BBO0131BFRS/GMRS TRANSCEIVER

User’s Guide TWO-WAY RADIO MODEL CXT145 Making Life Easier And Safer Staying in touch with your family and friends is convenient and easy when using your microTALK ® radio. Some of the many uses you will discover include: Communicating with others while hiking, biking, and working; keeping track of family and friends at a crowded public event; checking with travel companions in another car; talking with neighbors; arranging meeting spots with others while shopping at the mall. Customer Assistance In this user’s guide, you should find all the information you need to operate your microTALK ® radio. If you require further assistance after reading this guide, Cobra Electronics offers the following customer assistance services: For Assistance In The U.S.A. Automated Help Desk English only. 24 hours a day, 7 days a week 773-889-3087 (phone). Customer Assistance Operators English and Spanish. 8:00 a.m. to 5:30 p.m. Central Time, Monday through Friday (except holidays) 773-889-3087 (phone). Questions English and Spanish. Faxes can be received at 773-622-2269 (fax). Up/Down Buttons While in mode function, press and release to change channels. Press and release to adjust the volume. Call Button Press and release to alert others that you are calling. This tone is used only to establish voice communications. Printed in China Part No. 480-829-P Version H Talk Button Press and hold to communicate with others. With the microphone about two (2) inches [five (5) cm] from your mouth, speak in a normal voice. Release the Talk button when you are finished talking and listen for a response. You cannot receive incoming calls while pressing the Talk button. NOTE Both radios must be tuned to the same channel to communicate. LCD Display Maximum range may vary and is based on unobstructed line-of-sight communication under ideal conditions. Trademark Acknowledgement Cobra ® , microTALK ® , Nothing Comes Close to a Cobra ® and the snake design are registered trademarks of Cobra Electronics Corporation, U.S.A. Cobra Electronics Corporation™ is a trademark of Cobra Electronics Corporation, U.S.A. The Cobra ® line of quality products includes: CB Radios • microTALK ® Radios • Radar/Laser Detectors • Safety Alert ® Traffic Warning Systems • HighGear ® Accessories • CobraMarine ® VHF Radios • Power Inverters • Trucker Nav Systems • LED Lights • Jumpstarters • Accessories Speaker/Microphone Jack Channel Numbers While in Standby mode or when selecting a channel, shows current channel (1 through 22). When adjusting the volume, shows current level (1 through 8). Battery Low Icon Icon blinks and an audible tone will be heard when battery power level is low. Your microTALK ® radio has a unique circuit designed to extend battery life. If there are no transmissions within ten (10) seconds, the radio will automatically switch to Battery Save mode. This will not affect the radio’s ability to receive incoming transmissions. Receive Icon Visible when receiving a message. Transmit Icon Visible when transmitting a message. Channel/Volume Indicator Visible when receiving a message. “ CH” is visible when in Standby mode or when selecting a channel. “ LE” is visible when adjusting volume. Technical Assistance English only. www.cobra.com (on-line: Frequently Asked Questions). English and Spanish. productinfo @cobra.com (e-mail). For Assistance Outside The U.S.A. Contact Your Local Dealer Mode/Power Button Press and release to enter mode function to change channels. The channel numbers will blink when that mode is selected. Use the Up/ Down buttons to select a channel. Press and hold to turn the radio On or Off. Press and release again to enter the NOAA Weather Channels. Use the Up/Down buttons to select the strongest weather channel in your area. Battery Compartment Cover Belt Clip Antenna WR TX USB Charge Jack Installing Batteries To Install or Replace Batteries: 1. Remove belt clip by releasing belt clip latch and sliding clip up. 2. Pull up on the battery door latch to remove the battery compartment cover. 3. Insert three (3) AAA batteries. Position batteries according to polarity markings. 4. Replace battery compartment cover and belt clip. • Do not attempt to charge alkaline batteries. • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable (Ni-Cd, Ni-MH, etc.) batteries. Insert Batteries Pull Latch Up Remove Belt Clip Battery low icon will be displayed and blinking when the radio is charging. Weather Icon Visible when in NOAA weather radio mode. You can use your microTALK ® radio to listen to weather channels transmitting in your area. MODEL CXT145: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received,including interference that may cause undesired operation. NOTE: COBRA IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment a…

Text truncated - open the document above for the full version.

