BABFT0048ACar Navigation

User manual Model name Model No Car Navigation Index 1-Function list 2-Button function 3-FCC Page 3P-6P 7P 8P (1/8) FT0048A DENSOTENCONFIDENTIAL 株式会社デンソーテン DENSO TEN LIMITED (2/8) revision history revision number Date author Content of change 002021/02/02NEW 012021/04/08P,5 Bluetooh,WiFiadditional 株式会社デンソーテン DENSO TEN LIMITED DENSOTENCONFIDENTIAL 1-Function list (3/8) Function North America Canada ハンドルSTEERING WHEELLHD ← NAVINAVIGATIONSD ← RADIO←AM/FM ← フェースダイバーPHASE DIVER○ ← SWダイバーSWITCHING DIVER－ ← DTVDIGITAL TV－ ← デッキDECK DVD- PLAYER ← CDリッピングCD RIPPING－ ← USBオーディオUSB AUDIO○ ← BTオーディオBLUETOOTH AUDIO○ ← AUX←○ ← VTR←○ ← ハンズフリーHANDSFREE○ ← 後席映像出力 (DVD/VTR) REAR SEAT VIDEO OUTPUT（DVD/VTR） ○ ← A/C操作 A/C OPERATION SCREEN ○ ← 言語切替SET LANGUAGE○ ← 音声認識 SPEECH RECOGNITION ○ ← 株式会社デンソーテン DENSO TEN LIMITED DENSOTENCONFIDENTIAL (4/8) Function North America North America 周辺監視 SURROUND MONITORING○ ← クリソナ CLEARANCE SONAR ○ ← e-NAVIe-NAVI○ ← リモートサー ビス REMOTE SERVICE ○ ← ハザードＳＷHAZARD SWITCH- ← P席A/Bｲﾝ ｼﾞｹｰﾀ PASSENGER INDICATOR - ← ｾｷｭﾘﾃｨｲﾝｼﾞ ｹｰﾀ SECURITY INDICATOR - ← 株式会社デンソーテン DENSO TEN LIMITED DENSOTENCONFIDENTIAL (5/8) Function North America Canada 定格電圧RATED VOLTAGEDC 13.2V← 動作電源電圧 OPERATING VOLTAGE DC 10.5V～ 16V ← 暗電流BACK UP CURRENT MAX：3.7mA以下 (12V) MAX：3.7mA OR LESS(12V) ← 消費電流 POWER CONSUMPTION MAX：9.9A以下 (10.5V) MAX：9.9A OR LESS(10.5V) ← AM 受信周波数 AM TUNING RANGE 530～1710ｋ Ｈｚ ← FM 受信周波数 FM TUNING RANGE 87.75～ 107.9MHz ← XM 受信周波数 XM TUNING RANGE 2332.5～ 2345MHz ← HD-AM 受信周波数 HD-AM TUNING RANGE 530～1710ｋ Ｈｚ ← HD-FM 受信周波数 HD-FM TUNING RANGE 87.75～ 107.9MHz ← Bluetooth 受信周波数 Bluetooth TUNING RANGE 2402～ 2480MHz ← WiFi 受信周波数 WiFi TUNING RANGE 2412～ 2462MHz ← 株式会社デンソーテン DENSO TEN LIMITED DENSOTENCONFIDENTIAL (6/8) Function North America Canada DVD 部DVD PLAYER 12cm 1枚 12cm 1 DISC ← SD 容量 （MAP) SD CAPACITY （MAP) 16G← 性能保証温 度範囲 PERFORMANCE GUARANTEED TEMPERATURE RANGE -20～65°C← 通信機能 COMMUNICATION FUNCTION -30～65°C← メカ可動部MOVABLE PART-20～65°C← 保存温度範 囲 PRESERVATION TEMPERATURE RANGE -40～85°C← 株式会社デンソーテン DENSO TEN LIMITED DENSOTENCONFIDENTIAL (7/8) 2-Buttonfunction NoButton Name TimeFunction ① - DISC EJECT ② - Preset-ChannelDOWN Key Track DOWN Key ③ - Preset-Channel UP Key Track UP Key ④ - PWR supply switch (Audio ON/OFF) VOL control ⑤ - TUNE・SCROLLcontrol LIST choice ① ② ③ ⑤ ④ ＜ＣＨ・ＴＲＡＣＫ ＣＨ・ＴＲＡＣＫ＞ PWR・VOL TUNE・SCROLL 株式会社デンソーテン DENSO TEN LIMITED DENSOTENCONFIDENTIAL (8/8) 株式会社デンソーテン DENSO TEN LIMITED DENSOTENCONFIDENTIAL 3-FCC CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more away from person's body in normal use position. Co-location: This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

