BABFT0044DCar Navigation

DENSO TEN Limited

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Apr 10, 2013
Application Purpose: Original Equipment
Date of Application: Apr 09, 2013
Equipment Note: Car Navigation
Frequency Range: 2402.00000000 - 2480.00000000
Company: DENSO TEN Limited
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

FT0049D_User manual Explanation of the icon FUJITSU TEN CONFIDENTIAL ※The screen design may be changed. FUJITSU TEN CONFIDENTIAL FUJITSU TEN CONFIDENTIAL FUJITSU TEN CONFIDENTIAL FUJITSU TEN CONFIDENTIAL FUJITSU TEN CONFIDENTIAL SETUPWi‐Fi 2. Touch the "Setup". ※The screen design may be changed. 3. Touch the "Wi‐Fi" .4. Touch the "Wi‐Fi Power" . 5. Touch the "On" . 6. Touch the "Easy Setup" . 7. Touch the "Push Button" .8. This screen is displayed when searching the device which you would like to connect. 1.Press the "APPS" button. FUJITSU TEN CONFIDENTIAL ＞For vehicles sold in the U.S.A. ・FCC ID: BABFT0044D ＞For vehicles sold in Canada IC: 2024B-FT0044D CAUTION: Radio Frequency Radiation Exposure This equipment complies with IC radiation exposure limits set forth for uncontrolled equipment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated with at least 20cm and more between the radiator and person's body (excluding extremities: hands, wrists, feet and ankles). This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. ・CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should be installed and operated with at least 20cm and more between the radiator and person's body (excluding extremities: hands, wrists, feet and ankles). ・Co-location: This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

External Photos

FrontRear Right)Lleft Top Bottom CONFIDENTIAL CONFIDENTIALCONFIDENTIAL CONFIDENTIAL FT0044D External Photos FT0044D External PhotosFT0044D External Photos FT0044D External Photos ■Audio Board □Component side□Solder side ■CPU Board □Component side□Solder side ■SW Board □Component side□Solder side CONFIDENTIAL CONFIDENTIALCONFIDENTIAL CONFIDENTIAL FT0044D Internal Photos FT0044D Internal PhotosFT0044D Internal Photos FT0044D Internal Photos FT0044D Internal Photos FT0044D Internal PhotosFT0044D Internal Photos FT0044D Internal Photos ■Relay Board □Component side□Solder side CONFIDENTIAL CONFIDENTIALCONFIDENTIAL CONFIDENTIAL Bluetooth RF line Wi-Fi RF line Wi-Fi RF line Bluetooth RF line Wi-Fi Antenna mounting position Bluetooth Antenna mounting position

ID Label/Location Info

FT0044D Label MODEL:FT0044D

Internal Photos

Proprietary Information Confidential ALPS CONFIDENTIAL Copyright © 201 2 ALPS ELECTRIC CO.,LTD. UGKZ2-E### Photo View Outside View Outside View Inside View (TOP) (BOTTOM) Proprietary Information Confidential ALPS CONFIDENTIAL Copyright © 201 2 ALPS ELECTRIC CO.,LTD.

RF Exposure Info

ETC Report No. : 13-01-MAS-044-06 Sheet 1 of 2 Sheets FCC ID. : BABFT0044D Rev. No 1.0 MAXIMUM PERMISSIBLE EXPOSURE Standard Applicable Section 15.247 (b)(5) : Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this Chapter. Section 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (nW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 1 30 F = Frequency in MHz Calculations Friis transmission formula: P d = ( P out * G ) / ( 4 * pi * r 2 ) Where P d = power density in mW/cm 2 P out = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm The limit of P d is 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the P d at 20 cm is meet the limit of MPE. ETC Report No. : 13-01-MAS-044-06 Sheet 2 of 2 Sheets FCC ID. : BABFT0044D Rev. No 1.0 Result (Worse case mode) Radio Technology Operation Frequency (MHz) Distance (cm) Maximum Peak Output Power (dBm) Antenna Gain (dBi) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) WLAN 2462 20 20.29 2.34 0.03645 1 Bluetooth 2441 20 -0.40 0.63 0.00021 1 The P d at 20 cm distance calculated from the Friis transmission formula is mush smaller than the limit requirement 1 mW/cm 2 or 10W/m 2 . The Installation Manual instructs the user to install the device such that it has a separation of at least 20 cm from persons to comply with the FCC's requirements. This separation of 20 cm more than meets the FCC's and Industry Canada RF exposure requirements. Simultaneous Evaluation: Both of WLAN 2.4GHz and Bluetooth radio can transmit simultaneously. The formula of calculated MPE is: CPD1/LPD1+CPD2/LPD2+...etc. ＜ 1 CPD=Calculated Power Density LPD=Limit of Power Density The MPE evaluation is 0.03645/1+0.00021/1=0.03666＜1, which confirm the device comply the MPE limit.