August 26, 2014 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: BBO0131B Request for Confidentiality Dear Sirs: With regard to the referenced application, Cobra Electronics Corporation, is requesting confidentiality of certain sections of the accompanying documents. The documents for which Cobra Electronics Corporation is requesting confidentiality are: Schematic Diagram Block Diagrams Operational Descriptions Parts List Tune Up info This request is made under the provisions of Section 0.457(d) of the Commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. The material for which confidentiality is requested falls within the scope of Section 552(b)(4) as trade secrets and includes material covered by Section 0.459 of the Commission’s Rules. Sincerely, Chris De Waal Sr. Project Engineer

August 22, 2014 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: BBO0131B Dear Sirs: Cobra Electronics Corporation requests acceptance of the labeling proposal described below for the transceiver bearing FCC identifier BBO0131B. The subject transceiver is a compact handheld model as shown in figure 1, authorized under 47CFR Part 95 for FRS and GMRS services. Figure 1. Belt Clip Battery Door Clip Batteries Because the majority of the transceiver housing is composed of display, speaker, operating controls, and a battery access cover, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery access cover is not acceptable because the battery access cover is a removable item. For this reason, Cobra proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2. The consumer packaging for these models includes the batteries as separate items, NOT installed in the radio. As such, the FCC identifier will be readily visible to the user before the batteries are installed and whenever the batteries are removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a transparent plastic "clamshell" but, because the battery access cover is installed on the radio, the battery compartment cannot be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Cobra will add the FCC identifier "BBO0131B" to the insert card within the clamshell packaging. Sincerely, Paul Lee Project Engineer

APPLICANT: COBRA ELECTRONICS CORP. FCC ID: BBO0131B IC: 906A-0131B EXTERNAL PHOTOS

DIE LINE 22 x 15.5 mm 1 : 1 MODEL NO: CXT145C CXT145C RADIO SERIAL NUMBER LABEL TEMPLATE SILVER TEXT ON BLACK LABEL REV. 7-31-14 FCC ID: BBO0131B IC: 906A-0131B MADE IN CHINA 2 : 1 MODEL NO: CXT145C FCC ID: BBO0131B IC: 906A-0131B MADE IN CHINA

August 22, 2014 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: BBO0131B Dear Sirs: Cobra Electronics Corporation requests acceptance of the labeling proposal described below for the transceiver bearing FCC identifier BBO0131B. The subject transceiver is a compact handheld model as shown in figure 1, authorized under 47CFR Part 95 for FRS and GMRS services. Figure 1. Belt Clip Battery Door Clip Batteries Because the majority of the transceiver housing is composed of display, speaker, operating controls, and a battery access cover, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery access cover is not acceptable because the battery access cover is a removable item. For this reason, Cobra proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2. The consumer packaging for these models includes the batteries as separate items, NOT installed in the radio. As such, the FCC identifier will be readily visible to the user before the batteries are installed and whenever the batteries are removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a transparent plastic "clamshell" but, because the battery access cover is installed on the radio, the battery compartment cannot be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Cobra will add the FCC identifier "BBO0131B" to the insert card within the clamshell packaging. Sincerely, Paul Lee Project Engineer

APPLICANT: COBRA ELECTRONICS CORP. FCC ID: BBO0131B IC: 906A-0131B INTERNAL PHOTOS

802 N. Twin Oaks Valley Road, Suite 105 • San Marcos, CA 92069 • U.S.A. TEL (760) 471-2100 • FAX (760) 471-2121 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Cobra Electronics Corporation Dates of Test: August 18, 2014 6500 West Cortland St. Test Report Number: SAR.20140811 Chicago, IL 60707 This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003 and EN/IEC 62209 (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application is subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Testing Cert. # 2387.01 FCC ID: BBO0131B IC Certificate: 906A-0131B Model(s): CX102A, CX112, Cx116A, CX131A, CXT145C, CXT145 SP, CXT195 Test Sample: Engineering Unit Same as Production Serial Number: FCC #2 Equipment Type: Push-To-Talk Handheld Radio for General Population Use Classification: Portable Transmitter Next to Face and Body TX Frequency Range: 462.55 – 467.7125 MHz Frequency Tolerance: ± 2.5 ppm Maximum RF Output: 26.69 dBm Conducted Signal Modulation: FM Body Worn Accessories: Standard Belt Clip Audio Accessories: Model GA-EBM2 Antenna Type: Standard Integral Antenna Battery: Standard (Model 3-AAA NiMH, 3-AAA Alkaline) Application Type: Certification FCC Rule Parts: Part 2, 95 KDB Test Methodology: KDB 447498 D01 v05r02, KDB 643646 D01 v01r01, KDB 865664 D01 v01r03, KDB 865664 D02 v01r01 Industry Canada: RSS-102 Issue 4, Safety Code 6 Maximum SAR Value: 0.58 W/kg for Face; 1.23 W/kg for Body Reported Separation Distance: 25 mm for Face; 0 mm for Body © 2014 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Report Number: SAR.20140811 Table of Contents 1. Introduction ........................................................................................................................ 3 SAR Definition [5] ................................................................................................................... 4 2. SAR Measurement Setup ................................................................................................... 5 Robotic System ...................................................................................................................... 5 System Hardware ................................................................................................................... 5 System Electronics ................................................................................................................. 6 Probe Measurement System .................................................................................................. 6 3. Probe and Dipole Calibration .............................................................................................14 4. Phantom & Simulating Tissue Specifications .....................................................................15 Head & Body Simulating Mixture Characterization ................................................................15 5. ANSI/IEEE C95.1 – 1992 RF Exposure Limits [2] ..............................................................16 Uncontrolled Environment .....................................................................................................16 Controlled Environment .........................................................................................................16 6. Measurement Uncertainty .................................................................................................17 7. System Validation..............................................................................................................18 Tissue Verification .................................................................................................................18 Test System Verification ........................................................................................................18 8. SAR Test Data Summary ..................................................................................................19 Procedures Used To Establish Test Signal ...........................................................................19 Device Test Condition ...........................................................................................................19 Radio Body Test .......................................................................................................................20 SAR Data Summary – Head SAR Face Measurements ........................................................23 SAR Data Summary – Body SAR Measurements .................................................................24 9. Test Equipment List ...........................................................................................................25 10. Conclusion ....................................................................................................................26 11. References ....................................................................................................................27 Appendix A – System Validation Plots and Data .......................................................................28 Appendix B – SAR Test Data Plots ...........................................................................................33 Appendix C – SAR Test Setup Photos .............................…