DENSO TEN Limited 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan Tel.: +81.78-682-2159 Fax.: +81.78-682-2169 Letter of Authorization Date: April 22, 2021 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Applicant: DENSO TEN Limited FCC ID: BABFT0048A To whom it may concern: We, the undersigned, hereby authorize Akiyo Hayashi of Consumer Technology Division, UL Japan, Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Japan, Inc. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. The application for the subject equipment has not been submitted to another TCB for certification. Sincerely Yours, Kaoru Abe Department General Manager Quality Assurance Group Quality Control Div Regulatory Management Dept. DENSO TEN Limited

DENSO TEN Limited 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan Tel.: +81.78-682-2159 Fax.: +81.78-682-2169 Request for Confidentiality Date: April 22, 2021 UL Verification Services Inc. 47173 Benicia Street, Fremont, CA 94538 Applicant : DENSO TEN Limited FCC ID : BABFT0048A To whom it may concern: Please be advised that the following information is to be held confidential on behalf of us, referring to the FCC rules 0.457 and 0.459: Block Diagram Theory of Operation Schematics Parts List The application contains technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Sincerely, Kaoru Abe Department General Manager Quality Assurance Group Quality Control Div Regulatory Management Dept. DENSO TEN Limited

DENSO TEN Limited 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan Tel.: +81.78-682-2159 Fax.: +81.78-682-2169 FCC Request for Rule Changes based on 17-93 April 22, 2021 Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Road Columbia, Maryland 21046 FCC ID : BABFT0048A Applicant : DENSO TEN Limited To Whom It May Concern: This request is to add Equipment Code CXX for FCC ID: BABFT0048A, originally granted on 05/28/2013. We change FM receiver part had confirmed conformity of Part 15 Subpart B to “Certification” procedure from “Verification” based on KDB 178919 D02 Q&A7. This Car Navigation with 2.4 GHz band WLAN and Bluetooth was granted as Part 15 Subpart C for composite “DTS”/ “DSS”, and we add “CXX - Communications Rcvr for use w/ licensed Tx and CBs” as Equipment Code to this product. This time, we performed the re-testing of Part 15 Subpart B because we change the following points from the based model. Please refer to the test report submitted with this application. Also, for Part 15 Subpart C performed the testing and confirmed that it is Class 1 permissive change. - Microphone audio AD converter change: AK5381VT to PCM1808 - GPS TCXO change: NT2520SA to NT2520SB Thank you for your attention to this matter. Sincerely, Kaoru Abe Department General Manager Quality Assurance Group Quality Control Div Regulatory Management Dept. DENSO TEN Limited

External photo (FT0048A EUT) Front side PIOML Flank side (Right)Flank side (Left) Back side Upper sideLower side DENSO TENConfidential Please refer to a label design

FT0048A_Label design DENSO TEN CONFIDENTIAL 1. 114000-150**101US_ML 2. 114000-151**101US_PIO 3. 114000-015**101US_ML ５. 114000-221**101US_ML ６. 114000-222**101US_PIO ** ** ** ** * * * * ** * ** * 4. 114000-016**101US_PIO ７. 114000-135**101US_ML ８. 114000-136**101US_PIO ** * ** * ** * FT0048A Label position Label DENSO TEN CONFIDENTIAL

