BBOAIR1ABluetooth music streaming receiving device

Date: April 25, 2013 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Cobra Electronics Corporation, the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Cobra Electronics Corporation solely in matters relating to the application for an FCC equipment authorization for FCC ID: BBOAIR1A including the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen Morlab Communications Technology Co., Ltd. in connection with the Application shall have the same effect as acts of the Cobra Electronics Corporation. The Cobra Electronics Corporation also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, Chris deWaal Sr. Project Manager Cobra Electronics Corp.

Date: April 25, 2013 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Cobra Electronics Corporation FCC ID: BBOAIR1A FCC Part 15C Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Cobra Electronics Corporation requests that the following documents regarding this submission for FCC ID: BBOAIR1A be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Circuit Diagram.pdf Operational Description Operational Description.pdf Part list BOM.pdf Those documents contain detailed system and equipment description and related information about the product which Cobra Electronics Corporation considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Cobra Electronics Corporation considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Chris deWaal’ Sr. Project Manager Cobra Electronics Corp.

External Photos 1. EUT full view with accessories 2. EUT front view 3. EUT rear view 4. EUT left side view 5. EUT right side view 6. EUT top view 7. EUT bottom view

FCC ID: BBOAIR1A Label Label Location

Internal Photos 1. EUT uncover view 2. Mainboard View

SZ13030017W02 Page 2 of 79 DIRECTORY 1. GENERAL INFORMATION .................................................................................................... 3 1.1. EUT Description ....................................................................................................................... 3 1.2. Test Standards and Results ........................................................................................................ 4 1.3. Facilities and Accreditations ..................................................................................................... 5 2. 47 CFR PART 15C AND RSS-210 REQUIREMENTS ........................................................... 6 2.1. Antenna requirement ................................................................................................................. 6 2.2. Number of Hopping Frequency ................................................................................................ 6 2.3. Peak Output Power.................................................................................................................. 11 2.4. 20dB Bandwidth ..................................................................................................................... 13 2.5. Carried Frequency Separation ................................................................................................. 24 2.6. Time of Occupancy (Dwell time) ........................................................................................... 27 2.7. Conducted Spurious Emissions ............................................................................................... 34 2.8. Band Edge ............................................................................................................................... 41 2.9. Conducted Emission ............................................................................................................... 58 2.10. Radiated Emission................................................................................................................... 61 Change History Issue Date Reason for change 1.0 April 25, 2013 First edition SZ13030017W02 Page 3 of 79 1. General Information 1.1. EUT Description EUT Type ............................. : Bluetooth music streaming receiving device Serial No. .............................. : (n.a, marked #1 by test site) Hardware Version ................. : V1.1 Software Version .................. : Applicant .............................. : Manufacturer ........................ : V1.1 Cobra Electronics Corporation 6500 West Cortland Street, Chicago, IL 60707, USA Universal Microelectronics Co. Ltd. UMEC Shenzhen Company Ltd., Fuyong Town, Baoan, Shenzhen, China Frequency Range .................. : The frequency range used is 2402MHz - 2480MHz (79 channels, at intervals of 1MHz); The frequency block is 2400MHz to 2483.5MHz. Modulation Type .................. : Bluetooth: FHSS (GFSK(1Mbps), ∏/4-DQPSK(EDR 2Mbps), 8-DPSK(EDR 3Mbps)) Antenna Type ........................ : PCB antenna Antenna Gain ........................ : 1.0dBi Note 1: The EUT is a Bluetooth music streaming receiving device, it contains Bluetooth Module operating at 2.4GHz ISM band; the frequencies allocated for the Bluetooth Module is F(MHz)=2402+1*n (0<=n<=78). The lowest, middle, highest channel numbers of the Bluetooth Module used and tested in this report are separately 0 (2402MHz), 39 (2441MHz) and 78 (2480MHz). Note 2: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Note 3: a. When power on, the EUT will scan the whole frequency until a Connection command from the other BT devices. b. When receiving the signal from the other BT devices, The EUT transmit aresponse signal. c. The other devices receive the response signal and recognize it, then send a connection command to establish the connection. d. After the connection establish successfully, the data transmission is beginning. At the same time, the both devices will shift frequencies in synchronization per a same pseudo randomly ordered list of hopping frequencies, the hopping rate is1600 times per second. This device conforms to the criteria in FCC Public Notice DA 00-705. e. The bandwidth of the receiver, which is set to a fixed width by the software. Note 4: Bluetooth signal has 9 packages DH1, DH3, DH5, 3DH1, 3DH3, 3DH5, 5DH1, 5DH3, 5DH5, DH5 package is largest, we are testing DH5 in the document. SZ13030017W02 Page 4 of 79 1.2. Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart C and RSS-210 (Bluetooth, 2.4GHz ISM band radiators) for the EUT FCC/IC ID Certification: No. Identity Document Title 1 47 CFR Part 15 (10-1-09 Edition) Radio Frequency Devices 2 RSS-GEN:Issue 3, December 2010 General Requirements and Information for the Certification of Radio Apparatus 3 RSS-210: Issue 8 , December 2010 Low-power Licence-exempt Radiocommunication Devices (All Frequency Bands): Category I Equipment Test detailed items/section required by FCC rules and results are as below: No. Section in CFR 47 Section in RSS-GEN , RSS-210 Description Result 1 15.203 7.1.4 Antenna Requirement PASS 2 15.247(a) A8.1 (d) Number of Hopping Frequency PASS 3 15.247(b) A8.4 (2) Peak Output Power PASS 4 15.247(a) A8.1 (a) 20dB Bandwidth PASS 5 15.247(a) A8.1 (b) Carrier Frequency Separation PASS 6 15.247(a) A8.1 (d) Time of Occupancy (Dwell time) PASS 7 15.247(d) A8.1 (d) Conducted Spurious Emission PASS 8 15.247(d) A8.5 Band Edge PASS 9 15.207 7.2.2 Conducted Emission PASS 10 15.209 15.247(c) A8.5 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in DA-00-705. SZ13030017W02 Page 5 of 79 1.3. Facilities and Accreditations 1.3.1. Facilities Shenzhen Morlab Communications Technology Co., Ltd. Morlab Laboratory is a testing organization accredited by China National Accreditation Service for …
