BABTN0046ACar Audio

TN0046A User Manual DENSO TEN CONFIDENTIAL 1 Model Name Car Audio Model Number TN0046A Index 1-Rating 2-Button function spec 3-Bluetooth Device Pairing Procedure ItemContents RATED VOLTAGE12.0V negative ground LOAD IMPEDANCE 8Ω BACK UP CURRENT 1mA OR LESS RATED CURRENT3.0A OR LESS (VCC =14.4V 0.5W Output) 1.Rating DENSO TEN CONFIDENTIAL 2 2. Button Function Spec DENSO TEN CONFIDENTIAL 3 No. 釦名称 Button Name 時間 Time BEEP 機能 Function ⑪ PUSH －- POWER ON (POWER OFF時） Power On (when Power Off) 0.8sec以上 Over 0.8sec - POWER OFF (POWER ON時） Power Off (when Power On) 0.8sec未満 Below 0.8sec - ソース切替モードへの移行 Move to source change mode -- ソースの決定 Decide the source -- FUNCTION 設定モードの決定 Set to the Function setting mode. TURN -- （Rotary）音量調整 Volume control -- ソースの選択 Select the source -- FUNCTION 設定モードの選択 Select to the Function setting mode. ⑫FUNC -- FUNCTIONモードへの移行 Move to FUNCTION mode -- FUNCTIONモードの解除 Release to FUNCTION mode ③∨ －- FUNCTIONモードの解除 Release to FUNCTION mode －- ソース切替モードの解除 Release to source change mode 共通部操作機能 Common Part Operation Function DENSO TEN CONFIDENTIAL 4 No. 釦名称 Button Name 時間 Time BEEP 機能 Function ②∧ 0.8sec未満 Below 0.8sec - TUNE UP 0.8sec以上1.5sec 未満 Over 0.8sec and Below 1.5sec X SEEK UP 1.5sec以上 Over 1.5sec － Non-Stop SEEK UP ③∨ 0.8sec未満 Below 0.8sec - TUNE DOWN 0.8sec以上1.5sec 未満 Over 0.8sec and Below 1.5sec X SEEK DOWN 1.5sec以上 Over 1.5sec － Non-Stop SEEK DOWN ⑤～ ⑩ Preset 1～6 1.7sec未満 Below 1.7sec - P.CHの呼び出し Call preset channel. 1.7sec以上 Over 1.7sec X P.CHへの書込み Write preset channel. ラジオ部操作機能 Radio Part Operation Function DENSO TEN CONFIDENTIAL 5 No. 釦名称 Button Name 時間 Time BEEP 機能 Function ② ∧ 0.8sec未満 Below 0.8sec - FILE UP 0.8sec以上 Over 0.8sec X FOLDER UP ③ ∨ 0.8sec未満 Below 0.8sec - FILE DOWN 0.8sec以上 Over 0.8sec X FAST DOWN ⑤ Preset 1-- ・FILE REPEAT ・FOLDER REPEAT ・FOLDER RANDOM-FILE REPEAT、RANDOM-FILE REPEAT ⑥ Preset 2-- ・RANDOM (1-FOLDER RANDM) ・FOLDER RANDOM (1-DISC RANDOM) ⑨ Preset 5 0.8sec未満 Below 0.8sec - FOLDER DOWN 0.8sec以上 Over 0.8sec X HOME JUMP ⑩ Preset 6 0.8sec未満 Below 0.8sec - FOLDER UP ⑪ PUSH －- Fileの決定(再生開始) Activate File (Start playback.) －- リストカテゴリの決定 Activate Category (リスト選択モードへの移行) (Move to list select mode) -- 選択TEXTの決定 Activate the selected TEXT TURN -- TEXT切替 Change TEXT －- リスト切替 Change List -- リストカテゴリ切替 Change List category ⑫FUNC 0.8sec以上 Over 0.8sec - TEXTページの切替 Switching the TEXT page ⑬LIST - - TEXT切替モードの解除 Release TEXT change mode. - - リストカテゴリ選択モードの解除 Release list category select mode 0.8sec未満 Below 0.8sec - リストカテゴリ選択モードへの移行 Move to list category mode. 0.8sec以上 Over 0.8sec - TEXT切替モードへの移行 Move to TEXT change mode. ③∨ - - TEXT切替モードの解除 Release TEXT change mode. - - リストカテゴリ選択モードの解除 (カテゴリ選択ﾓｰﾄﾞ中） Release list category select mode (During Category selection mode.) 0.8sec未満 Below 0.8sec - 1階層上がる（ﾘｽﾄ選択ﾓｰﾄﾞ中） Back to the previous hierarchy. (During list selection mode.) 0.8sec以上 Over 0.8sec - 通常再生モードへの移行（ﾘｽﾄ選択ﾓｰﾄﾞ中） Move to normal playback mode. (During list selection mode.) USB部操作機能 USB Part Operation Function DENSO TEN CONFIDENTIAL 6 No. 