Test Report

FCC ID: BABFT0044D Sheet 1 of 75 Sheets ETC Report No. : 13-01-MAS-044-02 Rev. No 1.0 CONFORMANCE TEST REPORT FOR FCC 47 CFR, Part 15 Subpart C Report No.: 13-01-MAS-044-02 Client: FUJITSU TEN LIMITED Product: Car Navigation Model: FT0044D FCC ID: BABFT0044D Manufacturer/supplier: FUJITSU TEN LIMITED Date test item received: 2013/01/07 Date test campaign completed: 2013/03/06 Date of issue: 2013/03/06 The test result onl y corresponds to the tested sample. It is not permitted to copy this report, in part or in full, without the permission of the test laboratory. Total number of pages of this test report: 75 pages Total number of pages of photos: External photos 1 pages Internal photos 3 pages Setup photos 1 pages Test Engineer Checked By Approved By Phillip Luo Perry Lin James Cheng ELECTRONICS TESTING CENTER, TAIWAN NO.8, LANE 29, WENMING RD., LESHAN TSUEN, GUISHAN SHIANG, TAOYUAN COUNTY, TAIWAN 33383, R.O.C.TAIWAN, R.O.C. TEL: (03) 3276170~4 INT: +886-3-3276170~4 FAX: (03) 3276188 INT: +886-3-3276188 FCC ID: BABFT0044D Sheet 2 of 75 Sheets ETC Report No. : 13-01-MAS-044-02 Rev. No 1.0 Client : FUJITSU TEN LIMITED Address : 2-28, Gosho-dori, 1-chome, Hyogo-ku, Kobe 652-8510 Japan Manufacturer : FUJITSU TEN LIMITED Address : 2-28, Gosho-dori, 1-chome, Hyogo-ku, Kobe 652-8510 Japan EUT : Car Navigation Trade name : ---- Model No. : FT0044D Power Source : 12Vdc battery Regulations applied : FCC 47 CFR, Part 15 Subpart C The testing described in this report has been carried out to the best of our knowledge and ability, and our responsibility is limited to the exercise of reasonable care. This certification is not intended to believe the sellers from their legal and/or contractual obligations. The compliance test is only certified for the test equipment and the results of the testing report relate only to the item tested. The compliance test of this report was conducted in accordance with the appropriate standards. It’s not intention to assure the quality and performance of the product. This report shall not be reproduced except in full, without the approval of ETC. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. Laboratory Introduction: Electronics Testing Center, Taiwan is recognized, filed and mutual recognition arrangement as following:  ISO9001: TüV Product Service  ISO/IEC 17025: BSMI, TAF, NCC, NVLAP, ILAC MRA, UL, Compliance  Filing: FCC, Industry Canada, VCCI  MRA: Australia, Hong Kong, New Zealand, Singapore, USA, Japan, Korea, China, APLAC through TAF  FCC Registration Number: 91095, 392735, 278818  Industry Canada Site Registration number: IC 2949A-2 NVLAP Lab Code 200133-0 FCC ID: BABFT0044D Sheet 3 of 75 Sheets ETC Report No. : 13-01-MAS-044-02 Rev. No 1.0 Table of Contents Page 1 GENERAL INFORMATION ....................................................................................................... 5 1.1 Product Description...................................................................................................................... 5 1.2 Characteristics of Device ............................................................................................................. 5 1.3 Test Methodology ........................................................................................................................ 5 1.4 Modifiction List of EUT .............................................................................................................. 5 1.5 Test Facility.................................................................................................................................. 5 1.6 Test Summary .............................................................................................................................. 5 2 PROVISIONS APPLICABLE...................................................................................................... 6 2.1 Definition ..................................................................................................................................... 6 2.2 Requirement for Compliance ....................................................................................................... 7 2.3 Restricted Bands of Operation ..................................................................................................... 9 2.4 Labeling Requirement .................................................................................................................. 9 2.5 User Information ........................................................................................................................ 10 3. SYSTEM TEST CONFIGURATION ........................................................................................ 11 3.1 Justification ................................................................................................................................ 11 3.2 Devices for Tested System......................................................................................................... 11 4 RADIATED EMISSION MEASUREMENT ............................................................................ 13 4.1 Applicable Standard ................................................................................................................... 13 4.2 Measurement Procedure............................................................................................................. 13 4.3 Measuring Instrument ................................................................................................................ 15 4.4 Radiated Emission Data ............................................................................................................. 16 4.5 Field Strength Calculation ......................................................................................................... 22 5 CONDUCTED EMISSION MEASUREMENT ........................................................................ 23 6 ANTENNA REQUIRE…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: BABFT0044D ETC Report No. : 13-01-MAS-044 IC ID: 2024B-FT0044D Sheet 1 of 1 Sheets Photos of Radiation Measuring Setup