Internal photo (FT0048A EUT) Bluetooth/Wifi RF line Ｅｘｔｅｒｎａｌ When the panel and the front plate are dismounted. Fujitsu Ten Confidential Bluetooth RF line Wifi RF line Bluetooth RF line Wifi RF line Wifi RF line Bluetooth RF line Bluetooth Antenna mounting position Wifi Antenna mounting position Please refer to a label design NAVI Board *Please refer to another file DENSO TEN CONFIDENTIAL When the DECK is dismounted. Audio Board When the upper surface plate is dismounted. Upper side Lower side USCANADA DENSO TEN CONFIDENTIAL Panel Upper side Lower side DENSO TEN CONFIDENTIAL Bluetooth/ WiFi area Attachment document Denso Confidential Internal Photos Bluetooth/ WiFi Receiver Bluetooth antennaconnector WiFi antennaconnector Attachment document Internal Photos Denso Confidential Bluetooth/ WiFiarea Bluetooth area on PCB (Component Side)Bluetooth area on PCB (Solder Side)

Test report No. : 13703823H-C-R1 Page : 1 of 39 Issued date : May 13, 2021 FCC ID : BABFT0048A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Report Cover Page - 13-EM-F0429 Issue # 18.0 EMI TEST REPORT Test Report No. : 13703823H-C-R1 Applicant : DENSO TEN Limited Type of EUT : Car Navigation Model Number of EUT : FT0048A FCC ID : BABFT0048A Test regulation : FCC Part 15 Subpart B: 2021 Test Result : Complied (Refer to SECTION 3) Date of test: March 6 to May 12, 2021 Representative test engineer: Takafumi Noguchi Engineer Approved by: Tsubasa Takayama Leade r CERTIFICATE 5107.02 The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan. There is no testing item of "Non-accreditation". 1. This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc. 2. The results in this report apply only to the sample tested. 3. This sample tested is in compliance wi th the limits of the above regulation. 4. The test results in this test report are traceable to the national or international standards. 5. This test report must not be used by the customer to claim product certification, approval, or endorsement by the A2LA accreditation body. 6. This test report covers EMC technical requirements. It does not cover administrative issues such as Manual or non-EMC test related Requirements. (if applicable) 7. The all test items in this test report are conducted by UL Japan, Inc. Ise EMC Lab. 8. The opinions and the interpretations to the result of the description in this report are outside scopes where UL Japan has been accredited. 9. The information provided from the customer for this report is identified in SECTION 1. 10. This report is a revised version of 13703823H-C. 13703823H-C is replaced with this report. Test report No. : 13703823H-C-R1 Page : 2 of 39 Issued date : May 13, 2021 FCC ID : BABFT0048A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 REVISION HISTORY Original Test Report No.: 13703823H-C Revision Test report No. Date Page revised Contents - (Ori ginal) 13703823H-C April 22, 2021 - - 1 13703823H-C-R1 May 13, 2021 P.11 Addition of description for Item S 1 13703823H-C-R1 May 13, 2021 P.12 Addition of test place (No.4 semi anechoic cha mber) 1 13703823H-C-R1 May 13, 2021 P.13 Correction of distance factor on 1 GHz - 13 GHz from .029 dB to 0.29 dB 1 13703823H-C-R1 May 13, 2021 P.13 Addition of test date and engineer on Ma y 12, 2021 1 13703823H-C-R1 May 13, 2021 P.14 -Addition of test place (No.4 Measurement room) -Addition of test date and engineer on Ma y 12, 2021 1 13703823H-C-R1 May 13, 2021 P.29 Deletion of “+ ANT FACTOR” from Calculation formula. 