釦名称 Button Name 時間 Time BEEP 機能 Function ②∧ 0.8sec未満 Below 0.8sec － TRACK UP 0.8sec以上 Over 0.8sec X FAST UP ③∨ 0.8sec未満 Below 0.8sec － TRACK DOWN 0.8sec以上 Over 0.8sec X FAST DOWN ⑤ Preset 1 － － ・TRACK REPEAT ・1-ALBUM REPEAT ⑥ Preset 2 － － ・RANDOM (All Track) ・ALBUM RANDOM ⑦ Preset 3 － － PAUSE ⑧ Preset 4 －－ PLAY ⑨ Preset 5 －－ ALBUM DOWN ⑩ Preset 6 －－ ALBUM UP ⑪ PUSH －－ 選択TEXTの決定 Activate the selected item. TURN －－ TEXT切替 Change TEXT －－ BTAモード時音量調整 Volume control for BTA mode ⑫FUNC 0.8sec以上 Over 0.8sec － TEXTページの切替 Switching the TEXT page ⑬LIST － － TEXT切替モードの解除 Release TEXT change mode. 0.8sec以上 Over 0.8sec － TEXT切替モードへの移行 Move to TEXT change mode. ③∨ － － TEXT切替モードの解除 Release TEXT change mode. BT-Audio操作機能 BT-Audio Part Operation Function DENSO TEN CONFIDENTIAL 7 No. 釦名称 Button Name 時間 Time BEEP 機能 Function ⑪ TURN -- (Rotary) Mini Jack Volume Control AUX部操作機能 AUX Part Operation Function DENSO TEN CONFIDENTIAL 8 No. 釦名称 Button Name 時間 Time BEEP 機能 Function ④ OFF HOOK -- TELモードへの移行 Move TEL mode -- 通話開始 Call start -- 三者通話の開始 Three-way calling start -- 発信 outgoing call 0.8sec未満 Below 0.8sec - （通話中かつ保留呼有り時）通話呼切替 (During a call and Hold )Switching telephone call 0.8sec以上 Over 0.8sec - プライベートモードへの移行（携帯電話側 で通話） Move private mode (Talk by mobile phone) ⑬LIST -- 通話終了 End the call -- 現在の通話回線の切断 End the current call line -- 発信の取り消し Cancel the sending -- （着信中）着信拒否 Reject the call (During incoming) -- TELモードの解除 Release TEL mode ②∧ －－ 送話音量UP MIC Volume UP －－ トーン送出 Tone Sending －－ 入力桁の切替 Switch input digit ③∨ －－ 送話音量DOWN MIC Volume DOWN －－ 入力文字の削除 Delete input character BT-HF部操作機能 BT-HF Part Operation Function DENSO TEN CONFIDENTIAL 9 No. 釦名称 Button Name 時間 Time BEEP 機能 Function ⑪ PUSH －－ 発信outgoing call －－ 電話番号マニュアル入力モードへ移行 Move to phone number manual input mode －－ 発信履歴リストへの移行 Move to outgoing call history list －－ 着信履歴リストへの移行 Move to incoming call history list －－ 不在着信履歴リストへの移行 Move to missed call history list TURN －－ (Rotary) TELモードリストの切替 change TEL mode list －－ (Rotary) 履歴リスト選択select history list －－ (Rotary) 入力番号切替change input number －－ (Rotary) （着信中）着信音量の調整 Ringtone level control (During incoming) －－ (Rotary) （通話中）受話音量の調整 Call volume control (During a call) ⑫ FUNC －－ （通話中）トーンデータマニュアル入力モードへの移行 Move tone data manual input mode (During a call) 0.8sec以上 Over 0.8sec － TEXTページの切替 Switching the TEXT page ③ ∨ －－ 電話番号マニュアル入力モードの解除 Release phone number manual input mode －－ トーンデータマニュアル入力モードの解除 Release tone data manual input mode －－ 履歴選択リストの解除 Release history select list －－ TELモードの解除 Release TEL mode BT-HF部操作機能 BT-HF Part Operation Function DENSO TEN CONFIDENTIAL 10 3.Bluetooth Device Pairing Procedure 1. Press FUNC knob to display the “ SETUP ” mode. 2. Turn MODE knob to select “Bluetooth”, and then press MODE knob. 3. Press MODE knob to select “Pairing” 4. Operate the Bluetooth device to register. For Bluetooth devices not supporting Secure Simple Pairing (SSP): Enter the passkey into the Bluetooth device. For Bluetooth devices supporting Secur…