Text truncated - open the document above for the full version.

FCC PART 95 AND IC RSS-210 (i8) FRS/GMRS TRANSCEIVER TEST REPORT APPLICANT COBRA ELECTRONICS CORPORATION 6500 WEST CORTLAND STREET CHICAGOIL 60707 USA FCC ID BBO0131B IC 906A-0131B MODEL NUMBER CX102A, CX112, CX116A, CX131A, CXT145C, CXT145 SP, CXT195 PRODUCT DESCRIPTION FRS/GMRS TRANSCEIVER with W/X FCC STANDARD APPLIED IC STANDARD APPLIED 47 CFR § 95 Personal Radio Service Subpart A – General Mobile Radio Service (GMRS) Subpart B – Family Radio Service (FRS) IC Standard RSS-210 (i8), Annex 6 DATE SAMPLE RECEIVED 8/1/2014 DATE TESTED 8/18-19/2014 TESTED BY Cory Leverett APPROVED BY Sid Sanders TIMCO REPORT NO. 1353AUT14TestReport.docx TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM Table of Contents GENERAL REMARKS ........................................................................................................... 3 GENERAL INFORMATION .................................................................................................... 4 TEST PROCEDURES: ........................................................................................................... 5 TEST PROCEDURES: ........................................................................................................... 6 TEST PROCEDURES: ........................................................................................................... 7 TEST REPORT SUMMARY .................................................................................................... 8 RF POWER OUTPUT ............................................................................................................ 9 MODULATION CHARACTERISTICS .................................................................................... 10 EMISSION DESIGNATOR AND FREQUENCIES............................................................ 13 OCCUPIED BANDWIDTH ................................................................................................... 14 FRS OCCUPIED BANDWIDTH MASK B ................................................. 15 FCC 20dB Bandwidth .................................................................................................................................................... 15 IC 99% Power Bandwidth .............................................................................................................................................. 16 GMRS OCCUPIED BANDWIDTH MASK B ................................................ 17 FCC 20dB Bandwidth .................................................................................................................................................... 17 IC 99% Power Bandwidth .............................................................................................................................................. 18 FIELD STRENGTH OF SPURIOUS EMISSIONS .......................................... 19 Test Data (GMRS): ........................................................................................................................................................ 19 FREQUENCY STABILITY .................................................................................................... 21 EMC EQUIPMENT LIST ...................................................................................................... 22 Table of Contents Applicant: COBRA ELECTRONICS CORPORATION FCC ID: BBO0131B IC: 906A-0131B Report: C\COBRA\1353AUT14\1353AUT14TestReport.docx Page 2 of 22 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025: 2005 requirements. I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Cory Leverett Engineering Project Manager Date: 8/19/2014 Table of Contents Applicant: COBRA ELECTRONICS CORPORATION FCC ID: BBO0131B IC: 906A-0131B Report: C\COBRA\1353AUT14\1353AUT14TestReport.docx Page 3 of 22 GENERAL INFORMATION EUT Specification EUT Description FRS/GMRS TRANSCEIVER with W/X band EUT Application Portable short range communications FCC ID BBO0131B IC 906A-0131B Model Number CX102A, CX112, CX116A, CX131A, CXT145, CXT145C, CXT145 SP, CXT195 Serial Number N/A Operating Frequency GMRS:462.5500-462.7250 MHz FRS: 462.5625-467.7125 MHz Test Frequencies GMRS: 462.5625 MHz FRS: 467.7250 MHz No. of Channels 22 Type of Emission 10K5F3E EUT Power Source 110–120Vac/50–60Hz (Optional AC power Adapter) DC Power 13.8V Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Antenna Fixed Test Conditions The temperature was 26ºC with a relative humidity of 50-60%. Modification to the EUT None Test Exercise The EUT was placed in continuous transmit mode of operation Applicable Standards ANSI/TIA 603-D:2004, FCC CFR 47 Part 25 Test Facility Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 USA. Table of Contents Applicant: COBRA ELECTRONICS CORPORATION FCC ID: BBO0131B IC: 906A-0131B Report: C\COBRA\1353AUT14\1353AUT14TestReport.docx Page 4 of 22 TEST PROCEDURES: General: The test proced…