1 13703823H-C-R1 May 13, 2021 P.19, 21, 23, 25, 27, 29, 31, 33 Addition of “(Main)” for Mode 1 13703823H-C-R1 May 13, 2021 P.20, 22, 24, 26, 28, 30, 32, 34 Addition of test data 1 13703823H-C-R1 May 13, 2021 P.36 Addition of test equipment (test date: Ma y 12, 2021) 1 13703823H-C-R1 May 13, 2021 P.39 Addition of Antenna Terminal Con ducted Emission test setup photo Test report No. : 13703823H-C-R1 Page : 3 of 39 Issued date : May 13, 2021 FCC ID : BABFT0048A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Reference: Abbreviations (Including words undescribed in this report) AAN Asymmetric Artificial Network ILAC International Laboratory Accreditation Conference AC Alternating Current ISED Innovation, Science and Economic Development Canada AM Amplitude Modulation ISN Impedance Stabilization Network AMN Artificial Mains Network ISO International Organization for Standardization Amp, AMP Amplifier JAB Japan Accreditation Board ANSI American National Standards Institute LAN Local Area Network Ant, ANT Antenna LCL Longitudinal Conversion Loss AP Access Point LIMS Laboratory Information Management System ASK Amplitude Shift Keying LISN Line Impedance Stabilization Network Atten., ATT Attenuator MRA Mutual Recognition Arrangement AV Average N/A Not Applicable BPSK Binary Phase-Shift Keying NIST National Institute of Standards and Technology BR Bluetooth Basic Rate NS No signal detect. BT Bluetooth NSA Normalized Site Attenuation BT LE Bluetooth Low Energy NVLAP National Voluntary Laboratory Accreditation Program BW BandWidth OBW Occupied Band Width C.F Correction Factor OFDM Orthogonal Frequency Division Multiplexing Cal Int Calibration Interval PK Peak CAV CISPR AV P LT long-term flicker severity CCK Complementary Code Keying POHC(A) Partial Odd Harmonic Current CDN Coupling Decoupling Network Pol., Pola. Polarization Ch., CH Channel PR-ASK Phase Reversal ASK CISPR Comite International Special des Perturbations Radioelectriques P ST short-term flicker severity Corr. Correction QAM Quadrature Amplitude Modulation CPE Customer premise equipment QP Quasi-Peak CW Continuous Wave QPSK Quadri-Phase Shift Keying DBPSK Differential BPSK r.m.s., RMS Root Mean Square DC Direct Current RBW Resolution Band Width DET Detector RE Radio Equipment D-factor Distance factor REV Reverse Dmax maximum absolute voltage change during an observation period RF Radio Frequency DQPSK Differential QPSK RFID Radio Frequency Identifier DSSS Direct Sequence Spread Spectrum RSS Radio Standards Specifications EDR Enhanced Data Rate Rx Receiving e.i.r.p., EIRP Equivalent Isotropically Radiated Power SINAD Ratio of (Signal + Noise + Distortion) to (Noise + Distortion) EM clamp Electromagnetic clamp S/N Signal to Noise ratio EMC ElectroMagnetic Compatibility SA, S/A Spectrum Analyzer EMI ElectroMagnetic Interference SG Signal Generator EMS ElectroMagnetic Susceptibility SVSWR Site-Voltage Standing Wave Ratio EN European Norm THC(A) Total Harmonic Current e.r.p., ERP Effective Radiated Power THD(%) Total Harmonic Distortion EU European U…

Text truncated - open the document above for the full version.

Test report No. : 13703823H-C-R1 Page : 37 of 39 Issued date : May 13, 2021 FCC ID : BABFT0048A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 APPENDIX 3: Photographs of test setup Radiated Emission (Below 1 GHz) Photo 1 Photo 2 Test report No. : 13703823H-C-R1 Page : 38 of 39 Issued date : May 13, 2021 FCC ID : BABFT0048A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Radiated Emission (Above 1 GHz) Photo 1 Photo 2 Test report No. : 13703823H-C-R1 Page : 39 of 39 Issued date : May 13, 2021 FCC ID : BABFT0048A UL Japan, Inc. Ise EMC Lab. 4383-326 Asama-cho, Ise-shi, Mie-ken 516-0021 JAPAN Telephone : +81 596 24 8999 Facsimile : +81 596 24 8124 Antenna Terminal Conducted Emission Photo 1 Photo 2 End of Report