Text truncated - open the document above for the full version.

DENSO TEN Limited 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan Tel.: +81.78-682-2159 Date: January 16, 2024 Certification Attestation Statements Attn: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA To Whom It May Concern: 47 CFR section 2.911(d)(5)(i) Attestation Statement DENSO TEN Limited certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: (Not applicable) 47 CFR section 2.911(d)(5)(ii) Attestation Statement DENSO TEN Limited (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☒ - is not identified on the Covered List as an entity producing “covered” equipment. Thank you, Kaoru Abe Department General Manager Quality Assurance Group Quality Control Div Regulatory Management Dept. DENSO TEN Limited Tel # 81 78-682-2159 FCC ID: BABTN0046A 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters should be placed on appropriate letterhead.

DENSO TEN Limited 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan Tel.: +81.78-682-2159 U.S. Agent Designation for Service of Process ATTENTION: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA REGARDING: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Approve-IT, Inc. Contact Name: Nathan Grinager Street Address: 8011 34 th Ave South, Suite 342 City/Province/Zip: Bloomington, MN 55425 Telephone No: 651-247-1678 Email: [email protected] FRN #: 0027533835 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Signed by (Printed Name/Title): Nathan Grinager / Co-President *This letter must be dated within 5 years of the date the application is submitted to the TCB for device certification The Applicant confirms its explicit consent and acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: DENSO TEN Limited FCC ID: BABTN0046A Contact Name: Kaoru Abe Street Address: 2-28, Gosho-Dori 1-Chome, Hyogo-Ku City/Province/Zip: Kobe 652-8510, JAPAN Telephone No: 81 78-682-2159 Email: [email protected] Grantee FRN #: 0008516007 Applicant Signature: Date: January 16, 2024 17 January 2024 Signed by (Printed Name/Title): Kaoru Abe / Department General Manager Quality Assurance Group Quality Control Div Regulatory Management Dept.

DENSO TEN Limited 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan Tel.: +81.78-682-2159 Letter of Authorization Date: January 16, 2024 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Applicant: DENSO TEN Limited FCC ID: BABTN0046A To whom it may concern: We, the undersigned, hereby authorize Yukari Ito of Consumer, Medical & Information Technologies Division, UL Japan, Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Japan, Inc. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. The application for the subject equipment has not been submitted to another TCB for certification. Sincerely Yours, Kaoru Abe Department General Manager Quality Assurance Group Quality Control Div Regulatory Management Dept. DENSO TEN Limited

DENSO TEN Limited 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan Tel.: +81.78-682-2159 Request for Confidentiality Date: January 16, 2024 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Applicant : DENSO TEN Limited FCC ID : BABTN0046A To whom it may concern: Please be advised that the following information is to be held confidential on behalf of us, referring to the FCC rules 0.457 and 0.459: Block Diagram Theory of Operation Schematics Parts List The application contains technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, Kaoru Abe Department General Manager Quality Assurance Group Quality Control Div Regulatory Management Dept. DENSO TEN Limited

