60821001WIRE-JUMPER D=0.6MM200305292EA 0.2 403011H10199SPRING CONTACT (-VE)200305291EA 0.2 403011H10200ASPRING CONTACT (+VE)200305291EA 0.2 851001H11836-APCB ASSY, DIE, HE021200305291EA ..3042010H11156APCB200305291EA ..3211328H10268-DDIE KB-USA8 HE021200305291EA 1 851001H11839REMOTE RF 433.92MHZ200306031EA 0.2 038010H10513-2433 MC LABEL200306021EA 0.2 042010H11157APCB RF 433M92200306021EA 0.2 076-10400014CAP-MCC 100N 10% X7R 0603200306022EAC4,14 0.2 076-10900012CAP-MCC 1P .25P NPO 0603200306021EAC3 0.2 076-12100023CAP-MCC 120P 5% NPO 0603200306021EAC2 0.2 076-15900012CAP-MCC 1P5 .25P NPO 0603200306022EAC5,21 0.2 076-22000012CAP-MCC 22P 5% NPO 0603200306022EAC6,15 0.2 076-30900012CAP-MCC 3P .25P NPO 0603200306021EAC13 0.2 076-40900012CAP-MCC 4P .25P NPO 0603200306023EAC9,11,12 0.2 076-47900012CAP-MCC 4P7 .25P NPO 0603200306021EAC10 0.2 076-56000012CAP-MCC 56P 5% NPO 0603200306021EAC8 0.2 080001H10060SAW RESONATOR 433.92MHZ200306021EASAW 0.2 160-33800001INDUCTOR 330NH 10%200306021EAL2 0.2 160-56700006INDUCTOR 56NH 5% 0805 SMD200306021EAL1 0.2 209-00000003TRS-NPN 2SC3356 SMD200306022EAQ1,2 0.2 241-10100003RES-TFC 100R 5% 1/10W0603200306021EAR6 0.2 241-15100003RES-TFC 150R 5% 1/10W0603200306021EAR3 0.2 241-47000003RES-TFC 47R 5% 1/10W 0603200306021EAR4 0.2 241-68200003RES-TFC 6K8 5% 1/10W 0603200306023EAR1,2,5 0.2 354-12400000WIRE UL1007 #24 BLACK200306020.09M90MM 0.2 358-60821001WIRE-JUMPER D=0.6MM200306023EA

DCBA 12345678 ABCD 8 7 6 5 4 3 2 1 PICO ELECTRONICS Ltd., Eastfield Industrial Estate, Glenrothes, Fife, KY7 4NZ, SCOTLAND SHEET No. DATEDATE REVISION DATE FIRST DRAWN FILEDRNAPPD. DO NOT SCALE DRAWING TITLE: REV. Error : PICO.WMF File Not Found E:\SCH\JSPCREMA.SCH 11 of A JASCO PC IR REMOTE PRINT DATE 13:49:40 3-Jun-2003 BKW 28/5/03 28/5/03 28/5/03 LED1 R2330R C3100NF VSS C2100UF6.3V D2 D3 D4 Y14MHZ R11M IR1 TR1 9013G VSS R3 3R3 R4680R VSS 4 x AAA BATTERIES BATT1BATT2 +6V C4 VSS OPTIONAL * NOTES:-1/ ALL UNSPECIFIED DIODES 1N4148 OR EQUIVALENT.2/ ALL UNSPECIFIED DAUGHTER BOARD CAPACITORS ARE SMD TYPE.3/ ALL UNSPECIFIED DAUGHTER BOARD RESISTORS ARE SMD TYPE.4/ ALL UNSPECIFIED RESISTORS ARE 0.125W 5%.5/ ALL UNSPECIFIED CAPACITORS ARE AXIAL MLC TYPE."*" DENOTES COMPONENT NOT INSTALLED 11-7 26 D-0 11 D-1 12 11-6 25 11-5 24 C-1 35 C-0 34 TSTP_P 32 RSTP_N 29 SXI 31 SXO 30 D-7 18 D-6 17 D-5 16 D-4 15 D-3 14 D-2 13 10-1 2 10-0 1 10-3 4 10-2 3 10-5 6 10-4 5 10-7 8 10-6 7 11-1 20 11-0 19 11-3 22 11-2 21 C-3 37 VDD 33 C-2 36 FXI 28 FXO 27 GND 10 11-4 23 IR-OUT 9 U1 HE021 +3V VSS TR5* R9* R10* R14* D7* VDD C9* A0 1 A1 2 A2 3 VSS 4 SDA 5 SCL 6 WP 7 VCC 8 U2* VDD VSS GATE INPUT CLOCK DATA SIGNAL ENABLE NOT INSTALLED NOT INSTALLED NOT INSTALLED KEY13CBL13/3 KEY3CH.DOWN15/1KEY15RECORD15/3 KEY16STOP16/3 KEY17PAUSE17/3 KEY20SETUP14/4 KEY21115/4 KEY22216/4 KEY23317/4 KEY26A (DISPLAY)14/5 KEY27415/5 KEY28516/5 KEY29617/5 KEY32LAST14/6 KEY33B (RETURN)15/6 KEY35D (SUBTITLE)17/6 KEY39715/7 KEY41917/7KEY5CH.UP17/1 KEY9REWIND15/2 KEY10PLAY16/2 KEY11FF17/2 KEY1TV13/1 KEY4POWER16/1 KEY2MUTE14/1KEY8VOL.DOWN14/2KEY14VOL.UP14/3 KEY45A.B15/8 KEY47ENTER17/8(-/--) KEY34C (TITLE)16/6KEY40816/7KEY46016/8 KEY50UP14/19 KEY51LEFT15/19 KEY52OKAY16/19 KEY53RIGHT17/19 KEY57MENU15/20 KEY59EXIT17/20 KEY58DOWN16/20 KEY7VCR13/2KEY37DVD13/7 VSS RF DAUGHTER BOARD SHOWN FOR REFERENCE ONLY VSS R11 C4C5 C6*C7 C8 R12 TR4 R13 D2 L1 L2 DAUGHTER BOARD BATT3BATT4 KEY31PC13/6KEY55LEARN13/20NOT REQD 1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 3-Jun-2003 Sheet of File: A:\433TX-N5.SCH Drawn By: R1 6K8 R2 6K8 R4 22P R3 150R R56K8 SAW1 433MHz PCB2 L1 56N PCB1 C2 120P C1 * C31P C51P5 C6 47R C4 100N Q1 3356 6V C8 56P C7 * C94P C104P7 C12 4P C13 3P C11 4P Q2 2SC3356 R6 100R C14100N 6V C1522P RF IN C20 * 433MHz Tx C211P5 L2 0.33u 90MM ANT 851001H11839

Test Report No. R-9936 FCC ID: B4SUR91A APPLICANT X-10 USA, Inc. 19823, 58 th Place S. Kent, WA 98032 MANUFACTURER X-10 Electronics Shenzhen Co. Ltd. X-10 Building Labour Industrial District Shenzhen, Xixiang, Bao An Guang Dong, China, 518102 TEST SPECIFICATION: FCC Rules and Regulations Part 15, Subpart C, Para. 15.231 TEST PROCEDURE: ANSI C63.4:2000 TEST SAMPLE DESCRIPTION BRANDNAME: X-10 USA Model Number: UR91A TYPE: Pulsed Transmitter POWER REQUIREMENTS: 4 “AAA” Batteries FREQUENCY OF OPERATION: 433.92 MHz TESTS PERFORMED Para. 15.231(b), Radiated Emissions, Fundamental and Harmonics Para. 15.231(b), Radiated Emissions, Spurious Case Para. 15.35, Duty Cycle Determination Para. 15.231(c), Occupied Bandwidth REPORT OF MEASUREMENTS Applicant: X-10 (USA), Inc. Brand Name: GE Universal Device: Pulsed Transmitter FCC ID: B4SUR91A Test Report No. R-9936 FCC ID: B4SUR91A Power Requirements: 4 “AAA” Batteries Applicable Rule Section: Part 15, Subpart C, Section 15.231 Test Report No. R-9936 FCC ID: B4SUR91A REPORT OF MEASUREMENTS (continued) TEST RESULTS 15.231 (a): This device is used as a remote control transmitter. 15.231 (a)(1) & The transmitter is manually operated and ceases transmission within 5 15.231(a)(2): seconds after deactivation. 15.231 (a)(3): The transmitter does not perform periodic transmissions. 15.231 (b): The fundamental field strength did not exceed 10,996.7 μV/M (Average) at a test distance of 3 meters. In addition, the requirements of section 15.35 for averaging pulsed emissions and for limiting peak emissions were met. The field strength of harmonic and spurious emissions did not exceed 1,099.7 μV/M (AVERAGE). DETERMINATION OF FIELD STRENGTH LIMITS The field strength limits shown below are found in Section 15.231. Frequency Limit F1 = 260 3750 = L1 Fo = 433.92 Lo F2 = 470 12500 = L2 Test Report No. R-9936 FCC ID: B4SUR91A REPORT OF MEASUREMENTS (continued) The formula below was utilized to determine the limits: Limit = L1 + [(Fo-F1)(L2-L1)/(F2-F1)] Solving yields: Fundamental Limit = 10,996.7 μV/M (AVERAGE) @ 3 Meters Harmonic Limit = 1,099.7 μV/M (AVERAGE) @ 3 Meters DUTY CYCLE DETERMINATION The unit’s RF output was directly coupled to the input of the spectrum analyzer. The analyzer was set for a frequency span of 0Hz. The sweep time was then adjusted in order to display one full pulse train. The transmitter on time was then summed and compared to the time for one full cycle in order to obtain the duty cycle. Transmitter On Time = 26.02 milliseconds (maximum) Transmitter Cycle Time = >100 milliseconds Transmitter Duty Cycle = 26.02 % See separate e-file for plots named dutycycle.pdf for additional information. Test Report No. R-9936 FCC ID: B4SUR91A SPECTRUM ANALYZER DESENSITIZATION CONSIDERATIONS Due to the nature of the emissions being measured, care was taken to ensure that the resolution bandwidth of the spectrum analyzer was adequate to provide accurate measurements. The following formula was utilized: Setting pulse desensitization equal to zero and utilizing the minimum observed pulse width of 520 μs yields a minimum required bandwidth of 1,282.10 Hz. FCC specified bandwidths of 100kHz and 1MHz were utilized below and above 1GHz, respectively. GENERAL NOTES All readings were taken utilizing a peak detector function at a test distance of 3 meters. The duty cycle was applied to the peak readings in order to determine the average value of the emissions. The frequency range was scanned from 30 MHz to 4.3392 GHz. All emissions not reported were more than 20 dB below the specified limit. Test Report No. R-9936 FCC ID: B4SUR91A EQUIPMENT LIST FCC Part 15 Subpart C Fundamental & Harmonics EN Type Manufacturer Description Model No. Cal Date Due Date 067 Open Area Test Site Retlif 3 Meter RNY 09/20/2000 09/20/2003 128 Double Ridged Guide Electro-Mechanics 1 GHz - 18 GHz 3105 06/07/2002 06/07/2003 133 Broadband Pre-Amplifier Electro-Metrics 10 kHz - 1 GHz, 26dB BPA-1000 06/11/2002 06/11/2003 141 Spectrum Analyzer Hewlett Packard 100 Hz - 40 GHz 8566B 01/23/2003 07/23/2003 141A Graphics Plotter Hewlett Packard N/A 7470A 03/05/2003 03/05/2004 141B Quasi-Peak Adaptor Hewlett Packard 100 Hz - 1 GHz 85650A 01/23/2003 07/23/2003 206B 6.0 dB Attenuator Texscan 0 - 1.0 GHz FP-50 - 6 dB 06/11/2002 06/11/2003 543 Preamplifier Hewlett Packard 1.0 GHz - 26.5 GHz 8449B 07/11/2002 07/11/2003 617 Interference Analyzer Electro-Metrics 10 kHz - 1 GHz EMC-30 08/23/2002 08/23/2003 767 Biconilog EMCO 26 - 2000 MHz 3142B 09/03/2002 09/03/2003 Test Report No. R-9132-1 FCC ID: B4SUR91A FCC 15.231(b) RADIATED EMISSIONS, FUNDAMENTAL & SPURIOUS CASE (See separate e-file named Refundharm & REspur.pdf) FCC 15.231(c) OCCUPIED BANDWIDTH (See separate e-file named occbw.pdf) Test Report No. R-9936 FCC ID: B4SUR91A FCC 15.231(c) DUTY CYCLE (See separate e-file named dutycycle.pdf) Test Report No. R-9936 FCC ID: B4SUR91A Test Setup Photographs