DENSO TEN Limited 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan Tel.: +81.78-682-2159 Request for Short-Term Confidentiality Date: January 16, 2024 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Applicant : DENSO TEN Limited FCC ID : BABTN0046A To whom it may concern: Please be advised that the following information is to be held in confidence for 180 days from the date of the Grant of Equipment Authorization based on the FCC rules 0.457 and 0.459: External Photos Internal Photos Test Setup Photos User Manual The application contains technical information, which we deem to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, ____________________________________ Kaoru Abe Department General Manager Quality Assurance Group Quality Control Div Regulatory Management Dept. DENSO TEN Limited

TN0046A 外部写真/External photo DENSO TEN CONFIDENTIAL

TN0046A label diagram TOP ラベル図に記載されている認証表示は表示例です。 *部には認可後、正式な認可番号が表示されます。 ラベル材質はユポ80(UV)、インクはUVインクを使用しており、通常の合成紙に比べて繰 り返しの擦れ試験に対する耐久性がアップしています。 The certification display shown on the label diagram is an example display. *After approval, the official approval number will be displayed in the part. The label material is Yupo 80 (UV) and the ink is UV ink, which has improved durability against repeated rubbing tests compared to ordinary synthetic paper. Label pasting position

TN0046A 内部写真/internal photo DENSO TEN CONFIDENTIAL TN0046A 基板写真/PC Board photo Main PCBPanel PCBBT PCB DENSO TEN CONFIDENTIAL

Test Report No. 14937633H-B-R2 Page 1 of 31 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 EMI TEST REPORT Test Report No. 14937633H-B-R2 Customer DENSO TEN Limited Description of EUT Car Audio Model Number of EUT TN0046A FCC ID BABTN0046A Test Regulation FCC Part 15 Subpart B Test Result Complied Issue Date February 9, 2024 Remarks - Representative test engineer Approved by Tetsuro Yoshida Engineer Ryota Yamanaka Engineer CERTIFICATE 5107.02 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan, Inc. There is no testing item of "Non-accreditation". Report Cover Page - Form-ULID-003532 (DCS:13-EM-F0429) Issue# 23.0 Test Report No. 14937633H-B-R2 Page 2 of 31 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 ANNOUNCEMENT REVISION HISTORY Original Test Report No. 14937633H-B This report is a revised version of 14937633H-B-R1. 14937633H-B-R1 is replaced with this report. Revision Test Report No. Date Page Revised Contents - (Original) 14937633H-B December 18, 2023 - 1 14937633H-B-R1 February 7, 2024 Correction of following points by re-test. - P.5: Section 2.1: Test Date - P.6 Section 3.2: Worst margin - P.15 to 20, 23 to 25: Test data 2 14937633H-B-R2 February 9, 2024 P.26: Update and add Last Calibration Date for LIMS ID (141530, 141566, 141568, 141532, 141554, 141903 )  This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc.  The results in this report apply only to the sample tested. (Laboratory was not involved in sampling.)  This sample tested is in compliance with the limits of the above regulation.  The test results in this test report are traceable to the national or international standards.  This test report must not be used by the customer to claim product certification, approval, or endorsement by the A2LA accreditation body.  This test report covers EMC technical requirements. It does not cover administrative issues such as Manual or non-EMC test related Requirements. (if applicable)  The all test items in this test report are conducted by UL Japan, Inc. Ise EMC Lab.  The opinions and the interpretations to the result of the description in this report are outside scopes where UL Japan, Inc. has been accredited.  The information provided from the customer for this report is identified in SECTION 1.  For test report(s) referred in this report, the latest version (including any revisions) is always referred. Test Report No. 14937633H-B-R2 Page 3 of 31 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Reference: Abbreviations (Including words undescribed in this report) A2LA The American Association for Laboratory Accreditation GPS Global Positioning System AAN Asymmetric Artificial Network Hori. Horizontal AC Alternating Current ICES Interference-Causing Equipment Standard AM Amplitude Modulation I/O Input/Output AMN Artificial Mains Network IEC International Electrotechnical Commission Amp, AMP Amplifier IEEE Institute of Electrical and Electronics Engineers ANSI American National Standards Institute IF Intermediate Frequency Ant, ANT Antenna ILAC International Laboratory Accreditation Conference AP Access Point ISED Innovation, Science and Economic Development Canada ASK Amplitude Shift Keying ISN Impedance Stabilization Network Atten., ATT Attenuator ISO International Organization for Standardization AV Average JAB Japan Accreditation Board BPSK Binary Phase-Shift Keying LAN Local Area Network BR Bluetooth Basic Rate LCL Longitudinal Conversion Loss BT Bluetooth LIMS Laboratory Information Management System BT LE Bluetooth Low Energy LISN Line Impedance Stabilization Network BW BandWidth MRA Mutual Recognition Arrangement C.F Correction Factor N/A Not Applicable Cal Int Calibration Interval NIST National Institute of Standards and Technology CAV CISPR AV NS No signal detect. CCK Complementary Code Keying NSA Normalized Site Attenuation CDN Coupling Decoupling Network OBW Occupied BandWidth Ch., CH Channel OFDM Orthogonal Frequency Division Multiplexing CISPR Comite International Special des Perturbations Radioelectriques PER Packet Error Rate Corr. Correction PK Peak CPE Customer premise equipment P LT long-term flicker severity CW Continuous Wave POHC(A) Partial Odd Harmonic Current DBPSK Differential BPSK Pol., Pola. Polarization DC Direct Current PR-ASK Phase Reversal ASK DET Detector P ST short-term flicker severity D-factor Distance factor QAM Quadrature Amplitude Modulation Dmax maximum absolute voltage change during an observation period QP Quasi-Peak DQPSK Differential QPSK QPSK Quadrature Phase Shift Keying DSSS Direct Sequence Spread Spectrum r.m.s., RMS Root Mean Square DUT Device Under Test RBW Resolution BandWidth EDR Enhanced Data Rate RE Radio Equipment e.i.r.p., EIRP Equivalent Isotropically Radiated Power REV Reverse EM clamp Electromagnetic clamp RF Radio Frequency EMC ElectroMagnetic Compatibility RFID Radio Frequency Identifier EMI ElectroMagnetic Interference RNSS Radio Navigation Satellite Service EMS ElectroMagnetic Susceptibility RSS Radio Standards Specifications EN European Norm Rx Receiving e.r.p., ERP Effective Radiated Power SINAD Ratio of (Signal + Noise + Distortion) to (Noise + Distortion) ETSI European Telecommunications Standards Institute S/N Signal to Noise ratio EU European Union SA, S/A Spectrum Analyzer EUT Equipment Under Test SG Signal Generator Fac. Factor SVSWR Site-Voltage Standing Wave Ratio FCC Federal Communications Commission THC(A) Total Harmonic Current FHSS Frequency Hopping Spread Spectrum THD(%) Total Harmonic Distortion FM Frequency Modulation TR, T/R Test Receiver Freq. Frequency Tx Transmitting FSK Frequency Shift Keying VBW Video BandWidth Fund Fundamental Vert. Vertical FWD Forward WLAN Wireless LAN GFSK Gaussian Frequency-Shift Keying xDSL Generic term for all types o…

Text truncated - open the document above for the full version.

Test Report No. 14937633H-B-R2 Page 27 of 31 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 APPENDIX 3: Photographs of test setup Radiated Emission (Below 1 GHz) Mode 1 Photo 1 Photo 2 Test Report No. 14937633H-B-R2 Page 28 of 31 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Radiated Emission (Below 1 GHz) Mode 2 Photo 1 Photo 2 Test Report No. 14937633H-B-R2 Page 29 of 31 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Radiated Emission (Above 1 GHz) Mode 1 Photo 1 Photo 2 Test Report No. 14937633H-B-R2 Page 30 of 31 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Radiated Emission (Above 1 GHz) Mode 2 Photo 1 Photo 2 Test Report No. 14937633H-B-R2 Page 31 of 31 UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 Japan / +81-596-24-8999 Antenna Terminal Conducted Tests Photo 1 Photo 2 End of Report
